Table of Contents
loading

Related Manuals for Alpine INE-W977HD

Summary of Contents for Alpine INE-W977HD

  • Page 1 • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration. You will be informed of product and software updates (if applicable), special promotions, news about Alpine.
  • Page 2 • Open/close the product nose with care – dust or water may enter the product. Liquid and dust damage are not covered under warranty. Disclaimers Failure to install the product as directed in the installation manual may degrade dust and water resistance. X208U/INE-W977HD X209D...

  • Page 3: Table Of Contents

    Selecting the Output Speaker ......33 Adjusting the Volume ......... 17 Setting the Microphone Select (X208U/ Lowering Volume Quickly ......... 17 INE-W977HD only) ........33 Touch Screen Operation ........18 General Setup Switching Sources ..........18 Sound Setup ............34...
  • Page 4 Source Setup Alpine Connect App (Optional) Radio Setup ............43 Setting the TUNER (FM) Tone Quality Activate Alpine Connect App ......52 (Tuner Condition) ........43 Setting the TUNER (FM) Frequency Step ... 43 Radio/HD Radio™/RBDS SiriusXM Setup ............ 43...
  • Page 5 Receiving a Multicast (HD Radio™ Mode SiriusXM Satellite Radio Operation only) ..............55 (Optional) Selecting the Receivable Program Type (RBDS Receiving Channels with the SiriusXM FM Radio mode only) ........55 Tuner ..............67 Forced Analog Mode .......... 55 Tuning Channels by Category ......67 Displaying Radio Text (RBDS FM Radio mode Changing the Display .........
  • Page 6 Synchronizing the Phone Book ..... 85 Adding the Phone Book ......... 85 Playing a Disc ............ 76 Deleting the Phone Book Entries ....86 Searching in the Phone Book ......86 If a Menu Screen Appears ......77 Numeric Keypad Input Operations ..... 77 Bluetooth Audio Displaying the Top Menu Screen ....
  • Page 7 About Remote Control Operation (X209D only) When Using the Remote Control ..... 98 Battery Replacement ........... 98 Operating the DVD Player ........ 99 Information Product Software Update ......... 100 Cautions about Discs (X209D only) ....100 Discs Playable on This Unit (X209D only) ... 101 About the Supported Formats ......

  • Page 8: Operating Instructions

    If this is the case, pull over in a safe and legal manner • This product may be used in conjunction with the Alpine KAC-001 and location before attempting operation.

  • Page 9: Warning

    USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND. WARNING (Check with your dealer if you are not sure.) Failure to do so may result in fire, etc. • Operation of the system while driving is dangerous. Users should stop vehicle before operating the software. KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF •...

  • Page 10: Caution

    If you have problems, do not attempt to repair the unit yourself. The wiring and installation of this unit requires special technical Return it to your Alpine dealer or the nearest Alpine Service Station skill and experience. To ensure safety, always contact the dealer for servicing.
  • Page 11 Microsoft Corporation in the United States and/or other countries. Alpine accepts no responsibility for lost data, etc., even if data, etc., is • Apple, iPhone, iPod, and iPod touch are trademarks of Apple lost while using this product.
  • Page 12 X209D only • This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. • Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.

  • Page 13: Features

    Features The screen design used in the Owner’s Manual may differ from the actual screen. Favorite Function Frequently used functions can be easily recalled. For details, see “Favorite Function” (page 25). Favorite screen example • Frequently used functions and useful functions can be customized for your convenience. •...

  • Page 14: Switching The Audio Sources Screen To A Dedicated Screen

    Switching the Audio Sources Screen to a Dedicated Screen You can switch the Audio Sources screen to a dedicated screen by touching the icon on one of the four edges of the screen, or by swiping vertically or horizontally. For details on how to swipe the screen, see “Touch Screen Operation” (page 18). •...

  • Page 15: About Dual Screen

    * Touch [ ], or swipe to the left to switch to the Navigation menu screen. For details of navigation operations, refer to “Navigation System OM” in the website at http://www.alpine-usa.com. Dual Screen Display Position You can switch the left/right positions of the Audio/Visual screen and Navigation screen.

  • Page 16: Getting Started

    (Eject) button (X209D only) Ejects a disc. Controllable with Remote Control This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor. For X209D About the button descriptions used in this Owner’s...

  • Page 17: Turning Power On Or Off

    • When turned on, the system displays the last screen that was displayed before the ignition key was turned off. For example, if For X208U/INE-W977HD the unit is in radio mode when ignition is turned off, it will remain in radio mode when ignition is turned back on.

  • Page 18: Touch Screen Operation

    Touch Screen Operation Switching Sources You can operate the system by using the touch panel on the screen. Press the (AUDIO) button to change the source. • Be sure to touch the onscreen button lightly with the pad of your finger Switching sources using the (AUDIO) button to avoid scratching the display.

  • Page 19: Operating The Function Button On The Audio/Video Main Screen

    Operating the Function Button on the Audio/ About Basic Operation for List Screen Video Main Screen Basic operations on the Setup list screen and the Search list screen. How to display on the list screen differs depending on the selected item. Using the Function button on the Audio/Visual main screen.

  • Page 20: About The Shortcut Setup Screen

    Sound Setup Function About the Shortcut Setup Screen Tone Adjustment mode Displaying the Sound Setup screen, or the Shortcut Setup screen of the Rear Seat Entertainment System screen. Touch the top part of the Audio source screen or swipe downward. BASS ENGINE SQ mode The Sound Setup screen or the Rear Seat Entertainment System Setup Screen is displayed.

  • Page 21: Rear Seat Entertainment Function

    Adjusting Bass Level/Treble Level Rear Seat Entertainment Function Bass Level and Treble Level can be set independently set for Front and Rear speakers by touching [Front] or [Rear]. The Rear Seat Entertainment function independently routes different sources to the front and the rear side of the car. For example, while Setting item: listening to the radio or other audio sources in the front, HDMI can be Bass / Treble...

  • Page 22: About The Menu Screen

    *3 Use to display the Facebook Notification List on the connected smartphone via this unit. (page 29) Displays when Alpine TuneIt App is set to “USB (iPhone)” or “Bluetooth (Android), ” and when a smartphone with Alpine TuneIt App installed is connected. (page 28) *4 Displays the Android Auto screen, displayed when an Android Smartphone installed Android Auto App is connected.

  • Page 23: About The Indicator Display

    You can switch between the 12 hour display and 24 hour display options. For details of navigation operations, refer to “Navigation System OM” in the website at http://www.alpine-usa.com. Bluetooth devices Name* * When you connect two Hands-Free Phones, the information of the...

  • Page 24: How To Input Characters And Numbers (Keypad)

    How to Input Characters and Numbers (Keypad) The displayed screens and procedures may vary slightly depending on the function used, but the basic input method is the same. Input screen area. Cursor position alteration switch Cancel Keypad mode finishes. (Delete) Returns to the previous character and erases it.

  • Page 25: Favorite Function

    Favorite Function Editing the Favorite Screen You cannot edit the Favorites screen while driving. Using the Favorite Function Your vehicle must be parked with the ignition key in the ACC or ON position. For details, see “To display the Setup Menu screen” in “Setup Operation”...

  • Page 26: Changing Item Names

    • For details of navigation operations, refer to “Navigation System OM” Touch the icon you want to change from the icon list. in the website at http://www.alpine-usa.com. Phone (Shortcut Dialing)* You can register the user’s shortcut dialing stored in the Phone Book.

  • Page 27: Changing The Layout

    Changing the Layout Drag and drop the item to the desired location. The item location is changed. • When you move to other pages, switch pages, or when you make a new page and move to another, drag to the end of the screen, and lift your finger after the page changes.

  • Page 28: Applying Alpine Tuneit App

    Close button Smartphone is not in a service area or receives no signal. Close the notification screen. • Turn Apple CarPlay to Off before using Alpine TuneIt App. Refer to “Apple CarPlay Setup” (page 46). Touch the desired button to operate.
  • Page 29 Displaying Facebook Screen During Notification incoming or Notification List screen, you can switch to Facebook screen. Facebook screen example Message content Poster’s photo Close button: Close the Facebook screen. Touch the poster’s picture and name to switch to the Facebook screen. The detailed information of Notification is displayed.

  • Page 30: Setup

    Touch the required setting icon on the upper part of the Setup Setup main screen or swipe the list area vertically, then touch the setting item. Setting items: Wireless: See “Wireless (Bluetooth) Setup” (page 31). Setup Operation General: See “General Setup” (page 33). Source: See “Source Setup”...

  • Page 31: Wireless (Bluetooth) Setup

    Make sure the “Bluetooth” setting is “On” ( Phone Speaker You can display the Bluetooth device name and device address of this Microphone Select (X208U/INE-W977HD olny) unit. *1 This setting is only available when “Bluetooth” is set to “On” (...

  • Page 32: Hands-Free Device Primary/Secondary Setting

    Touch [ ] (Audio), [ ] (Hands-free) or [ ] (Both) Hands-free Device Primary/Secondary Setting of the device you want to connect from the list. Make sure the “Bluetooth” setting is “On” ( ). See “Bluetooth Setup” Audio: Device is used as an Audio device. (page 31).

  • Page 33: Changing The Character Code Of The Phone Book

    Display/Key Hands-Free Microphone. Screen/Lighting Setting item: Screen Color Microphone Select Setting contents: Illumination Color (X208U/INE-W977HD only) Built-in / Add-on (Initial setting) Text Scroll Built-in: Use the built-in microphone. (see location on page 16) Artwork Position Add-on: Use the supplied microphone.

  • Page 34: Sound Setup

    *1 You can make this setting in the Sound Setup screen of the Shortcut Fad./Bal. screen Setup. For details, see “Sound Setup Function” (page 20). *2 You can also make the setting in the Bal./Fad. screen. For details on how to adjust, see “Setting the Balance/Fader/Rear Speaker/Subwoofer”...

  • Page 35: Setting The Media Xpander (Mx Hd)

    Level2 Level3. • You can set this for each source. • iPod/iPhone/USB Audio/USB Video/Bluetooth Audio/Pandora/ Bluetooth Pandora/Alpine Connect App/Apple CarPlay Music/Google Play Music correspond to Compressed Media. • Factory Media (USB/iPod)/Factory SiriusXM correspond to Factory Audio. Front/Rear speaker switching button Not displayed when Front/Rear Sync is ”On”...

  • Page 36: Adjusting The Crossover Settings (X-Over)

    Adjusting the Frequency Adjusting the Crossover Settings (X-Over) Touch [ ] or [ ] of “Frequency” to adjust the frequency of the selected band. Before performing the following procedures, see “About the Crossover” (page 38). Adjustable frequency bands: 20 Hz to 20 kHz (in 1/3 octave steps) Setting item: Band1: 20 Hz~100 Hz (63 Hz)

  • Page 37: Adjusting The Time Correction (Tcr)

    Adjusting the Time Correction (TCR) Setting the Volume for Each Source Before performing the following procedures, see “About Time Setting item: Source Volume Setup Radio / SiriusXM / Compressed Media* Correction” (page 39). 2, 3 iPod Music / AUX* / HDMI* / Bluetooth Audio / Factory Audio* Setting item: Apple Carplay*...

  • Page 38: Adjusting The Ring Tone Level

    Adjusting to a frequency range initialized. outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused by...

  • Page 39: About Time Correction

    Example 2. Listening Position: All Seats About Time Correction Adjust the time correction level of each speaker to almost the same level. The distance between the listener and the speakers in a car vary widely due to the complex speaker placement. This difference in the distances Sit in the listening position (driver’s seat, etc.) and from the speakers to the listener creates a shift in the sounds image and measure the distance (in meters) between your head and...

  • Page 40: Picture Quality Setup

    Adjusting Tint of Picture Picture Quality Setup Setting item: [Picture Quality] is selected on the General Setup Menu screen in step Tint Setting content: 1. See “General Setup” (page 33). R15 to G15 (Initial setting: 0) You can set up items related to an image. Adjust the Color from R15 to G15.

  • Page 41: Display/Key Setup

    The Screen/Lighting setup screen appears. Switching the Illumination Color (X208U/ Setting item: INE-W977HD only) Dimmer / Key Illumination Level / Screen Dimmer Level Setting the Brightness of the Backlighting You can choose the color of the Front Panel button from one of 7 colors.

  • Page 42: General Setup

    Name, and to initialize various settings. Displaying the Product Information You can view the version information of this product. Make note of this information and refer to it whenever you contact Alpine Tech Support or an Alpine-authorized dealer. Setting contents:...

  • Page 43: Source Setup

    Source Setup Radio Setup [Source] is selected on the Setup main screen in step 3. See “Setup [Radio] is selected on the Source Setup Menu screen in step 1. See Operation” (page 30). “Source Setup” (page 43). Source Setup Menu screen Setting the TUNER (FM) Tone Quality (Tuner <Setting items>...

  • Page 44: Setting The Alert Individually For An Artist/Song/Favorite Team

    Setting the Alert individually for an Artist/ Setting the Favorite Sports Team Alerts Song/Favorite Team This menu option allows you to select your favorite teams, organized by leagues, so that you will be alerted later when your favorite teams are This menu option allows you to enable the Artist/Song/Team alert for playing on other channels.

  • Page 45: Signal Strength Information

    Touch the numeric keypad to input a 4-digit passcode. AUX Setup The initial default 4-digit passcode is set to 0000. After entering the digit, it is displayed as “*” (asterisk). • Touch [ ] to delete an entered number. [AUX] is selected on the Source Setup Menu screen in step 1. See •...

  • Page 46: Hdmi Setup

    *3 You can select this item only when Camera Select is “Front” or “Rear. ” *4 You can select this item only when Camera Select is “Rear. ” *5 Set this setting after closing the Alpine TuneIt App and Alpine Connect [Apple CarPlay] is selected on the Sources Setup Menu in step 1. See App.

  • Page 47: Camera Setup

    Touch [ ] to return to the main source screen. Multi View compatible Front Camera/Rear Camera • To return to the previous List screen, touch [ ] or [ ] in the Touch [Back], [Panorama], [Corner], or [Top]. previous page. For details, see “About Basic Operation for List Screen”...

  • Page 48: Camera Interrupt Setting (Power Off Mode) (Rear Camera Only)

    Front Camera screen example When Hitch Guide is set to On <Side Camera> Side Camera screen example Touch [Link]. The 2 vertical guides of the currently-selected guide link together, allowing them to be adjusted simultaneously. Touch [ ], [ ], [ ] or [ ] to adjust the position of the guide.

  • Page 49: Setting Multi Camera To On/Off

    Setting Multi Camera to On/Off Setting the Source Category When connecting the optional Multi Camera Interface module, you can You can set whether the following source icon in the Menu screen is connect up to 3 cameras as Front Camera/Rear Camera/Side Camera. available.

  • Page 50: Rear Seat Entertainment Setup

    Rear Seat Entertainment Setup External Accessories Setup [Rear Seat Entertainment] is selected on the System Setup Menu screen [External Accessories] is selected on the System Setup Menu screen in in step 1. See “System Setup” (page 46). step 1. See “System Setup” (page 46). When a Rear monitor equipped with HDMI input is connected to this unit, change this setting to “On.

  • Page 51: Smartphone Apps Setup

    SNS. pressing or VOICE button. • Set this setting after closing the Alpine TuneIt App and Alpine Connect • When an iPhone 5 or later is reconnected, touch the pop-up message- App. “Apple CarPlay connected. ” within 5 seconds to access to Apple CarPlay •...

  • Page 52: Android Auto (Optional)

    Activate Alpine Connect App Android Auto is designed to make it easier to use apps from your phone Download an app that supports Alpine Connect to your smartphone, and you can operate it from the unit. while you’re on the road. Navigate with Google Maps, listen to playlists Alpine Connect App is downloadable from Apple’s App Store;...

  • Page 53: Radio/Hd Radio™/Rbds

    Info area Radio/HD Radio™/ RBDS Station Info. mode: Program Type /Frequency and PS Name/Artist Name/Song RBDS Name/Album Name Radio Text mode: Frequency/ Radio Text The unit can receive HD Radio broadcasting signals based on digital • For details on switching the display of the Radio text, see radio broadcast standards, in addition to analog radio broadcasts using “Displaying Radio Text (RBDS FM Radio mode only)”...

  • Page 54: Radio Basic Operation

    Radio Basic Operation Presetting Stations Manually Tune in a desired radio station you wish to store in the Listening to the Radio preset memory by manual or automatic seek tuning. Touch the Preset number you want to store, for at least Press the (AUDIO) button to select radio mode.

  • Page 55: Inputting Frequency Directly And Receiving The Radio Station

    Inputting Frequency Directly and Receiving the Selecting the Receivable Program Type (RBDS Radio Station FM Radio mode only) You can input a frequency of the same band directly and receive the You can select and receive the currently receivable stations in the radio station.

  • Page 56: Using Ballgame Mode (Hd Radio™ Mode Only)

    Using Ballgame Mode (HD Radio™ Mode only) In live broadcast, such as sportscasts, etc., a time lag occurs between digital sound and analog sound. Therefore, when live broadcasts are received, a time lag between the real broadcast may occur and the unit can change to analog broadcasting automatically.

  • Page 57: Usb Flash Drive (Optional)

    USB Video main screen example USB Flash drive (Optional) You can play back music files (MP3/WMA/AAC/FLAC) and video files (AVI/MKV/MP4) stored in a USB flash drive on the internal player of this system. WARNING It is dangerous for the driver to watch video while driving the vehicle.

  • Page 58: Playback

    Playback Stopping Playback (USB Video only) Touch [ ] during playback. Press the (AUDIO) button to select USB mode. “STOP” indicator is displayed, and playback stops. The display shows the USB mode screen. • Playback starts from the beginning when [ ] is touched while •...

  • Page 59: Switching Display Modes (During Video File Play Back)

    Full Search mode Touch [Audio] or [Video] to switch whether the search list displays music files or video files. Touch your desired Folder name* or File name. When you select a File name, the selected song is played. When you select a Folder name, repeat the same procedure to select another Folder name or File name.

  • Page 60: Ipod/Iphone (Optional)

    Function mode iPod/iPhone (Optional) Artwork display • You can change the artwork position. For details, see “Switching the Artwork Position” (page 41). A separately sold Lightning to USB cable (KCU-471i), etc., is required. Current song no./Total song no. When the unit is connected by the above cable, the controls on the iPod Artist title/Release Date* are disabled.

  • Page 61: Playback

    Quick Search Mode Playback In Quick Search mode, the list from the previous search mode is displayed. For example, if the last time you searched for songs was is in Press the (AUDIO) button to select iPod mode. Albums, the Album list is displayed. If you have not used the search The display shows the iPod mode screen.

  • Page 62: Alphabet Search Function

    Alphabet Search Function Repeat Play The unit is provided with an alphabet search function for effective Touch [ ] to repeatedly play back the currently track. searching. When you use this function in the search mode, you can The tracks (files) will be played repeatedly. Touch [ ] again to deactivate Repeat play.

  • Page 63: Pandora® Internet Radio (Optional)

    USB port and change the Audio source from Bluetooth Audio, set Launch the Pandora® on the smartphone. “Alpine TuneIt App” to “USB (iPhone)” or “Off. ” For more details, see “Pairing a Bluetooth Device” (page 31) and “Smartphone Apps Setup”...

  • Page 64: Thumbs" Feedback

    “Thumbs” Feedback Creating a New Station You can personalize your stations with “Thumbs Up” or “Thumbs Based on the currently playing song or artist, a personalized Pandora Down” feedback, which the system takes into account for future music station can be created. The new station will play more music like it. selections.

  • Page 65: Connecting A Bluetooth Device (Bluetooth Pandora® Only)

    Connecting a Bluetooth Device (Bluetooth Pandora® Only) Registering a Bluetooth device in the unit enables automatic connection. If it does not connect automatically, run through the connection procedure again. Touch [ ] (Phone Setting). The Device Setting select pop up screen is displayed. Touch [Reconnect].

  • Page 66: Siriusxm Satellite Radio Operation

    < During Replay mode > SiriusXM Satellite Radio Operation Signal Indicator Indicates the signal strength of SiriusXM. Info area (Optional) Channel Info. Mode*: Channel No/Long Channel Name/Category Name Song Info.Mode: SiriusXM Tuner operation: Artist Name/Song Name/Content Info When an optional SiriusXM Tuner is connected to this unit, the Album Art following operations may be performed.

  • Page 67: Tuner

    Select the desired channel. Receiving Channels with the SiriusXM Tuner Changing the Display About SiriusXM Satellite Radio Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the Text information, such as the channel name, artist name/feature, and best sports, news, talk, comedy and entertainment.

  • Page 68: Smartfavorites Functions

    Touch [ ] (TuneScan). SmartFavorites Functions The [ ] (TuneScan) icon is highlighted during TuneScan mode. SmartFavorites allow you to rewind and replay any missed Touch [ ] (TuneScan) during scan playback, programming from your current Band of Preset channels. Miss a music, TuneScan mode will be canceled and the selected track news, talk or sports segment? No Problem, because you can rewind and will be played back normally.

  • Page 69: Selecting The Channel Directly

    Searching by My Music Touch the “Artist Saved” or “Song Saved” to choose to store the Artist or the Song. Touch [My Music]*. Total registrations and Remaining number of registration slots is The artist names and song titles that you have stored and are displayed for 2 seconds, then the Artist or Song is registered as currently playing will be displayed in a list.

  • Page 70: Replay Function

    Replay Function Using Jump Memory and Jump Recall function In SiriusXM mode, you can pause, rewind and replay live Satellite Radio. The Jump Channel is a special channel that you can jump to with the press of a dedicated button and then jump back to the previous channel. Replay mode screen example This channel is often used to select your favorite SiriusXM traffic and weather report channel.

  • Page 71: Hdmi Device

    You can also operate the DVD player using the Remote Control unit position. For details, see “To display the Setup Menu screen” in supplied with X209D. (For X208U/INE-W977HD, supplied with the “Setup Operation” (page 30). DVE-5300) For detailed notes on handling and operating the Remote Control unit, see “About Remote Control Operation (X209D only)”...

  • Page 72: System Setup

    Delaying Image Output System Setup Use this function when an external audio processor is connected. Depending on the connected audio processor, the audio and image Switching the Bar Color currently played back may not be output at the same time. In this case, Select the colors (8) used for highlighting items in the System Setup you can output an image delayed by 0.1 second by setting to On.

  • Page 73: Cd Contents Setup

    • Languages set upon shipment from the factory: Digital audio output Audio language : Auto Audio recording Optical digital Disc Subtitle language : Auto format Digital audio output Digital audio Menu language : Auto output (when a digital output (HDMI setting audio processor is output)

  • Page 74: Cd/Mp3/Wma/Aac/Wav

    CD/MP3/WMA/AAC/WAV Playback MP3/WMA/AAC main screen example Press the (AUDIO) button to select DVD (CD) mode. The display shows the DVD (CD) mode screen. Info mode • You can also select and change from the Menu screen (page 22) or Favorite screen (page 25). When a disc is inserted into the disc slot of the DVD Player, with the label side facing up, the unit starts playback of the disc.

  • Page 75: Mix (Random Play)

    MIX (Random Play) Touch [ ] during playback. DVD Video main screen example The tracks (files) on the disc will be played back in a random sequence. The MIX mode switches every time [ ] is touched. MP3/WMA/AAC: MIX Folder* MIX (Disc)* MIX Folder* *1 Only files in a folder are played back in random sequence.

  • Page 76: Playing A Disc

    Info mode Playing a Disc WARNING It is dangerous for the driver to watch the DVD while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur. Install the unit correctly so that the driver cannot watch DVD unless the vehicle is stopped and the emergency brake is applied.

  • Page 77: If A Menu Screen Appears

    If a Menu Screen Appears Numeric Keypad Input Operations On DVD mode, menu screens may appear automatically. If this Touch [Key] again in the menu operation mode. happens, perform the operation described below to start playback. The numeric keypad input mode screen appears. Direct Menu Operations Touch a desired number.

  • Page 78: Stopping Playback

    Stopping Playback Forward/Reverse frame-by-frame Playback Touch [ ] during playback. “ ” indicator is displayed, and playback stops. In the pause mode, touch [ ] or [ • Playback starts from the beginning when [ ] is touched while The picture advances by one frame each time the button is playback is stopped.

  • Page 79: Searching By Title Number

    Searching by Title Number Switching the Audio Tracks Use this function to easily find positions on the DVD using the DVD’s DVDs with multiple audio tracks or languages allow switching the titles. Perform operations while playback is stopped. sound during playback. Touch [ ] (Audio).

  • Page 80: Hdmi Operation

    • The electronic device must possess an HDMI output interface. • Not all devices with an HDMI output interface can be recognised by this unit. • Use only the Alpine Special HDMI connection cable. Press the (AUDIO) button to select HDMI mode.

  • Page 81: Bluetooth Operation

    Bluetooth compatible device to this unit. The device mobile device or personal computer over short distances. This enables a name of this unit is “X209D”, “X208U” or “INE-W977HD” and the hands-free call or data transmission between Bluetooth compatible initial number of the passcode is “0000.

  • Page 82: Answering A Call

    Answering a Call Call Waiting Function Incoming calls are announced by the received call ring tone and a If a call comes in from another phone during a call, a notice is displayed displayed message (PHONE No., etc.). on the screen. This function can only be used if the connected mobile phone has a call waiting function service included.

  • Page 83: Calling

    Second incoming call during a conversation in the Phone Touch the Short Cut icon. Operation screen A contact’s name, phone number, and a confirmation message of the phone number are displayed. • The display or operation may differ depending on the connected mobile phone or the caller’s mobile phone.

  • Page 84: Using Voice Recognition Function

    Entering a Phone Number to Make a Call Speak into the microphone supplied with this unit. • If no speech is detected, the unit may pause depending on version Touch [ ] (Keypad). of the connected iPhone. In that case, touch the microphone icon ] in the center of the Voice Control mode screen.

  • Page 85: Operations During A Conversation

    Adjusting the volume Phone Book Function Adjust the speaker/microphone volume in Voice Dial mode. Perform the same procedure to adjust the speaker/microphone volume of hands- free phone. Phone Book screen example Touch [ ] or [ ]. Adjust the speaker and microphone volumes. Stopping input to the microphone If the surrounding sound (road noise, etc.) is loud, you may wish to cut input to the microphone for 3 seconds.

  • Page 86: Deleting The Phone Book Entries

    Deleting the Phone Book Entries Bluetooth Audio Deleting One Entry from the Phone Book If a Bluetooth compatible mobile phone, portable player, etc. is connected by wireless, you can play back a song (operation is Touch [ ] (Edit). controllable from the unit). Touch the checkbox [ ] of the contact name (or phone •...

  • Page 87: Playback

    Playback Random Play Available for AVRCP Ver. 1.3, 1.4 and 1.5 only. Press the (AUDIO) button to select Bluetooth Audio mode. Touch [ The display shows the Bluetooth Audio mode screen. The Random Play mode select pop up screen is displayed. •...

  • Page 88: Connecting A Bluetooth Device

    Connecting a Bluetooth Device Registering a Bluetooth device in the unit enables automatic connection. If it does not connect automatically, run through the connection procedure again. Touch [ ] (Settings). The Device Setting select pop up screen is displayed. Touch [Reconnect]. Bluetooth connection will start.

  • Page 89: Auxiliary Device (Optional)

    Operating an AUX, AUX DVD or GAME Auxiliary Device Example for AUX, AUX DVD, GAME mode display (Optional) Operating Auxiliary Devices (Optional) To operate devices connected to the AUX terminals of the unit, follow the procedure described below. • Set AUX to “On. ” See “AUX Setup” (page 45). •...
  • Page 90 Touch the switch to advance to the beginning of the next chapter/track/file. Touch and hold to fast forward. ] (Menu) Calls up the Menu screen. ] (Menu Control)* Calls up the menu operation mode. ] (Folder Down) Switches the program/playlist/folder down. ] (Folder Up) Switches the program/playlist/folder up.

  • Page 91: Camera Operation (Optional)

    Touch [Camera]. Camera Operation The Rear Camera view is displayed. • Touch the screen while the camera image is being displayed, and touch (Optional) ] or [ ] to return to the main source screen or previous screen. • You can perform a Guide Adjustment. For details, see “Adjusting the Rear/Front/Side Camera Guide”...

  • Page 92: Adjusting The Caution Display Location

    Touch [Guide Off] or [Hitch Guide Off] on the Rear • The camera has a limited range of vision. Objects at extreme angles to the camera (e.g. under the bumper or at opposite ends of the bumper) camera display screen. may not be in the its field-of-vision.

  • Page 93: Front Camera Operation

    <Situation of the car> Front Camera Operation Actual distances Displaying the Front Camera image from the Menu screen. Press the MENU button. The menu screen is displayed. Error Error The distance guidance mark represents the distance to a flat road surface. Therefore in the case of an upward slope behind the car, the distance guides are displayed closer to the rear bumper than the actual distance.

  • Page 94: About The Adjustment Of Guide Display On/Off Setting And Adjustment Of Caution Display Location

    About the adjustment of guide display ON/ Switching the Image Pattern for the Side OFF setting and adjustment of Caution Camera display location If the camera has a view switch function, the Direct Change switch is displayed. As with the rear camera, the front camera guide display ON/OFF setting and Caution display location can be adjusted.

  • Page 95: Idatalink Operation

    Adjust or confirm the item/information accordingly. iDataLink Operation • Operable functions and displays may differ depending on the vehicle. iDataLink Function Screen example When the unit is connected to the car’s iDataLink module, you can transfer and receive data between the car and the unit to check the car’s Climate screen example status, or to make various operations from the unit.

  • Page 96: About Parking Sensor Screen

    Vehicle Information screen example Parking Sensor Camera interlock screen example (Rear camera) You can check for open doors, check the tire pressure, the battery life, You can check for obstacles through an interlocked camera image by etc. for the vehicle. connecting a Front or Rear Camera.

  • Page 97: External Accessory Control Operation

    When changing the name: External Accessory Control Operation Touch the icon name, then input characters into Edit Name (Keypad). You can also select a basic name from the [Template] of the Keypad. For details on how to input characters using the You can set the headlights to ON/OFF or adjust the air suspension from keypad, see “How to Input Characters and Numbers (Keypad)”...

  • Page 98: About Remote Control Operation (X209D Only)

    About Remote Battery Replacement Battery type: CR2025 battery or equivalent. Control Operation Opening the battery case Slide out the battery cover while firmly pressing in the direction (X209D only) of the arrow. Replacing the battery Put the battery in the case with the (+) indication upward as shown in the illustration.

  • Page 99: Operating The Dvd Player

    DVD/Video CD mode: Operating the DVD Player • Move to the desired position on the disc. • During playback, press and hold for more than 1 second to reverse the disc at double speed. Hold for more than 5 seconds to reverse the disc at 8 times the normal speed. Hold for more than 10 seconds to reverse the disc at 32 times the normal speed.

  • Page 100: Product Software Update

    The software installed in the product contains open-source software. of the disc with a ballpoint pen or other such instrument, then See the following Alpine website for details on the open source software. insert the disc again. http://www.alpine.com/e/oss/download...

  • Page 101: Discs Playable On This Unit (X209D Only)

    We recommend on the disc to find the scene you want to watch and view various not using these accessories on discs played in Alpine DVD players. types of information in dialog style. Using compact discs (CD/CD-R/CD-RW) If you use unspecified compact discs, correct performance cannot be guaranteed.

  • Page 102: About The Supported Formats

    MP3 files contain compressed audio data. MP3 encoding is capable of compressing audio data at extremely high ratios, reducing the size On handling compact discs (CD/CD-R/CD-RW) of music files to as much as one-tenth their original size. This is • Do not touch the surface. achieved while still maintaining near CD quality.

  • Page 103: About Wav (Disc)

    ID3 tags/WMA tags Terminology This device supports ID3 tag v1.0, v1.1, v2.2, v2.3, v2.4, and WMA tag Bit rate Ver.1.x. If tag data is in an MP3/WMA/AAC file, this device can display This is the “sound” compression rate specified for encoding. The higher the title (track title), artist name, and album name ID3 tag/WMA tag the bit rate, the higher the sound quality, but also the larger the files.

  • Page 104: About Dvds

    About DVDs Music CDs and DVDs have grooves (tracks) in which the digital data is recorded. The data is represented as microscopic pits recorded into the track – these pits are read by a laser beam to play the disc. On DVDs, the density of the tracks and pits is twice that of CDs, so DVDs can contain more data in less space.

  • Page 105: List Of Language Codes

    List of Language Codes (For details, see page 72.)

  • Page 106: In Case Of Difficulty

    • If the area you are in is a primary signal area, the antenna may properly connected, or then consult your authorized not be grounded and connected properly. Alpine dealer. - Check your antenna connections; make sure the antenna is properly grounded at its mounting location.

  • Page 107: If This Message Appears

    . After the error indication disappears, insert the disc again. If the above-mentioned solution does not solve the USB Hub is not supported. problem, consult your nearest Alpine dealer. • A USB flash drive with a hub is connected. MP3/WMA/AAC is not played back.
  • Page 108 Bluetooth Check Antenna • The SiriusXM Satellite Radio antenna or cable is either damaged Please connect a Bluetooth audio device. or not connected correctly to the SiriusXM Tuner. • The Bluetooth audio device was not connected correctly. - Check that the SiriusXM antenna cable is connected to the - Check the settings for the unit and the Bluetooth audio device SiriusXM Tuner and check that the antenna cable is not kinked and reconnect.
  • Page 109 - Drive the vehicle in an area of good GPS reception to allow the and eject the disc. unit to recalibrate itself. Move to a location where strong GPS If the disc still does not eject, consult your Alpine dealer. 2) When the error indication remains after ejecting, press reception is possible.

  • Page 110: Specifications

    HFP (Hands-Free Profile) OPP (Object Push Profile) Screen Size 9” (X209D) PBAP (Phone Book Access Profile) 8” (X208U) A2DP (Advanced Audio 7” (INE-W977HD) Distribution Profile) LCD Type Transparent type TN LCD AVRCP (Audio/Video Remote Operation System TFT active matrix Control Profile) Number of Picture Elements 1,152,000 pcs.
  • Page 111 42 mm (1-11/16”) Height 90 mm (3-5/8”) Depth 11.6 mm (15/32”) Weight 50 g (2 oz) (battery excluded) CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM INE-W977HD (Bottom side of player) 171 mm (6-3/4”) 178 mm (7-1/8”) 18 mm (23/32”)

  • Page 112: End User License Agreement (Here)

    System. The right to use the System shall expire either when the user destroys this software, or when any of the terms for use is violated and Alpine, Space Machine and/or HERE exercise the option to revoke the license to use this software.

  • Page 113: Limited Warranty

    ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the telephone numbers listed below.
  • Page 114 N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration. Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente...

This manual is also suitable for:

X208uX209d

Table of Contents
