Application Note
Hardware Design Guide for AM62A7/AM62A3 Devices
This hardware design guide gives an overview of the design considerations to be followed by the board
designers using AM62A7/AM62A3 family of processors. This application note is intended to be used at different
stages of board design as a guide by the designers. The hardware design guide additionally references to
collaterals (device-specific and common) that could help the designers to optimize the efforts during the board
design.
