XTR5+
Airless Spray Gun
For use with protective coating materials. For professional use only.
XTR5+
5000 psi (35 MPa, 345 bar) Maximum
Working Pressure
XTR7+, XTR7+ High Flow
7250 psi (50 MPa, 500 bar) Maximum
Working Pressure
Important Safety
Instructions
Read all warnings and instructions
in this manual before using the
equipment. Save these instructions.
Important Medical
Information
Read the medical alert card
provided with the gun. It contains
injection injury treatment
information for a doctor. Keep it
with you when operating the
equipment.
™
and XTR7+
™
3A7469D
EN
II 2 G Ex h T6 Gb
Advertisement
Table of Contents
Related Manuals for Graco XTR7+ XTR720
Summary of Contents for Graco XTR7+ XTR720
- Page 1 Instructions ™ ™ XTR5+ and XTR7+ 3A7469D Airless Spray Gun For use with protective coating materials. For professional use only. XTR5+ 5000 psi (35 MPa, 345 bar) Maximum Working Pressure XTR7+, XTR7+ High Flow 7250 psi (50 MPa, 500 bar) Maximum Working Pressure Important Safety Instructions...
-
Page 2: Table Of Contents
Technical Specifications ......22 Graco Standard Warranty ......23... -
Page 3: Models
Models Models XTR5+ Airless Spray Gun XTR7+ High Flow Airless Spray Gun Part Number Description Part XTR520 1 in. round handle, four-finger Number Description trigger, no tip XTR710 High flow, round handle, four-finger XTR521* 1 in. round handle, four-finger trigger, no tip trigger, flat tip XTR711* High flow, round handle, four-finger... -
Page 4: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. - Page 5 Warnings WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component.
- Page 6 Warnings WARNING BURN HAZARD Equipment surfaces and fluid that is heated can become very hot during operation. To avoid severe burns: • Do not touch hot fluid or equipment. RECOIL HAZARD Gun may recoil when triggered. If you are not standing securely, you could fall and be seriously injured.
-
Page 7: Installation
Installation Installation Grounding System Requirements • Install a bleed-type master air valve on a pneumatic pump air supply line to relieve air trapped between this valve and pump after air regulator is shut off. Trapped air The equipment must be grounded to can cause the pump to cycle reduce the risk of static sparking. -
Page 8: Spray Tip Installation
Installation Spray Tip Installation Install tip cylinder (20c) as shown. Turn 90° counterclockwise to spray position, so the arrow faces forward. Install the RAC tip guard (19) onto spray gun. To avoid serious injury from skin injection, do not put your hand in front of the spray tip when installing or removing the spray tip and tip guard. -
Page 9: Operation
Operation Operation If pressure is not fully relieved: • Spray tip is clogged. For RAC tip, see Clean Spray Tips/Clear Clogs, page 10. For flat tip, slowly loosen tip guard Pressure Relief Procedure retaining nut to relieve pressure. Remove and clean the tip. Follow the Pressure Relief •... -
Page 10: Adjust Spray Pattern
Operation Adjust Spray Pattern Clean Spray Tips/Clear Clogs The spray tip orifice and spray angle determine pattern coverage and size. When NOTE: Clean the spray tip and tip guard at you need more coverage, use a larger spray the end of each workday. tip rather than increasing fluid pressure. -
Page 11: Maintenance
Maintenance Maintenance Clean and Replace Filter (Not applicable for XTR530, Failure to clean or replace the filter or a XTR710-XTR715, and 17V677) damaged handle bore can result in Follow the Pressure Relief Procedure, serious injury. page 9. Before performing any maintenance on Engage the trigger lock. -
Page 12: Repair
Repair Repair Disassembly Follow the Pressure Relief Procedure, page 9. Engage the trigger lock. Disconnect the fluid hose. Remove the RAC tip guard and tip (19 and 20a–20c) or flat tip guard and tip (30, 31, and 32). RAC tip only: Use tool to push gasket and seal out the back of the housing. -
Page 13: Trigger Removal
Repair Trigger Removal Assembly NOTE: To avoid losing parts, be ready for Press a new gasket (3*) into the gun body. Lightly grease the seal retainer two actuator pins (7) to fall out of the gun (2*) and install. Torque to 48–72 in-lb body when the trigger (16) is removed. -
Page 14: Parts
Parts Parts XTR5+ 3A7469D... - Page 15 Parts XTR5+ Parts List Quantity Ref. Part Description XTR520 XTR521 XTR522 XTR523 XTR524 XTR525 XTR530 19B236 BODY, gun 245881 SEAL, retainer assembly GASKET 19B237 CAP, end 117350 SPRING 15E088 RETAINER, needle 15E085 PIN, actuator 18C010 NEEDLE 156766 GASKET 245858 SEAT, valve 255275 HANDLE;...
-
Page 16: Xtr7+, Xtr7+ High Flow
Parts XTR7+, XTR7+ High Flow 3A7469D... - Page 17 Parts XTR7+ Parts List Quantity Ref. Part Description XTR720 XTR721 XTR722 XTR723 XTR724 XTR725 19B238 BODY, gun 245881 SEAL, retainer assembly GASKET 19B239 CAP, end 117350 SPRING 15E088 RETAINER, needle 15E085 PIN, actuator 18C010 NEEDLE 156766 GASKET 245858 SEAT, valve 248952 KIT, repair, handle 17V749...
- Page 18 Parts Quantity Ref. Part Description XTR720 XTR721 XTR722 XTR723 XTR724 XTR725 220251 GUARD, flat tip 163519 TIP, flat --- Not for sale. ▲ Replacement Danger and Warning labels, tags, and cards are available at no cost. Parts included in Repair Kit 273141, purchased separately. ★...
- Page 19 Parts XTR7+ High Flow Parts List Quantity Ref. Part Description XTR710 XTR711 XTR712 XTR713 XTR714 XTR715 17V677 19B240 BODY, gun SEAL, retainer 245881 assembly GASKET 19B239 CAP, end 117350 SPRING 15E088 RETAINER, needle 15E085 PIN, actuator 18C010 NEEDLE 156766 GASKET 245858 SEAT, valve 17V749 KIT, repair, handle...
- Page 20 Parts Quantity Ref. Part Description XTR710 XTR711 XTR712 XTR713 XTR714 XTR715 17V677 220251 GUARD, flat tip 163531 TIP, flat --- Not for sale. ▲ Replacement Danger and Warning labels, tags, and cards are available at no cost. Parts included in Repair Kit 273141, purchased separately. ★...
-
Page 21: Accessories
Accessories Accessories XTR+ Gun and Hose Kit Part Number Description *26C962 XTR520, (2) XHD519 tips, Hose, Whip, 5000psi (350bar) *273142 XTR520, XHD317, XHD319, Hose, Whip, 5000psi (350bar) *26C963 XTR720, (2) XHD519 tips, Hose, Whip, 7250psi (500bar) *273143 XTR720, XHD317, XHD319, Hose, Whip, 7250psi (500bar) 26C972 8 pack of 26C962 with display 273144... -
Page 22: Technical Specifications
Technical Specifications Technical Specifications XTR5+ and XTR7+, XTR7+ High Flow, and 17V677 Metric Maximum working pressure (XTR5+) 5000 psi 35 MPa, 345 bar Maximum working pressure (XTR7+, XTR7+ High 7250 psi 50 MPa, 500 bar Flow, 17V677) Maximum fluid operating temperature 160°F 71°C Noise (dBa) -
Page 23: Graco Standard Warranty
Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts. - Page 24 Graco Information For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6921 or Toll Free: 1-800-328-0211 Fax: 612-378-3505 All written and visual data contained in this document reflects the latest product information available at the time of publication.
