Page 1: Installation And
TSMS58RK Manual.qxd 8/8/05 8:35 AM Page 1 TSMS-5/8RK Rack-Mounted 14V/18V Satellite Multiswitch Installation and Operation Manual Operation www.picomacom.com Ph: 800-421-6511 Manual Rev. 07/05... -
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the TSMS-5/8RK Rack-Mounted Satellite Multiswitch, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 21. Outdoor Antenna Grounding: Before attempting to install this product, be sure the antenna or cable system is grounded so as to Page 3 TSMS-5/8RK provide some protection against voltage surges and built-up static charges. a. Use No.10 AWG (5.3mm) copper, No.8 AWG (8.4mm) alu- minum, No.7 AWG (10mm) copper-clad steel or bronze wire or...
- Page 4 The TSMS-5/8RK is compatible with DIRECTV phase three dish reception systems by allowing 4 LNB inputs and 1 antenna and providing 8 outputs.
-
Page 5: Specifications
15 dB min. 15 dB min. Return Loss Input / Output -7 dB min. -12 dB min. Ordering Information TSMS-5/8RK DIRECTV Phase 3 ODU Compatible 5 Input 8 Output Page 5 TSMS-5/8RK Rack-Mounted 14V/18V Satellite Multiswitch Front View Rear View... -
Page 6: Operation And Controls
TSMS58RK Manual.qxd 8/8/05 8:36 AM Operation and Controls TSMS-5/8RK Back Panel Control 24Vac / 1A: Connect cable from wall adaptor. ANT IN: Connect the cable from an off-air antenna to this port. 13V/22kHz: Connect the 13Vdc 22 kHz output of a LNB to this port. -
Page 7: Installation Procedure
Connect a cable from the LHCP port of an LNB to the LNB LHCP (18V) port of the TSMS-5/8RK. Connect a cable from the RHCP port of an LNB to the LNB RHCP (14V, 22kHz) port of the TSMS-5/8RK. Connect a cable from the LHCP port of an LNB to the LNB LHCP (18V, 22kHz) port of the TSMS-5/8RK. -
Page 8: Limited Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
