612804202L1-1A
January 2004
TRACER 4102/4202
System Manual
12804102L1A
TRACER 4102 System (Plan A)
12804102L1B
TRACER 4102 System (Plan B)
12804202L1A
TRACER 4202 System (Plan A)
12804202L1B
TRACER 4202 System (Plan B)

Advertisement

Table of Contents
loading

Related Manuals for ADTRAN TRACER 4102

Summary of Contents for ADTRAN TRACER 4102

  • Page 1 TRACER 4102/4202 System Manual 12804102L1A TRACER 4102 System (Plan A) 12804102L1B TRACER 4102 System (Plan B) 12804202L1A TRACER 4202 System (Plan A) 12804202L1B TRACER 4202 System (Plan B) 612804202L1-1A January 2004...
  • Page 2 To the Holder of the Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
  • Page 3 TRACER 4102/4202 System Manual Revision History Revision History Document Date Description of Changes Revision January 2004 Initial release of manual. Notes provide additional useful information. Cautions signify information that could prevent service interruption. Warnings provide information that could prevent damage to the equipment or endangerment to human life.
  • Page 4 Safety Instructions TRACER 4102/4202 System Manual Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: 1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 5 Connect the equipment and the affected receiver to power outlets on separate circuits. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate the equipment. 612804202L1-1A...
  • Page 6 It is recommended that the installer place radio frequency hazard warnings signs on the barrier that prevents access to the antenna. • Prior to installing the antenna to the TRACER 4102/4202 output, make sure the power is adjusted to the settings specified in section 2 of this manual. •...
  • Page 7 Warranty and Customer Service Warranty and Customer Service ADTRAN will repair and return this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty. Customer Service, Product Support Information, and Training ADTRAN will repair and return this product within the warranty period if it does not meet its published specifications or fails while in service.
  • Page 8 Your reseller should serve as the first point of contact for support. If additional support is needed, the ADTRAN Support web site provides a variety of support services such as a searchable knowledge base, updated firmware releases, latest product documentation, service request ticket generation and trouble-shooting tools.
  • Page 9 System Description ........11 This section of ADTRAN’s TRACER 4102/4202 System Manual is designed for use by net- work engineers, planners, and designers for overview information about the TRACER 4102/4202.
  • Page 10 Table of Contents TRACER 4102/4202 System Manual © 2004 ADTRAN, Inc. 612804202L1-1A...
  • Page 11 SYSTEM DESCRIPTION This section of ADTRAN’s TRACER 4102/4202 System Manual is designed for use by network engineers, planners, and designers for overview information about the TRACER 4102/4202. It contains general information and describes physical and operational concepts, network relationships, provisioning, testing, alarm status, and system monitoring. This section should be used in conjunction with Section 3, Engineering Guidelines, of the system manual.
  • Page 12 30 miles (line-of-sight path required). As authorized under Part 15.247 of the FCC Rules, the TRACER 4102 and 4202 operate license-free in the 2.4 GHz and 5.8 GHz Industrial, Scientific, and Medical (ISM) bands, respectively. These bands require no frequency coordination or licensing of end users.

  • Page 13: Table Of Contents

    Table 4. Receiver Sensitivity for the TRACER 4102/4202 ......20 Table 5.
  • Page 14 Section 2 Microwave Path Engineering Basics TRACER 4102/4202 System Manual © 2004 ADTRAN, Inc. 612804202L1-1A...

  • Page 15: Line-Of-Sight

    Section 2 Microwave Path Engineering Basics LINE-OF-SIGHT The TRACER 4102 and 4202 systems are designed for operation in the license-free 2.400 to 2.4835 GHz and 5.725 GHz to 5.850 GHz industrial, scientific and medical (ISM) bands, respectively. Radio wave propagation in these bands exhibit microwave characteristics which are ideally suited for point-to-point, line-of-sight communications.

  • Page 16: Receiver Power

    Section 2 Microwave Path Engineering Basics TRACER 4102/4202 System Manual most applications, 20 to 30 dB of fade margin should ensure a reliable link. The following sections further discuss the necessary power calculations and their components. RECEIVER POWER The viability of a particular microwave path is determined by the power of the transmitted microwave signal, the transmit and receive antenna gain, distance, and accumulated system losses (such as RF coaxial cable losses and path loss).

  • Page 17: Antenna Gain

    6 dBi. At 2.4 GHz (TRACER 4102), the 1-watt maximum transmitter power must be reduced by 1 dB for every 3 dB of antenna gain over 6 dBi. Since the TRACER 4102 maximum transmit power is 100 milliwatts, only antennas with gains above 36 dBi (12-foot diameter parabolic dishes) require any reduction in transmit power.

  • Page 18: Carrier Wavelength (L)

    Coaxial cable is required to attach the TRACER 4102/4202 to the antenna. The length of the cable varies from a few feet to hundreds of feet, depending upon your application and the proximity of the TRACER 4102/4202 to the antenna. Various grades of coaxial cable will work sufficiently well for connecting the TRACER 4102/4202 unit to the antenna.

  • Page 19: Path Loss (L P )

    TRACER 4102/4202 System Manual Section 2 Microwave Path Engineering Basics Table 2 gives typical loss figures for some of the more common coaxial cable types (per 100 feet). Table 2. Typical Coaxial Loss for Common Cable Types 2.4 GHz Loss/100 ft.

  • Page 20: Receiver Sensitivity

    Receiver sensitivity of the TRACER 4102/4202 is dynamic as a function of desired bandwidth; receiver sensitivity improves as delivered bandwidth decreases. In situations where 2xT1 connectivity is not...

  • Page 21: Antenna Information

    More bars means more RSSI, which ensures more received signal strength and better link performance. If both the local and remote end of the system are operational, the remote TRACER 4102/4202 can be viewed from the local TRACER 4102/4202 VT100 terminal menu interface.

  • Page 22: Fresnel Zones, Earth Curvature, & Antenna Heights

    2400 MHz to 2483.5 MHz frequency band for TRACER 4102 models, and the 5725 MHz to 5850 MHz frequency band for the TRACER 4202 system.

  • Page 23: Other Considerations

    TRACER 4102/4202 System Manual Section 2 Microwave Path Engineering Basics Table 5. Minimum Antenna Height for Given Path Lengths (Continued) Min. Antenna Height Min. Antenna Height Path Length @ 2.4 GHz @ 5.8 GHz (miles) (ft) (ft) OTHER CONSIDERATIONS Path Availability The path availability of a wireless link is a metric that expresses the fractional amount of time a link is available over some fixed amount of time, and depends on several factors.
  • Page 24 Section 2 Microwave Path Engineering Basics TRACER 4102/4202 System Manual values normally used are listed below Climate Climate Factor Description Very Dry desert regions Temperate mainland, interior region Humid humid and coastal regions © 2004 ADTRAN, Inc. 612804202L1-1A...
  • Page 25 Reviewing the TRACER 4102/4202 Rear Panel Design ....... . .

  • Page 26: Equipment Dimensions

    Section 3 Engineering Guidelines TRACER 4102/4202 System Manual EQUIPMENT DIMENSIONS The TRACER 4102/4202 unit is 17.12” W, 9.34” D, and 1.72” H and can be used in 19 or 23-inch rack-mount configurations. POWER REQUIREMENTS The TRACER 4102/4202 system has a maximum power consumption of 20 Watts and a maximum current draw of 0.95 Amp (at 21 VDC).

  • Page 27: Reviewing The Tracer 4102/4202 Rear Panel Design

    REVIEWING THE TRACER 4102/4202 REAR PANEL DESIGN Figure 2 identifies the various features of the TRACER 4102/4202 rear panel and Table 1 on page 26 provides a brief description of each interface.

  • Page 28: Rs-232 Connection (Db-25) - Terminal Use

    RS-232 functions: • Accepts EIA-232 input from a PC or terminal for controlling the TRACER 4102/4202 system • Operates at 9600 bps Table 2 shows the pinout. Wiring diagrams for connecting to the connector (for various RS-232 applications) are provided following the pinout.

  • Page 29: Rs-232 Connection (Modem Use)

    The TRACER 4102/4202 must be interfaced to a modem via an RS-232 null modem adapter or cable. The null modem converts Clear To Send (CTS) and Data Set Ready (DSR) into Ready To Send (RTS) and Data Terminal Ready (DTR), respectively.

  • Page 30: T1 Connections (Rj-48C)

    Hangup-on-DTR-drop may need to be explicitly enabled on some modems. Table 5 contains the wiring diagram needed for connecting the TRACER 4102/4202 RS-232 interface to a modem using the null modem adapter. The null modem interface must route Carrier Detect (CD) on pin 8 directly from the modem.

  • Page 31: Alarm Contacts (Plug-In Terminal Block)

    (the most negative voltage) to the TRACER 4102/4202 – terminal. Alternately, a -48V supply should be delivered to the TRACER 4102/4202 by connecting ground (the most positive voltage) to the + terminal of the TRACER 4102/4202 power terminal block and -48 V to the – terminal.

  • Page 32: Antenna Interface (N-Type Connector)

    When determining the cable specifications for your application, refer to Section 2, Microwave Path Engineering Basics (System Losses (L) on page 18) for a discussion on cable length and loss factors. AT-A-GLANCE SPECIFICATIONS The following is a list of specifications for the TRACER 4102/4202 system. Table 9. At-A-Glance Specifications Hardware Description...
  • Page 33 -25° C to 65° C Size 17.12” W x 9.34” D x 1.72” H Humidity 95%, Non-condensing Weight 9 lbs (TRACER 4102), 7 lbs (TRACER 4202) Power Input Voltage 21 to 60 VDC, either polarity referenced to ground Power Consumption < 20 Watts...
  • Page 34 Section 3 Engineering Guidelines TRACER 4102/4202 System Manual © 2004 ADTRAN, Inc. 612804202L1-1A...
  • Page 35 Figure 1. 2.4 GHz Bandwidth Division (TRACER 4102) ....... . 37 Figure 2.

  • Page 36: Introduction

    This system MUST be installed by qualifed service personnel in a Restricted Access Location. Each TRACER 4102/4202 is shipped in its own cardboard shipping carton. Open each carton carefully and avoid deep penetration into the carton with sharp objects. After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier, then contact ADTRAN Customer Service (see Customer Service, Product Support Information, and Training information in the front of this manual).

  • Page 37: Customer Provides

    CHANNEL SELECTION The FCC has allocated 83.5 MHz of spectrum in the 2.4 GHz band where the TRACER 4102 operates, and 125 MHz of spectrum in the 5.8 GHz band where the TRACER 4202 operates. Figure 1 and Figure 2 illustrate the bandwidth division.

  • Page 38: Grounding Instructions

    The letter of the channel plan (A or B) must be different on both ends and the number of the bandplan (1, 2, or 3) must be the same on both ends. The default bandplan configuration for the TRACER 4102/4202 is bandplan 1.

  • Page 39: Supplying Power To The Unit

    (P/N 1280650L1). MOUNTING OPTIONS Install the TRACER 4102/4202 in a location that requires minimal antenna feedline length (the loss in this cable directly affects overall system performance). The TRACER 4102/4202 is designed to be mounted in a rack. If multiple units are installed in one location, one half inch of spacing is recommended above and below the unit.

  • Page 40: Connecting The T1 Interface

    Section 4 Network Turnup Procedure TRACER 4102/4202 System Manual ALARM T1A T1B T1C T1D TRACER 4206 Figure 3. 19-inch Rackmount Illustration ALARM T1A T1B T1C T1D TRACER 4206 Figure 4. 23-inch Rackmount Illustration CONNECTING THE T1 INTERFACE The physical T1 interface is provided using two RJ-48C jacks for transmit and receive. The provided straight through T1 interface cables can be used to interface to any standard T1 DTE device.
  • Page 41 Figure 5. 2.4 GHz Bandwidth Division (TRACER 4102) ....... . 48 Figure 6.

  • Page 42: Navigating The Terminal Menu

    Terminal Menu Window The TRACER 4102/4202 uses a series of menu pages and a single main menu page to access its many features. The main menu page (see Figure 1) provides a link to all available configuration/status pages. After connecting a VT100 terminal to the TRACER 4102/4202, press <Ctrl + L> to redraw the current screen.

  • Page 43: Navigating Using The Keyboard Keys

    TERMINAL MENU AND SYSTEM CONTROL Password Protection The TRACER 4102/4202 provides optional password protection of the terminal interface. If enabled, a password prompt is presented at power-up, reboot, modem logout, or after ten minutes of inactivity on the terminal. The password is enabled and defined via the system options menu.

  • Page 44: Menu Descriptions

    ELECTION >TRACER S YSTEM TATUS Figure 2 shows the TRACER 4102/4202 System Status menu page. The status of major system components for both sides of the TRACER link are displayed, but no configuration can be performed from this view. Elapsed...
  • Page 45 Displays the frequency plan (A or B) for the TRACER 4102/4202 unit. For an operational TRACER 4102/4202 system you should have a frequency plan A radio at one end of the link and a frequency plan B radio at the other end of the link.

  • Page 46: Main Menu

    From the keyboard, use the up and down arrow keys to scroll through the available pages, or enter the number or letter of the selected page (to highlight the menu page) and press <Enter>. Press <m> from any menu in the TRACER 4102/4202 VT100 menu structure to access the TRACER 4102/4202 Main Menu page.

  • Page 47: Tracer System Options

    >TRACER S YSTEM PTIONS Figure 4 shows the TRACER 4102/4202 System Options menu page. System option parameters for both the local and remote TRACER 4102/4202 units are available through this menu page. Figure 4. TRACER 4102/4202 System Options Press <O> from any menu in the TRACER 4102/4202 VT100 menu structure to access the TRACER System Options menu page.
  • Page 48 PTIONS ANDPLAN Sets the bandplan for the TRACER 4102/4202. Each channel is divided into three bandplans (1, 2, or 3). Both local and remote TRACER 4102/4202 must be configured with the same bandplan (1, 2, or 3) but different channel plans (Plan A or Plan B). For example, the transmitter at one end of the link will transmit in bandplan 1 of channel A (the lower portion of the spectrum) and receive in bandplan 1 of channel B (the upper portion).
  • Page 49 -96 dBm -93 dBm A, B 1xT1 -98 dBm -95 dBm Both ends of the TRACER link must be set to the same number of active T1 ports. The TRACER 4102/4202 comes factory programmed with set to T1 P CTIVE ORTS When changing active T1 ports on installed links, change the remote end first.

  • Page 50: Tracer Link Performance History

    Press <N> to view the next 8 hours worth of 15-minute totals and <P> to view the previous 8 hours. Press <L> from any menu in the TRACER 4102/4202 VT100 menu structure to access the TRACER Link Performance History menu page.

  • Page 51: T1X Status/Configuration/Loopback

    Figure 8 shows the T1x Status/Configuration/Loopback menu page, which displays a real-time graphical representation for the T1x link using data from both the local and remote TRACER 4102/4202 units. T1x operational configuration parameters and testing functions are configured from this menu.
  • Page 52 OOPBACK IGNALING Configures the framing format for the T1 link for both the local and remote TRACER 4102/4202 units. The TRACER 4102/4202 transports T1 data across the link (as long as the T1 signal is properly timed). Configure the framing format (using the...
  • Page 53 ORMAL TATE EMOTE Activates a loopback at the remote TRACER 4102/4202 T1 framer towards the local end of the wireless link (see Figure 10). Use the remote loopback to loop the data transmitted from the local end of the link across the radio link to the local end of the link.

  • Page 54: T1X Performance History

    The following menus for the T1x Performance History apply to both available T1 interfaces (A and B). Figure 13 shows the T1x Performance History menu page, which displays detailed error statistics for the T1 link (from both the local and remote TRACER 4102/4202 units) in 15-minute and 24-hour increments. Days Hours Figure 13.
  • Page 55 Installing/Configuring T1 Hardware..........60 612804202L1-1A © 2004 ADTRAN, Inc.

  • Page 56: Overview

    1. Verify that the power source is delivering between 21 and 60 VDC. 2. Check the polarity of the power connection (referenced to ground) of both the TRACER 4102/4202 unit and the power source. See DC Power Connection (Plug-In Terminal Block) on page 31 for details on power supply connections.

  • Page 57: Rf Low Led

    1. Verify that the T1 cable is connected to the T1 interface on the TRACER 4102/4202. 2. Verify the connections at the opposite end of the T1 cable. 3. Verify that the framing mode (D4 or ESF) is the same for both the TRACER 4102/4202 and the T1 equipment.

  • Page 58: Rf Errors

    (relative to ground) at the RSSI front panel test jack. Optimal antenna alignment is achieved by peaking the front panel RSSI voltage or the the Rx Power "fuel gauge" on the TRACER 4102/4202 terminal diplay. Consult the ADTRAN TRACER Data Sheet included with the unit to verify that the actual receive signal level agrees with the calculated receive signal.
  • Page 59 6. Attach the RF coaxial cables to be used in the permanent installation to the N-type connectors on the back of the TRACER 4102/4202 unit. Attach the other end of the coaxial cable(s) to an RF power meter or spectrum analyzer, if either is available. The power measured by the meter/analyzer will be the RF power available at the input of the antenna.

  • Page 60: Installing/Configuring T1 Hardware

    Remember to subtract both antenna gains (local and remote) from the attenuator setting. 12. Initiate a line loopback on the local TRACER 4102/4202 unit and run a test pattern from the connected T1 equipment. This will verify the connection between the T1 equipment and the local TRACER 4102/4202 unit.
