• Do not change the engine governor settings or
overspeed the engine;
• Do not alter or tamper with any sealed adjustment for
the engine speed control.
• The lawn mower safety systems or features shall not
be tampered with or disabled.
• Disengage all blades and drive clutches before starting
the engine;
• Start the engine carefully according to instructions and
with feet well away from the blade(s);
• Do not tilt the lawn mower when starting the engine;
• Do not start the engine when standing in front of the
discharge chute;
• Do not put hands or feet near or under rotating parts.
Keep clear of the discharge opening at all times;
• Never pick up or carry a lawn mower while the engine
is running;
• Stop the engine and disconnect the spark plug wire,
make sure that all moving parts have come to a
complete stop and, where a key is fitted remove the
key:
- Before clearing blockages or unclogging chute;
- Before checking, cleaning or working on the lawn
mower;
- After striking a foreign object. Inspect the lawn
mower for damage and make repairs before
restarting and operating the lawn mower;
- If lawn mower starts to vibrate abnormally (check
immediately);
• Stop the engine and disconnect the spark plug wire,
make sure that all moving parts have come to a
complete stop and, where a key is fitted remove the
key:
- Whenever you leave the lawn mower;
- Before refueling;
• Reduce the throttle setting during engine shut down
and, if the engine is provided with a shut-off valve, turn
the fuel off at the conclusion of mowing.
Maintenance and storage
• Keep all nuts, bolts and screws tight to be sure the
equipment are in safe working condition;
• Never store the equipment with petrol in the tank inside
a building where fumes can reach an open flame or
spark;
• Allow the engine to cool before storing in any
enclosure; Clean and maintain the lawn mower before
storage.
• To reduce the fire hazard, keep the engine, silencer,
battery compartment and petrol storage area free of
grass, leaves, or excessive grease;
• Check the grass catcher frequently for wear or
deterioration;
• Replace worn or damaged parts for safety;
• If the fuel tank has to be drained, this should be done
outdoors.
• Improper maintenance, use of non-conforming
replacement components, or the removal or
modification of safety components can damage the
lawn mower and injure the operators seriously.
• Only use the recommended blades and spare parts by
the manufacturer. The use of non-genuine parts can
damage the machine and injure the operators. Keep
the lawn mower in good working condition.
• If the blade stopping device doesn't work, please
contact service center for help.
Transportation and handling
• Whenever the machine is to be handled, raised,
transported or tilted you must:
- wear strong working gloves;
- grasp the machine at the points that offer a safe grip,
taking account of the weight and its distribution;
- use an appropriate number of people for the weight
of the machine and the characteristics of the vehicle
or the place where it has to be placed or collected.
• During transport, fasten the machine securely with
ropes or chains.
WARNING: Do not touch rotating blade.
WARNING: Refuel in a well ventilated area with
the engine stopped.
3. PARTS DESCRIPTION (Fig. A
& B, C)
Including
A: Spark plug wrench
