Summary of Contents for Toyota Land Cruiser 200 2018

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Operation of each Reading this manual ....12 component How to search......13 Pictorial index ......14 3-1. Key information Keys........102 For safety and security 3-2. Opening, closing and locking the doors Side doors ......
Page 3 4-5. Using the driving support Driving systems Toyota Safety Sense P..234 4-1. Before driving (Pre-Collision System)..241 Driving the vehicle..... 166 Cargo and luggage.... 175 (Lane Departure Alert)..254 Vehicle load limits ..... 181 Dynamic radar cruise Trailer towing..... 182 control......
Page 4 TABLE OF CONTENTS 5-4. Using the other interior Interior features features Other interior features..412 • Cool box ......412 5-1. Using the air conditioning • Sun visors ..... 414 system and defogger • Vanity mirror ....414 Front automatic air •...
Page 5 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers... 508 the vehicle exterior..442 If your vehicle has Cleaning and protecting to be stopped in the vehicle interior... 445 an emergency....509 6-2.
Page 6 TABLE OF CONTENTS Vehicle specifications Index 8-1. Specifications What to do if... (Troubleshooting)..... 598 Maintenance data (fuel, oil level, etc.) ..560 Alphabetical index ...... 602 Fuel information ....568 Tire information ....571 8-2. Customization Customizable features ..582 8-3.
Page 7 LC200_OM_OM60Q26U_(U)
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 10 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 11 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 12: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 13: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 602 ■ Searching installation position • Pictorial index....P. 14 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 598 ■ Searching by title • Table of contents .....P. 2 LC200_OM_OM60Q26U_(U)
Page 14: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 106 Locking/unlocking .
Page 15 Pictorial index Windshield wipers ....... . . P. 223 Rear window wiper ....... . P. 227 Precautions against winter season .
Page 16 Pictorial index ■ Instrument panel Engine switch........P. 199 Starting the engine/changing the modes .
Page 17 Pictorial index Multi-information display ......P. 89 Display ..........P. 89 When the warning messages are displayed .
Page 18 Pictorial index ■ Switches Window lock switch....... . P. 157 Door lock switches .
Page 19 Pictorial index Tire pressure warning reset switch ....P. 472 VIEW switch ........P. 303 PCS (Pre-Collision System) switch .
Page 20 Pictorial index Audio remote control switches Meter control switches ......P. 91 Vehicle-to-vehicle distance switch .
Page 21 Pictorial index Heated steering wheel switch ..... . P. 396 Front seat heater/ventilator switches ....P. 395 Four-wheel drive control switch.
Page 22 Pictorial index ■ Interior SRS airbags ........P. 38 Floor mats .
Page 23 Pictorial index Inside rear view mirror ......P. 151 Sun visors ........P. 414 Vanity mirror.
Page 24 Pictorial index LC200_OM_OM60Q26U_(U)
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......38 Front passenger occupant classification system ..50 Safety information for children ......56 Child restraint systems..57 Installing child restraints..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 151, 153) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Fastening and releasing the third center seat belt Pull out the tab. Tab A Tab B Push tab B into buckle B until a clicking sound is heard. Tab B Buckle B Push tab A into buckle A until a clicking sound is heard.
Page 32 1-1. For safe use Push either the mechanical key or tab A into buckle B. When releasing and storing the seat belt, hold the belt while wind- ing it back gently. Buckle B Tab A Buckle B Put tabs A and B together and stow them in the holder.
Page 33 1-1. For safe use Adjusting the seat belt shoulder anchor height (front and second outboard seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 34 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. LC200_OM_OM60Q26U_(U)
Page 35 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 36 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 37 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 38: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 39 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the second outboard seats SRS curtain shield airbags ●...
Page 40 1-1. For safe use SRS airbag system components Knee airbags Airbag sensor assembly Curtain shield airbags Front impact sensors Front passenger airbag Seat belt pretensioners (sec- ond outboard seats) Side impact sensors (front door) Driver’s seat position sensor Front side airbags “AIR BAG ON”...
Page 41 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 42 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 43 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not lean against the door, the roof side rail or the front, side and rear pil- lars. ● Do not allow anyone to kneel on the passenger seats toward the door or put their head or hands outside the vehicle.
Page 44 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
Page 45 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 46 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 47 1-1. For safe use The SRS curtain shield airbags may also deploy under the situations shown in the illustration. ● The angle of vehicle tip-up is marginal ● The vehicle skids and hits a curb stone ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal...
Page 48 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 49 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 50: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. SRS warning light Front passenger’s seat belt reminder light “AIR BAG OFF”...
Page 51 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light flashing Front passenger airbag Side airbag...
Page 52 1-1. For safe use ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
Page 53 1-1. For safe use : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. : In the event the front passenger is wearing a seat belt.
Page 54 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 55 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 56: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 57: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 58 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible   vertible seat seat ...
Page 59 1-1. For safe use ■ When installing a child restraint system on the front passenger seat When you have to use a child restraint system on the front passenger seat, adjust the following: ● The seatback to the most upright posi- tion ●...
Page 60 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 61 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 62: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 63 1-1. For safe use Installation with LATCH system Fold the seatback forward and then adjust it as upright as pos- sible. Take off the covers between the seat cushion and seatback, then confirm the position of the LATCH anchors below the sym- bol in the seatback.
Page 64 1-1. For safe use  Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯...
Page 65 1-1. For safe use Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 66 1-1. For safe use Place the child restraint sys- tem on the second or third seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 67 1-1. For safe use ■ Booster seat Fold the seatback while pull- ing the seatback angle lever. Return the seatback and secure it at the first lock posi- tion. (→P. 135) Place the child restraint sys- tem on the seat facing the front of the vehicle.
Page 68 1-1. For safe use Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap  Second outboard seats Secure the child restraint sys- tem using a seat belt or LATCH anchors, and move the head restraint in place at the upmost...
Page 69 1-1. For safe use  Second center seat Secure the child restraint sys- tem using a seat belt and remove the head restraint. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 70 1-1. For safe use WARNING ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 34) ■...
Page 71 1-1. For safe use WARNING ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 72: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 73: Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 74 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system WARNING ■ Certifications for the engine immobilizer system Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTICE ■...
Page 75: Alarm
1-2. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function or wireless remote control.
Page 76 1-2. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. ● Nobody is in the vehicle. ●...
Page 77 1-2. Theft deterrent system ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ● When a person remaining in the vehicle unlocks the door and the alarm is activated.
Page 78 1-2. Theft deterrent system LC200_OM_OM60Q26U_(U)
Page 79: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......80 Gauges and meters .... 85 Multi-information display ..89 Fuel consumption information ......98 LC200_OM_OM60Q26U_(U)
Page 80: Instrument Cluster Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration display all warning lights and indicators illuminated.
Page 81 There may be a mal- function in a system if the lights do not come on, or turn off. Have the vehi- cle inspected by your Toyota dealer. : The light flashes or illuminates to indicate a malfunction.
Page 82 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Power mode indicator (→P. 213) (→P. 206) Headlight high beam Second start mode indicator (→P. 214) indicator (→P. 206) Low speed four-wheel Headlight indicator drive indicator light...
Page 83 If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction with the system. If this occurs, have the vehicle inspected by your Toyota dealer. : This light illuminates on the outside rear view mirrors.
Page 84 Have the vehicle inspected by your Toyota dealer immediately if this occurs. LC200_OM_OM60Q26U_(U)
Page 85: Gauges And Meters
2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the tar- get region. Engine oil pressure gauge Displays the engine oil pressure Tachometer Displays the engine speed in revolutions per minute Speedometer Displays the vehicle speed Voltmeter Displays the charge state Fuel gauge...
Page 86 2. Instrument cluster Shift position and shift range display Displays the selected shift position or selected shift range (→P. 205) Odometer/trip meter display change button Switches between odometer and trip meter displays Instrument panel light control dial The brightness of the instrument panel light can be adjusted Changing the display Pressing this button switches between odometer and trip meter.
Page 87 2. Instrument cluster ■ The meters and display illuminate when The engine switch is in IGNITION ON mode. ■ The brightness of the instrument panel lights When the tail lights are turned on, the meter’s brightness will be reduced slightly unless the meter brightness level adjustment is set to the brightest setting.
Page 88 When the oil pressure drops even though the engine oil amount has not decreased, or if the oil pressure does not increase when engine oil is added, contact your Toyota dealer, as there may be a problem with the lubri- cation system.
Page 89: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The following information will be displayed when a menu icon is selected. (→P. 91) Some of the information may be displayed automatically depend- ing on the situation. Drive information Select to display various drive data. (→P. 92) Vehicle information display (if equipped) Select to display the vehicle information.
Page 90 2. Instrument cluster Warning message display Select to display warning messages and measures to be taken if a malfunction is detected. (→P. 527) • When there are no current warning messages, “No Messages” is displayed. • When there are multiple warning messages, can be used to switch the displayed warning message.
Page 91 2. Instrument cluster Operating the meter control switches The multi-information display is operated using the meter control switches. Switching displayed items Operate up and down: Switches screens and moves the cursor Press: Enters, moves to next screen and turns functions on/off : For some functions Press: Displays the screen registered as the top screen When no screen has been registered, the drive information screen will be...
Page 92 2. Instrument cluster Drive information Items displayed can be switched by operating up and down. ■ Drive information 4 of the following items can be registered and displayed as the drive information 1 and the drive information 2 (2 items on each screen).
Page 93 2. Instrument cluster ■ Eco Indicator (Eco Driving Indicator Zone Display) →P. 96 ■ Speed Displays the vehicle speed. ■ Sway warning (if equipped) Detects the sway of the vehicle within a lane, which is often associ- ated with a decrease in the driver’s attention level, and displays the decrease in attention using a bar display.
Page 94 2. Instrument cluster Vehicle information Items displayed can be switched by operating up and down. ■ Front tire angle (if equipped) Displays the direction of the front tires. The tire direction is displayed in 3 stages for both left and right, in accordance with the angle of the tire.
Page 95 2. Instrument cluster ■ Setting items ● LDA (Lane Departure Alert) Select to set up LDA. (→P. 582) • Alert sensitivity • Sway warning • Sway sensitivity ● BSM (Blind Spot Monitor) Select to activate/deactivate BSM. (→P. 582) • BSM on/off •...
Page 96 2. Instrument cluster • Accent color Select to change the accent colors on the screen, such as the cursor color. • Initialization Select to reset the meter display settings. : If equipped ■ Eco Driving Indicator Eco Driving Indicator Light (→P. 84) Eco Driving Indicator Zone Display Suggests the Zone of Eco driving with current Eco driving ratio based on...
Page 97 2. Instrument cluster ■ Tire inflation pressure ● It may take a few minutes to display the tire inflation pressure after the engine switch is turned to IGNITION ON mode. It may also take a few minutes to display the tire inflation pressure after inflation pressure has been adjusted.
Page 98: Fuel Consumption Information
2. Instrument cluster Fuel consumption information The fuel consumption information can be displayed on the navi- gation system or multimedia system screen. Display the trip information or past record screen Press the “INFO/APPS” button, and then select “Fuel Consumption” on the screen. Trip information Reset the trip information data Previous fuel consumption per...
Page 99 2. Instrument cluster Past record Reset the past record data Best recorded fuel consumption Average fuel consumption Previous fuel consumption record Update the past record data These images are examples only, and may vary slightly from actual conditions. ■ Resetting the data Selecting “Clear”...
Page 100 2. Instrument cluster LC200_OM_OM60Q26U_(U)
Page 101: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........102 3-2. Opening, closing and locking the doors Side doors......106 Back door......114 Smart key system ..... 126 3-3. Adjusting the seats Front seats ......133 Rear seats......135 Driving position memory ... 142 Head restraints....
Page 102: 3-1. Key Information
Locks the doors (→P. 106) Unlocks the doors (→P. 106) Opens the windows and moon roof (→P. 106) Opens/closes the power back door* (→P. 114) Sounds the alarm (→P. 103) : This setting must be customized at your Toyota dealer. : If equipped LC200_OM_OM60Q26U_(U)
Page 103 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using another mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 104 3-1. Key information ■ When riding in an aircraft When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic key in your bag etc., ensure that the buttons are not likely to be pressed accidentally.
Page 105 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. LC200_OM_OM60Q26U_(U)
Page 106: Side Doors
Unlocks all the doors Pressing the button unlocks the driver’s door. Pressing the but- ton again unlocks the other doors. Press and hold to open the win- dows and moon roof. : These settings must be customized at your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 107 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Windows and moon roof: A buzzer sounds to indicate that the windows and moon roof are operating.
Page 108 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 109 3-2. Opening, closing and locking the doors Locking the driver’s door from the outside without a key Move the inside lock button to the lock position. Close the door. The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 110 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 582. Function Operation Shift position linked door Shifting the shift lever out of P locks all the locking function doors.
Page 111 3-2. Opening, closing and locking the doors ■ Setting and canceling the functions To switch between setting and canceling, follow the procedure below: Close all the doors and turn the engine switch to IGNITION ON mode. (Perform step within 20 seconds.) Shift the shift lever to P or N, and press and hold the door lock switch (...
Page 112 3-2. Opening, closing and locking the doors ■ Changing the door unlock function setting It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 113 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 114: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Locking and unlocking the back door ◆ Smart key system Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
Page 115 3-2. Opening, closing and locking the doors Opening the back door from the inside (vehicles with power back door) The power back door can be opened/closed using the power back door switch or wireless remote control. (→P. 114) Push and hold the switch to close or open.
Page 116 3-2. Opening, closing and locking the doors Open the lower back door Pull the handle. Power back door switch (if equipped) Pressing the switch closes upper back door automatically. buzzer sounds.) Pressing the switch while the upper back door is closing opens it again.
Page 117 3-2. Opening, closing and locking the doors When closing the back door ● Make sure that the lower side of the back door is closed before closing the upper side of the back door. ● Lower the back door using the back door handle, and make sure to push the back door down from the outside to close...
Page 118 3-2. Opening, closing and locking the doors ■ Power back door operating conditions (vehicles with power back door) ● When the engine switch is off or in accessory mode, the power back door can be opened and closed if the power back door main switch is on and all of the following conditions are met.
Page 119 3-2. Opening, closing and locking the doors Push the lever for the back door motor, open the back door.  Vehicles without power back door  Vehicles with power back door IY32LA068 ■ Jam protection function (vehicles with power back door) If anything obstructs the power back door while it is closing/opening, the back door will automatically operate in the opposite direction.
Page 120 3-2. Opening, closing and locking the doors ■ Back door reserve lock function (vehicles with power back door) This function is a function which reserves locking of all doors, beforehand, when the back door is open. When the following procedure is performed, all the doors except the back door are locked and then back door will also be locked at the same time it is closed.
Page 121 3-2. Opening, closing and locking the doors WARNING ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 122 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. LC200_OM_OM60Q26U_(U)
Page 123 3-2. Opening, closing and locking the doors WARNING ■ Back door closer (vehicles with power back door) ● In the event that the back door is left slightly open, the back door closer will automatically close it to the fully closed position.
Page 124 When installing an accessory part to the back door, using a genuine Toyota part is recom- mended. ■...
Page 125 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other Damper stay than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it. ■...
Page 126: Smart Key System
3-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Locks and unlocks the side doors (→P. 106) ●...
Page 127 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handle.
Page 128 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 129 3-2. Opening, closing and locking the doors ● When carrying the electronic key together with the following devices that emit radio waves • When carrying a portable radio, cellular phone, cordless phone or other wireless communication device • Another vehicle’s electronic key or a wireless key that emits radio waves •...
Page 130 3-2. Opening, closing and locking the doors ● If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly. In this case, follow the following correction procedures to wash the vehicle. •...
Page 131 3-2. Opening, closing and locking the doors ■ If the smart key system does not operate properly ● Locking and unlocking the doors: Use the mechanical key. (→P. 548) ● Starting the engine: →P. 549 ■ Customization Settings (e. g. smart key system) can be changed. (Customizable features: →P.
Page 132 (→P. 126) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 133: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Seat position control switch Seatback angle control switch Seat cushion (front) angle control switch Vertical height control switch Lumber support control switch (driver’s side only) Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
Page 134 3-3. Adjusting the seats ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 135: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedure  Second seats Seatback angle adjustment lever Seat position adjustment lever  Third seats Seatback angle adjustment lever LC200_OM_OM60Q26U_(U)
Page 136 3-3. Adjusting the seats Tumbling the second seats and third seat entry For easy access to the third seat, perform in “Tumbling the second seats”. (→P. 137) ■ Before tumbling the second seats Stow the seat belt buckles and lower the head restraints to the lowest position.
Page 137 3-3. Adjusting the seats ■ Tumbling the second seats Fold down seatback while pulling the seatback angle adjustment lever, and swing the whole seat up and forward. Hook the holding strap to the assist grip and secure the seat by pulling its free end. When returning the second seat to its original position, stow the holding strap.
Page 138 3-3. Adjusting the seats Folding up the third seats ■ Before folding up the third seats Stow the seat belts buckles. Stow the center head restraint in the seatback. (→P. 148) Pass the outer seat belts through the seat belt hangers and secure the seat belt plates.
Page 139 3-3. Adjusting the seats Push the seatback angle levers and fold the third seat- backs. Pull the seat leg lock release levers. The seat will rise, and the seat- back striker will also automati- cally sit up. Before raising, make sure that the handle on the rear of the seatback is secure.
Page 140 3-3. Adjusting the seats ■ Returning the third seats Remove the seat hook cov- ers from the floor and install them into the back of the seat cushion. Unlock the seats by pulling the stowed seat lock release levers and lower the seats to its original position.
Page 141 3-3. Adjusting the seats Raise the head restraints. WARNING ■ Seat adjustment To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Page 142: Driving Position Memory
3-3. Adjusting the seats Driving position memory This feature automatically adjusts the driver’s seats, steering wheel and outside rear view mirrors to make entering and exit- ing the vehicle easier or to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be recorded and recalled by pressing a button.
Page 143 3-3. Adjusting the seats ■ Recall procedure Check that the shift lever is in P. Turn the engine switch to IGNITION ON mode. Press one of the buttons for the driving position you want to recall until the buzzer sounds. ■...
Page 144 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. ■ Registering procedure Record your driving position to button “1”, “2” or “3” before perform- ing the following: Carry only the key you want to register, and then close the driver’s door.
Page 145 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
Page 146: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Angle adjustment (if equipped) Second seats Pull the head restraints up.
Page 147 3-3. Adjusting the seats Third outboard seats To fold the head restraints, pull the head restraint angle lever ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 148 3-3. Adjusting the seats  Third center seat Pull the head restraint up while pressing the lock release button. Lock release button  Third outboard seats Push a flathead screwdriver into the slot. The slot is located on the left side of the left head restraint anchor.
Page 149: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Operating the switch moves the steering wheel in the following direc- tions: Down Toward the driver Away from the driver Auto tilt away When the engine switch is off, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry...
Page 150 3-4. Adjusting the steering wheel and mirrors ■ The steering wheel can be adjusted when The engine switch is in ACCESSORY or IGNITION ON mode : If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of engine switch mode. ■...
Page 151: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view in accordance with the driver’s seating posture. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 152 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 153: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding and extending the mirrors ■ Using the switch Extends the mirrors Folds the mirrors...
Page 154 3-4. Adjusting the steering wheel and mirrors ■ Setting automatic mode The door mirrors can be automatically folded and extended by link- ing them to the lock and unlock operations of the smart key system and wireless remote control. They can also be extended by turning the engine switch to IGNITION ON mode.
Page 155 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The engine switch is in ACCESSORY or IGNITION ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defog- gers.
Page 156 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 157: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 158 3-5. Opening, closing the windows and moon roof ■ The power windows can be operated when The engine switch is in IGNITION ON mode. ■ Operating the power windows after turning the engine off The power windows can be operated for approximately 45 seconds even after the engine switch is turned to ACCESSORY mode or turned off.
Page 159 ● The power windows can be opened using the wireless remote control. (→P. 106) : The settings must be customized at your Toyota dealer. ■ Power windows open warning buzzer The buzzer sounds and a message is shown on the multi-information display in the instrument cluster when the engine switch is turned off and the driver’s...
Page 160 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 161: Moon Roof
3-5. Opening, closing the windows and moon roof Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 162 (→P. 548) ● The moon roof can be opened using the wireless remote control. (→P. 106) : The settings must be customized at your Toyota dealer. ■ When the moon roof does not close normally Perform the following procedure: ●...
Page 163 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open reminder function The buzzer sounds and message is shown on the multi-information display in the instrument panel when the engine switch is turned off and the driver’s...
Page 164 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 165: Driving
Cargo and luggage ... 175 4-5. Using the driving support Vehicle load limits ..... 181 systems Trailer towing..... 182 Toyota Safety Sense P ..234 Dinghy towing ....198 4-2. Driving procedures (Pre-Collision System) ..241 Engine (ignition) switch ..199 Automatic transmission ..
Page 166: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 199 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 205) Release the parking brake. (→P. 212) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 167 If a warning message is shown on the multi-information display, read the message and follow the instructions. ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●...
Page 168 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer, perform the bedding-down operation. ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel.
Page 169 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
Page 170 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 171 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is stopped ● Do not race the engine. If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident.
Page 172 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Always apply the parking brake, shift the shift lever to P, stop the engine and lock the vehicle.
Page 173 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ If the vehicle becomes stuck Do not spin the wheels excessively when any of the tires is up in the air, or the vehicle is stuck in sand, mud, etc.
Page 174 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 175: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Roof luggage carrier (if equipped) Roof rails Cross rails Adjusting the position of cross rails (if equipped) Turn the knobs counterclock- wise to release the cross rails.
Page 176 4-1. Before driving Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) − (Total weight of occupants) Steps for Determining Correct Load Limit ⎯ (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 177 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 560) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 178 4-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 179 Roof luggage carrier precautions (if equipped) To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. Follow the manufacturer’s instructions and precautions when installing the cross rails or their equivalent.
Page 180 4-1. Before driving NOTICE ■ Cross rail adjustment Do not remove the cross rail stoppers, or the moon roof may be damage when it is tilted. ■ When loading cargo on the roof luggage carrier (if equipped) Be careful not to scratch the surface of the moon roof. LC200_OM_OM60Q26U_(U)
Page 181: Vehicle Load Limits
4-1. Before driving Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ◆ Total load capacity (vehicle capacity weight): →P. 560 Total load capacity means the combined weight of occupants, cargo and luggage.
Page 182: Trailer Towing
To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating conditions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about addi- tional requirements such as towing kits, etc.
Page 183 4-1. Before driving Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 184 4-1. Before driving ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 185 4-1. Before driving ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 187) LC200_OM_OM60Q26U_(U)
Page 186 4-1. Before driving Weight limits ● The gross trailer weight must never exceed 8100 lb. (3675 kg). ● The gross combination weight must never exceed 14400 lb. (6532 kg). ● The gross vehicle weight must never exceed the GVWR indi- cated on the Certification Label.
Page 187 4-1. Before driving Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 188 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 189 4-1. Before driving Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 190 4-1. Before driving Positions for towing hitch receiver Hitch receiver pin hole position: 45.3 in. (1151 mm) Connecting trailer lights Use the wire harness stored in the rear end under the vehicle body. Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights.
Page 191 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 192 4-1. Before driving ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before making a turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 193 4-1. Before driving ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoidable, do so only after performing the following: Apply the brakes and keep them applied.
Page 194 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 195 4-1. Before driving ■ Maintenance ● If you tow a trailer, your vehicle will require more frequent maintenance due to the additional load. (See “Owner’s Guide”, “Warranty and Services Guide”, “Owner’s Manual Supplement” or “Warranty Booklet”.) ● Retighten the fixing bolts of the towing ball and bracket after approximately 600 miles (1000 km) of trailer towing.
Page 196 4-1. Before driving WARNING ■ To avoid accident or injury ● Do not exceed the TWR, unbraked TWR, GCWR, GVWR or GAWR. ● If the gross trailer weight is over 2000 lb. (907 kg), a sway control device with sufficient capacity is required. ●...
Page 197 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 198: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. LC200_OM_OM60Q26U_(U)
Page 199: Driving Procedures
4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal.
Page 200 4-2. Driving procedures Stopping the engine Stop the vehicle. Set the parking brake (→P. 212), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that the display on the instru- ment cluster is off. Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal released.
Page 201 If the engine does not start ● The engine immobilizer system may not have been deactivated. (→P. 73) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 202 ■ When “Smart Key System Malfunction See Owner’s Manual” is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer, immediately. ■ If the electronic key battery is depleted →P. 487 ■...
Page 203 4-2. Driving procedures WARNING ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 204 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 205: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in IGNITION ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped. Shift position purpose Shift position Purpose and condition...
Page 206 4-2. Driving procedures Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. ■ Power mode For powerful acceleration and driving in mountainous regions. Press the button again to cancel power mode. ■ Second start mode For starting on slippery road surfaces, such as on snow.
Page 207 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever can be oper- ated as follows: Upshifting Downshifting The selected shift range will be displayed in the meter. The initial shift range in S mode is set automatically to 6, 5 or 4 according to vehicle speed.
Page 208 4-2. Driving procedures ■ Driving on a downhill On declines, there may be case where the vehicle shifts down automatically to obtain engine braking. As a result of the downshifting, the engine speed may increase. ■ Second start mode automatic deactivation Second start mode is automatically deactivated if the engine is turned off after driving in second start mode.
Page 209 If the “S” indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. ■ Downshift restriction warning buzzer (S mode) To help ensure safety and driving performance, downshifting operation may sometimes be restricted.
Page 210 4-2. Driving procedures WARNING ■ When driving on slippery road surfaces Do not accelerate or shift gears suddenly. Sudden changes in engine braking may cause the vehicle to spin or skid, resulting in an accident. ■ To prevent an accident when releasing the shift lock Before pressing the shift lock override button, make sure to set the parking brake and depress the brake pedal.
Page 211: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The turn signal lever can be used to show the following intentions of the driver: Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 212: Parking Brake
4-2. Driving procedures Parking brake Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Parking the vehicle →P.
Page 213: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: daytime running lights turn off. The side marker, park- ing, tail, license plate, instrument panel lights, daytime running...
Page 214 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 215 4-3. Operating the lights and wipers ■ Daytime running light system ● The daytime running lights illuminate using the same lights as the headlights and illuminate dimmer than the headlights. ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically when all of the following conditions are met.
Page 216 ■ If the automatic headlight leveling system warning light flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Light reminder buzzer A buzzer sounds when the engine switch is turned to ACCESSORY or OFF mode and the driver’...
Page 217: Automatic High Beam
Do not install a parking tag or any other accessories near or around the inside rear view mirror and the camera sensor. ● Do not modify the vehicle. ● Do not replace windshield with a non-genuine windshield. Contact your Toyota dealer.  Vehicles with PCS (Pre-Collision System): →P. 238 LC200_OM_OM60Q26U_(U)
Page 218 4-3. Operating the lights and wipers Activating the Automatic High Beam system Push the lever away from you with the headlight switch in the position. Press the Automatic High Beam switch. The Automatic High Beam indica- tor will come on when the head- lights are turned on automatically to indicate that the system is active.
Page 219 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 21 mph (34 km/h). •...
Page 220 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. ■ If a warning message of the Automatic High Beam is displayed... It may indicate a malfunction in the system. Contact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 221 4-3. Operating the lights and wipers ■ Temporary lowering sensor sensitivity The sensitivity of the sensor can be temporarily lowered.  Vehicles without PCS (Pre-Collision System): To lower the sensitivity, push and hold on the inside rear view mirror for 15 to 20 seconds, and release.
Page 222: Fog Light Switch
4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam.
Page 223: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows.  Intermittent windshield wipers with interval adjuster Intermittent operation Low speed operation High speed operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 224 4-3. Operating the lights and wipers Washer/wiper dual operation The wipers will automatically operate a couple of times after the washer squirts. Rain-sensing windshield wipers  Rain-sensing operation (“AUTO”) Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain.
Page 225 4-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation The wipers operate automati- cally. (After operating several times, the wipers operate one more time after a short delay to prevent dripping.) ■...
Page 226 4-3. Operating the lights and wipers ■ If no windshield washer fluid sprays Check that the washer nozzles are not blocked if there is washer fluid in the windshield washer fluid reservoir. WARNING ■ Caution regarding the use of windshield wipers in “AUTO” mode (vehi- cles with rain-sensing windshield wipers) The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO”...
Page 227: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer. Intermittent operation Normal operation Washer/wiper dual operation LC200_OM_OM60Q26U_(U)
Page 228 4-3. Operating the lights and wipers ■ The rear window wiper and washer can be operated when The engine switch is in IGNITION ON mode. ■ If no washer fluid sprays Check that the washer nozzles are not blocked if there is washer fluid in the washer fluid reservoir.
Page 229: Headlight Cleaner Switch
4-3. Operating the lights and wipers ∗ Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ■ The headlight cleaners can be operated when The engine switch is in IGNITION ON mode and the headlight switch is turned on.
Page 230: Refueling Opening The Fuel Tank Cap
■ Fuel types →P. 568 ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle.
Page 231 4-4. Refueling WARNING ■ When refueling Observe the following precautions to prevent fuel overflowing from the fuel tank: ● Securely insert the fuel nozzle into the fuel filler neck. ● Stop filling the tank after the fuel nozzle automatically clicks off. ●...
Page 232 4-4. Refueling Opening the fuel tank cap Pull the lever. Turn the fuel tank cap slowly to open. Hang the fuel tank cap on the back of the fuel filler door. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click.
Page 233 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 234: Using The Driving Support
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 235 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 236 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor LC200_OM_OM60Q26U_(U)
Page 237 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 238 ● Do not attach window tinting to the windshield. ● Replace the windshield if it is damaged or cracked. If the windshield needs to be replaced, contact your Toyota dealer. ● Do not get the camera sensor wet. ● Do not allow bright lights to shine into the camera sensor.
Page 239 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 240 4-5. Using the driving support systems ■ Certification LC200_OM_OM60Q26U_(U)
Page 241: (Pre-Collision System)
4-5. Using the driving support systems ∗ PCS (Pre-Collision System) The pre-collision system uses a radar sensor and camera sen- sor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal col- lision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 242 4-5. Using the driving support systems ◆ Pre-collision warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 243 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 244 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 245 4-5. Using the driving support systems Changing settings of the pre-collision system ■ Disabling the pre-collision system Press the PCS switch for 3 sec- onds or more. The PCS warning light will turn on and a message will be dis- played on the multi-information display.
Page 246 4-5. Using the driving support systems ■ Operational conditions The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high. Each function is operational at the following speeds: ●...
Page 247 4-5. Using the driving support systems ■ Pedestrian detection function The pre-collision system detects pedestri- ans based on the size, profile, and motion of a detected object. However, a pedes- trian may not be detected depending on the surrounding brightness motion, posture, angle...
Page 248 4-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adja- cent lane may change, such as on a winding road • When rapidly closing on a vehicle ahead • If the front of the vehicle is raised or lowered, such as when the road sur- face is uneven or undulating •...
Page 249 4-5. Using the driving support systems • When passing under an object (bill- board, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
Page 250 4-5. Using the driving support systems ■ Situations in which the system may not operate properly ● In some situations such as the following, a vehicle may not be detected by the radar sensor and camera sensor, preventing the system from operating properly: •...
Page 251 4-5. Using the driving support systems • When a very bright light, such as the sun or the headlights of oncoming traffic, shines directly into the camera sensor • When the surrounding area is dim, such as at dawn or dusk, or while at night or in a tunnel •...
Page 252 4-5. Using the driving support systems ● Some pedestrians such as the following may not be detected by the radar sensor and camera sensor, preventing the system from operating properly: • Pedestrians shorter than approximately 3.2 ft. (1 m) or taller than approx- imately 6.5 ft.
Page 253 If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 254: Lda
4-5. Using the driving support systems ∗ LDA (Lane Departure Alert) Summary of functions When driving on roads with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visi- ble white (yellow) lines with the camera sensor on the upper por- tion of the front windshield.
Page 255 4-5. Using the driving support systems ◆ Vehicle sway warning function When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 256 Toyota dealer. ● Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 257 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates. Press the LDA switch again to turn the LDA system off. When the LDA system is turned on or off, operation of the LDA system continues in the same condition the next time the engine is started.
Page 258 4-5. Using the driving support systems Indications on multi-information display Lane departure alert function dis- play Displayed when the multi-informa- tion display is switched to the driv- ing assist system information screen.  Inside of displayed white lines  Inside of displayed white lines is white is black Indicates that the system is recog-...
Page 259 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 260 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 261 The system may not be operating Alert properly. → Have the vehicle inspected at your Malfunction Visit Your Dealer” Toyota dealer. Dirt, rain, condensation, ice, snow, etc. are present on the windshield in “Forward Camera front of the camera sensor. System →...
Page 262 4-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert function Adjust alert sensitivity Turn function on and off Vehicle sway warning function Adjust alert sensitivity For how to change settings, refer to P. 582. LC200_OM_OM60Q26U_(U)
Page 263: Dynamic Radar Cruise Control
4-5. Using the driving support systems ∗ Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 264 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 265 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 266 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 328 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 267 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 268 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 269 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 270 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 271 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 272 The center differential lock/unlock is not completed within 5 seconds while the cruise control system is on. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 273 If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Warning messages and buzzers for dynamic radar cruise control Warning messages and buzzers are used to indicate a system malfunction or to inform the driver of the need for caution while driving.
Page 274 4-5. Using the driving support systems ● When your vehicle is pointing upwards (caused by a heavy load in the luggage compartment, etc.) ● Preceding vehicle has an extremely high ground clearance ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary.
Page 275: Cruise Control
4-5. Using the driving support systems ∗ Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 276 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 277 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. WARNING ■...
Page 278: Intuitive Parking Assist
4-5. Using the driving support systems Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, the multimedia screen (if equipped), the navigation system screen, and a buzzer.
Page 279 4-5. Using the driving support systems Display When the sensors detect an obstacle, a graphic is shown on the multi- information display, navigation system screen depending on the posi- tion and distance to the obstacle.  Multi-information display Front corner sensor operation Rear corner sensor operation Rear center sensor operation ...
Page 280 4-5. Using the driving support systems Sensor detection display, obstacle distance ■ Distance display Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Multi- Navigation Insert information system Rear center display Corner sensor display screen sensor 4.9 ft.
Page 281 4-5. Using the driving support systems ■ Buzzer operation and distance to an obstacle A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
Page 282 You can change the buzzer sounds volume and the screen operating conditions. Press the “SETUP” button on the multimedia system or navigation system. Select “Vehicle” on the “Setup” screen and select “TOYOTA Park Assist Settings”. Select the desired item. The buzzer sounds volume can be adjusted.
Page 283 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
Page 284 If “Parking Assist Malfunction” is displayed on the multi-information dis- play Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Toyota dealer. ■ Customization Settings (e.g. buzzer sounds volume) can be changed.
Page 285 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● A buzzer does not sound when you turn the intuitive parking assist on.
Page 286: Four-Wheel Drive System
4-5. Using the driving support systems Four-wheel drive system Use the four-wheel drive control switch and center differential lock/unlock switch to select the following transfer and center differential modes. Four-wheel drive control switch H4 (high speed position) Normal driving on all types of roads.
Page 287 4-5. Using the driving support systems Center differential lock/unlock switch Lock the center differential when your vehicle’s wheels get stuck in a ditch or when driving on a slip- pery or bumpy surface. The center differential lock indica- tor will come on. Unlock the center differential after the wheels have been freed, or after moving to a flat, non-slippery...
Page 288 4-5. Using the driving support systems ■ The four-wheel drive control switch can be operated when ● The engine switch is in IGNITION ON mode. ● The shift lever is in the N position. ● The vehicle is stopped completely. ■...
Page 289 In this case, you may not be able to shift between H4 and L4, and the center differential lock may not be operable. Have the vehicle inspected by your Toyota dealer immediately. WARNING ■...
Page 290: Crawl Control (With Turn Assist Function)
4-5. Using the driving support systems Crawl Control (with Turn Assist function) Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Mini- mizes loss of traction or vehicle slip when driving on slippery road surfaces, helping for stable driving.
Page 291 4-5. Using the driving support systems Speed modes The following table shows some typical terrains and the recom- mended speed modes. Mode Road condition Rock, mogul (downhill) and gravel (downhill) Lo-Med Mogul (uphill) Snow, mud, gravel (uphill), sand, Med-Hi dirt, mogul (uphill) and grass Turn Assist function This function assists cornering performance in accordance with steer- ing operation when driving through a tight corner.
Page 292 4-5. Using the driving support systems When the system is turned off  Crawl Control Press the ON/OFF switch while Crawl Control is operating. If the switch is turned off, the slip indicator and the Turn Assist indicator will go off (if the Turn Assist function is in use), the Crawl Control indicator will flash until the system has turned off completely, and a message stating that Crawl Control has been turned off will be displayed on the multi-information display for several seconds.
Page 293 4-5. Using the driving support systems ■ Automatic system cancelation  Crawl Control In the following situations, the buzzer will sound intermittently and Crawl Con- trol will be canceled automatically. In this event, the Crawl Control indicator will flash and then go off, the Turn Assist indicator will go off (if the Turn Assist function is in use), and a message stating that Crawl Control has been turned off will be displayed on the multi-information display for several seconds.
Page 294 4-5. Using the driving support systems ■ When depressing the accelerator pedal while the Crawl Control is oper- ating Multi-terrain Select operates in AUTO mode. (→P. 296) ■ Sounds and vibrations caused by the Crawl Control system ● A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move.
Page 295: Multi-Terrain Select
4-5. Using the driving support systems Multi-terrain Select Multi-terrain Select is a system that helps drivability in off-road situations.  When the Crawl Control is turned off Select a mode that most closely matches the type of terrain on which you are driving from among 5 modes. Brake control can be optimized in accordance with the selected mode.
Page 296 4-5. Using the driving support systems Selectable modes When the Crawl Control is turned off, a mode which matches the road conditions can be selected from among following modes. MUD & SAND LOOSE ROCK MOGUL ROCK & DIRT ROCK Mode Road Conditions Suitable for muddy roads, sandy roads, snow-cov- MUD &...
Page 297 4-5. Using the driving support systems Switching modes Operate the Multi-terrain Select mode select switch during Multi- terrain Select control to select a mode. Once the mode is confirmed, the mode name will be displayed and the control will switch. ■...
Page 298 Multi-terrain Select. ■ When there is a malfunction in the system The slip indicator light will come on. Have the vehicle inspected by your Toyota dealer immediately. WARNING ■ When using the Multi-terrain Select Observe the following precautions to avoid an accident that could result in death or serious injuries: ●...
Page 299: Multi-Terrain Monitor
4-5. Using the driving support systems Multi-terrain Monitor The Multi-terrain Monitor helps the driver to check the vehicle surroundings. It assists in determining the conditions around the driver in a variety of situations, such as when judging condi- tions during off-road driving or checking for obstacles when parking.
Page 300 4-5. Using the driving support systems ■ Screens when the four-wheel drive control switch is in L4 ● When checking the area to the front and sides of the vehicle  Front view & dual side view  Front view & dual side view (front magnified) →P.
Page 301 4-5. Using the driving support systems ● When checking the area to the rear of the vehicle Rear view & dual side view Wide rear view   →P. 314 →P. 314 ■ Screens when the four-wheel drive control switch is in H4 ●...
Page 302 4-5. Using the driving support systems ● When checking the area to the rear of the vehicle Panoramic view & rear view Wide rear view   →P. 321 →P. 321 ● When checking the area to the sides, front and rear of the vehicle (with outside rear view mirrors retracted) Wide front view &...
Page 303 4-5. Using the driving support systems Using the Multi-terrain Monitor screen ■ Displaying the Multi-terrain Monitor screen The Multi-terrain Monitor screen will be displayed when the VIEW switch is pressed while the engine switch is in IGNITION ON mode. When the vehicle speed exceeds a certain value, the display returns to the navigation or information display screen.
Page 304 4-5. Using the driving support systems ■ Switch operations On some screens, the display mode or display settings can be changed using the switches. ● Automatic display mode switch When automatic display mode is turned on, the Multi-terrain Monitor screen is displayed in the following conditions, even if the VIEW switch has not been operated.
Page 305 4-5. Using the driving support systems Changing the Multi-terrain Monitor screen The screen display can be switched by operating the switches as fol- lows while the Multi-terrain Monitor screen is displayed. (Screens that can be displayed will vary depending on the positions of the shift lever and four-wheel drive control switch) ■...
Page 306 4-5. Using the driving support systems Front view & dual side view Under vehicle terrain view & (front magnified): →P. 308 dual side view: →P. 312 Under vehicle terrain view & Rear view & dual side view: →P. 314 dual side view (front magnified): →P.
Page 307 4-5. Using the driving support systems ■ Screens when the four-wheel drive control switch is in H4 : Press : Select : Operate the shift lever Navigation screen, information Panoramic view & rear view: →P. 321 settings screen, etc. Side views: →P. 318 Wide rear view: →P.
Page 308 4-5. Using the driving support systems ■ Multi-terrain Monitor screen display The amount of time that the Multi-terrain Monitor screen is displayed changes as follows according to the vehicle speed at the time the VIEW switch was pressed. The Multi-terrain Monitor screen is displayed if the vehicle speed is approxi- mately 7 mph (12 km/h) or less when the VIEW switch is pressed.
Page 309 4-5. Using the driving support systems ● Screen description Under vehicle terrain view 6 ft. (2 m) distance guide line selection switch (blue) Switches between front view and Items indicate the esti- under vehicle terrain view display mated distance from the front end each time the switch is selected.
Page 310 4-5. Using the driving support systems ● Front view rotating display function This function operates when the four-wheel drive control switch is in L4. The front view image is automatically adjusted to be parallel and assist the driver to check road surface conditions regardless of the vehicle inclination.
Page 311 4-5. Using the driving support systems ● Slip display When tire slippage detected, the tilt meter dis- play area is automatically switched to the slip display. Tire display Indicates the position of freely spinning tires in yellow if the tire spins. (During Crawl Con- trol is operating, all of the tires are indicated in yellow.) Pop-up display of the intuitive parking assist...
Page 312 4-5. Using the driving support systems ■ Under vehicle terrain view & dual side view Lines indicating current vehicle and tire position are displayed in a composite view on an image taken approximately 10 ft. (3 m) behind the current vehicle position and assists the driver to check conditions underneath the vehicle or determine the position of the front tires.
Page 313 4-5. Using the driving support systems ■ Under vehicle terrain view & dual side view ● The screen can be displayed when the shift lever is in D or N. ● While the under vehicle terrain view is displayed, if the vehicle speed reaches or exceeds approximately 3 mph (5 km/h), the screen automatically returns to the front view display.
Page 314 4-5. Using the driving support systems ■ Rear view & dual side view/wide rear view Guide lines are displayed in a composite view on an image of the area to the rear of the vehicle to use as a reference when deciding a course of movement and assist the driver to check the safety of the area to the rear of the vehicle or to park the vehicle.
Page 315 If the back door is not closed, guide lines will not be displayed. If the guide lines do not display even when the back door is closed, have the vehicle inspected at your Toyota dealer. ■ Intuitive parking assist pop-up display →P.
Page 316 4-5. Using the driving support systems ■ Panoramic view & wide front view The image looking down at the vehicle from above and the image from the front camera are displayed simultaneously and assist the driver to check conditions in front, and to the right and left, of the vehicle at intersections or T-junctions with poor visibility.
Page 317 4-5. Using the driving support systems ● Switching to automatic display mode →P. 304 ● Switching guide line display modes The mode switches and the switch display changes each time the guide line display selection switch is selected. Distance guide line Projected course line Selected mode display mode...
Page 318 4-5. Using the driving support systems ■ Side views The image from the both side cameras is displayed and assists the driver to check conditions on the sides of the vehicle or to confirm the safety of narrow roads. ● Screen description Side view (left front side) Side view (right front side) Display area...
Page 319 4-5. Using the driving support systems ● Using the vehicle width lines The relative distance of obstacles from the vehicle width lines can be confirmed. Example 1: When there is an obstacle in front of the vehicle Operate the steering wheel so that the vehicle width line and the obstacle do not overlap.
Page 320 4-5. Using the driving support systems ■ Side views ● The screen can be displayed when the shift lever is in P, D or N. ● When the outside rear view mirrors are retracted, the displayed area changes (the area on the screen that is not masked in black). (→P. 327) ■...
Page 321 4-5. Using the driving support systems ■ Panoramic view & rear view/wide rear view • Panoramic view & rear view: The image looking down at the vehicle from above and the image from the rear camera are displayed simultaneously and assist the driver to check the safety of the area when parking.
Page 322 4-5. Using the driving support systems ● Switching modes The display mode switches and the icon display changes each time the guide line display selection switch is selected. Parking assist Projected course Distance guide Selected mode guide line display line display mode line display mode mode Icon display...
Page 323 4-5. Using the driving support systems Distance guide line display  mode Front distance guide line (blue) Indicates a distance approximately 3 ft. (1 m) from the front end of the vehicle. Rear vehicle width extension guide lines Indicate the estimated course of the vehicle when backing up straight. •...
Page 324 4-5. Using the driving support systems Intuitive parking assist When the intuitive parking assist is on, an icon will be displayed when an obstacle is detected. (Refer to P. 278 for information about the intuitive parking assist.) Vehicle center line (blue) Indicates the estimated vehicle center on the ground.
Page 325 4-5. Using the driving support systems When the rear position of the vehicle has entered the parking space, turn the steering wheel so that the vehicle width exten- sion guide lines are within the left and right dividing lines of the parking space.
Page 326 5 minutes or more. If the symptom is not resolved, have the vehicle inspected by your Toyota dealer. ● Rear vehicle width extension guide lines are displayed wider than the actual vehicle width.
Page 327 4-5. Using the driving support systems ■ Display when the outside rear view mirrors are retracted (side view and side views) When the outside rear view mirrors are retracted, one of the follow- ing screens is displayed and assists the driver to confirm the safety of the area around the vehicle, or park alongside and close to another object.
Page 328 4-5. Using the driving support systems For information about other than the side view and side views display area, refer to the page for the respective screen. Front distance guide line (red) Indicates a distance approximately 1.5 ft. (0.5 m) from the front end of the vehicle.
Page 329 4-5. Using the driving support systems ● Using the vehicle width lines The relative distance of obstacles from the vehicle width lines can be confirmed. • Approach the shoulder, but do not allow the vehicle width line to overlap the curb or other obstacles. •...
Page 330 4-5. Using the driving support systems ■ Intuitive parking assist and RCTA cooperative display When either the Intuitive parking assist (→P. 278) or Blind Spot Monitor (→P. 349) is turned on, a popup icon warns the driver when an obstacle is detected. Example of pop-up display in the panoramic view Example of pop-up display in the wide rear view Example of pop-up display in the side view (with mirrors retracted)
Page 331 4-5. Using the driving support systems When using the Multi-terrain Monitor Observe the following precautions. Failure to do so may result in an unexpected accident. Also, when driving, make sure to directly con- firm the safety of your surroundings and the area to the rear of the vehicle.
Page 332 4-5. Using the driving support systems NOTICE ■ Panoramic view ● In the panoramic view, the system combines images taken from the front, back, left and right side cameras into a single image. There are limits to the range and content that can be displayed. Understand the characteris- tics of this system before using.
Page 333 4-5. Using the driving support systems ■ Display range ● Panoramic view Not displayed. Not displayed. (Displayed in black around the vehicle icon.) ● Wide front view Masking Parts of the vehicle (such as the bumper or grille) are displayed on the screen.
Page 334 4-5. Using the driving support systems ● Side views The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera ● Side view The side of the vehicle is displayed on the screen. Camera visibility range Object detectable by camera LC200_OM_OM60Q26U_(U)
Page 335 4-5. Using the driving support systems ● Rear view The corners of the bumper are not seen on the screen. ● Wide rear view The corners of the bumper are not seen on the screen. LC200_OM_OM60Q26U_(U)
Page 336 4-5. Using the driving support systems ■ Panoramic view display range ● In the panoramic view, the system processes and displays images acquired form the 4 cameras under the assumption that the vehicle is on a flat road surface. Therefore, the display may appear as follows. •...
Page 337 4-5. Using the driving support systems ■ Multi-terrain Monitor cameras ● Camera positions The cameras of the Multi-terrain Monitor system are installed as follows. Side camera (left and right sides) Front camera Rear camera ● Using the cameras If dirt or foreign matter (such as water droplets, snow, mud, etc.) is adhering to the camera, it cannot transmit a clear image.
Page 338 If the camera is accidentally subjected to an impact, have the vehicle inspected at your Toyota dealer. • Do not remove, disassemble or modify the camera or surrounding parts Doing so may result in the camera malfunctioning. This also may result in a loss of waterproof performance.
Page 339 4-5. Using the driving support systems ■ Differences between the panoramic view screen and the actual road The distance guide lines, the combined panoramic view image, guide lines, etc., indicate estimated distances on a flat road sur- face. In the following situations, actual distances and vehicle course will differ from the guide lines on the screen.
Page 340 4-5. Using the driving support systems ● When the ground behind the vehicle slopes down sharply The distance guide lines are displayed further away than the actual distance. Therefore, obstacles on a downward slope appear closer than the actually are. In the same way, the actual course of the vehicle will differ from the course indicated by the guide lines.
Page 341 4-5. Using the driving support systems ■ Differences between the panoramic view display and actual three-dimensional objects Be aware of the following points when three-dimensional objects higher than the surface of the road (such as a vehicle bumper) are nearby. ●...
Page 342 4-5. Using the driving support systems ● Projected course lines Projected course lines are displayed under the assumption that the vehicle is on a flat road surface. Therefore, the position of three-dimensional objects higher than the road surface (such as a vehicle bumper) cannot be determined.
Page 343 4-5. Using the driving support systems ■ Differences between the rear view or wide rear view and actual roads The guide lines on the screen are intended for flat surfaces (such as the road). Be aware of the following points when three-dimen- sional objects with protrusions (obstacles such as the cargo bed of a truck) are nearby.
Page 344 4-5. Using the driving support systems ■ Differences between the panoramic view, rear view and wide rear view and actual roads ● Distance guide lines Guide lines are displayed in reference to the road surface and cannot be used to determine the distance of three-dimensional objects from the vehicle.
Page 345 4-5. Using the driving support systems ■ Using under vehicle terrain view ● The images displayed were previously taken approximately 10 ft. (3 m) behind the current vehicle position. Therefore, actual conditions may differ from those shown on the screen in the following situations.
Page 346 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 347 There is a malfunction in the signals Have the vehicle inspected by your being output by the steering sensor Toyota dealer.  Guide lines are not displayed Close the back door. If this does not resolve the symptom,...
Page 348 • The camera can be damaged by flying rocks and other debris. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC200_OM_OM60Q26U_(U)
Page 349: (Blind Spot Monitor)
4-5. Using the driving support systems ∗ BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The BSM (Blind Spot Monitor) function Assists the driver in making the decision when changing lanes ●...
Page 350 4-5. Using the driving support systems Multi-information display The BSM function/RCTA function can be turned on/off. (→P. 351) The RCTA function is available when the BSM function is on. Outside rear view mirror indicator BSM function: When a vehicle is detected in a blind spot of the outside rear view mirrors or approaching rapidly from behind into a blind spot, the outside rear view mirror indicator on the detected side will illuminate.
Page 351 ■ When “Blind Spot Monitor System Malfunction” is shown on the multi- information display There may be a sensor malfunction or voltage abnormality. Have the vehicle inspected at your Toyota dealer. ■ Certification for the Blind Spot Monitor LC200_OM_OM60Q26U_(U)
Page 352 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. LC200_OM_OM60Q26U_(U)
Page 353: Bsm Function
4-5. Using the driving support systems BSM function The BSM function uses radar sensors to detect the following vehicles traveling in adjacent lanes and advises the driver of the presence of such vehicles via the indicators on the outside rear view mirrors. Vehicles that are traveling in areas that are not visible using the out- side rear view mirrors (the blind spots) Vehicles that are approaching rapidly from behind in areas that are...
Page 354 4-5. Using the driving support systems BSM function detection areas The areas that vehicles can be detected in are outlined below. The range of each detection area is: Approximately 1.6 ft. (0.5 m) to 11.5 ft. (3.5 m) from either side of the vehicle : The area between the side of the vehicle and 1.6 ft.
Page 355 4-5. Using the driving support systems ■ The BSM function is operational when The BSM function is operational when all of the following conditions are met: ● The BSM function is on. ● The shift lever is in a position other than R. ●...
Page 356 4-5. Using the driving support systems ■ Conditions under which the BSM function may not function correctly ● The BSM function may not detect vehicles correctly in the following situa- tions: • When the sensor is misaligned due to a strong impact to the sensor or its surrounding area •...
Page 357: Rcta Function
4-5. Using the driving support systems RCTA function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 358 4-5. Using the driving support systems ■ RCTA icon display When a vehicle approaching from the right or left at the rear of the vehicle is detected, the following will be displayed on the monitor screen Display Content A vehicle is approaching from the left at the rear of the vehicle A vehicle is approaching from the right at the rear of the vehicle...
Page 359 4-5. Using the driving support systems The RCTA function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 360 4-5. Using the driving support systems ■ Conditions under which the RCTA function will not detect a vehicle The RCTA function is not designed to detect the following types of vehicles and/or objects: ● Vehicles approaching from directly behind ● Vehicles backing up in a parking space next to your vehicle ●...
Page 361 4-5. Using the driving support systems ■ Conditions under which the RCTA function may not function correctly ● The RCTA function may not detect vehicles correctly in the following situa- tions: • When the sensor is misaligned due to a strong impact to the sensor or its surrounding area •...
Page 362 4-5. Using the driving support systems ● Instances of the RCTA function unnecessarily detecting a vehicle and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
Page 363: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 364 4-5. Using the driving support systems ◆ VGRS (Variable Gear Ratio Steering) Helps to adjust the wheel turning angle in accordance with the vehicle speed and steering wheel movement. ◆ Trailer Sway Control Helps the driver to control trailer sway by selectively applying brake pres- sure for individual wheels and reducing engine torque when trailer sway is detected.
Page 365 When the message is displayed on the multi-information display show- ing that TRAC has been disabled even if the VSC OFF switch has not been pressed Active TRAC, hill-start assist control, Crawl Control cannot be operated. Con- tact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 366 4-5. Using the driving support systems ■ Automatic reactivation of Active TRAC, VSC and Trailer Sway Control Turning the engine switch off after turning off the Active TRAC and VSC sys- tems will automatically re-enable them. ■ Automatic Active TRAC reactivation If only the Active TRAC system is turned off, the Active TRAC system will turn on when vehicle speed increases.
Page 367 4-5. Using the driving support systems WARNING Any of the following conditions may result in an accident which could cause death or serious injury: ■ The Multi Terrain ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road).
Page 368 The Multi Terrain ABS, Active TRAC, VSC and Trailer Sway Control will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 369 KDSS In the following situations, there is the possibility that a system malfunction has occurred, and drive comfort and the vehicle’s ability to travel on poor road surfaces may be reduced. Take the vehicle to your Toyota dealer immediately. ●...
Page 370: 4-6. Driving Tips
4-6. Driving tips Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications. Off-road vehicle features ●...
Page 371 4-6. Driving tips WARNING ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 372 4-6. Driving tips Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the clo- sure of areas to off-road vehicles: ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 373 4-6. Driving tips WARNING ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death, seri- ous injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 374 4-6. Driving tips NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
Page 375: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 376 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Use the correct tire chain size when mounting the snow chains.
Page 377 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 378 4-6. Driving tips LC200_OM_OM60Q26U_(U)
Page 379 Interior features 5-1. Using the air conditioning 5-3. Using the storage features system and defogger List of storage features ..402 • Glove box...... 403 Front automatic air conditioning system ..380 • Console box....404 • Overhead console..405 Rear air conditioning •...
Page 380: Using The Air Conditioning
5-1. Using the air conditioning system and defogger Front automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Press to display the air conditioning control screen. Control panel ■ Adjusting the temperature setting Press to increase the temperature and to decrease the...
Page 381 5-1. Using the air conditioning system and defogger ■ Changing the air flow mode Press The air flow mode switches each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air flows to the feet and the windshield defogger oper-...
Page 382 5-1. Using the air conditioning system and defogger Option control screen Select to set cooling and dehu- midification function on/off Adjust temperature driver, front passenger and rear seats separately (Individual mode) (→P. 383) Prevent ice from building up on windshield wiper blades (if equipped) (→P.
Page 383 5-1. Using the air conditioning system and defogger Adjusting the temperature for driver and passenger seats sepa- rately (Individual mode) To turn on the individual mode, perform any of the following proce- dures: ● Press “4-ZONE” on the option control screen. ●...
Page 384 5-1. Using the air conditioning system and defogger Changing the rear seat settings Press on the control screen to display the rear air con- ditioning control screen. Adjust the temperature set- ting (left-hand rear seat) Adjust the fan speed setting Adjust the temperature set- ting (right-hand rear seat) Select to set automatic mode...
Page 385 5-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between (recirculated air mode) and (outside air mode) modes each time the button is pressed. ■ Defogging the windshield Defoggers are used to defog the windshield and front side win- dows.
Page 386 5-1. Using the air conditioning system and defogger ■ Defogging the rear window and outside rear view mirrors Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. Press Press the switch again to turn the defogger off.
Page 387 5-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume changes according selected air flow mode. ■ Adjusting the position of and opening and closing the air out- lets ...
Page 388 5-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 389 5-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 390 5-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 391: Rear Air Conditioning System
5-1. Using the air conditioning system and defogger Rear air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. ■ Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on The temperature for the right-hand and left-hand seats can be set sepa- rately.
Page 392 5-1. Using the air conditioning system and defogger ■ Changing the air flow mode Press The air flow mode switches each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet LC200_OM_OM60Q26U_(U)
Page 393 5-1. Using the air conditioning system and defogger Air conditioning controls ■ Using the automatic mode Press Adjust the temperature setting. To stop the operation, press ■ If the system is operated manually in automatic mode If the fan speed setting or air flow modes are operated, the auto- matic mode indicator goes off.
Page 394 5-1. Using the air conditioning system and defogger NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is not running. LC200_OM_OM60Q26U_(U)
Page 395: Heated Steering Wheel /Seat Heaters/Seat Ventilators
5-1. Using the air conditioning system and defogger ∗ Heated steering wheel /seat heaters/seat ventilators Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats. Seat ventilators maintain good airflow by blowing air from the seats. WARNING ●...
Page 396 If the indicator light still flashes, a malfunction may be occurring. Turn the heated steering wheel off and have the vehicle inspected by your Toyota dealer. Front seat heaters and ventilators Seat heater switches...
Page 397 The engine switch is in IGNITION ON mode. ■ Replacing the air filters Filters are installed in the seat ventilators. For replacement of the filters, con- tact your Toyota dealer. ■ Customization The automatic mode settings for the seat heaters and ventilators can be changed.
Page 398 5-1. Using the air conditioning system and defogger Second outboard seat heaters (if equipped) For left-hand second seat For right-hand second seat High heating temperature Low heating temperature To turn on the seat heater, press “HI” or “LO”. ■ The seat heaters can be used when The engine switch is in IGNITION ON mode.
Page 399: Using The Interior Lights
5-2. Using the interior lights Interior lights list Front interior lights (→P. 400) Footwell lights Front personal lights (→P. 401) Scuff lights Rear interior lights (→P. 400) Engine switch light Rear personal lights (→P. 401) Door courtesy lights Inside door handle lights Door trim lights LC200_OM_OM60Q26U_(U)
Page 400: Interior Lights
5-2. Using the interior lights Interior lights  Front Door position on/off Turns the light on/off  Rear On/door position on LC200_OM_OM60Q26U_(U)
Page 401: Personal Lights
5-2. Using the interior lights Personal lights  Front Turns the light on/off  Rear Turns the light on/off ■ Illuminated entry system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed.
Page 402: 5-3. Using The Storage Features
5-3. Using the storage features List of storage features Card holders (→P. 409) Console box (→P. 404) Cool box (if equipped) Overhead console (→P. 405) (→P. 412) Glove box (→P. 403) Cup holders (→P. 406) Bottle holders (→P. 408) Auxiliary box (if equipped) Door pockets (→P.
Page 403: Glove Box
5-3. Using the storage features Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical key ■ Glove box light The glove box light turns on when the tail lights are on. ■ Removing the separate tray Pull out the separate tray while releasing the clips.
Page 404: Console Box
5-3. Using the storage features Console box Your vehicle is equipped with either a lower console box or cool box. For vehicles with the cool box, refer to page 412.  Upper console box Press the tab to open.  Lower console box (if equipped) Lift the lever to open.
Page 405: Overhead Console
5-3. Using the storage features Overhead console Press the button. WARNING ■ Items unsuitable for storing Do not store items heavier than 0.4 lb. (0.2 kg). Doing so may cause the overhead console to open and the items inside may fall out, resulting in an accident. ■...
Page 406: Cup Holders
5-3. Using the storage features Cup holders  Front seats  Second seats Press down and release the lid. To open, pull down the armrest, press the button and release the You can adjust or remove the sep- rear cup holder on the armrest. arator inside.
Page 407 5-3. Using the storage features ■ Removing the cup holder insert (front cup holders) Pull up the insert. Cup holder insert may be removed for cleaning. WARNING ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Even with the lid is closed, items must not be stored in the cup holders.
Page 408: Bottle Holders
5-3. Using the storage features Bottle holders  Front seats  Second seats NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
Page 409: Card Holders
5-3. Using the storage features Card holders  Sun visor  Instrument panel Auxiliary boxes Your vehicle is equipped with either a front auxiliary box or wireless charger. For vehicles with wireless charger, refer to page 418.  Front (if equipped) ...
Page 410: Luggage Compartment Features
5-3. Using the storage features Luggage compartment features Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items. Cargo net hooks To hang the cargo net, use the cargo net hooks and rear tie-down hooks.
Page 411 5-3. Using the storage features First-aid kit holder Remove the cover. Hold the first- aid kit with a band. The first-aid kit itself is not included as an original equipment. WARNING ● To avoid injury, always return the cargo hooks to their positions when not in use.
Page 412: Other Interior Features
5-4. Using the other interior features Other interior features Cool box (if equipped) While the engine is running, the cool box, which is cooled by the air conditioning, can be used. Lift the lid while pulling up the lower lever to release the lock. Turns the cool box on/off When on, the indicator light comes If the front air conditioning system...
Page 413 5-4. Using the other interior features WARNING Keep the cool box closed while driving. Injuries may result in the event of sudden braking, sudden swerving or an accident. NOTICE To prevent battery discharge, do not leave the cool box on longer than nec- essary when the engine is not running.
Page 414: Sun Visors
5-4. Using the other interior features Sun visors  Main sun visor To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 415: Clock
The outside temperature is displayed when The engine switch is in IGNITION ON mode. ■ When --- is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 416: Power Outlets
5-4. Using the other interior features Power outlets The power outlet can be used for the following components: 12 V DC: Accessories that run on less than 10 A 120 V AC: Accessories that use less than 100 W ■ Center of console Front (12 V DC) ...
Page 417 5-4. Using the other interior features ■ Luggage compartment (120 V AC) ■ The power outlet can be used when 12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode. 120 V AC: The engine switch is in IGNITION ON mode. NOTICE ■...
Page 418: Wireless Charger
5-4. Using the other interior features Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smart phones and mobile batteries, etc., on the charge area.
Page 419 5-4. Using the other interior features ■ Using the wireless charger Press the lid to open. Press power supply switch of the wireless char- ger. Switches on and off with each press of the power supply switch. When turned on, the operation indicator light (green) comes on.
Page 420 Handle the error based on the following table. Operation indicator Suspected causes Handling method light Flashing repeatedly Vehicle to charger com- Contact your Toyota once every second munication failure. dealer. (Orange) Remove foreign A foreign substance is substance...
Page 421 5-4. Using the other interior features ■ The wireless charger can be operated when The engine switch is in ACCESSORY or IGNITION ON mode. ■ Usable portable devices Qi standard wireless charge standard can be used on compatible devices. However, not all Qi standard devices and compatibility are guaranteed. Starting with mobile phones and smart phones, it is aimed for low power elec- trically supplied portable devices of no more than 5W.
Page 422 5-4. Using the other interior features ■ Certification for the wireless charger LC200_OM_OM60Q26U_(U)
Page 423 5-4. Using the other interior features LC200_OM_OM60Q26U_(U)
Page 424 5-4. Using the other interior features WARNING ■ Caution while driving When charging a portable device, for safety reasons, the driver should not operate the portable device while driving. ■ Caution regarding interference with electronic devices People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the usage of the wireless charger.
Page 425 When other wireless keys (that emit radio waves) are being used nearby In addition, excluding the above-mentioned, when the charger does not per- form normally or the operation indicator light is flashing continuously, it is considered that the wireless charger is malfunctioning. Contact your Toyota dealer. ■...
Page 426: Armrest
5-4. Using the other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage, do not apply too much load on the armrest. Coat hooks The coat hooks are provided with the second seat assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook.
Page 427: Assist Grips
5-4. Using the other interior features Assist grips An assist grip (Type A) can be used to support your body while sitting on the seat. An assist grip (Type B) can be used when getting in or out of the vehi- cle and others.
Page 428: Garage Door Opener
5-4. Using the other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® Programming the HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 429 5-4. Using the other interior features ® ■ Programming HomeLink Steps through must be performed within 60 seconds, other- wise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 430 5-4. Using the other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● Indicator light illuminates: Programming of a fixed code device has completed. The garage door or other device should oper- ®...
Page 431 5-4. Using the other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor operates when the ®...
Page 432 5-4. Using the other interior features ® ■ Reprogramming a single HomeLink button When the following procedure is performed, buttons which already have devices registered to them can be overwritten: ® With one hand, press and hold the desired HomeLink button.
Page 433 Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the  HomeLink ■ Certification for the garage door opener ■ When support is necessary Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. LC200_OM_OM60Q26U_(U)
Page 434 5-4. Using the other interior features WARNING ■ When programming a garage door or other remote control devices The garage door or other devices may operate, so ensure people and objects are out of danger to prevent potential harm. ■ Conforming to federal safety standards ...
Page 435: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 436 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” button in your vehicle for further subscription details. ■...
Page 437 ● Green indicator light on = Active service ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active LC200_OM_OM60Q26U_(U)
Page 438 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 439 5-4. Using the other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 440 5-4. Using the other interior features ■ Certification for Safety Connect LC200_OM_OM60Q26U_(U)
Page 441 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..442 Cleaning and protecting the vehicle interior... 445 6-2. Maintenance Maintenance requirements ....448 General maintenance..451 Emission inspection and maintenance (I/M) programs......454 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 442: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 443 ■ Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 444 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 445: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 446 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 447 ■ When cleaning the inside of the windshield (vehicles with Toyota Safety Sense P) Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
Page 448: 6-2. Maintenance
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 449: Maintenance
■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 450 6-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 451: General Maintenance
“Warranty and Service Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 452 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmission • When parked on a slope and the shift lever is “Park” mechanism in P, is the vehicle securely stopped? •...
Page 453 6-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 454: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 455: Do-It-Yourself Maintenance Do-It-Yourself Service
Brake fluid level • Rag or paper towel (→P. 464) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology.
Page 456: Do-It-Yourself Maintenance
6-3. Do-it-yourself maintenance Items Parts and tools • Water or washer fluid containing antifreeze (for win- Washer fluid ter use) (→P. 470) • Funnel (used only for adding water or washer fluid) WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized.
Page 457: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Lift the hood catch and lift the hood. WARNING ■ Pre-driving check Check that the hood is fully closed and locked.
Page 458: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Power steering fluid reservoir Brake fluid reservoir (→P. 466) (→P. 464) Engine oil level dipstick Fuse box (→P. 489) (→P. 460) Washer fluid tank (→P. 470) Engine coolant reservoir Battery (→P. 467) (→P. 463) Condenser (→P.
Page 459 6-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure the cover is securely installed in its original position. LC200_OM_OM60Q26U_(U)
Page 460 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 461 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 462 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 463 “Toyota Super Long Life Coolant” is a mixture of 50 % coolant and 50 % deionized water. (Minimum temperature: -31°F [-35°C]) For more details about engine coolant, contact your Toyota dealer.
Page 464 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. WARNING ■...
Page 465 6-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking efficiency. Use only newly opened brake fluid. WARNING ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
Page 466 6-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when hot) Add fluid (when hot) Full (when cold) Add fluid (when cold) Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
Page 467 6-3. Do-it-yourself maintenance WARNING ■ When checking the reservoir Take care as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 468 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts at both methods, con- tact your Toyota dealer. WARNING ■...
Page 469 6-3. Do-it-yourself maintenance WARNING ■ How to recharge the battery Only perform a slow charge (5A or less). The battery may explode if charged at a quicker rate. ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention.
Page 470 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. WARNING ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 471: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the same interval as tire inspection. Front Do not fail to initialize the tire pressure warning system after tire rotation.
Page 472 6-3. Do-it-yourself maintenance Tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire infla- tion pressure before serious problems arise. ● If the tire pressure drops below a predetermined level, the driver is warned by a screen display and a warning light.
Page 473 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 474 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 475 6-3. Do-it-yourself maintenance ■ Tire types ● Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 476 ● In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equip- ment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 477 After performing initialization, the tire pressure warning light blinks for 1 minute then stays on after driving for about 20 minutes. If the inflation pressure of each tire is still not displayed, have the vehicle inspected by your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 478 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 479 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 480: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 566) LC200_OM_OM60Q26U_(U)
Page 481 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 482 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours and has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 483: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 484 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 485: Air Conditioning Filter
Hold the air gun 2 in. (5 cm) from the filter and blow for approxi- mately minutes (500 kPa, 5.0 kgf/cm or bar). If it is not available, have the filter cleaned by your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 486 6-3. Do-it-yourself maintenance Replacement method Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the fil- ter should be pointing up. ITY43C090 ■ Checking interval Inspect, clean and replace the air conditioning filter according to the maintenance schedule.
Page 487: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small Phillips-head screwdriver ● Lithium battery (CR2032) Replacing the battery Take out the mechanical key. Remove the cover.
Page 488 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 489: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. Open the fuse box cover. ...
Page 490 6-3. Do-it-yourself maintenance  Passenger’s side instrument panel Remove the cover. Remove the lid. Remove the fuse with the pull-out tool. Only type A fuse can be removed using the pull-out tool. LC200_OM_OM60Q26U_(U)
Page 491 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C and D: Contact your Toyota dealer.  Type A ...
Page 492 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 495) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 493: Headlight Aim
6-3. Do-it-yourself maintenance Headlight aim Vertical movement adjusting bolts Adjustment bolt A (Vertical adjustment) Adjustment bolt B (Horizontal adjustment) Before checking the headlight aim Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed. Park the vehicle on level ground.
Page 494 Turn bolt B the same number of turns and in the same direction as step If the headlight cannot be adjusted using this procedure, take the vehi- cle to your Toyota dealer to adjust the headlight aim. LC200_OM_OM60Q26U_(U)
Page 495: Light Bulbs
Light bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 496 6-3. Do-it-yourself maintenance ■ Rear Rear turn signal light License plate lights Back-up light LC200_OM_OM60Q26U_(U)
Page 497 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Front side marker light left side only: Remove the securing clip and move the washer fluid filler opening. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60Q26U_(U)
Page 498 6-3. Do-it-yourself maintenance ■ Front turn signal lights left side only: Remove the securing clip and move the washer fluid filler opening. To allow enough working space, remove the bulb base of the front side marker light. Wrap the removed bulb base with cloth to prevent damage to the bulb base.
Page 499 6-3. Do-it-yourself maintenance Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60Q26U_(U)
Page 500 6-3. Do-it-yourself maintenance ■ Back-up light Open the back door and remove the nuts and lamp assembly. Unplug the connector while pressing the lock release. Remove the cover. Unclip the connector wire and turn the bulb bases counterclockwise. LC200_OM_OM60Q26U_(U)
Page 501 6-3. Do-it-yourself maintenance Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60Q26U_(U)
Page 502 6-3. Do-it-yourself maintenance ■ Rear turn signal lights Open the back door and attach protective tape under the light unit. (Use masking tape. Do not use any duct tape, as duct tape may leave markings.) Remove the cover. Remove the 2 bolts and lamp assembly.
Page 503 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb bases counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC200_OM_OM60Q26U_(U)
Page 504 6-3. Do-it-yourself maintenance ■ License plate light Open the back door and remove the license plate light unit. Turn the bulb base counter- clockwise. ITY43C067 Remove the light bulb. ITY43C068 When installing, reverse the steps listed. LC200_OM_OM60Q26U_(U)
Page 505 ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water are built up on the inside of the lens.
Page 506 6-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 507: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..508 If your vehicle has to be stopped in an emergency ....509 7-2. Steps to take in an emergency If your vehicle needs to be towed ..... 510 If you think something is wrong ......
Page 508: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 509: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 510: If Your Vehicle Needs
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 511 7-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck  From the front  From the rear Use a towing dolly under the rear Use a towing dolly under the wheels.
Page 512 7-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 513 7-2. Steps to take in an emergency Emergency towing procedure Securely attach cables chains to the towing hooks. Take care not to damage the vehi- cle body. Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to IGNITION ON mode.
Page 514 7-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with all four wheels raised off the ground. If the vehicle is towed with the tires contacting the ground, the drivetrain or related parts may be damaged, the vehicle may fly off...
Page 515 7-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck ● Do not tow the vehicle from the rear when the engine switch is off. The steering lock mechanism is not strong enough to hold the front wheels straight.
Page 516: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 517: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 518: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or • The brake system is malfunctioning. → Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system...
Page 519 ABS warning light Indicates a malfunction in: • The Multi Terrain ABS; or • The brake assist system → Have the vehicle inspected by your Toyota dealer immediately. Slip indicator Indicates a malfunction in: or • The VSC (Vehicle Stability Control) system;...
Page 520 • The tire pressure warning system is malfunctioning → Immediately stop the vehicle in a safe place. Handling method (→P. 523) Automatic headlight leveling system warning light Indicates a malfunction in the automatic headlight leveling system → Have the vehicle inspected by your Toyota dealer immediately. LC200_OM_OM60Q26U_(U)
Page 521 7-2. Steps to take in an emergency : Brake system warning buzzer: The buzzer sounds to indicate that the brake fluid level is low (with the vehicle reached a speed of 3 mph [5 km/h]). : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]).
Page 522 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 523 (→P. 472) If the warning light does not turn off even after several minutes have elapsed, have the vehicle inspected by your Toyota dealer immediately.  If the tire pressure warning light flashes for 1 minute then stay on There may be a malfunction in the tire pressure warning system.
Page 524 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 525 7-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 526 7-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly. LC200_OM_OM60Q26U_(U)
Page 527: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the mes- sage on the multi-information dis- play. If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 528 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 529 If “See Owner’s Manual” is shown ● If “Smart key System Malfunction” is shown, this may be a malfunction. Immediately have the vehicle inspected by your Toyota dealer. ● If “Transmission Fluid Temp High” is shown, it indicates that the automatic transmission fluid temperature is too high.
Page 530 7-2. Steps to take in an emergency ■ If “Forward Camera System Unavailable” or “Forward Camera System Unavailable Clean Windshield” is displayed. (→P. 253, 518) (if equipped) The following systems may be suspended until the problem shown in the message is resolved. ●...
Page 531 Indicates that the engine oil should be changed. (The indicator will not work properly unless the message has been reset.) Check and change the engine oil, and oil filter by your Toyota dealer. After changing the engine oil, the message should be reset. (→P. 460) ■...
Page 532: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: →P. 471 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 533 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Jack Tool box Spare tire LC200_OM_OM60Q26U_(U)
Page 534 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 535 7-2. Steps to take in an emergency Taking out the jack Remove the cover. Unhook the rubber band and take out the jack. Loosen Tighten Loosen and remove the jack. Taking out the tool box Remove the cover. IN82LA044 Take out the tool box. LC200_OM_OM60Q26U_(U)
Page 536 7-2. Steps to take in an emergency Taking out the spare tire Assembling the jack handle. Remove the jack handle and the jack handle extension bar from the tool box and assemble by following these steps. Loosen the screw using a screwdriver.
Page 537 7-2. Steps to take in an emergency Insert the jack handle extension into the lowering screw. Lower Raise Place a rag under the jack handle extension to protect the back door. Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket.
Page 538 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock position Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire In front of the front right-hand side Left-hand side tire Rear...
Page 539 7-2. Steps to take in an emergency Assembling the jack handle. Remove the jack handle, jack extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolt and the screw using either the jack handle end or a screwdriver.
Page 540 7-2. Steps to take in an emergency Position the jack at the jack points as shown. Front Under the chassis frame side rail Rear Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 541 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 542 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 543 7-2. Steps to take in an emergency Reinstall the wheel ornament. Remove the center wheel orna- ment from the flat tire by pushing from the reverse side, and rein- stall it. WARNING ■ Stowing the flat tire Failure to follow steps listed under stowing the tire may result in damage to the spare tire carrier and loss of the tire, which could result in death or serious injury.
Page 544 7-2. Steps to take in an emergency Install holding bracket, inserting the claw into the wheel lug nut hole. Turn the jack han- dle extension clockwise to take up slack in the chain. Then, check to ensure the claw is in the wheel lug nut hole and the incorrect holding bracket is centered in the...
Page 545 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 546: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (→P. 199), consider each of the follow- ing points: The engine will not start even when the starter motor operates normally.
Page 547 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 551) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 548: If The Electronic Key Does Not Operate Properly
Unlocks the doors Turning the key rearward unlocks the driver’s door. Turning the key once again unlocks the other doors. Opens the windows and moon roof (turn and hold) : These settings must be customized at your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 549 Firmly depress the brake pedal and check that is shown on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.
Page 550 7-2. Steps to take in an emergency WARNING ■ When using the mechanical key and operating the power windows or moon roof Operate the power window or moon roof after checking to make sure that there is no possibility of any passenger having any of their body parts caught in the window or moon roof.
Page 551: If The Vehicle Battery Is Discharged
You can also call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12 volt battery, you can jump start your Toyota following the steps below.
Page 552 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were connected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 553 7-2. Steps to take in an emergency WARNING ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 554: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. LC200_OM_OM60Q26U_(U)
Page 555 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 556 7-2. Steps to take in an emergency WARNING ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 557: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the rear wheels.
Page 558 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 559 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..560 Fuel information ....568 Tire information ....571 8-2. Customization Customizable features ..582 8-3. Initialization Items to initialize ....593 LC200_OM_OM60Q26U_(U)
Page 560: Specifications Maintenance Data
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 196.5 in. (4990 mm) Overall width 78.0 in. (1980 mm) 74.0 in. (1880 mm) Overall height 76.2 in. (1935 mm) Wheelbase 112.2 in. (2850 mm) Front 65.0 in. (1650 mm) Tread Rear 64.8 in.
Page 561 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 562 8-1. Specifications Engine Model 5.7L V8 (3UR-FE) Type 8-cylinder V type, 4-cycle, gasoline 3.70 × 4.02 in. (94.0 × 102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Valve clearance Automatic adjustment Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane rating 87 (Research octane number 91) or higher...
Page 563 8-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toy- ota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 564 8-1. Specifications Cooling system Capacity 17.1 qt. (16.2 L, 14.3 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol- Coolant type based non-silicate, non-amine, non- nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 565 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 566 8-1. Specifications Brakes Pedal clearance 4.49 in. (114 mm) Min. ⎯ 0.24 in. (1.0 ⎯ 6.0 mm) Pedal free play 0.04 Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear 0.04 in. (1.0 mm) limit ⎯ 7 clicks Parking brake adjustment Fluid type SAE J1703 or FMVSS No.
Page 567 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Front turn signal lights 7444NA ⎯ Front side marker lights ⎯ Exterior Rear turn signal lights Back-up lights ⎯ License plate lights ⎯ Interior Vanity lights A: Wedge base bulbs B: Double end bulbs LC200_OM_OM60Q26U_(U)
Page 568: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 569 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 570 8-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 571: Tire Information
8-1. Specifications Tire information Typical tire symbols Tire size (→P. 573) Summer tires or all season tires (→P. 475) An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
Page 572 8-1. Specifications Typical DOT and Tire Identification Number (TIN)  Type A  Type B DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer’s code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 573 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 574 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer LC200_OM_OM60Q26U_(U)
Page 575 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 576 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 577 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 578 8-1. Specifications Tire related term Meaning A metal support for a tire or a tire and tube assembly upon which the tire beads are seated Rim diameter Nominal diameter of the bead seat (Wheel diameter) Rim size designation Rim diameter and width The industry manufacturer’s designation for a Rim type designation rim by style or code...
Page 579 8-1. Specifications Tire related term Meaning The parting of cords from adjacent rubber Cord separation compounds Any parting within the tread, sidewall, or inner- Cracking liner of the tire extending to cord material A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the tire is designed to fit on the underside of...
Page 580 8-1. Specifications Tire related term Meaning Any parting at any junction of tread, sidewall, Open splice or innerliner that extends to cord material Outer diameter The overall diameter of an inflated new tire The linear distance between the exteriors of the sidewalls of an inflated tire, including ele- Overall width vations due to labeling, decorations, or protec-...
Page 581 8-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in ASTM F-1805-00, Standard Test Method for Snow tire Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and...
Page 582: 8-2. Customization
The settings of these fea- tures can be changed by using the navigation system, the multi- information display, or at your Toyota dealer. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in P and the parking brake set.
Page 583 8-2. Customization Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using the navigation system Settings that can be changed using the multi-information display Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, –...
Page 584 8-2. Customization ■ Smart key system (→P. 126) and wireless remote control (→P. 102) Customized Function Default setting setting Operation signal (Emer- — gency flashers) Time elapsed before automatic door lock 30 seconds function is activated if 60 seconds — door is not opened after 120 seconds being unlocked...
Page 585 8-2. Customization ■ Power back door (→P. 114) Customized Function Default setting setting Power back door switch Push and hold One short push — — operation Back door opener switch automatic open — — function Operation signal — — On (Push Wireless remote control twice) linked operation (one...
Page 586 8-2. Customization ■ Moon roof (→P. 161) Customized Function Default setting setting Mechanical key linked — — operation (open) Mechanical key linked — — operation (close) Linked operation components when door Slide only Tilt only — — key is used Wireless remote control —...
Page 587 8-2. Customization ■ Illumination (→P. 399) Customized Function Default setting setting Interior lights illumina- — — tion control Time period before the 15 seconds 7.5 seconds — interior lights turn off 30 seconds Operation after engine switch is turned — —...
Page 588 8-2. Customization ■ Automatic light control system (→P. 213) Customized Function Default setting setting Light sensor sensitivity Standard -2 to 2 — Daytime running light — system Time elapsed before headlights automati- 30 seconds 60 seconds — cally turn off after doors are closed 90 seconds Welcome lighting illumi-...
Page 589 8-2. Customization ■ Outside rear view mirrors (→P. 153) Customized Function Default setting setting Linked to lock- Automatic folding/ ing/unlocking of — — Linked to engine extending operation the doors switch operation Linked mirror function — — when reversing ■ Front seat heaters and ventilators (→P.
Page 590 8-2. Customization ■ Multi-information display (→P. 89) Default Customized Function setting setting French Language English — Spanish miles (MPG Imperial) miles Units — (MPG US) km (L/100 km) km (km/L) Eco Driving Indicator Light — – Drive Desired status switch settings —...
Page 591 8-2. Customization ■ LDA (Lane Departure Alert) (→P. 254) Default Customized Function setting setting Alert sensitivity Standard High — — Vehicle sway warning — — Vehicle sway warning Standard — — sensitivity High If equipped ■ BSM (Blind Spot Monitor) (→P.
Page 592 8-2. Customization ■ Vehicle customization ● If the smart key system is turned off, unlock door cannot be selected. ● If the doors are not opened after unlocking and are then automatically re- locked, a signal will be given if Operation signal (Emergency flashers) or Operation signal (Buzzer) are set to on.
Page 593: Initialization
8-3. Initialization Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- After the maintenance is per- P.
Page 594 8-3. Initialization LC200_OM_OM60Q26U_(U)
Page 595: For U.s. Owners
For U.S. owners Reporting safety defects for U.S. owners......596 LC200_OM_OM60Q26U_(U)
Page 596: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 597 Index What to do if... (Troubleshooting) ....598 Alphabetical index ..... 602 For vehicles with a navigation system or a multimedia system, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Audio/video system •...
Page 598: What To Do If
Toyota dealer. (→P. 103) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (→P. 105) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (→P. 487) ●...
Page 599 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the brake pedal? (→P. 199) ● Is the shift lever in P? (→P. 201) ●...
Page 600 What to do if... (Troubleshooting) The engine switch is turned off automatically ● The auto power off function will be operated if the vehicle is left in ACCES- SORY or IGNITION ON mode (the engine is not running) for a period of time.
Page 601 What to do if... (Troubleshooting) A warning buzzer sounds when leaving the vehicle ● Is the electronic key left inside the vehicle or the moon roof opened? Check the message on the multi-information display. (→P. 527) A warning light turns on or a warning message is displayed ●...
Page 602: Alphabetical Index
Alphabetical index Alphabetical index Airbags ........38 Airbag operating conditions ..46 A/C ........380, 391 Airbag precautions for Air conditioning filter ..... 485 your child......41 Changing the rear seat Airbag warning light ....518 settings ....... 384 Correct driving posture ... 28 Front automatic air Curtain shield airbag conditioning system....
Page 603 Alphabetical index Anti-lock brake system Automatic transmission ..205 (ABS) ........363 2nd start switch..... 206 Function ........ 363 Downshift restriction Warning light......519 warning buzzer....209 Approach warning If the shift lever cannot be Dynamic radar cruise shifted from P ..... 209 control.........
Page 604 Alphabetical index ® Bluetooth audio Cargo capacity......181 ® Bluetooth phone Cargo hooks ......410 Bottle holders ......408 CD player Brake Chains ........376 Fluid ........566 Child restraint system....57 Parking brake......212 Booster seat definition .... 58 Warning light......
Page 605 Alphabetical index Child safety ........ 56 Crawl Control......290 Airbag precautions....41 Cruise control Back door precautions ..120 Cruise control ....... 275 Battery precautions..468, 553 Dynamic radar cruise Child-protectors ....109 control ........ 263 Child restraint system ..... 57 Cup holders ......
Page 606 Alphabetical index Do-it-yourself maintenance ..455 Door courtesy lights Eco Driving Indicator ....96 Location ........ 399 EDR (Event data recorder)..10 Doors Electronic key ......102 Automatic door locking and Battery-saving function ..128 unlocking system....110 If the electronic key does Back door......
Page 607 Alphabetical index Emergency flashers ....508 Engine First-aid kit holder ....411 Accessory mode ....200 Flat tire ........532 Air cleaner......456 Floor mats ........26 Compartment ......458 Fluid Engine switch......199 Automatic transmission ..565 Exhaust gas precautions ..72 Brake ........
Page 608 Alphabetical index Front passenger occupant Fuel consumption classification system ....50 information ......98 Front passenger’s seat Fuel filler door ......230 belt reminder light....520 Opener........232 Front seats ....... 133 Refueling ......230 Adjustment......133 Fuel pump shut off system..517 Cleaning........
Page 609 Alphabetical index Heaters Initialization Front automatic air Items to initialize ....593 conditioning system.... 380 Maintenance ......449 Outside rear view mirrors..386 Power windows..... 159 Seat heaters ......396 Tire pressure warning High mounted stoplight system........ 473 Replacing......505 Inside door handle light..
Page 610 Alphabetical index Light Automatic High Beam KDSS (Kinetic Dynamic system........ 217 Suspension System)..... 363 Door courtesy lights....399 Keyless entry Engine switch light Smart key system ....126 (ignition switch light)... 399 Wireless remote control ..102 Fog light switch..... 222 Keys ..........
Page 611 Alphabetical index Meter ........... 85 Indicators ........ 80 Navigation system Instrument panel light Noise from under vehicle ... 8 control........86 Meters........85 Multi-information display ..89 Odometer ........85 Warning lights ....... 518 Off road precautions ....370 Warning messages ....527 Micro dust and pollen filter..
Page 612 Alphabetical index Panic mode ......103 Radar cruise control Parking assist sensors (dynamic radar cruise (intuitive parking assist)..278 control)........263 Parking brake......212 Radiator........464 Operation ......212 Radio Parking brake engaged RCTA (Rear Cross Traffic warning buzzer ....212 Alert)........
Page 613 Alphabetical index Replacing Seats......... 133, 135 Electronic key battery ... 487 Adjustment....133, 135 Fuses ........489 Adjustment Light bulbs ......495 precautions....134, 141 Tires........532 Armrest ......... 426 Reporting safety defects Child seats/child restraint for U.S. owners...... 596 system installation....
Page 614 Alphabetical index Shift lever Stop/tail lights Automatic transmission..205 Replacing light bulbs .... 505 If the shift lever cannot be Storage feature ......402 shifted from P ..... 209 Stuck Shift lock system ..... 209 If the vehicle becomes Side airbags ....... 38 stuck........
Page 615 Alphabetical index Meter control switches .... 91 Moon roof switches....161 Tachometer ........ 85 Outside rear view mirror Tail lights........213 switches......153 Light switch......213 Personal light switch ..... 401 Replacing light bulbs .... 505 Power back door switch..115 Talk switch Power door lock switch ..
Page 616 (VSC) ........363 Trailer Sway Control ..... 364 Ventilators Trailer towing ......182 (seat ventilators) ....396 Toyota Safety Sense P .... 234 VSC (Vehicle Stability TRAC (Traction Control) ..363 Control) ........363 Trailer Sway Control....364 Trailer towing ......182 Transmission Automatic transmission..
Page 617 Alphabetical index Warning messages....527 Warning reflector holder..410 Warning buzzers...... 518 Washer ......223, 227 Approach warning....270 Checking....... 470 Brake system ......518 Preparing and checking Downshifting ......209 before winter ...... 375 Driver’s seat belt Switch ......223, 227 reminder ......
Page 618 Alphabetical index LC200_OM_OM60Q26U_(U)
Page 619 Alphabetical index LC200_OM_OM60Q26U_(U)
Page 620 Cold tire inflation P. 566 pressure Engine oil capacity (Drain and refill — With filter 7.9 qt. (7.5 L, 6.6 Imp.qt.) reference) Without filter 7.5 qt. (7.1 L, 6.2 Imp.qt.) “Toyota Genuine Motor Oil” or equivalent Engine oil type P. 562 LC200_OM_OM60Q26U_(U)

Toyota Land Cruiser 200 2018 Manual

Quick Links

Related Manuals for Toyota Land Cruiser 200 2018

Summary of Contents for Toyota Land Cruiser 200 2018

Table of Contents
