- Page 1 CP 5623/CP 5624 Preface Description of the device SIMATIC NET Software installation Hardware installation PG/PC - PROFIBUS CP 5623/CP 5624 Configuration Technical specifications Operating Instructions Approvals Dimension drawing 12/2022 C79000-G8976-C281-06...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Preface
• Certificate of license Please check that the consignment you have received is complete. If it is not complete, please contact your supplier or your local Siemens office. Validity of this documentation These operating instructions are valid for the following products: •... - Page 4 → Entry list → Entry type "Manuals / Operating Instructions" Trademarks The following and possibly other names not identified by the registered trademark sign ® are registered trademarks of Siemens AG: HARDNET, SOFTNET, CP 5612, CP 5613, CP 5614, CP 5622 CP 5623/CP 5624...
- Page 5 Preface Industry Online Support In addition to the product documentation, you are supported by the comprehensive online information platform of Siemens Industry Online Support at the following Internet address: Link: (https://support.industry.siemens.com/cs/de/en/) Apart from news, there you will also find: • Project information: Manuals, FAQs, downloads, application examples etc.
- Page 6 Industrial Security RSS feed at: (https://www.siemens.com/cert) SIMATIC NET glossary The SIMATIC NET glossary describes terms that may be used in this document. You will find the SIMATIC NET glossary in the Siemens Industry Online Support at the following address: (http://support.automation.siemens.com/WW/view/en/50305045) Recycling and disposal The products are low in harmful substances, can be recycled and meet the requirements of the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
-
Page 7: Table Of Contents
Table of contents Preface ..............................3 Description of the device ........................9 Properties of the CP 5623 ..................... 9 Properties of the CP 5624 ....................11 PROFIBUS interface ......................12 Meaning of the LED display ....................14 Software installation ........................... 15 Installing the "SIMATIC NET PC Software"... - Page 8 Table of contents CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06...
-
Page 9: Description Of The Device
Description of the device Properties of the CP 5623 Properties The CP 5623 is a communications processor for connecting PCs or PGs to PROFIBUS and MPI networks. The essential properties are as follows: • Transmission speeds up to 12 Mbps. •... - Page 10 Description of the device 1.1 Properties of the CP 5623 Appearance The following graphic shows the CP 5623 communications processor: LEDs PROFIBUS interface PB1 (DP master or DP device) CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06...
-
Page 11: Properties Of The Cp 5624
Description of the device 1.2 Properties of the CP 5624 Properties of the CP 5624 Properties The CP 5624 is a communications processor for connecting PCs or PGs to PROFIBUS and MPI networks. In addition to the properties of the CP 5623, the CP 5624 also has the following features: •... -
Page 12: Profibus Interface
You will find information about the structure of a PROFIBUS network in the system manual "PROFIBUS Network Manual". The document is part of the Manual Collection. You will also find this on the Product Support pages under the following entry ID: 35222591 (https://support.industry.siemens.com/cs/ww/en/view/35222591) CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06... - Page 13 Description of the device 1.3 PROFIBUS interface PIN assignment The D-sub female connector has the following pin assignment: Short name Meaning Input/output Socket pin 1 is not connected. NC (M24) Socket pin 2 is not connected. With other MPI/DP components, the return line of the floating 24 V power supply may be via this pin.
-
Page 14: Meaning Of The Led Display
Description of the device 1.4 Meaning of the LED display Meaning of the LED display LED display The meaning of the LED display is as follows: Green and yellow LED Meaning Green on Shows the token rotation (in other words, normal operation) Green off Incorrect bus parameters, defective bus or CP not in operation Green flashing at one-second... -
Page 15: Software Installation
Install the software as described in the installation manual "SIMATIC NET PC Software". You will find this installation manual on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) You should also note the current information on the "SIMATIC NET PC software" on the Product Support pages: Support (https://support.industry.siemens.com/cs/ww/en/ps/15362/pm) -
Page 16: Uninstalling The "Simatic Net Pc Software
Uninstall the entire software package as described and recommended in the installation manual "SIMATIC NET PC Software". You will find the installation manual on the "SIMATIC NET PC Software" DVD or on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06... -
Page 17: Hardware Installation
Hardware installation Safety notices WARNING Electric shock possible - work only when the power supply is off Opening the PG/PC and plugging or pulling the communications processor is permitted only when the power is off. Turn off your PG/PC and pull the power cable connector before you start the hardware installation. -
Page 18: Installing Hardware
Hardware installation 3.2 Installing hardware Installing hardware Permitted number of communications processors in the PG/PC The driver software supports a maximum of 4 communications processors per PG/PC. Procedure Note First install the software First install the software before you insert the communications processor in the slot. Activated plug and play function The plug and play function must be activated in the BIOS of your PG/PC. -
Page 19: Hardware Compatibility
Hardware installation 3.3 Hardware compatibility Hardware compatibility Compatibility with predecessor versions The CP 5623 can replace the following predecessor versions: • CP 5613 A2 • CP 5613 The CP 5624 can replace the following predecessor versions: • CP 5613 A2 and CP 5614 A2 •... - Page 20 Hardware installation 3.3 Hardware compatibility CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06...
-
Page 21: Configuration
Configuration Configuring To be able to configure the communications processor, the following engineering or configuration tools are available: • STEP 7 V5.5 • STEP 7 Professional (TIA Portal) • Communication Settings (COML S7) The steps involved are described in the "Commissioning PC Stations" manual or in the relevant online helps. - Page 22 Configuration CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06...
-
Page 23: Technical Specifications
Technical specifications Technical specifications of the CP 5623/CP 5624 Connection to PROFIBUS Amount • For CP 5623 • For CP 5624 Transmission speeds 9.6 kbps, 19.2 kbps, 45.45 kbps, 93.75 kbps, 187.5 kbps, 500 kbps, 1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps Design 9-pin D-sub female connector with screw locking mechanism... - Page 24 Technical specifications Technical specifications of the CP 5623/CP 5624 Relative humidity (EN 60068-2-30) ≤ 95% at +25 °C ... +55°C, no condensation Vibration (EN 60068-2-6) 8.51 ... 500 Hz Acceleration 10 m/s 5 ... 8.51 Hz Amplitude 3.5 mm Shock (EN 60068-2-29) Half-sine: 250 m/s (25 g), 6 ms Design, dimensions and weight...
-
Page 25: Approvals
Declaration of conformity You will find the declaration of conformity for this communications processor on the Product Support pages under the following entry ID: 58826997 (https://support.industry.siemens.com/cs/ww/en/view/58826997) C-TICK approval The communications processor meets the requirements of the Australian AS/NZS 3548 standard according to EN 61000-6-3. - Page 26 • Consult the dealer or an experienced radio/TV technician for help. Siemens AG is not responsible for any radio television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Siemens AG. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user.
-
Page 27: Dimension Drawing
19BDimension drawing Dimension drawing Front view and side view of the CP 5623 and CP 5624 Figure B-1 All dimensions in millimeters. CP 5623/CP 5624 Operating Instructions, 12/2022, C79000-G8976-C281-06...
