- Page 1 VS-616/676 Series Option Instruction Manual Isolated Analog Monitor Card AO-12B2...
- Page 2 NOTICE Printed April, 1998. The information contained within this document is the proprietary property of Yaskawa Electric America, Inc., and may not be copied, reproduced or transmitted to other parties without the expressed written authorization of Yaskawa Electric America, Inc.
- Page 3 INTRODUCTION The Isolated Analog Card AO-12B2 mounts to an inverter’s control board via connection to option port 3CN, and is used to output dual analog signals for monitoring the inverter’s status: output frequency, out- put current, etc. The signal level is jumper selectable for -10 to +10 VDC, 0-20mA, or 4-20mA ranges. The channels are isolated from the inverter, but not from each other.
-
Page 4: Installation
2. After unpacking the card, verify that you have received the correct code number and that no dam- age had occurred during shipping. Contact your YASKAWA representative should you require any assistance. 3. Turn OFF the main electrical power to the inverter, and allow sufficient time (usually 5 minutes) for the DC bus to decay to less than 50V DC. -
Page 5: Top View
Female Connector 11 12 Control PCB Terminal Block TOP VIEW SIDE VIEW Fig. 1 Location of Isolated Analog Monitor Card AO-12B2 Note: VR1,VR2 VR3 and VR4 are factory calibrated and should not be readjusted. Monitor Card & Code Number Locations Fig. - Page 6 INTERCONNECTION BETWEEN EQUIPMENT MCCB L1 (R) T1(U) L2 (S) T2(V) L3 (T) T3(W) TB1-1 VS-616G3 VS-616G5 VS-616H3 TB1-2 VS-676VG3 VS-676VH3 TB1-3 G(E) Isolated Analog Monitor Card AO-12B2 Fig. 3 Interconnection Between Inverter and Peripheral Equipment Fig.3 shows interconnection of the inverter with the Isolated Analog Monitor Card AO-12B2, and peripheral equipment where the card is connected to analog meters.
-
Page 7: Wiring Notes
CAUTION WIRING NOTES 1. Separate the output signal wires that are connected to the Isolated Analog Monitor Card’s terminal block (TB1) from the main circuit wires and other power cables. 2. Use a twisted pair-shielded wire to connect output signals. Connect the shield as shown in Fig. 3 to prevent noise interference. - Page 8 WIRING Refer to the following table for the external terminal designations. Table 2: External Terminal Designations Terminal Terminal Block Symbol Function Number Isolated Monitor Output Channel 1 (+) Isolated Monitor Output Channel 2 (+) Common Monitor Output (-) Wiring Connection Notes: 1.
-
Page 9: Jumper Selection
JUMPER SELECTION Figure 6 shows the AO-12B2 Option Card’s terminal block and jumper locations. The pin arrangement is also shown. Refer to Tables 4 & 5 for jumper configuration details. Header Pin Layout Fig. 6 Isolated Analog Monitor Card Header Layout Locations Notes: 1. - Page 10 Table 5: Channel Two Jumper Selections Signal Level HDR3 Jumper Positions HDR1 Jumper Positions 2 to 4 4 to 6 2 4 6 2 4 6 Voltage (-10 to 10) 1 to 3 1 to 3 3 to 4 0-20mA 5 to 6 4 to 6 2 4 6...
- Page 11 PROGRAMMING PARAMETER SETTINGS Program the output terminal to the desired signal using the parameters in the following tables: Table 7: Programming settings with G3 Table 8: Programming settings with H3 Table 9: Programming settings with G5 Table 10: Programming settings with VG3 or VH3 Table 7: Programming Settings With VS-616G3 Program Output...
- Page 12 Table 8: Programming Settings With VS-616H3 Program Output Terminal Output Contents Constant No. Value Accuracy Frequency reference: 1.0% Max. frequency/100% Output frequency: 3.0% Max. frequency/100% TB1-1 bn-15 Output current 1.5% Channel 1 Rated current/100% Output voltage reference: input voltage/100% 1.5% DC voltage (V 400v/100% (200V class) Output Power...
- Page 13 Table 9: Programming Settings With VS-616G5 Program Output Output Terminal Constant No. Value Content Accuracy Frequency reference 0.2% 10V/max. output frequency Output frequency 0.2% 10V/max. output frequency Output current 10V/inverter rated current Motor speed 0.2% 10V/max. output frequency Output voltage 10V/200V or 400V TB1-1 F4-01 Channel 1...
- Page 14 Table 10: Programming With VS-676VG3 or VS-676VH3 Program Output Terminal Parameter Output Contents Value Accuracy Number Frequency reference 10V/max. output frequency Output frequency 10V/max. output frequency Output current: 3.0% Motor rated current 100% Output voltage reference: TB1-1 bn-15 No-load voltage/100% Channel 1 1.5% DC voltage (V...
- Page 15 OUTPUT SIGNAL LEVEL SETTING Output signal level of external terminal TB1-1 or TB1-2 can be set by programming the appropriate parameter to a value as indicated by 10 volts (or 4-20mA) x setting value /100%. Applicable External Program Setting Setting Initial Inverter Terminal...
