Page 3: Preface
Preface Purpose of the This manual contains all the information you need for working with the Manual PG 720PII programming device. You can use this information to do the following: Unpack the programming device and power it up. Familiarize yourself with the functions and settings of the various components (display, keyboard, programming facilities, etc.).
Page 4 Additional If you have any questions concerning subjects not covered in the Assistance manual, simply get in touch with the Siemens representative in your area or call the SIMATIC Hotline. The addresses are listed in your Product Information Bulletin. If you have any questions about the manual itself or would like to make or suggestions, please complete the reply card at the end of the manual.
Page 5: Table Of Contents
Contents Preface ..............Product Overview .
Page 6 Contents PG 720 Expansions ........... . . Opening the Unit .
Page 7: Product Overview
SIMATIC programmable logic control systems. SIEMENS The PG’s Hardware You can use the PG 720 programming device to program SIMATIC S5 and and Software SIMATIC S7 programmable logic controllers.
Page 8 Product Overview Advantages of the Compared with a PC with standard hardware and software, the PG 720 PG 720 programming device of the SIMATIC family has numerous advantages: You can develop, debug, and document user programs for SIMATIC S5 and SIMATIC S7 programmable logic controllers with the PG 720 without the need for additional hardware or software.
Page 9 Unpacking and Setting Up the PG 720 What Does This This chapter contains important information about unpacking, setting Chapter Contain? up, and transporting the PG 720, such as: Opening and closing the keyboard Changing the angle of inclination of the device Using the extra pull-out support How to move the unit.
Page 10: Unpacking And Setting Up The
Unpacking and Setting Up the PG 720 Setting Up the PG 720 Unpacking Your Unpack your PG 720 as follows: PG 720 1. Remove the packing. 2. Do not throw the original packing away. Keep it in case you have to ship or transport the unit again at some time in the future.
Page 11 Unpacking and Setting Up the PG 720 Changing the With the keyboard open, you can incline the PG 720 to any angle Angle of between 0 and 90 . To adjust the angle, proceed as follows: Inclination 1. Lower the keyboard into position. 2.
Page 12 Unpacking and Setting Up the PG 720 Detaching the In certain situations, it is helpful to remove the keyboard. Keyboard Press in the catches in the middle of the hinges Figure 2-3 Detaching the Keyboard Caution Risk of tipping! If the keyboard is detached, there is a risk of the unit tipping over. Before removing the keyboard, make sure that you pull out the support from the device stand (Figure 2-4) and pull out the additional hoop.
Page 13 Unpacking and Setting Up the PG 720 Keyboard Angle When the keyboard is attached to the unit, its angle of inclination is 6 , the height of the middle row of keys is 30 mm (about 1 inch). When it is detached, the angle of inclination is 4.5 , and the height of the middle row of keys is 27 mm.
Page 14: Moving The Programming Device
Unpacking and Setting Up the PG 720 Moving the Programming Device Preparations The PG 720 is easy to carry. Before carrying it, however, you should take the following measures: 1. Shut down the operating system. To prevent data loss, you must exit Windows 98 completely.
Page 15 Getting to Know the PG 720 What Does This This chapter contains all the information you require about the most Chapter Contain? important components of the device, such as: LED displays Drives Keyboard Programming facilities of the PG 720 External power unit and battery. Chapter Section Contents...
Page 16: Getting To Know The Pg 720 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1 Hardware Components Of The
Getting to Know the PG 720 Hardware Components of the PG 720 Front You can access all of the important operator controls and displays from the front, base, or sides of the unit. Figure 3-1 shows the front of the PG 720.
Page 17 Getting to Know the PG 720 Table 3-1 The LEDs and What They Mean The LEDs and Label Meaning What They Mean Device is in mains supply mode; external power unit is supplying power Device is in mains supply mode; battery is re- charging Akku Device is in battery mode;...
Page 18 Getting to Know the PG 720 Note Press the On/Off button for approximately one second to switch on the device. The device switches off automatically if it is powered down in Windows. If it is not in Windows, switch off the device by pressing the On/Off button.
Page 19 Getting to Know the PG 720 Left-Hand Side All the connectors and interface ports for connecting to external Panel devices are located on the left side panel of the PG 720 (Communications (communications side). Side) VGA port COM 2 port Power switch LEDs COM 1 port...
Page 20 Getting to Know the PG 720 Right-Hand Side You access the slots for programming S5 submodules, S5/S7 memory Panel (Processing cards, the PCMCIA port, and the disk drive from the right-hand side of Side) the PG 720 (processing side). Ejector for PC cards Ejector for diskettes PC cards types I/II;...
Page 21 Getting to Know the PG 720 Base Panel You can access the CD-ROM drive and the rechargeable battery from the base of the PG 720 device. Battery CD-ROM-Drive Ventilation Slits There are ventilation slits on the top and bottom panels of the unit. These slits must not be covered or blocked in any way (for example, by placing the device on carpets or rugs).
Page 22: Display
Getting to Know the PG 720 Display Available Displays The PG 720 has a color display. Contrast control Figure 3-4 PG 720 Display The PG 720 has a 12.1” ( 31 cm) TFT color display with a resolution Color Display of the PG 720 of 800 x 600 pixels.
Page 23: Keyboard
Getting to Know the PG 720 Keyboard Keyboard Layout The keyboard is divided into the following areas: Alphanumeric or typewriter keyboard with special keys LED displays Function keys Cursor control keys. Print Pause SysRq Break Scroll @ ” ^ & &...
Page 24 Getting to Know the PG 720 Alphanumeric The largest block of keys on the keyboard is the alphanumeric keyboard Keyboard with all the keys for the letters of the alphabet, numerals and special characters. The characters are arranged in basically the same way as on a normal typewriter.
Page 25 Getting to Know the PG 720 Table 3-5 Functions of the Special Keys “Fn” Special Key (combination key) In conjunction with a second key (key combination), you activate other key codes for special applications with this key. This key is also used to emulate the numeric keypad (Figure 3-8 Numeric Keypad).
Page 26 Getting to Know the PG 720 Cursor Keys The key block shown in the picture below is used for cursor control. Home Move cursor to beginning of file Page back Page Page Move cursor up Page forward Move cursor to end Move cursor left of file Move cursor right...
Page 27 Getting to Know the PG 720 Key Combinations A selection of some of the most important key combinations are shown in the following table. Table 3-6 Key Combinations Restart Ctrl Delete Switch over to international character set Ctrl Switch over to German character set: the German keyboard driver must be loaded.
Page 28: Trackball
Getting to Know the PG 720 Trackball Trackball The trackball is a pointing device for cursor control and menu selection in many programs that support mouse operation. By moving the trackball, the cursor can be positioned anywhere on the screen. By pressing the left-hand button, you set a marker.
Page 29 Getting to Know the PG 720 Figure 3-9 Cleaning the Trackball Figure 3-10 Cleaning the Trackball Housing Figure 3-11 Cleaning the Rollers PG 720 PII Programming Device 3-15 C79000-G7076-C756-02...
Page 30: Drives
Getting to Know the PG 720 Drives Drive Types The PG 720 is equipped with the following drives as standard: Table 3-7 Standard Drives Type of Drive Format Capacity Floppy (diskette) drive 3.5 inch 1.44 Mbytes Hard disk drive 2.5 inch See Product Information leaflet Floppy Disk Drive...
Page 31 Getting to Know the PG 720 Hard Disk Drive You can use a number of different hard disk drives in your PG 720. The memory capacity of the particular type of hard disk can be found in the Product Information Bulletin and SETUP program. When the hard disk is accessed, this status is indicated by the access LED for external storage media on the front of the device.
Page 32: Cd-Rom Drive
Getting to Know the PG 720 CD-ROM Drive Overview You can use the CD-ROM drive to read information from CDs into the PG 720. The CD-ROM drive is installed at the back of the PG 720. It is operated on the same port as the hard disk drive. Opening the Swing the PG 720 into a horizontal position.
Page 33: External Power Unit And Battery
Getting to Know the PG 720 External Power Unit and Battery External Power The external power unit is used to supply the PG 720 with power when Unit it is being operated with 120 V or 230 V mains supplies. The voltage range is set automatically.
Page 34: Sound
Getting to Know the PG 720 Charging stops as soon as the battery is fully charged. In storage, a fully charged battery runs down in approximately 2 months. It must then be recharged. The battery has an integral charge-status monitor (”fuel gauge”). You can check the battery charge level in Windows 98.
Page 35 Installing and Operating the PG 720 What Does This This chapter describes what you have to do to set up your PG 720 Chapter Contain? correctly for operation. This includes: The basic steps for commissioning your PG 720 Working in the battery mode and changing the battery Working with memory submodules and cards for the programmable logic controllers Connecting your PG 720 to other devices.
Page 36: Installing And Operating The Pg 720 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.1 Connecting The Pg 720 To The Power Supply
Installing and Operating the PG 720 Connecting the PG 720 to the Power Supply Connecting to the You can operate the PG 720 on 120 V and 230 V power systems using Power Supply the external power supply unit. The voltage is selected automatically. 1.
Page 37: Battery Mode
Installing and Operating the PG 720 Battery Mode Charge-Status The battery has electronic circuitry for showing the current charge Indicator status. The electronics incorporate a metering unit which has to be calibrated at regular intervals so that it can compensate for error. The chemical properties of the battery change in the course of time, so the electronics have to relearn the battery’s characteristics at regular intervals.
Page 38 Installing and Operating the PG 720 Note You can speed up the discharge stage by deactivating the Power management functions in the BIOS (see Setup menu, Section 6.1.4 Power Savings Disabled..). Under Windows 98 you can achieve the fastest possible discharge by clicking Taskbar > Start > Settings > Energy Management >...
Page 39 Installing and Operating the PG 720 Note Do not start a work session in battery mode unless the battery is fully charged. This is the only way of ensuring that the full on-battery operating time is available; note that if the Battery LED is orange when you switch on with the programming device is connected to the a.c.
Page 40 Installing and Operating the PG 720 Unlocking the battery connector - press here 1 Battery connector 3 Pull out Support 2 Akku 4 Akku compartment cover Figure 4-2 Changing the Akku Note Whenever possible, avoid running down the batterie to a low level. Switch off the device after use.
Page 41: Connecting I/O Devices
Installing and Operating the PG 720 Connecting I/O Devices Connecting the To connect your printer, proceed as follows: Printer to the 1. Switch off the PG 720 and the printer. Parallel Port 2. Open the cover to the interface ports on the left-hand side panel. 3.
Page 42 Recommended You connect external multisynchronous monitors using the standard Monitors VGA connector on the left-hand panel side of the unit. We recommend that you use a Siemens monitor. VGA socket Figure 4-4 Connecting the Monitor Connecting You must switch the PG 720 off before connecting the monitor cable.
Page 43 Installing and Operating the PG 720 Using a Mouse You can connect both a PS/2–USB and a serial mouse to the PG 720. When the PG 720 is supplied, the mouse driver for the trackball and PS/2 mouse is already loaded. Connecting a PS/2 You can connect an external PS/2 mouse or another external pointing Mouse...
Page 44 Installing and Operating the PG 720 Connecting a You can connect a serial mouse to the COM2 serial port. To operate a Serial Mouse serial mouse, the appropriate mouse driver must be initialized and assigned parameters. You will find the information you need to do this in the description of your mouse or in the description of the operating system.
Page 45 Installing and Operating the PG 720 Connecting a PS/2 To connect the keyboard, proceed as follows: Keyboard 1. Switch off your device. 2. Unplug the keyboard connector from the base of the unit. 3. Plug in the PS/2-type keyboard connector. Note It is advisable to use a keyboard cable with an angled connector, so that the connector does not extend beyond the back panel.
Page 46: Working With Simatic S5 Memory Submodules
Installing and Operating the PG 720 Working with SIMATIC S5 Memory Submodules Working with You can read and program SIMATIC S5 EPROMs and EEPROMs SIMATIC S5 using the 48-pin S5 EPROM and EEPROM programming port. You will Submodules find information about using the programming software in the STEP 5 User Manual.
Page 47 Installing and Operating the PG 720 Caution Risk of damage to EPROMs or EEPROMs! If you insert or remove the EPROM or EEPROM while it is in use, there is a danger that it will be damaged. You must not remove the S5 EPROM or EEPROM while the LED indicating that the EPROM or EEPROM is being read etc.
Page 48: Working With Simatic Memory Cards
Installing and Operating the PG 720 Working with SIMATIC Memory Cards Working with SIMATIC memory cards can be read, programmed, and erased using SIMATIC Memory the 68-pin connector. SIMATIC memory cards are available for Cards SIMATIC S5 and SIMATIC S7 software. Orientation point SIMATIC memory cards Figure 4-9 Slot for SIMATIC Memory Cards...
Page 49: Working With Pc Cards
Installing and Operating the PG 720 Working with PC Cards PC Cards The PC card interface supports Cardbus cards (32-bit) and PCMCIA cards (16-bit). The PG 720 has two PC card ports. You can plug communication modules for MODEM, FAX-MODEM, ISDN, Token Ring, ETHERNET, memory expansion and SCSI interface modules in credit-card format into these ports.
Page 50 Installing and Operating the PG 720 Note Do not use PC cards along with a SIMATIC-S5 module or a SIMATIC memory card. Always follow the instructions in your Operating Instructions. Note In order to use a PC card you must enter BIOS-SETUP, open the Main menu, select the Hardware Option submenu and set “Cardbus/ PCMCIA Slot”...
Page 51: Connecting The Pg 720 To Other Simatic S5 Units
Installing and Operating the PG 720 Connecting the PG 720 to other SIMATIC S5 Units Point-To-Point In this section, you will learn how to connect your PG 720 to a Connection programming device or S5 programmable logic controller using a point-to-point connection.
Page 52 Installing and Operating the PG 720 Connecting the You can connect the PG 720 to a SIMATIC S5 programmable logic PG 720 to S5 controller using the COM1/TTY interface port. The cable for connecting Programmable to SIMATIC S5 CPUs is supplied with the PG 720 ( Order Controllers no.: 6ES5734-2BD20).
Page 53 Installing and Operating the PG 720 Connecting the The connecting cable 6ES5 734-2BD20 is supplied with the PG 720. PG 720 Using an An adapter is available for connecting the programmable logic Adapter controller using older standard cables. Table 4-2 Adapter for the PG 720 Connecting Cable Port Connection...
Page 54 Installing and Operating the PG 720 Note If you connect two programming devices using the TTY interface, you must deactivate the TTY interface (COM1) on one of the devices by changing the jumper settings. When supplied, this interface is always active.
Page 55: Connecting The Pg 720 To A Simatic S7 Network (Mpi/Dp)
Installing and Operating the PG 720 Connecting the PG 720 to a SIMATIC S7 Network (MPI/DP) Connecting an S7 You can connect your PG 720 to a SIMATIC S7 programmable logic Programmable controller using the floating*) MPI/DP interface. The MPI cable for Controller via an connection to SIMATIC S7 CPUs is supplied with the PG 720.
Page 56 Installing and Operating the PG 720 Connecting Via the MPI/DP interface, you can connect your programming devices MPI networks (S7-200, S7-300, and S7-400) or PROFIBUS DP networks (DP components). MPI/PROFIBUS DP Up to 32 devices (PC, programming device, or programmable Network controller) can be connected to the MPI/DP interface to form a network segment.
Page 57: Networking The Pg 720 With Other Stations On Profibus
Installing and Operating the PG 720 Networking the PG 720 with Other Stations on PROFIBUS Networking the PROFIBUS is an open and robust bus system for industrial use. It can PG 720 on be used to configure networks with up to 32 stations per segment. The PROFIBUS data transfer rate for PROFIBUS is 1.5 Mbps.
Page 58: 4.10 Networking The Pg 720 And Other Computers On Industrial Ethernet
(10 Mbps), simple expansion, open communication, and widespread application. How the Network Industrial Ethernet is the name of Siemens networks and network Functions components operating according to the CSMA / CD (ETHERNET) principle. Industrial Ethernet is a bus-type LAN that uses a triaxial cable (H1) as its transmission medium.
Page 59 PG 720 Expansions What Does This You can enhance the performance of your PG 720 by adding additional Chapter Contain? memory. This chapter describes how to expand your PG 720. Please observe the relevant safety guidelines. Chapter Section Contents Page Overview Opening the Unit Components Visible After Opening the Unit...
Page 60: Pg 720 Expansions
Limitation of All technical specifications and licences apply only to expansion Liability functions approved by SIEMENS. No liability can be accepted for impairment of functions caused by the use of devices and components of other manufacturers. All the modules and components in the PG 720 are electrostatically sensitive.
Page 61 PG 720 Expansions Tools Use a screwdriver to open the unit. Opening the To open your PG 720, proceed as follows: PG 720 1. Switch off the PG 720, pull out the power supply connector, and remove all connecting cables from the unit, including the keyboard cable.
Page 62: Components Visible After Opening The Unit
PG 720 Expansions Components Visible After Opening the Unit Components Once you have removed the top cover of your unit, the components are visible. 1 Drives 3 Power supply 2 Motherboard 4 Jumpers for TTY setting Figure 5-2 PG 720 open PG 720 PII Programming Device C79000-G7076-C756-02...
Page 63: Block Diagram Of The Motherboard
PG 720 Expansions Block Diagram of the Motherboard Î Î Î Î Î Î Î Î Î Î Î Î Figure 5-3 Block Diagram, PG 720PII PG 720 PII Programming Device C79000-G7076-C756-02...
Page 64 PG 720 Expansions Motherboard The motherboard is the heart of the PG 720. Here, data are processed and stored, and interfaces and device I/Os controlled and managed. 10/14 11 12 28 30 29 Figure 5-4 Motherboard Components on The following components are located on the motherboard of the the Motherboard PG 720: Table 5-1...
Page 65: Switch Settings / Jumpers
PG 720 Expansions Table 5-1 Components of the Motherboard Serial Functions Number Connector for On/Off switch Connector for display unit Connector, reserved (microphone) Jumper not installed Connector, reserved (earphones) Connector for speaker, left Connector for speaker, right Programming submodule RS 485 hybrid Switch Settings / Jumpers TTY Jumpers Function...
Page 66: Installing Memory Expansion Submodules
PG 720 Expansions Installing Memory Expansion Submodules Standard Memory The motherboard has 2 slots for 144 pin SO DIMM memory submodules. This allows you to expand the memory capacity of your PG 720 to a maximum of 256 Mbytes. The basic configuration consists of a 64 Mbyte SDRAM module. Only one module has to be installed.
Page 67: Processor Upgrade
PG 720 Expansions Caution Risk of damage! The electronic components of the printed circuit boards are extremely sensitive to electrostatic discharge. Certain precautionary measures are therefore necessary when handling such components. These measures are explained in the guidelines for handling electrostatically-sensitive devices at the end of this manual.
Page 68: Replacing The Backup Battery
PG 720 Expansions Replacing the Backup Battery Battery Power A backup battery (3.6 V lithium battery) powers the real-time clock Supply for even after the PG 720 is switched off. In addition to the time of day, all Real-Time Clock the information about the PG 720 (device configuration) is stored in and Configuration RAM.
Page 69: Closing The Unit
PG 720 Expansions Closing the Unit Closing the Unit To close the unit, proceed as follows: 1. Tilt the unit to the horizontal position. 2. Place the front section on the casing. 3. Insert the CD-ROM ribbon cable and the CD-ROM audio line into the drive connector on the backplane.
Page 70 PG 720 Expansions PG 720 PII Programming Device 5-12 C79000-G7076-C756-02...
Page 71 Configuring the PG 720 What Does This In this chapter, you will learn how to configure your programming Chapter Contain? device. You need to do this if you change your system by adding, removing, or exchanging expansion modules and memory expansions, or by replacing a system module.
Page 72: Configuring The Pg 720 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.1 Changing The Device Configuration With Setup
Configuring the PG 720 Changing the Device Configuration with SETUP Changing the Your PG 720 device configuration is set for working with the software Device supplied with the unit. You should only change the preset values if you Configuration have modified your PG 720 in any way or if a fault occurs when the unit is powered up.
Page 73 Following shown below appears following power-on: Power On Phoenix NoteBIOS 6.0 A5E000xxxxx-01 Copyright 1985-98 Phoenix Technologies Ltd., All Rights Reserved. SIEMENS PG 720PII CPU = Pentium II 266MHz 640K System RAM Passed 63MB Extended RAM Passed 0512K Cache SRAM passed...
Page 74 Configuring the PG 720 The following screen form appears when you start the BIOS setup: Header PhoenixBIOS Setup Utility Menu bar Main Advanced Security Power Boot Sequence Version Exit Item Specific Help System Time: [ 15:35:32 ] [ 01/23/1999 ] System Date: Shift-Tab , or...
Page 75 Configuring the PG 720 6.1.1 The Main Menu PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help System Time: [ 15:35:32 ] [ 01/23/1999 ] System Date: Shift-Tab , or Enter Diskette A: [ 1.44 MB, 31/2” ] selects field.
Page 76 Configuring the PG 720 System Time and System Time and System Date indicate the current values. Once you System Date have selected the appropriate option, you can use the [+] and [–] keys to modify the time setting Hour:Minute:Second and the date Month/Day/Year.
Page 77 Configuring the PG 720 Primary Master The system jumps to the following submenu when you select this type Primary Slave of menu field: Secondary Master- Secondary Slave PhoenixBIOS Setup Utility Main Advanced Security Power Boot Sequence Version Exit Primary Master [6495MB] Item Specific Help Type: [Auto]...
Page 78 Configuring the PG 720 ”Multi-Sector Trans- The entry in the Multi-Sector Transfer field defines the number of fer” Field sectors transferred per interrupt. The value depends on the drive and should be set only by setting the Type field to Auto . Disabled 2,4,8,16 sectors...
Page 79 Configuring the PG 720 “Memory Cache” The following pop-up menu appears when you select the option Field “Memory cache” in the main menu: PhoenixBIOS Setup Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help [ 15:35:32 ] System Time: [ 01/23/1998 ] System Date:...
Page 80 Configuring the PG 720 Option “Boot The following submenu appears when you select the option “Boot Options” Options” in the main menu: PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Boot Options Item Specific Help [Enabled] QuickBoot Mode: Allows the system to skip certain tests while booting.
Page 81 Configuring the PG 720 Example of a summary screen: PhoenixBIOS Set Up Utility SIMATIC PG PG720 PII BIOS Version: V7..CPU: Fxx – FFFF Pentium System ROM: CPU Speed 266 MHz BIOS Date: 03/06/97 System 640 KB COM Ports: 03F8, 02F8 Extended 63 MB LPT Ports:...
Page 82 Configuring the PG 720 “Hardware The following submenu appears when you select the “Hardware Options” Field Options” field in the main menu: PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Hardware Options Item Specific Help [Enabled] PCI - MPI / DP: Enable or disable the Plu [Enabled] Cardbus/PCMCIA Slot:...
Page 83 Configuring the PG 720 Entry Meaning CRT 1024 x Refresh rate with a resolution of 1024x768 pixels [Normal] LCD Screen- The display window in Text and Graphic size modes is not expanded to full screen size. [Text expand] Only the Text modes are expanded to full screen size.
Page 84: The Advanced Menu
Configuring the PG 720 6.1.2 The Advanced Menu Menu Structure PhoenixBIOS Setup-Utility Main Security Power Boot Sequence Version Exit Advanced Item Specific Help Set up Warning. Setting titems on this menu to incorrect values may cause yuor system to malfunction. Peripherial Configuration COM / LPT Configuration PCI Configuration...
Page 85 Configuring the PG 720 Harddisk Pre- [Disabled] No additional start-up delay for the hard disk. Delay 3 to 30 Additional start-up delay for the seconds hard disk; needed only for older-generation hard disks. Memory Gap at [Disabled] The area from 15 to 16 Mbytes is not available 15 MByte as PC-Card memory.
Page 86 Configuring the PG 720 PCI Configuration PhoenixBIOS Setup Utility Submenu Main Security Power Boot Sequence Version Exit Advanced PCI Configuration Item Specific Help Reserve specific IRQs for use by legacy ISA devices PCI/PNP ISA Resource Exclusion PCI IRQ line 1: [Auto Select] PCI IRQ line 2: [Auto Select]...
Page 87 Configuring the PG 720 Submenu PCI/PNP Available means that the Plug&Play mechanism in BIOS can allocate ISA IRQ Resource the IRQ to plug & play submodules or motherboard functions. Exclusion Use the ’Reserved’ setting only if the interrupt has to be assigned specifically to PCMCIA submodules with no plug&play capability.
Page 88 Configuring the PG 720 Option PhoenixBIOS Setup Utility. “PCI IRQ line” Main Security Power Boot Sequence Version Exit Advanced Item Specific Help PCI Configuration PCI devices can use hardware interrupts Disabled called IRQs. A PCI Auto Select device cannot use IRQs already in use by ISA or PCI/PNP ISA Resource EISA devices.
Page 89: The Security Menu
Configuring the PG 720 6.1.3 The Security Menu Summary You can only edit the fields enclosed in square brackets. Two passwords are assigned to protect your programming device from unauthorized use. You can use the supervisor password to prevent use of diskettes for the normal user and to limit use of the hard disk.
Page 90 Configuring the PG 720 Fixed disk boot Normal All types of hard-disk access are permitted. sector protected No operating system can be installed. This is a way of protecting against boot viruses. Diskette This mode of protection is not active unless ”Password on access boot ”...
Page 91: The Power Menu
Configuring the PG 720 6.1.4 The Power Menu Summary This menu has the following structure: PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help APM: Enabled Power Savings: Disabled APM (Advanced Power Management) allows APM aware software to Standby Timeout: manage power savings, if enabled Suspend Timeout:...
Page 92 Configuring the PG 720 Major components are shut down in suspend mode. The information needed for reactivating the programming device is buffered. Suspend Mode [Save to Disk] In suspend mode all relevant data is written to a defined sector of the hard disk [Save to DRAM] In suspend mode all relevant data is...
Page 93: The Boot Sequence Menu
Configuring the PG 720 6.1.5 The Boot Sequence Menu Summary This menu allows you to prioritize the boot devices. PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help Diskette Drive Removable Devices Keys used to view or configure devices: Hard Drive <Enter>...
Page 94 Configuring the PG 720 Groups marked + can contain more than one device. When you select a group marked in this way, hit Enter to view the list of devices in the group. See the figure below for an illustration: PhoenixBIOS Setup-Utility Main Advanced...
Page 95: The Version Menu
Configuring the PG 720 6.1.6 The Version Menu This menu contains the information you will have to quote when you send us technical questions about your system. PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help SIMATIC PG PG 720PII BIOS Version...
Page 96: The Exit Menu
Configuring the PG 720 6.1.7 The Exit Menu The Exit Menu The setup program is always terminated using this menu. PhoenixBIOS Setup-Utility Main Advanced Security Power Boot Sequence Version Exit Item Specific Help Save Changes & Exit Exit Without Saving Changes Exit after writing all changed SETUP Get Default Values item values to CMOS.
Page 97 Configuring the PG 720 Documenting Your If you have made any modifications to your standard SETUP settings, you Device can enter them in the following table. You can then refer to these entries Configuration if you need to make any hardware modifications later. Note Print the following table out and keep the pages in a safe place once you have filled in your entries.
Page 98 Configuring the PG 720 System Parameter Standard Settings Your Entries COM/LPT Configuration Internal COM1 Enabled Base I/O address Interupt IRQ4 Internal COM2 Enabled Base I/O address Interrupt IRQ3 Internal LPT1 Enabled Mode Output only Base I/O address Interrupt IRQ7 DMA Channel DMA @ PCI-Configuration PCI/PnP ISA IRQ Exclusuion...
Page 99 Configuring the PG 720 System Parameter Standard Settings Your Entries Power Enabled Power Savings Disabled Powersavings by Customize Standby Timeout Suspend Timeout Suspend Mode Save to DRAM Hard Disk Timeout Disabled Fan Control Enabled Backlight Full on Resume on Modem Ring Resume on Time Resume Time 00:00:00...
Page 100: Configuring The Pc Card Interface
MS-DOS, such as Socket Services Card Services Client Drivers Flash File System from your nearest Siemens sales office or representative. Your programming device comes supplied with Windows 98 already installed; this supports the PC card interface. PG 720 PII Programming Device 6-30...
Page 101: Error Diagnostics
Error Diagnostics What Does This This chapter will help you to locate, identify, and in some cases Chapter Contain? eliminate simple errors and faults. The symptoms of the problem, possible causes, and remedies are listed in the form of a table. PG 720 PII Programming Device C79000-G7076-C756-02...
Page 102 Error Diagnostics Table 7-1 Errors/Faults in PG 720 Operation Power- LED does not light up PG 720 is switched off Switch the unit on Power supply not properly Check the power supply, connected power cable, and power connector Battery run down Charge or replace battery Display remains dark after Back lighting is not active...
Page 103 Error Diagnostics Table 7-1 Errors/Faults in PG 720 Operation Trackball not working Trackball is switched off Activate trackball with key combination F External mouse plugged in Check Setup entry PS/2 interface is set to external or disabled in Setup After power on: Battery is no longer Acknowledge error message Error message:...
Page 104: Programming Device Self-Test Prior To Booting
Error Diagnostics Programming Device Self-Test Prior to Booting When the PG 720 is powered up, it runs a self-test (POST = Power On Self Test). If the POST detects a fault, it outputs the sequence of beeps (beep code) assigned for the fault. Each beep code consists of 2 x 2 sequences.
Page 105 Error Diagnostics Hex Code Meaning Description TP_VERIFY_REAL Test whether CPU in Real mode TP_RESET_PIC Reset interrupt controller TP_RESTORE_CR0 Restore control register TP_PCI_BM_RESET PCI Bus Master reset TP_CHK_SHUTDOWN Check shutdown code TP_SET_HUGE_ES Set ES to special mode TP_DISABLE_NMI Disable NMI TP_CPU_INIT Early initialization of CPU TP_GET_CPU_TYPE Determine CPU type...
Page 106 Error Diagnostics Hex Code Meaning Description TP_ADV_CS_CONFIG Configure advanced chip set TP_VECTOR_INIT Initialize interrupt vectors TP_COPYRIGHT Check copyright TP_PCI_INIT Initialize PCI interface TP_CONFIG Check configuration TP_VIDEO Initialize video interface If the INSERT key is pressed during booting of the system, three short beeps are sounded.
Page 107 Hardware Information What Does This This chapter contains important reference data about the following: Chapter Contain? Hardware addresses Interrupt assignments Information about connecting cables Chapter Section Contents Page Overview Hardware Address Table Interrupt Assignments PG 720 Video Modes Connector Pinouts Connecting Cables 8-14 PG 720 PII Programming Device...
Page 108: Hardware Information
Hardware Information Hardware Address Table There are two kinds of address area: Memory address area I/O address area. Different read/write signals (I/O WR, I/O RD, MEMR, MEMW) are used to address these areas. The following tables provide you with an overview of the address areas used.
Page 109 Hardware Information Table 8-2 I/O Address Assignments Address Assignment Remarks From 0000 000F DMA controller 1 0020 0021 Interrupt controller 1 0024 003D Motherboard resources 0040 0043 Timer 1 0060 0060 Keyboard controller, data 0061 0061 NMI, system speaker settings 0064 0064 Keyboard controller, command, status...
Page 110 Hardware Information Table 8-2 I/O Address Assignments Address Assignment Remarks From 1000 103F PIIX IO 1040 104F PIIX power management 1050 1057 First IDE controller (dual FIFO) 1058 105F Second IDE controller (dual FIFO) 1060 107F PCI/USB universal host controller 1080 10E7 ESS SOLO -1 audio device...
Page 111: Interrupt Assignments
Hardware Information Interrupt Assignments Interrupt The PG 720 uses the two integrated interrupt controllers of type 82C59 Assignment to handle the 16 hardware interrupts (IRQ 0 to IRQ 15). The INT output of the slave controller is connected to the IRQ 2 input of the master controller.
Page 112: Video Modes
Hardware Information PG 720 Video Modes Mode No. VESA Video mode (text/ Colors LCD/ (Hex) mode No. graphic) (I) = Interlaced Simultaneous (L) = linear mode 00+/01+ –– Text 40x25 70Hz 60Hz 02+/03+ –– Text 80x25 70Hz 60Hz 04/05 –– Gr.320x200 70Hz 60Hz...
Page 113: Connector Pinouts
Hardware Information Connector Pinouts Socket Connector The socket for the external power supply unit has the following for the External potentials: Power Unit + 17.5 V +5% DC voltage – 0 V Ground Figure 8-1 Power Supply Connector Connecting a PS/2 You can connect a PS/2 mouse to your PG 720.
Page 114 Hardware Information Connecting an You can connect an external keyboard to your PG 720. The connector External Keyboard has the following pinout: View of the socket connector Figure 8-3 Connector Pinout for an External Keyboard Pin No. Designation Input/Output Data line, keyboard Input/output Data line, trackball Input/output...
Page 115 Hardware Information VGA Socket The VGA socket connector on the PG 720 has the following pinout: Connector Figure 8-4 VGA Socket Connector Pin No. Designation Description Input/Output R_EXT Output G_EXT Green Output B_EXT Blue Output – – Ground – Ground Ground Ground Ground...
Page 116 Hardware Information MPI/DP Socket The MPI/DP socket connector on the PG 720 has the following pinout: Connector Figure 8-5 MPI/DP Socket Connector Signal Pin No. Designation Description Input/ Output Description Pin 1 is not assigned – Pin 2 is not assigned –...
Page 117 Hardware Information Parallel Port The parallel port (LPT1) on the PG 720 has the following pinout: Figure 8-6 LPT1 Parallel Port (Socket) Signal Description Input/Output /Strobe (CLK) Output (open collector) Data - bit 0 Output (TTL level) Data - bit 1 Output (TTL level) Data - bit 2 Output (TTL level)
Page 118 Hardware Information Serial Port The serial port (COM1) on the PG 720 has the following pinout: (PLC/RS-232/ Modem) Figure 8-7 COM1 Serial Port (Socket) Pin No. Designation Description Input/Output TxD (D1) Serial transmit data Output RxD (D2) Serial receive data Input RTS (S2) Request to send...
Page 119 Hardware Information Serial Port The serial port (COM2) on the PG 720 has the following pinout: (RS-232/Mouse) Figure 8-8 COM2 Serial Port (Connector) Designation Description Input/Output DCD (M5) Data carrier detect Input RxD (D2) Receive data Input TxD (D1) Transmit data Output DTR (S1) Data terminal ready...
Page 120: Connecting Cables
Hardware Information Connecting Cables Overview PG 6xx 6ES5731-6AG00 PLC-SS/TTY COM1/TTY 6ES5733-2xxx0 PG 7xx 6ES5733-5xxx0 COM1/RS-232 COM1/RS-232 Link via RS-232 6ES5731-6AG0 S5-90U to S5-155U 15-pin PG IF 6ES5731-1xxx0 COM1/TTY 6ES5734-2xxx0 6ES5731-6AG0 25-pin PG IF S5-150U (AS 511) 6ES5731-0xxx0 Printer 6AP1901-0AL0 Centronics LPT1/Centronics 6ES5731-6AG0 CP523-525...
Page 121 Hardware Information Standard Using the standard connecting cable (supplied with the unit) you can Connecting Cable connect your PG 720 to a Siemens programmable logic controller. Please refer to the information in Chapter 3. PG 7xx Connecting cable 25-pin male connector...
Page 122 Hardware Information Connecting Cable With 25-Pin Socket Connector PG 7xx PG 695 II Adapter S5-PLC, V.24 Connecting cable 25-pin male 6ES5 731-6AG00 25-pin female 6ES5 731-0xxx0 activated (Release 2) deactivated 330 ohms –V 330 ohms Shield –V Casing Figure 8-12 Connecting Cable With 25-Pin Socket Connector Cable for You can connect your PG 720 to other programming devices with this Interconnecting...
Page 123 Hardware Information Connection to S5 If you want to connect your PG 720 to the S5/RS-232 port of a PG 6xx PLC/RS-232 and programming device, you require an adapter. In this case, the PG 720 COM1/TTY of a must be the active programming device. Please read the information PG 6xx about activating and deactivating the TTY/COM1 port in Chapter 4.
Page 124 Hardware Information PG 720 PII Programming Device 8-18 C79000-G7076-C756-02...
Page 125: Guidelines For Handling Electrostatically-Sensitive Devices (Esd)
Guidelines for Handling Electrostatically-Sensitive Devices (ESD) Chapter Section Contents Page Overview What is ESD? Electrostatic Charging of Persons General Protective Measures Against Electrostatic Discharge Damage PG 720 PII Programming Device C79000-G7076-C756-02...
Page 126: What Is Esd
Guidelines for Handling Electrostatically-Sensitive Devices (ESD) What is ESD? Definition All electronic modules are equipped with large-scale integrated ICs or components. Due to their design, these electronic elements are very sensitive to overvoltages and thus to any electrostatic discharge. These Electrostatically-Sensitive Devices are commonly referred to by the abbreviation ESD.
Page 127: Electrostatic Charging Of Persons
Guidelines for Handling Electrostatically-Sensitive Devices (ESD) Electrostatic Charging of Persons Charging Every person with a non-conductive connection to the electrical potential of its surroundings can be charged electrostatically. Figure A-1 shows you the maximum values for electrostatic voltages which can build up on a person coming into contact with the materials indicated in the figure.
Page 128: General Protective Measures Against Electrostatic Discharge Damage
Guidelines for Handling Electrostatically-Sensitive Devices (ESD) General Protective Measures Against Electrostatic Discharge Damage Ensure Sufficient Make sure that the personnel, working surfaces, and packaging are Grounding sufficiently grounded when handling electrostatically-sensitive devices. You thus avoid electrostatic charging. Avoid Direct You should touch electrostatically-sensitive devices only if it is Contact unavoidable (for example, during maintenance work).
Page 129: Glossary
This chapter contains a glossary in which you will find a list of the Chapter Contain? terminology used in conjunction with the Siemens range of programming devices and a brief explanation of each of the terms. PG 720 PII Programming Device...
Page 130 Glossary Access Protection Access to the programs and data of a programming device can be protected by passwords. ACPI Advanced Configuration and Power Interface. Advanced Power Management. Application An application is a program which builds directly on, for example, the MS-DOS/Windows operating system.
Page 131 Glossary Cardbus interface This interface is compatible with 32-bit Cardbus cards with PCI perfor- mance compliant with the PC Card standard. CD ROM (Compact Disc – Read Only Memory) Removable memory for large amounts of data. Click Pressing and immediately releasing the left mouse button; this selects objects or trigger commands.
Page 132 Glossary Disk Drive The disk drive (floppy disk drive) is used to store programs and data on diskette (write access) or to load from diskette to the computer (read access). Diskette The diskette (floppy disk) is an external data access memory on which all types of files and programs can be stored.
Page 133 Glossary File A file is the collection of data under one name. Formatting Formatting divides the memory area on a magnetic data medium into tracks and sectors. Formatting deletes all the data on a data medium. Every data medium must be formatted before it is used for the first time.
Page 134 Glossary Interrupt Request Line Industrial Standard Architecture JEIDA (Japanese Electronics Industry Development Association) Association of Japanese electronics manufacturers whose aim is to set up standards worldwide for the miniaturization and flexible application of PC expansion cards. Cooperates with PCMCIA. Keyboard The keyboard is the collection of keys which are used to input data, text, characters, letters, numbers, special characters, and control commands in a computer.
Page 135 Glossary Module Modules are boards (printed circuit boards) which can be plugged into a programmable logic controller or programming device. They are available, for instance, as central controller modules, interface modules, or as bulk memory modules. Monitor The monitor or screen is a visual display unit via which the programming device communicates with the user.
Page 136 Glossary Operating System Collective term for all functions which, in conjunction with the hardware, control and monitor execution of the user programs, the distribution of resources among the individual user programs, and the maintenance of the operating mode (for example, Windows 98, MS-DOS). Information is transmitted a byte at a time via a parallel interface (port).
Page 137 Glossary Programmable The programmable logic controllers (PLC) of the SIMATIC S5 system Logic Controller consist of a central controller, one or more CPUs and various I/O modules. The PLCs of the SIMATIC S7 system (for example, S7-200, -300, -400) consist of one or more CPUs and various I/O modules. Programmable The programmable logic controllers (PLC) of the SIMATIC S5 system Logic Controller...
Page 138 Glossary SETUP A program in which information about the device configuration (that is, the configuration of the hardware on the programming device) is defined. The device configuration of the programming device is preset with defaults. Changes must therefore be entered in the SETUP if a memory extension, new modules, or a new drive are added to the hardware configuration.
Page 139 Glossary Text Cursor The cursor shows where text may be entered, for example, in text editors and in dialog windows. In many applications the position of the cursor can be changed by moving and clicking the mouse pointer. TFT Display Thin Film Transistor Color Display Trackball The trackball is used as a pointing device for programs serviced by a...
Page 140 Glossary Write Protection Write protection for files or diskettes Write protection for files; this type of write protection is stored in the computer and is allocated by the system manager. Diskette write protection; for 3 1/2 in. diskettes by opening the write protection hole.
Page 141: Index
Index Activating/deactivating, 4-20 Function keys, 3-12 Address areas, 8-2 Hard disk drive, 3-17 Battery, 4-4, 4-5 Hardware information, 8-1 BIOS, 6-2 date, 6-6 time, 6-6 I/O address area, 8-2 Industrial Ethernet, 4-24 Installation, 4-1 Calibration cycle, 4-3, 7-3 Interrupt, 8-5 Cardbus, 4-15 CD-ROM, 3-18 Closing the unit, 5-11...
Page 142 Index MPI, 3-5 MPI connector, 8-10 S5 memory submodule, 4-12 Serial port, 8-12, 8-13 SETUP, 6-2 Setup Opening the keyboard, 2-2 Advanced menu, 6-14 disk drive type, 6-6 hardware options, 6-12 keyboard features, 6-11 Security menu, 6-19 Parallel port, 8-11 SIMATIC memory cards, 4-14 PC interface, 4-15 SINEC H1, 4-3...

Siemens SIMATIC PG 720 PII Manual

Quick Links

Related Manuals for Siemens SIMATIC PG 720 PII

Summary of Contents for Siemens SIMATIC PG 720 PII

Table of Contents
