Impex MARCY SM-6200 Manual

Impex MARCY SM-6200 Manual

Deluxe smith machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
SM-6200
Retain This
Manual for
Reference
08-06-09
OWNER'S
MANUAL
DELUXE SMITH MACHINE
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
MARCY
SM-6200
®
IMPEX
INC.

Advertisement

Table of Contents
loading

Related Manuals for Impex MARCY SM-6200

Summary of Contents for Impex MARCY SM-6200

  • Page 1 Hardware Identifier SM-6200 Assembly Instruction Parts List Warranty Ordering Parts Model SM-6200 Retain This Manual for Reference 08-06-09 OWNER'S MANUAL ® IMPEX INC. 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...

  • Page 2: Table Of Contents

    WARRANTY....................… ORDERING PARTS..................BEFORE YOU BEGIN ® Thank you for selecting the MARCY SM-6200 Smith Machine by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 4: Smith Machine Hardware Pack

    The warning labels shown here have been placed on the Cross Brace, Rear Stabilizer and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown. SMITH MACHINE HARDWARE PACK...
  • Page 6 SMITH MACHINE HARDWARE PACK...
  • Page 7 SMITH MACHINE HARDWARE PACK...

  • Page 8: Smith Machine Assembly Instructions

    SMITH MACHINE ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Do not tighten all nuts and bolts until instructed to do so. B.) Attach one Base Frame (#1) to the Left Vertical Frame (#3).
  • Page 9 DIAGRAM 1...
  • Page 10 STEP 2 (See Diagram 2) A.) Attach the Vertical Frame Base (#9) to the Cross Brace (#6) from the bottom. Attach the Rear Vertical Frame (#8) onto the Cross Brace on the top. Align the holes and secure them together with two M10 x 2 3/8” Carriage Bolts (#83), Ø ¾” Washers (#89), and M10 Aircraft Nuts (#90).
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Weight Glide Post (#11) to the bracket on the Vertical Frame Base (#9). Secure it with one 3 1/8” x 1 ¾” Bracket (#31), M10 x 2 ½” Carriage Bolt (#84), Ø ¾” Washer (#89), and M10 Aircraft Nut (#90) to the upper hole, one M10 x 2 ½”...
  • Page 12 DAIGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the Butterfly Base (#37) to the Rear Vertical Frame (#8). Secure it with two M10 x 2 ½” Carriage Bolts (#84), Ø ¾” Washers (#89), and M10 Aircraft Nuts (#90). B.) Attach two Swivel Pulley Brackets (#35) to the open brackets on the Rear Vertical Frame (#8).
  • Page 14 CABLE LOOP DIAGRAM...
  • Page 15 STEP 5 (See Diagram 5 & Cable Loop Diagram) A.) Attach the 142” Upper Cable (#40) to the front opening on the Upper Frame (#7). Attach a Pulley (#59) to the opening. Secure it with one M10 x 2 1/8” Allen Bolt (#79), two Ø 1 1/8” x 3/8” Pulley Bushings (#52), and one M10 Aircraft Nut (#90).
  • Page 16 STEP 6 (See Diagram 6 & Cable Loop Diagram) A.) Attach one end of the 86” Butterfly Cable (#42) to the clip on the Right Butterfly (#39). Draw the Cable to the right open Swivel Pulley Bracket (#35). B.) Attach a Small Pulley (#58) to the Swivel Pulley Bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#78), two Ø...
  • Page 17 STEP 7 (See Diagram 7 & Cable Loop Diagram) A.) Insert the tip of the 127” Lower Cable (#41) through the opening on the Foot Plate (#26) to the opening on the Vertical Frame Base (#9). B.) Attach a Small Pulley (#58) to the opening. Attach the Foot Plate to the Frame. Align the holes and secure the Foot Plate, Vertical Frame Base, and the Small Pulley with one M10 x 2 ¾”...
  • Page 18 DIAGRAM 7...
  • Page 19 STEP 8 (See Diagram 8) A.) NOTE: Help of another person is strongly recommended for this step. Place the Lifting Sleeve (#13) in between the two Safety Stop Frames (#16). Align the holes and insert the Weight Bar (#15) all the way through. Center the bar and use the two M8 x 3/8” Allen Bolts (#86) on the two Safety Stop Frame to secure the Weight Bar on each side.

  • Page 20: Exploded Diagram

    SMITH CAGE EXPLODED DIAGRAM...

  • Page 21: Smith Machine Parts List

    SMITH CAGE PARTS LIST KEY NO. DESCRIPTION Q’ty Base Frame Ø 1” x 5/8” Pulley Bushing Front Vertical Frame Ø 1 1/8” x 3/8” Pulley Bushing Left Vertical Frame Ø 1” x ¾” Pulley Bushing Right Vertical Frame 1 ½” Sleeve Front Top Beam 5 ¾”...

  • Page 22: Multi-Purpose Bench Hardware Pack

    MULTI-PURPOSE BENCH HARDWARE PACK...

  • Page 23: Multi-Purpose Bench Assembly Instructions

    MULTI-PURPOSE BENCH ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Left &...
  • Page 24 STEP 2 (See Diagram 2) A.) Align the bracket on the Backrest Adjustment Support (#6) in between the two Backrest Supports (#12). Secure it with four M8 x 1 5/8” Allen Bolts (#40), eight Ø 5/8” Washers (#45), and four M8 Aircraft Nuts (#48). Do not tighten the Nuts and Bolts yet.
  • Page 25 STEP 3 (See Diagram 3) A.) Place the Seat Pad (#17) onto Seat Bracket (#5). Secure it with four M8 x 1 3/8” Allen Bolts (#41) and Ø 5/8” Washers (#45). B.) Attach the Backrest Board (#16) to the two Backrest Supports (#12). Secure it with four M8 x 1 3/8”...
  • Page 26 STEP 4 (See Diagram 4) A.) Attach the Leg Developer (#4) to the open bracket on the Leg Developer holder on Main Frame (#1). Secure it with an Axle (#15), two M10 x 5/8” Allen Bolts (#35), and two Ø ¾” Washers (#44).

  • Page 28: Multi-Purpose Bench Parts List

    MULTI-PURPOSE BENCH PARTS LIST KEY NO. DESCRIPTION Q’ty Main Frame Left Rear Stabilizer Right Rear Stabilizer Leg Developer Seat Bracket Backrest Adjustment Support Arm Curl Stand Curl Bar Handle Support Backrest Adjustment Lever ¾” Curl Bar Support End Cap Lock Pin Backrest Support Foam Tube 3”...

  • Page 29: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
