INSTALLATION INSTRUCTIONS
80G2UH-V
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
507335-03
This manual must be left with the homeowner for future reference.
WARNING
WARNING
Table of Contents
Unit Dimensions ..........................................................2
Parts Arrangement.......................................................3
80G2UH-V Gas Furnace .............................................4
Shipping and Packing List ...........................................4
Safety Information .......................................................4
General ........................................................................5
Combustion, Dilution & Ventilation Air .........................6
Setting Equipment .......................................................8
Filters .........................................................................11
Duct System ..............................................................11
Gas Piping .................................................................22
Electrical ....................................................................24
Adjusting Airflow ........................................................28
Start-Up .....................................................................29
Maintenance ..............................................................35
Control Diagnostics ...................................................36
Planned Service ........................................................37
Repair Parts List ........................................................37
*P507335-03*
Issue 2302
Warm Air Gas Furnace
Upflow/Horizontal
Left/Right Air Discharge
(P) 507335-03
Page 1 of 39
