User's Manual
Color LCD Monitor
Important
Please read this "User's Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective
usage.
• See the Setup Guide for monitor installation and connection.
• For the latest product information including the "User's Manual", refer to
our web site:
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo FlexScan EV3240X-BK
Summary of Contents for Eizo FlexScan EV3240X-BK
- Page 1 User’s Manual Color LCD Monitor Important Please read this "User’s Manual", and "PRECAUTIONS" (separate volume) carefully to familiarize yourself with safe and effective usage. • See the Setup Guide for monitor installation and connection. • For the latest product information including the "User’s Manual", refer to our web site: www.eizoglobal.com...
-
Page 2: Location Of Caution Statement
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. -
Page 3: About This Product
About This Product About This Product About the Usage of This Product • Aside from creating documents, viewing multimedia content, and other general purposes, this product is also suited to applications such as creating CAD data and other drawings (Assuming usage of approximately 12 hours per day). •... -
Page 4: About The Installation
About This Product sooner, requiring replacement. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • Do not press hard on the surface or outer frame of the LCD panel, as this may result in display malfunctions, such as interference patterns, etc. -
Page 5: Table Of Contents
CONTENTS CONTENTS Location of Caution Statement ................. About This Product ....................About the Usage of This Product ................ About the LCD Panel ..................About the Installation................... Cleaning ......................To Use the Monitor Comfortably ................. 1 Introduction ........................ Features ......................1.1.1 Two Window Display................ - Page 6 CONTENTS Using PbyP Display..................... 30 Using PinP Display....................31 Linking the Input Signal and USB Port..............32 4.4.1 Linking..................... 32 4.4.2 Switching USB Ports................33 5 Administrator Settings....................34 Basic Operation of the "Administrator Settings" Menu........34 Functions of the "Administrator Settings" Menu..........35 6 Troubleshooting ......................
-
Page 7: Introduction
Introduction | 1 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1.1 Features 1.1.1 Two Window Display PbyP (Picture by Picture) and PinP (Picture in Picture) functions are available to split the screen into left and right and display two input signals at the same time. -
Page 8: Reduction Of Power Consumption
1 | Introduction • By attaching the monitor to an arm, the screen can be used in a multi-monitor configuration benefiting from the feature of framelessness on all four sides (see Attaching the Optional Arm [} 44]). 1.1.4 Reduction of Power Consumption This product provides a function that automatically adjusts the screen brightness to reduce power consumption . -
Page 9: Docking Station Function
Introduction | 1 Note • Screen InStyle can be downloaded from our web site (www.eizoglobal.com). • The Windows operating systems are only supported. 1.1.6 Docking Station Function This product is equipped with a LAN port and USB hub so that it can be used as a docking station. -
Page 10: Controls And Functions
1 | Introduction 1.2 Controls and Functions 1.2.1 Front 1. Speakers Outputs audio. 2. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is automatically adjusted according to the ambient brightness (see Auto EcoView [} 17]). 3. Operation switches Displays menus. -
Page 11: Rear
Introduction | 1 1.2.2 Rear 1. Handle This handle is used for transportation. 2. Stand Adjusts the height and angle (tilt and swivel) of the monitor. The monitor can also be rotated vertically. 3. Cable holder Holds the monitor cables. 4. Security lock slot Complies with Kensington's MicroSaver security system. - Page 12 1 | Introduction 11. USB-A connector (downstream) 12. HDMI connector Connects to a PC with HDMI output. 13. DisplayPort connector Connects to a PC with DisplayPort output. 14. USB-C connector Connects to a PC with USB-C output. This also transmits the USB (upstream) signal that is necessary for using software that requires a USB connection or the docking station function (see...
-
Page 13: Supported Resolutions
Introduction | 1 1.3 Supported Resolutions The monitor supports the following resolutions: PbyP display Layout 1 Layout 2 Layout 3 PbyP PbyP PbyP-A PbyP-A PbyP-B PbyP-B PinP display Large Window Small Window ✓: Supported, -: Not supported Resolution Vertical DisplayPort / USB-C HDMI scan Single... - Page 14 1 | Introduction Resolution Vertical DisplayPort / USB-C HDMI scan Single PbyP display Single PbyP display frequency windo windo PbyP- PbyP- PbyP- PbyP- PbyP- PbyP- (Hz) display display / PinP / PinP display display 1680 x 1050 59.954 ✓ ✓ ✓ ✓ ✓...
-
Page 15: Basic Adjustment/Setting
Basic Adjustment/Setting | 2 2 Basic Adjustment/Setting This product enables users to change the brightness according to personal preference or to suit the usage environment, and to reduce power consumption to conserve energy. For advanced adjustment and setting procedures using the Setting menu, see 3 Advanced Adjustments/Settings [} 19]. -
Page 16: Switching Display Modes (Color Modes)
2 | Basic Adjustment/Setting 2.3 Switching Display Modes (Color Modes) This product is preinstalled with color modes for various display purposes. By switching the color mode according to the purpose and contents of the display, you can display images in an appropriate manner. 2.3.1 Color Modes Color Mode Purpose... - Page 17 Basic Adjustment/Setting | 2 Note • The power saving level (Power Reduction, CO Reduction, and Eco Performance Level) can be checked on the "EcoView Settings" menu. The more indicators that light up representing the Eco Performance Level, the higher the power saving level attained. –...
-
Page 18: Adjusting Brightness
2 | Basic Adjustment/Setting 2.5 Adjusting Brightness Settings: "0" to "100" The brightness of the screen can be adjusted to suit the installation environment or personal preference. The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). 2.6 Adjusting Volume Settings: "0"... -
Page 19: Advanced Adjustments/Settings
Advanced Adjustments/Settings | 3 3 Advanced Adjustments/Settings This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see 2 Basic Adjustment/Setting [} 15]. 3.1 Basic Operation of the Setting Menu 1. Touch any switch (except The operation guide appears. 2. -
Page 20: Setting Menu Functions
3 | Advanced Adjustments/Settings 3.2 Setting Menu Functions 3.2.1 Color The color mode settings can be adjusted according to personal preference. The adjusted settings are saved for each color mode. Functions that can be adjusted differ depending on the color mode. ✓: Adjustable, -: Not adjustable Function Color Mode User1... - Page 21 Advanced Adjustments/Settings | 3 Note • For details on the adjustment status of each color mode, see 2.3 Switching Display Modes (Color Modes) [} 16]. Brightness Settings: "0" – "100" The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).
- Page 22 3 | Advanced Adjustments/Settings Note • If "Paper" is selected for the color mode, "Paper" is displayed for the gamma value. • If "DICOM" is selected for the color mode, "DICOM" is displayed for the gamma value. Advanced Settings - Overdrive Settings: "Enhanced" / "Standard" / "Off" This function allows you to set the overdrive intensity based on the use of the monitor.
-
Page 23: Signal
Advanced Adjustments/Settings | 3 3.2.2 Signal Set the details regarding input signal, such as the screen size and color format. Window Selection Settings: "Left" / "Right" / "Large Window" / "Small Window" Select the screen to apply "Signal" to when using PbyP/PinP display. Please perform this selection when starting usage of PbyP/PinP display. - Page 24 3 | Advanced Adjustments/Settings Note • Setting example Full-screen Fixed aspect ratio Actual size (input signal) • During PinP display, the small window is displayed in a fixed aspect ratio and the display size of the window cannot be changed. Sharpness Settings: "-2" – "2" When a low-resolution image is displayed using picture expansion mode ("Full Screen"...
-
Page 25: Preferences
Advanced Adjustments/Settings | 3 Note • When "YUV" is selected in "Input Color Format", the setting is automatically set to "Limited". Additionally, when "Auto" is selected and the monitor determines the input color format to be YUV, the setting is automatically set to "Limited". 3.2.3 Preferences The monitor’s settings can be configured to suit the usage environment or personal preference. - Page 26 3 | Advanced Adjustments/Settings Note • At the time of shifting to power saving mode, a message that indicates the transition is displayed five seconds in advance. • When using PbyP/PinP display, the monitor will revert to power saving mode only when both PCs are in power saving mode.
-
Page 27: Languages
Advanced Adjustments/Settings | 3 • "Small Window" Outputs audio of the small window of PinP display. Note • This can only be set when using PbyP/PinP display. • For information on PbyP, see 4.2 Using PbyP Display [} 30]. • For information on PinP, see 4.3 Using PinP Display [} 31]. -
Page 28: Information
3 | Advanced Adjustments/Settings 3.2.5 Information You can check the monitor information (model name, serial number (S/N), firmware version, usage time) and the input signal information. Example: - Single window display - PbyP display - PinP display When is selected, the certification standard logo appears on the screen. -
Page 29: Connecting Multiple Pcs
Connecting Multiple PCs | 4 4 Connecting Multiple PCs 4.1 Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. Connection Examples HDMI DisplayPort USB-C USB cable DisplayPort HDMI cable (USB-C - USB-C) cable (HDMI - HDMI) CC150SS81G-5A... -
Page 30: Using Pbyp Display
4 | Connecting Multiple PCs Note • You can select the input signal to display using the operation switch ( ) on the front of the monitor. For details, see 2.2 Switching Input Signals [} 15]. • This product provides a function that automatically recognizes the connector through which PC signals are input, and displays images on the screen accordingly. -
Page 31: Using Pinp Display
Connecting Multiple PCs | 4 4.3 Using PinP Display If you select PinP display and input multiple signals to the monitor, you can display them in the large window and small window. Multiple screens can be displayed on one screen, so switching signals is no longer necessary and work productivity improves. The signal combination of the large window and small window can be switched. -
Page 32: Linking The Input Signal And Usb Port
4 | Connecting Multiple PCs 4.4 Linking the Input Signal and USB Port When two PCs are connected to one monitor, you can link the input signal with the USB upstream port. This makes it possible to connect USB devices such as a mouse or keyboard to the monitor and use them from multiple PCs. -
Page 33: Switching Usb Ports
Connecting Multiple PCs | 4 4.4.2 Switching USB Ports Use either of the following methods to switch the USB upstream port. Changing the input signal The USB upstream port switches automatically. Input signal: USB-C Input signal: DisplayPort USB port: USB-C USB port: USB-B Using the operation switch ( ) on the front of the monitor to switch ports (when using PbyP/PinP display) -
Page 34: Administrator Settings
5 | Administrator Settings 5 Administrator Settings This chapter describes how to configure monitor operation using the "Administrator Settings" menu. 5.1 Basic Operation of the "Administrator Settings" Menu 1. Touch to turn off the monitor. 2. While touching the leftmost switch, touch for more than two seconds to turn on the monitor. -
Page 35: Functions Of The "Administrator Settings" Menu
Administrator Settings | 5 5.2 Functions of the "Administrator Settings" Menu Auto Input Detection Settings: "On" / "Off" This function automatically recognizes the connector through which PC signals are input, and displays images on the screen accordingly. • "On" When the monitor is connected to multiple PCs, if a specific PC enters power saving mode or no signals are input to the monitor, the connector is automatically changed to another one to which signals are input. - Page 36 The type of signal that can be displayed on the monitor can be changed. Try changing this setting if the input signal is not displayed correctly or the intended display does not show. On-Screen Logo Settings: "On" / "Off" When the monitor is turned on, the EIZO logo and certification standard logo appears on the screen.
- Page 37 Administrator Settings | 5 When this function is set to "Off", the logos do not appear. Key Lock Settings: "Off" / "Menu" / "All" In order to prevent changes to settings, the operation switches on the front of the monitor can be locked. •...
-
Page 38: Troubleshooting
6 | Troubleshooting 6 Troubleshooting 6.1 No Picture Power indicator does not light up. • Check whether the power cord is connected properly. • Turn on the main power switch on the back of the monitor. • Touch • Turn off the main power switch on the back of the monitor, and then turn it on again a few minutes later. -
Page 39: Imaging Problems
[} 20]). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, try changing the Auto EcoView setting to "On". The monitor... -
Page 40: Other Problems
6 | Troubleshooting • An afterimage may appear even after a short time period has elapsed depending on the displayed image. To remove such a phenomenon, change the image or keep the power turned off for several hours. Green / red / blue / white / dark dots remain on the screen. •... - Page 41 [} 50]). • If the peripheral devices work correctly when they are directly connected to the PC, contact your local EIZO representative. • Check the PC's BIOS (UEFI) setting for USB when using Windows. (See the manual of the PC for details.) •...
- Page 42 6 | Troubleshooting Even when the mouse or keyboard are used, the PC does not return from sleep. • Turn the setting "On" for "Compatibility Mode" on the "Administrator Settings" menu (see Compatibility Mode [} 35]). The monitor does not supply power (USB Power Delivery) to the PC. •...
-
Page 43: Attaching/Removing The Stand
Attaching/Removing the Stand | 7 7 Attaching/Removing the Stand 7.1 Removing the Stand The stand section of this product can be removed. Attention • Do not move the stand up and down after removing it. If you move the stand up and down while it is not attached to the monitor, this may cause damage or injury. -
Page 44: Attaching The Optional Arm
If the monitor is used in these positions without the edge supports, the front panel may come away. If you require edge supports, contact the EIZO group company or distributor in your country or territory (www.eizoglobal.com/contact/). - Page 45 Attaching/Removing the Stand | 7 Attention • When attaching an arm or stand, follow the instructions of the respective User's Manual. • When using another manufacturer's arm or stand, confirm the following in advance and select one conforming to the VESA standard. –...
-
Page 46: Attaching The Original Stand
7 | Attaching/Removing the Stand 7.3 Attaching the Original Stand 1. Lay the LCD monitor on a soft cloth spread over a stable and flat surface with the LCD panel surface facing down. 2. Remove the fixing screws on the optional arm (or optional stand), and detach the optional arm (or optional stand). -
Page 47: Reference
Reference | 8 8 Reference 8.1 Using the Docking Station Function This product is equipped with a LAN port and USB hub so that it can be used as a docking station. By connecting a USB-C cable, you can create a stable network environment even on notebook PCs or tablet devices that are not equipped with LAN ports. - Page 48 8 | Reference Attention • This function may not work depending on the PC you are using, your OS, and your peripheral devices. Contact the manufacturer of each device for information about USB compatibility. • Even when the monitor is in power saving mode, devices connected to the USB downstream port are operational.
-
Page 49: Specifications
Reference | 8 8.2 Specifications 8.2.1 LCD Panel Type IPS (Anti-Glare) Backlight Size 31.5" (80 cm) Resolution 3840 dots x 2160 lines Display Size (H x V) 697.3 mm x 392.2 mm Pixel Pitch 0.182 mm x 0.182 mm Display Colors 8-bit colors 16.77 million colors Viewing Angle (H / V, typical) 178˚... -
Page 50: Audio
Sierra (10.12) or later Wired LAN IEEE802.3ab (1000BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T) EIZO support will end when OS vendor support ends. 8.2.6 Power Input 100 – 240 VAC ±10 %, 50 / 60 Hz, 2.00 – 0.85 A Maximum Power Consumption... -
Page 51: Operating Environmental Requirements
Reference | 8 8.2.8 Operating Environmental Requirements Temperature 5 ˚C – 35 ˚C Humidity 20 % – 80 % R.H. (no dew condensation) Air Pressure 540 hPa – 1060 hPa 8.2.9 Transportation / Storage Environmental Requirements Temperature -20 ˚C – 60 ˚C Humidity 10 % –... -
Page 52: Appendix
ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. - Page 53 03V60481A1 UM-EV3240X Copyright © 2023 EIZO Corporation. All rights reserved. 1st Edition – February, 2023...
