Air purifier
Floor standing or desktop type
Floor standing or desktop type
Model
MC55VBFVM
• Thank you for purchasing this air purifier.
• Please read the operation manual carefully and follow it for correct use.
• Please read the "Safety Precautions" section before use.
Please keep the operation manual in a safe place for later reference.
Air Purifier
OPERATION MANUAL
►Page 3, 4

Advertisement

Table of Contents
loading

Related Manuals for Daikin MC55VBFVM

Summary of Contents for Daikin MC55VBFVM

  • Page 1 Floor standing or desktop type Floor standing or desktop type Air Purifier Model MC55VBFVM OPERATION MANUAL • Thank you for purchasing this air purifier. • Please read the operation manual carefully and follow it for correct use. • Please read the “Safety Precautions” section before use.

  • Page 2: Read First

    Read First Features Streamer Technology Streamer discharge decomposes adsorbed odour. • Decomposition cycle that maintains deodorising capacity. Adsorption Odour Deodorising catalyst Deodorising catalyst adsorbs odour. Replacement of the deodorising This cycle catalyst is maintains This technology employs a “streamer discharge”, a unnecessary.

  • Page 3: Table Of Contents

    Read First Contents Read First Features ................Safety Precautions ............Names of Parts and Operations ........Preparation Before Operation .......... Using the Air Purifying Operation ........10 Operation Changing the Airfl ow Rate ..........10 Operating the Unit in a MODE ........11 AUTO FAN / ECONO / ANTI-POLLEN Useful Functions Using the Child Proof Lock ..........

  • Page 4: Safety Precautions

    Read First Safety Precautions „ Observe these precautions in order to prevent property damage or injury. „ The consequences of incorrect use are categorised as follows: WARNING CAUTION Failure to follow these instructions properly may Failure to follow these instructions properly result in property damage or personal injury, which may result in personal injury or loss of life.
  • Page 5 Read First WARNING Observe in order to prevent fire, electric shock or severe injury. „ Concerning the remote controller • Do not place the remote controller in places that can be reached by small children. (Bodily harm may result from misoperation of the unit or accidental ingestion of the battery) • Make sure not to put the battery in the wrong polarity (+/-) orientation.

  • Page 6: Names Of Parts And Operations

    Read First Names of Parts and Operations CAUTION Do not lift up the unit holding the grip on the deodorising fi lter unit. (Injury may result from the unit falling) Front Back Operating/Indicator panel Air outlet ►Page 6, 7 Active plasma ion generation unit Grip Inside the air outlet. (for carrying the unit) Deodorising fi lter unit Model name / Production no.
  • Page 7 Read First Operating/Indicator panel When a lamp is blinking ►Page 21 MODE lamps [green] ON/OFF lamp [green] Child proof lock lamp [orange] Indicate the MODE in operation. Lamp will light up when the power is ON. Lamp will be lit when the Child proof lock active. FAN lamps [green] Streamer lamp [blue] Indicates the active FAN setting (4 settings: Quiet, Low, Standard, Turbo).
  • Page 8 Read First Names of Parts and Operations Operating/Indicator panel Signal receiver FAN/MODE button ON/OFF button Press to cycle between FAN settings Press to turn the power ON or OFF. Receives signals from the remote controller. ►Page 10 and MODEs. ►Page 10-12 Receiving tones sound when signals are received, confi rming successful reception. • Operation start...2 short beeps • Setting change...1 short beep • Operation end...1 long beep...

  • Page 9: Preparation Before Operation

    Read First Preparation Before Operation Positioning the unit Pointers for good positioning Before installation, peel off the tape fixing the power • Choose a position from where airflow can reach all areas of the room. supply cord to the bottom • Place on a stable surface. If the unit is placed on an unstable of the unit and draw out the surface, vibrations from the unit may be amplified.
  • Page 10 Read First Preparation Before Operation Preparing the remote controller Replacing the battery Attach the remote controller holder. • Insert the hook on the remote controller holder into Move the catch on the cover at the bottom of the the notch in the back of the unit. remote controller in the direction of the arrow.

  • Page 11: Operation

    Operation WARNING Operation Do not turn off the unit by unplugging it from the power socket. (Fire or an electric shock may result from heating) Operation Detailed settings can be made Remote controller Unit using the remote controller. Operation via remote controller. Operation via operating/indicator panel on unit.

  • Page 12: Operating The Unit In A Mode

    Useful Functions Useful Functions Remote controller Unit Operating the Unit in a MODE Select a MODE specifi c to your needs. Airfl ow is adjusted automatically when the unit is running in a MODE. Remote controller Press • Each press cycles between the MODE lamps [green]. (AUTO FAN) (ECONO) (ANTI-POLLEN) Unit Press • Each press cycles between the MODE lamps [green] and FAN lamps [green]. MODE (AUTO FAN) (ECONO)
  • Page 13 Useful Functions MODE Usage and Function Automatic airflow rate adjustment FAN setting (Quiet, Low, Standard, High) is automatically adjusted according to the degree of air impurity. AUTO FAN Purifying capacity increases as airflow rate rises. • Degree of air impurity corresponds to the volume of dust and the intensity of odours in the ambient air. Saving energy In Power saving mode within ECONO MODE, the FAN setting automatically switches between Quiet and Low only.

  • Page 14: Using The Child Proof Lock

    Useful Functions Useful Functions Remote controller Unit Using the Child Proof Lock Button operation is restricted preventing misoperation by small children. Remote controller Unit Hold down for about 2 Cannot be set from unit. seconds. • Hold down for 2 seconds again to turn off child lock. • When Child proof lock is active, operations will be restricted.

  • Page 15: Streamer Output Settings

    Advanced Settings Advanced Settings If the hissing sound generated by the streamer discharge or the smell of ozone bother you *Setting at time of purchase Streamer Output Settings Regular* Setting procedures Remote controller Hold down for about 3 seconds when the unit is off. • Each time are held down for about 3 seconds, the setting switches between Regular and Low.

  • Page 16: Setting Dust/Pm2.5 Sensor Sensitivity

    Advanced Settings Advanced Settings When the sensitivity of the dust/PM2.5 sensor does not meet your preferences *Setting at time of purchase Setting Dust/PM2.5 Sensor Sensitivity High High Normal* Normal* Setting procedures Remote controller Unit Hold down on the unit for about 5 seconds and when a short beep sounds, press on the remote controller while pressing on the unit.

  • Page 17: Settings Of Modes Within Econo Mode

    Advanced Settings If you wish to turn Monitoring mode (within ECONO MODE) OFF *Setting at time of purchase Monitoring Monitoring Monitoring Monitoring Settings of Modes within ECONO MODE Setting procedures Remote controller Unit Hold down on the unit for about 5 seconds and when a short beep sounds, press on the remote controller while pressing on the unit.

  • Page 18: Maintenance

    Maintenance WARNING Maintenance Before cleaning and maintenance work, make sure to unplug the unit. (An electric shock or injury may result) Outfl ow grille Wipe Wash/Rinse When dirt becomes an issue Removing • Wipe up dirt with a soft damp cloth and rinse with water.
  • Page 19 Maintenance WARNING • Do not use petrol, benzine, thinner, polishing compound, paraffin, alcohol, etc. (An electric shock, fire, or cracking may result) • Do not wash the main body of the unit with water. (An electric shock, fire, or malfunctioning/breakage may result) Deodorising filter unit When concerned about odours or dirt Removing Hold the lever and grip of the deodorising filter Vacuum clean Do not use water unit and remove. • Remove from the unit together with the frame Lever and remove dust using a vacuum cleaner. • If odour becomes an issue, wet the surface lightly with an atomiser etc., and then leave the part to dry in a shaded area with good ventilation.

  • Page 20: Replacing The Streamer Unit

    Maintenance WARNING Maintenance Before cleaning and maintenance work, make sure to unplug the unit. (An electric shock or injury may result) Replacing the Streamer Unit If the streamer lamp blinks The streamer unit will not need to be replaced. However, depending on where the unit is used (places where oils are present, or dust and humidity is abundant, or sprays and chemical agents are used, etc.) replacement may become necessary.

  • Page 21: Separately Sold Part

    Maintenance Separately Sold Part Contact the place of purchase. Replacement part Dust collection filter (electrostatic HEPA filter) ( 1 piece Model: KAFP080B4E • Replace about every 10 years. • Catches dust and pollen. • Failure to maintain part properly may result in: • Reduced air purifying capacity. • Reduced deodorising capacity.

  • Page 22: About The Indicator Lamps

    Troubleshooting About the Indicator Lamps Operating/Indicator panel Check the indicator lamps and respond as indicated below. Indicator lamp Cause/Solution Odour sensor lamp is blinking. This lamp blinks if the deodorising filter unit has become detached or is not attached properly. ...

  • Page 23: Faqs

    Troubleshooting FAQs Please check the following before contacting the place of purchase. Q: The dust/PM2.5 sensor seems to have poor sensitivity... Perform periodic cleaning of the dust/PM2.5 sensor as dirt on its lens can lead to poor sensitivity. ►Page 17 In addition, the response time of the dust/PM2.5 sensor varies depending on room size. Make adjustments in accordance with the procedure for setting dust/PM2.5 ►Page 15...

  • Page 24: Troubleshooting

    Troubleshooting Troubleshooting „ Before making an inquiry or a request for repair, please check the following. If the problem persists, contact the place of purchase. „ In the event of malfunction during operation If the indicator lamps light up abnormally, or become inoperable, due to a lightning strike etc., remove the power supply plug, wait at least 5 seconds then reinsert the power supply plug and turn the unit on again.
  • Page 25 Troubleshooting Phenomenon Check points All the FAN lamps ( (Quiet), • Are the pre-fi lter, outfl ow grille, and dust collection fi lter attached? These lamps may blink if the unit is operated without a part attached. (Low), (Standard), and (Turbo)) blink together [If one or more parts are not attached]...
  • Page 26 Troubleshooting Troubleshooting „ Air purifying function Phenomenon Check points Air purifying capacity is reduced • Is the unit positioned in a place where airfl ow cannot reach or surrounded by obstacles?  Choose a position that is obstacle-free and from where airfl ow can reach all areas of the room. • Is the pre-fi lter or dust collection fi lter dirty? ...

  • Page 27: Specifications

    Troubleshooting Specifications Model name MC55VBFVM Power supply Single phase 50Hz 220-240V / 60Hz 220-230V Air Purifying Operation mode Turbo Standard Quiet Power consumption (W) Operating sound (dB) Airflow rate (m³/h) Coverage area (m²) External dimensions (mm) 500(H)× 270(W)× 270(D) Weight (kg) Power supply cord length (m) • These specification values are applicable to both 50Hz 220–240V and 60Hz 220–230V.
  • Page 28 The bar code is a manufacturing code. The two-dimensional bar code is a manufacturing code. 3P549981-1B M18B152B (1912) HT...
