Network Bullet Camera
CA-NC328P-VBZ-WH
Quick Start Guide

Advertisement

Table of Contents
loading

Related Manuals for Phantom Cables CA-NC328P-VBZ-WH

Summary of Contents for Phantom Cables CA-NC328P-VBZ-WH

  • Page 1 Network Bullet Camera CA-NC328P-VBZ-WH Quick Start Guide...
  • Page 2 Network Bullet Camera·Quick Start Guide Quick Start Guide About this Manual This Manual is applicable to Network Bullet Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Bullet Camera·Quick Start Guide encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 4 Network Bullet Camera·Quick Start Guide 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
  • Page 5 Network Bullet Camera·Quick Start Guide serious injury or death. injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
  • Page 6 Network Bullet Camera·Quick Start Guide ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ● Do not touch sensor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.
  • Page 7 Network Bullet Camera·Quick Start Guide and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details. ● Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only.

  • Page 8: Table Of Contents

    Network Bullet Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............8 2 Installation ..................10 2.1 Memory Card Installation ..........10 2.2 Camera Mounting ............12 2.2.1 Ceiling/Wall Mount..........12 2.2.2 Mounting with a Gang Box ........18 3 Setting the Network Camera over the LAN ........

  • Page 9: Appearance Description

    Network Bullet Camera·Quick Start Guide 1 Appearance Description The overview of the bullet camera is shown below. 12 13 Overview of the Camera...
  • Page 10 Network Bullet Camera·Quick Start Guide Description Description Sun Shield Lens Front Cover Three-axis Adjustment Bracket Junction Box Side Outlet Cover Alarm Interface Audio Interface RJ 45 Network Interface Power Interface Cover Reset Button Video Out (BNC) Memory Card Slot Note: Hold RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 11: Installation

    Network Bullet Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or PoE (802.3at). Make sure your power supply matches with your camera.
  • Page 12 Network Bullet Camera·Quick Start Guide Remove the Cover of the Memory Card Slot 2. Insert the memory card into the card slot. Insert the Memory Card 3. Tighten the screws to replace the slot cover.

  • Page 13: Camera Mounting

    Network Bullet Camera·Quick Start Guide Replace the Slot Cover 2.2 Camera Mounting 2.2.1 Ceiling/Wall Mount Steps: 1. Drill screw holes in the wall/ceiling according to the holes 1 on the supplied adapter.
  • Page 14 Network Bullet Camera·Quick Start Guide Drill Holes in the Wall/Ceiling 2. Secure the adapter to the wall/ceiling with the screws. Install the Adapter 3. Loosen the screws to remove the junction box.
  • Page 15 Network Bullet Camera·Quick Start Guide Remove the Junction Box 4. Route the cables through the sealing plugs in the junction box. Pierce the sealing plugs on the junction box. Thread cables through the sealing plugs. Note: For RJ45 network interface, use the supplied cable routing ...
  • Page 16 Network Bullet Camera·Quick Start Guide Route the Cables through the Junction Box 5. Secure the junction box in the wall/ceiling with screws. Secure the Junction Box 6. Hook the camera to the junction box with the safety rope and connect the cables to the camera.
  • Page 17 Network Bullet Camera·Quick Start Guide Hook the Camera to the Junction Box 7. Secure the camera to the junction box with the screws. Secure the Camera 8. Adjust the view angle. 3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum camera rotation and placement. Follow the steps below to adjust the view angle.
  • Page 18 Network Bullet Camera·Quick Start Guide Loosen the lock screw using the supplied Allen wrench. Adjust the view angle of the camera. The adjusting range of the panning is from 0° to 360°, the tilting is from 0° to 90° and the rotation is from 0°...

  • Page 19: Mounting With A Gang Box

    Network Bullet Camera·Quick Start Guide 2.2.2 Mounting with a Gang Box Before you start: The gang box is not included in the package. You need to prepare one for this mounting type. Steps: 1. Secure the adapter to a gang box with the screws. 2.

  • Page 20: Setting The Network Camera Over The Lan

    Network Bullet Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 21: Activating The Camera

    Network Bullet Camera·Quick Start Guide 3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.

  • Page 22: Activation Via Sadp Software

    Network Bullet Camera·Quick Start Guide Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 23 Network Bullet Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 24: Modifying The Ip Address

    Network Bullet Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 25 Network Bullet Camera·Quick Start Guide For IP address modification via client software, refer to the user manual of client software. Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 26: Accessing Via Web Browser

    Network Bullet Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 27 Network Bullet Camera·Quick Start Guide 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 28: Operating Via Guarding Vision App

    Network Bullet Camera·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models. 5.1 Enable Guarding Vision Service on Camera Purpose: Guarding Vision service should be enabled on your camera before...

  • Page 29: Enable Guarding Vision Service Via Web Browser

    Network Bullet Camera·Quick Start Guide Service” “Privacy Policy” Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 30 Network Bullet Camera·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Platform Access Configuration (Web) 3. Select Platform Access Mode as Guarding Vision. 4.

  • Page 31: Guarding Vision Setup

    Network Bullet Camera·Quick Start Guide 5.2 Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching “Guarding Vision” in App Store or Google Play 2. Launch the app and register for a Guarding Vision user account. 3.
  • Page 32 Network Bullet Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 33: Initializing The Memory Card

    Network Bullet Camera·Quick Start Guide 5.4 Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
