Network Dome Camera
CA-2240V-WH
Quick Start Guide

Advertisement

Table of Contents
loading

Related Manuals for Phantom Cables CA-2240V-WH

Summary of Contents for Phantom Cables CA-2240V-WH

  • Page 1 Network Dome Camera CA-2240V-WH Quick Start Guide...
  • Page 2 Network Dome Camera·Quick Start Guide Quick Start Guide About this Manual This manual is applicable to Network Dome Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Dome Camera·Quick Start Guide FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Network Dome Camera·Quick Start Guide 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
  • Page 5 Network Dome Camera·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 6 Network Dome Camera·Quick Start Guide according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket.
  • Page 7 Network Dome Camera·Quick Start Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C to +60°C, or -40°C to +60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation.

  • Page 8: Table Of Contents

    Network Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............8 2 Installation ..................10 Memory Card Installation ..........11 Mounting Preparation ........... 11 2.3 Camera Mounting ............13 2.3.1 Ceiling Mounting ............. 13 2.3.2 Wall Mounting ............19 2.3.3 Pendant Mounting ...........

  • Page 9: Appearance Description

    Network Dome Camera·Quick Start Guide 1 Appearance Description The overview of the network dome camera is shown below. Figure 1-1 Overview of Dome Camera...
  • Page 10 Network Dome Camera·Quick Start Guide Table 1-1 Overview of Dome Camera Description Description Bubble Junction box Alarm input/output Sealing plugs Audio input/output Lens RJ45 Ethernet port (PoE) Reset button Power interface (12 VDC) Memory card slot Video Out (BNC) Grounding screw Notes: ●...

  • Page 11: Installation

    Network Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC or PoE (802.3af). Make sure your power supply matches with your camera.

  • Page 12: Memory Card Installation

    Network Dome Camera·Quick Start Guide Memory Card Installation Steps: 1. Unscrew the memory card slot cover. Memory Card Cover Install Memory Card Figure 2-1 2. Insert the memory card into the memory card slot, and push to get it mounted. 3.
  • Page 13 Network Dome Camera·Quick Start Guide Steps: 1. Lift the camera body to separate the junction box and the adapter plate. 2. Separate the junction box and the adapter plate. 3. Unscrew the bubble. Bubble Junction Adapter Plate Disassemble the Camera Figure 2-2...

  • Page 14: Camera Mounting

    Network Dome Camera·Quick Start Guide Camera Mounting 2.3.1 Ceiling Mounting Before you start: Plan the cable routing before installation. This camera series supports cable-routing through the ceiling and through side outlet. ● Through the ceiling: you should cut a hole in ceiling and route the cables in advance.
  • Page 15 Network Dome Camera·Quick Start Guide 2. (Skip if not needed) Route cables through a conduit. Screw the supplied conduit joint to the conduit. Connect the Conduit Joint to Conduit Figure 2-4 Fit the adapter plate into the conduit joint. Install the Conduit Figure 2-5 3.
  • Page 16 Network Dome Camera·Quick Start Guide Thread cables through the sealing plugs. Note: For RJ45 network interface, use supplied cable routing tool. Sealing Plug Cable Routing Tool Route RJ45 Network Interface through Sealing Plug Figure 2-6 Junction Box Route Cables through Junction Box Figure 2-7...
  • Page 17 Network Dome Camera·Quick Start Guide 5. Align the “FRONT” marks on junction box and adapter plate. Secure the junction box to adapter plate with three screws. Install Junction Box Figure 2-8 6. Hang the camera body on the safety rope. 7.
  • Page 18 Network Dome Camera·Quick Start Guide 8. Fix the camera body to the junction box with three screws. Fix the Camera Body Figure 2-10 9. Adjust surveillance angle. Use supplied BNC video out cable to connect the camera to a monitor. Power on the camera to obtain live image of the camera.
  • Page 19 Network Dome Camera·Quick Start Guide Connect Video Out Figure 2-11 Hold the lens to adjust the panning, tilting, and rotating position. Pan: 0° to 355° Rotate: 0° to 355° Tilt: 0° to 75° Adjust Surveillance Angle Figure 2-12...

  • Page 20: Wall Mounting

    Network Dome Camera·Quick Start Guide 10. Peel off the protective films and screw the bubble back to the camera body. 2.3.2 Wall Mounting Before you start: Wall mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. The wall mounting bracket shown below is only for demonstration.

  • Page 21: Pendant Mounting

    Network Dome Camera·Quick Start Guide 4. Route the cables through the cable hole on adapter plate and secure the adapter plate to the cap. Install Adapter Plate to Bracket Figure 2-14 5. Repeat step 4 to step 10 of Section 2.3.1 Ceiling Mounting to complete camera installation.
  • Page 22 Network Dome Camera·Quick Start Guide Fixing Screw Install the Pendant Mounting Bracket Figure 2-15 3. Align the screw holes of the adapter plate with the correspondent screw holes of the cap. 4. Route the cables through the cable hole on adapter plate and secure the adapter plate to the cap.

  • Page 23: Setting The Network Camera Over The Lan

    Network Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 24: Activating The Camera

    Network Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 25: Activation Via Sadp Software

    Network Dome Camera·Quick Start Guide Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 26 Network Dome Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 27: Modifying The Ip Address

    Network Dome Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 28 Network Dome Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Note: You can enable the Guarding Vision service for the device during activation.

  • Page 29: Accessing Via Web Browser

    Network Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 8.0 and above version, Mozilla Firefox 30.0 to 51, and Google Chrome 31.0 to 44.
  • Page 30 Network Dome Camera·Quick Start Guide 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 31: Operating Via Guarding Vision App

    Network Dome Camera·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models. Enable Guarding Vision Service on Camera Purpose: Guarding Vision service should be enabled on your camera before...

  • Page 32: Enable Guarding Vision Service Via Web Browser

    Network Dome Camera·Quick Start Guide “Privacy Policy” Service” Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 33 Network Dome Camera·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Platform Access Configuration (Web) 3. Select Platform Access Mode as Guarding Vision. 4.

  • Page 34: Guarding Vision Setup

    Network Dome Camera·Quick Start Guide Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching “Guarding Vision” in App Store or Google Play 2. Launch the app and register for a Guarding Vision user account. 3. Log in Guarding Vision app after registration. Adding Camera to Guarding Vision Before you start: You need to enable the Guarding Vision service on camera before...
  • Page 35 Network Dome Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 36: Initializing The Memory Card

    Network Dome Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
