- Page 1 X12 SATA Product Manual Standard 512E models ST12000NM0007 Self-Encryption 512E models ST12000NM0017 100828036, Rev. C April 2020...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Raid Rebuild and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 31 Seagate Exos X12 SATA Product Manual, Rev. C...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM and Distribution partner and Seagate reseller portal, visit: http://www.seagate.com/partners Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 6: Introduction
• Supports latching SATA cables and connectors. • Top Cover Attached motor for excellent vibration tolerance • Worldwide Name (WWN) capability uniquely identifies the drive. Seagate recommends validating the configuration with the selected HBA/RAID Note controller manufacturer to ensure use of full capacity is supported. -
Page 7: About The Serial Ata Interface
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 8: Drive Specifications
Non-Operational Shock (max at 2 ms - typical) 250 Gs 5–22 Hz: 0.25 Gs, Limited displacement Vibration, operating 22–350 Hz: 0.50 Gs 350–500 Hz: 0.25 Gs Operation Rotational vibration 20–1500Hz: 12.5 rads/s² Vibration, nonoperating 2–500 Hz: 2.27 Grms ref Seagate Exos X12 SATA Product Manual, Rev. C... - Page 9 *One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Exos X12 SATA Product Manual, Rev. C...
-
Page 10: Formatted Capacity
Sustained data transfer rate (MiB/s max) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 20/30 Standby to Ready (sec) (typ/max) 20/30 Ready to spindle stop (sec) (max) Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 11: Power Specifications
0.769 0.322 7.71 Maximum DC (peak) 0.912 1.824 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 12: Conducted Noise
800 mV pp from 100 Hz to 8 KHz. 450 mV pp from 8 KHz to 20 KHz. 250 mV pp from 20 KHz to 5 MHz. 2.5.3 Voltage tolerance Voltage tolerance (including noise): 5V ± 5% 12V ± 10% Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 13: Extended Power Conditions - Powerchoicetm
• Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T. Read Data Reports • Attribute 192 - Emergency Retract Count • Attribute 193 - Load/Unload Cycle Count Seagate Exos X12 SATA Product Manual, Rev. C... - Page 14 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Exos X12 SATA Product Manual, Rev. C...
-
Page 15: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. Temperature Check Point Figure 2. -
Page 16: Shock
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 2–500 Hz 2.27 Grms ref Linear Random Freq (Hz) .001 .001 Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 17: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 18: Reliability
The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives. Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 19: Reference Documents
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 20: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure Figure 3. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Exos X12 SATA drives support latching SATA connectors. Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 21: Drive Mounting
MAX TORQUE 6 IN/LBS 1.028 MAX 26.11MM .138±.015 2 2.000 C L OF DRIVE Figure 4. Mounting configuration dimensions The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 22: About Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two ATA commands: •... -
Page 23: Random Number Generator (Rng)
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: The download must be an SED file. -
Page 24: Power Requirements
The drive shall not support the OVERWRITE EXT and BLOCK ERASE EXT sub-commands. Support of the SANITIZE FREEZE LOCK EXT command shall be determined on a customer-specific basis. OEM drives shall support the command. Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 25: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane config- uration. All used voltage pins (V ) must be terminated. Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 26: Supported Ata Commands
Sanitize Device - Crypto Scramble / 0011 Sanitize Device - Freeze Lock Ext / 0020 Sanitize Device - Status Ext / 0000 Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Seagate Exos X12 SATA Product Manual, Rev. C... - Page 27 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Exos X12 SATA Product Manual, Rev. C...
-
Page 28: Identify Device Command
Advanced PIO modes supported (modes 3 and 4 supported) 0003 Minimum multiword DMA transfer cycle time per word (120 ns) 0078 Recommended multiword DMA transfer cycle time per word (120 ns) 0078 Seagate Exos X12 SATA Product Manual, Rev. C... - Page 29 If bit 0 is set to one, then the device supports SCT Command Transport. xxBD Bits 7:2 indicate individual SCT feature support. 207-254 ATA-reserved 0000 Integrity word xxA5 See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate Exos X12 SATA Product Manual, Rev. C...
- Page 30 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Exos X12 SATA Product Manual, Rev. C...
-
Page 31: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Exos X12 SATA Product Manual, Rev. C... -
Page 32: S.m.a.r.t. Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Exos X12 SATA Product Manual, Rev. C... - Page 33 Seagate Technology LLC AMERICAS Seagate Technology LLC 47488 Kato Road, Fremont, California 94538, United States, 510-661-1000 Publication Number: 100828036, Rev. C April 2020...
