FETCO Hot Tea Brewer Extractor
Description & Features:
-Low profile
-High-Volume hot tea brewer with hot water bypass feature
-Eight programmable recipes: Factory set with two user adjustable permanent recipes
-Six additional recipes may be optionally programmed or hidden
-Individual recipe temperatures can be set by use
-Hot water tank recovers rapidly and may be quickly lowered for specialty recipe temperature with "PURGE" function
-Fully serviceable from the front
THE FOLLOWING CAN BE ACCESSED AND PROGRAMMED:
-BATCH SIZE & BYPASS [Hot Water Bypass] Infinitely variable-factory set at 4.0 liter brew/34% hot water bypass.
-BREW TEMPERAURE
-PURGE TO LOWER BREW TEMPERATURE: OPTIONAL SELECTION! Operator may use PURGE touch key.
Holding the key for the maximum five seconds releases 150 cc/4 fl.oz hot tank water to reduce brew temperature.
-PULSE BREW: Using information entered, the software calculates how much water to dispense for brew and for hot
water "bypass". The total dispense time is divided into on/off cycles that dispenses the exact volume of water and
pauses to drain the brew basket. Pulse brew can be set by the operator. Factory set is four on/off fill/drain cycles.
Controls automatically cycle valves to dispense the correct amount of water set in the recipe.
-RECIPES are all adjustable. Recipes 1&5 are permanent; recipes 2, 3, 4, 6, 7, 8 can be programmed or hidden.
See pages 6-13 for programming, adjustments and calibration.
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047-0429 • USA
Product made in USA
INTERNET: www.fetco.com
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
©2016-2020 FOOD EQUIPMENT TECHNOLOGIES COMPANY
HOT TEA BREWER TBS-2111
User's Guide & Operator Instructions
TBS-2111
fetco.com
®
Touch Screen Models
PHONE: (800) 338-2699 (US & CANADA)
(847) 719-3000 (All Countries and International)
FAX:(847) 719-3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupport@fetco.com (all service queries)
P152 rev.003 August 2021
Advertisement
Table of Contents
Related Manuals for Fetco TBS-2111
Summary of Contents for Fetco TBS-2111
- Page 1 (847) 719-3000 (All Countries and International) 600 ROSE ROAD FAX:(847) 719-3001 LAKE ZURICH • IL • 60047-0429 • USA EMAIL:sales@fetco.com Product made in USA orders@fetco.com (to order parts and equipment) INTERNET: www.fetco.com fetco.com techsupport@fetco.com (all service queries) PATENTS:https://www.fetco.com/pl,pages,patents,74.html P152 rev.003 August 2021 ©2016-2020 FOOD EQUIPMENT TECHNOLOGIES COMPANY...
-
Page 2: Table Of Contents
Temperature Control—as set by factory: 90°C inside hot water tank (at sea level). -RANGE User selectable: 77-97°C/170°-207°F -Brew Temperature may be individually set for each of the eight recipes. Coffee Filter Size: 15” X 5 ½ ”– standard FETCO # F001... -
Page 3: Operational Description
Touch for 2-3 seconds to begin brew. 90°C 90°C ] 6.00L ] 6.00L Have container under brew funnel ¯ ¯ 90°C <5 sec Go to fetco.com for the latest versions of all information Page 3 User Guide & Operator instructions P152 rev.003 August 2021... - Page 4 User can determine any bypass delay At 0:00, recipe screen will refresh See following page for programming Icons shown for factory set recipe #1 Go to fetco.com for the latest versions of all information Page 4 User Guide & Operator instructions P152 rev.003 August 2021...
-
Page 5: Instructions To Access The Programming Menu
<Screen Contrast> <Firmware Version> Batch 7 DEMO Mode <Batch ON/OFF> Batch 8 Password <Batch ON/OFF> Batch Copy <Copy From B.> Go to fetco.com for the latest versions of all information Page 5 User Guide & Operator instructions P152 rev.003 August 2021... -
Page 6: Program
1:30 mm:ss |_____ ___________| basket during drip-out Safety Feature 0:30 10:00 • Alarm at End |______________ YES ……… NO Go to fetco.com for the latest versions of all information Page 6 User Guide & Operator instructions P152 rev.003 August 2021... - Page 7 Touch the purge icon for 5 90°C 90°C sec. This will lower hot water tank temperature 3-4 90°C 90°C degrees 90°C 90°C 90°C 90°C Go to fetco.com for the latest versions of all information Page 7 User Guide & Operator instructions P152 rev.003 August 2021...
-
Page 8: General
Temperature Probe SD Card If Yes: Calibrate Follow directions Cal. Touch Scr Calibrate ________________[]____ on the touch screen Go to fetco.com for the latest versions of all information Page 8 User Guide & Operator instructions P152 rev.003 August 2021... - Page 9 Press To Test • Buzzer Test TEST Use for servicing. Screen Contrast • Screen Contrast |____________[]____| • S. Brightness Brightness |____________[]____| Go to fetco.com for the latest versions of all information Page 9 User Guide & Operator instructions P152 rev.003 August 2021...
-
Page 10: How To Calibrate The Flow Rate
A 3 liter/1 gal BREW valve. measuring container is recommended. Calibration must be repeated for the BYPASS valve Go to fetco.com for the latest versions of all information Page 10 User Guide & Operator instructions P152 rev.003 August 2021... - Page 11 <. Calibrate/Test .> shown—scroll through the positions with the right/left arrows. TBS-2111 Test automatically calibrates based on the flow entered. The highlighted FLOW RATE is used to enter the flow rate and for Service and to fine tune the flow »...
- Page 12 .> Calibrate/Test and Flow Rate. To access these: with the 3 level highlighted as Test shown—scroll through the positions with the right/left arrows. TBS-2111 » automatically calibrates based on the flow volume entered. The highlighted FLOW « RATE is used to enter the flow rate and for Service and to fine tune the flow Scroll down to “Cal...
-
Page 13: Other
SETUP. new password The new password cannot -see note. be defeated or reset. Go to fetco.com for the latest versions of all information Page 13 User Guide & Operator instructions P152 rev.003 August 2021... -
Page 14: Error Codes
This is a SAFETY FEATURE ! Never attempt to remove a brew basket-during brew-this is a safety feature Go to fetco.com for the latest versions of all information Page 14 User Guide & Operator instructions P152 rev.003 August 2021... - Page 15 5. Do not attempt to move hot beverage equipment once it is filled. Drain equipment before moving. 6. FETCO commercial coffee brewers prepare large amounts of coffee or tea in a single batch using very hot water 7. Commercial coffee brewers provide very hot water from the spray head, brew basket and faucet when it is pulled.
- Page 16 4. Brewers in this series wire differently in regards to a neutral wire. Review the wire diagrams. 5. The electrical diagram is located in the User’s Guide and online at www.fetco.com. 6. Make sure of the tight grounding of the equipment and use the external ground bolt.
- Page 17 Do not operate if unit has been submerged or saturated with water. Labels and warnings for hot beverage equipment For BACK PANEL of equipment 1046.00035.00 Go to fetco.com for the latest versions of all information Page 17 User Guide & Operator instructions P152 rev.003 August 2021...
-
Page 18: Parts Drawings And Wiring Diagrams
Parts Drawings and Wiring Diagrams Go to fetco.com for the latest versions of all information Page 18 User Guide & Operator instructions P152 rev.003 August 2021... - Page 19 LABEL, WARNING, "HOT WATER FAUCET" Ref. B020000G2 BREW BASKET ASS'Y., TBS-2111, GREEN HANDLE PLUG-STANDARD Ref. B022000G1 Stainless Steel Brew Basket TBS-2111 16" X 6", Green Handle-OPTIONAL Ref. 1063.00030.00 CORD PWR, 16A/250VAC, EU1-16P PLUG, W/O Ref. 1063.00011.01 POWER CORD, AUSTRALIAN 15A 250V, 2.5M LG. W/O TERMINALS Ref.
- Page 20 1081.00042.00 STANDOFF, 1/4" HEX 1044.00004.00 LABEL, DANGER, HIGH VOLTAGE 1022.00101.00 BACK INSULATION, TANK, TBS-2111 1022.00102.00 FRONT INSULATION, TANK, TBS-2111 Go to fetco.com for the latest versions of all information Page 20 User Guide & Operator instructions P152 rev.003 August 2021...
- Page 21 10:30 minutes: seconds 0.125 8:10 minutes: seconds 0.140 6:30 minutes: seconds 0.180 3:30 minutes: seconds 0.280 1:20 minutes: seconds Go to fetco.com for the latest versions of all information Page 21 User Guide & Operator instructions P152 rev.003 August 2021...
- Page 22 OPTIONAL Stainless Steel Brew Basket (OPTIONAL) Ref# Part Number Description B022000G1 Complete TBS-2111 brew basket 16" X 6", GREEN HANDLE 1112.00505.00 BB WELDMENT, 16"x6", WITH FORMED HOLE, TBS-2111 1102.00066.00 HANDLE W/MAGNET ASSEMBLY, GREEN RUBBER Optional colored 1102.00065.00 HANDLE W/MAGNET ASSEMBLY, RED...
-
Page 23: Hot Water Faucet Installation Instructions
Factory configured for 7 inch dispenser To Configure for wider dispensers: Remove screw and 7 inch adapter as shown Go to fetco.com for the latest versions of all information Page 23 User Guide & Operator instructions P152 rev.003 August 2021... - Page 24 End of section notes...
