1. Prepare the Window
Lower sash must
Side louvers and the rear of the AC must have clear air space to allow enough air ow through the
condenser for heat removal. The rear of the unit must be outdoors, not inside a building or garage.
Mounting Hardware
Lock Frame
(For Wooden windows)
(2)
3/4'' (or 1/2")
Screws
(7)

2. Prepare the Air Conditioner

Before installing the unit, the top rail must be assembled on the unit for some models with a capacity of
less than 1000BTU/h.
B: Remove top rail from the packaging material as shown in Fig. D.
Top Rail Hardware
3/8" Screws
(4)
Packaging
Page 16
to allow a clear vertical opening (see dimension H in Table 1).
Lock Frame
(For Vinyl-Clad windows)
(2)
Weather stripping
10"*3/4"*1/12"
(5)
Top Rail
(1)
Fig. D
Fig. D
Top Rail
NOTICE
Weather stripping is only for
ENERGY STAR models only.
Sash Lock
(1)
Window sash
seal foam
(1)
at surface.
Top Rail
