HPE LSWM2XGT2PM Interface Card
(JH156A) User Guide
Part number: 5998-7834s
▌Introduction
Product
code
JH156A
Overview
The LSWM2XGT2PM interface card provides two 1/10GBase-T
Ethernet ports.
Figure 1 LSWM2XGT2PM interface card
(1) 1/10GBase-T Ethernet
port LED
(3) Captive screw
HPE description
HPE 5130/5510 10GBASE-T
2-port Module
(2) 1/10GBase-T Ethernet port
(4) Ejector lever
1
Alias
LSWM2XGT2PM
Advertisement
Related Manuals for HP HPE LSWM2XGT2PM
Summary of Contents for HP HPE LSWM2XGT2PM
- Page 1 HPE LSWM2XGT2PM Interface Card (JH156A) User Guide Part number: 5998-7834s ▌Introduction Product HPE description Alias code HPE 5130/5510 10GBASE-T JH156A LSWM2XGT2PM 2-port Module Overview The LSWM2XGT2PM interface card provides two 1/10GBase-T Ethernet ports. Figure 1 LSWM2XGT2PM interface card (1) 1/10GBase-T Ethernet...
- Page 2 NOTE: The switch models that the LSWM2XGT2PM interface card are applicable to may change over time. For the most recent list of applicable switch models, contact HPE Support or marketing staff. 1/10GBase-T Ethernet ports Table 1 1/10GBase-T Ethernet port specifications Item Specification Connector type...
-
Page 3: Installing And Removing An Interface Card
LED status Description Flashing yellow The port is sending or receiving data at 1 Gbps. No link is present on the port. NOTE: The 1/10GBase-T port LEDs are not affected by the port mode switching button on your switch. For more information about the port mode switching button, see the installation guide of the switch. - Page 4 2. Insert the flat blade screwdriver through the handle on the filler panel to pull out the filler panel, as shown by callout 2 in Figure Figure 2 Removing a filler panel NOTE: Keep the removed screw and filler panel secure for future use. Installing an LSWM2XGT2PM interface card 1.
-
Page 5: Removing An Interface Card
Figure 3 Installing an LSWM2XGT2PM interface card Removing an interface card CAUTION: • Before you remove an interface card, remove the cable from it. • After removing an interface card, if no new interface card is to be installed, install the filler panel as soon as possible to prevent dust and ensure good ventilation in the device. -
Page 6: Verifying The Installation
Figure 4 Removing an LSWM2XGT2PM interface card Verifying the installation After the installation is complete, identify whether the interface card is operating correctly according to the status of the 1/10GBase-T port LEDs. If the interface card fails to operate correctly, perform the following steps: 1.
