- Page 1 DISHWASHER DW60FC2W1 FP AA PRODUCT CODE: 81635-B PARTS MANUAL...
-
Page 2: Table Of Contents
CONTENTS Introduction Chassis & Tub components Basket components Spray Arm components Base & flood components Door components... -
Page 3: Introduction
MODEL PRODUCT CODE Fisher & Paykel 230-240VAC 50Hz DW60FC2W1 FP AA 81635-B MODELS The models covered by this manual are listed on the front cover. The information detailed in this manual is subject to change without notice. The latest version is indicated by the reprint date and replaces any earlier editions. -
Page 4: Chassis & Tub Components
CHASSIS & TUB COMPONENTS DWG 005238... - Page 5 CHASSIS & TUB COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION H0120300248 GASKET TUB H0120100582 PANEL SIDE LH WHITE PLUG H0120200393 COMPLETE TOP ASSY WHITE H0120802919 DOOR LOCK/HOOK ASSEMBLY H0120801601 HOUSING THERMO DRY H0120802341 GASKET SEALING H0120200605 HOSE THERMO DRY H0120200604 SUPPORT CROSSPIECE UPPER REAR H0120201556 FELT SOUND DEADENING SIDE/TOP H0120300074...
-
Page 6: Basket Components
BASKET COMPONENTS DWG 004248... - Page 7 BASKET COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION MID RAIL SUPPORT H0120802832A MID RAIL-LEFT H0120802954 MID RAIL-RIGHT H0120802949 MID RAIL STOP BACK H0120201502 UPPER BASKET H0120803057A HANDLE FRONT ASSY H0120803302 HANDLE BACK H0120201179B CUP RACK H0120201180 H0120201180B CUP RACK SUPPORT-LEFT CUP RACK SUPPORT-RIGHT H0120201180C LIFTING MECHANIC-LEFT H0120802976...
-
Page 8: Spray Arm Components
SPRAY ARM COMPONENTS DWG 005235... - Page 9 SPRAY ARM COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION WEIR INCL FLOW METER H0120801702A O-RING GASKET WEIR H0120200382 NUT BREATHER RING WEIR H0120200401 HOSE DRAIN (LONG) H0120200643 SPRAYER 3RD H0120201003 O RING GASKET H0120301022 UPPER SPRAY BASE H0120202701 CLAMP HOSE H012G1040020 H0120200543C HOSE TOP SPRAYER SECOND SPRAYER ASSEMBLY...
- Page 10 SPRAY ARM COMPONENTS DWG 005235...
- Page 11 SPRAY ARM COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION DRAIN PUMP H0120400050B FRAME NON-RETURN VALVE H0120200374 FLAP NON-RETURN VALVE H0120200373 SENSOR TEMP/TURBIDITY (EMZ) H0120400076 CLAMP DRAIN HOSE H0120600024 HOSE DRAIN (SHORT) H0120200672 HOSE H0120200543B COVER FOR SUMP H0120200396 H0120200764 O RING GASKET CLAMP HOSE H0120600020 FIRE BLANKET...
-
Page 12: Base & Flood Components
BASE & FLOOD COMPONENTS DWG 004240... - Page 13 BASE & FLOOD COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION BASEBOARD WH H0120201298 FOOT FRONT FREESTANDING H0120200766 FRONT FOOT SUPPORT H0120100851 PLATE PLASTIC OVERFLOW H0120200365 CROSSPIECE LOWER FRONT H0120100829 HOSE OVERFLOW PLATE H0120200635 TRAY BOTTOM BASE H0120100239 FLOAT H0120505219A SUPPORT FOR FLOAT H0120202056C MICRO SWITCH FLOAT SWITCH H012G6050040...
-
Page 14: Door Components
DOOR COMPONENTS DWG 004241... - Page 15 DOOR COMPONENTS REFERENCE PART NUMBER PART DESCRIPTION DOOR PANEL WHITE LOGO H0120101019B DISPLAY PANEL H0120201256B CONTROL PANEL DW60FC WHT H0120803030 COVER DISPLAY H0120201295 BOX DISPLAY BOARD H0120201324 COVER BUTTON H0120201326 DISPLAY BOARD H0121800094A COVER BOX DISPLAY BOARD H0120201327 COVER DISPENSER H0120202582 DOOR SWITCH H0120801599...
- Page 16 FISHERPAYKEL.COM © Fisher & Paykel Appliances Ltd 2019. All rights reserved. The product specifications in this document apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this document correctly describes the product currently available.
