QUICK START GUIDE
DISHWASHER - DW60FC6 MODELS
For detailed information on the
features of your dishwasher
For warranty information
If you...
have any questions or comments
●
need a Fisher & Paykel authorized
●
technician to service your product
need replacement parts or accessories
●
want to register your product
●
PRODUCT OVERVIEW
Cutlery tray
Upper basket
Lower basket
Door seal
Serial label
CONTROLS OVERVIEW
F
H I J
K L
G
M
E
A B C D
Controls Description
A Off/On
Press to turn the dishwasher on or off.
Half load selector 1/2
Press and hold for a second until you hear
a beep. The half load indicator will come on.
B
Wash programme selector
Press to scroll through the wash
programmes.
C Wash modifier selector
Press to scroll through the wash modifier
options. (See 'Setting wash modifiers')
see your 'User guide'
see your 'Service and warranty' booklet
see your 'Service and warranty' booklet or contact us
NZ toll-free, 24/7 0800 372 273
AU toll-free, 24/7 1300 650 590
www.fisherpaykel.com
Make sure the installer has removed all packaging and
completed the 'Final checklist' in the Installation instructions.
Upper spray arm
Centre spray arm
Lower spray arm
Filters
Detergent
and rinse aid
dispensers
D Start F Wash program indicators
Press once to start the wash. These show which programme is
To pause: selected.
Press again or open the door
carefully. G Half load indicator
If lit: half load function is activated
Delay start
Press and hold the button for a
H
Wash modifier indicators
second to enter delay start.
If lit: wash modifer is activated
(See 'Setting delay start')
I
Display
E
Keylock
This shows:
Keylock disables all the buttons so
●
- the time remaining (minutes)
that a wash cannot accidentally be
- the delay start time (hours)
started.
- Fault code numbers
Keylock can be activated or canceled
●
(see section 'If there is a fault code')
at any stage, including while a wash
programme is running.
J Wash progress indicators
To activate:
Shows the stage of the wash cycle
Press and hold and together
currently in progress.
for a second until you hear a beep.
The keylock indicator will come
K Keylock indicator
on and remain lit until keylock is
If lit: keylock is activated.
canceled.
L Rinse aid indicator
To cancel:
If lit: Rinse aid dispenser requires
Press and hold and together
filling.
for four seconds until you hear a
beep. The keylock indicator will flash
M
Delay start indicator
and then go out.
If lit: start is delayed.
USING YOUR DISHWASHER – QUICK REFERENCE
Starting a wash
NZ AU
1 Discard food scraps and load dishes
carefully
Scrape large food particles off (e.g.
●
bones, fruit stones) and remove any
foreign objects (e.g. toothpicks, strings,
paper).
To help with wash performance, arrange
●
dishes so they are evenly spaced and
not nesting.
For more detail, see user guide:
'Caring for your dinnerware'
'Loading'
Spray arm
5 Check that nothing obstructs the spray
arms, then close the door firmly
8 Start wash
Press to start the wash programme
●
OR set Delay start
Press and hold for a second to enter
●
delay start. Press and hold again to
increase the time (in hours).
For more detail, see user guide:
'Setting Delay start'
To cancel a wash once it has started
Press to cancel the programme.
●
--- will show in the display, then the
wash progress indicators will go out and
the display will turn off.
If you wish, you can start a different
●
programme.
Note: you may need to refill the
detergent dispenser.
2 Add detergent 3 Turn power on
(also check water is turned on)
Fill the detergent dispenser with
●
powdered detergent and close the For more detail, see user guide:
dispenser door or place a dishwasher
'Controls and starting a wash'
tablet in the cutlery basket.
4 Check rinse aid level, refill if necessary
For more detail, see user guide:
If the rinse aid level is low, the rinse aid
●
'Water hardness and dishwashing'
indicator on the display will light up.
'Wash programmes and detergent
●
quantities'
'Adding detergent'
●
●
For more detail, see user guide:
'Using rinse aid'
Auto
Heavy
Normal
(Default)
Normal
Eco
6 Select wash programme Fast
Press to scroll through the wash
●
Delicate
programmes.
7 Select wash modifiers (optional)
Rinse
Press to scroll through the wash
●
modifier options
not all modifiers are available for
●
every wash programme
only one modifier can be set at a time
●
For more detail, see user guide:
●
'Setting wash modifiers'
After the wash has ended
To pause and restart a wash
programme
Press to pause the programme.
●
The programme status (eg Wash) will
●
flash while the dishwasher is paused.
Open the door very slowly.
IMPORTANT!
9 The dishwasher will beep. The display
There is a risk of being sprayed with
hot water. Do not fully open the door will show
until the spray arms have stopped display will turn off.
rotating.
!0 Open the door slightly and leave ajar to
Load, remove, or rearrange any dishes
●
help drying. Once cooled, unload dishes
if needed.
carefully
Press to restart the programme.
●
For more detail, see user guide:
If the dishwasher is not restarted
'After the wash'
within 7 minutes, it will then beep
Check condition of dishwasher, clean if
●
until the cycle is restarted.
necessary
Rinse aid level indicator
Press the button to snap the
dispenser cover open
Pour rinse aid into the circular
opening (up to the MAX marking)
Wipe up any spills and click shut the
cover.
Senses the optimal wash programme for
your dishes
Heavily soiled pots, pans and dishes.
Dishes with normal soils for optimum
wash and dry performance
Dishes with normal soils for optimum
energy and water usage
A fast wash for lightly soiled dishes
For lightly soiled and heat sensitive
crockery
Prevents odours and soils from drying
on dishes
0
. After 30 seconds the
