- Page 1 Introduction Safety notes Description SIMATIC NET Mounting Industrial Ethernet switches Power supply unit PS598-1 for Connection SCALANCE XR-500 Upkeep and maintenance Compact Operating Instructions Technical data Dimension drawings Approvals 02/2023 A5E03275848-05...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Table of contents Introduction ............................5 Security information ......................5 Safety notes ............................7 Description............................. 9 Product characteristics ......................9 Unpacking and checking ....................10 Mounting ............................. 11 Safety notices for installation ..................... 11 19" rack mounting of the PS598-1..................11 Mounting the PS598-1 on the rear panel of an XR500............ - Page 4 Table of contents Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 5: Introduction
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed under https://www.siemens.com/cert (https://www.siemens.com/cert). Device defective If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are not possible. Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05... - Page 6 2012/19/EU for the disposal of electrical and electronic equipment. Do not dispose of the products at public disposal sites. For environmentally friendly recycling and the disposal of your old device contact a certified disposal company for electronic scrap or your Siemens contact (Product return (https:// support.industry.siemens.com/cs/ww/en/view/109479891)).
-
Page 7: Safety Notes
Safety notes CAUTION To prevent injury and damage, read the manual before using the device. Safety notices on the use of the devices The following safety notices must be adhered to when setting up and operating the device and during all work relating to it such as installation, connecting up, replacing devices or opening the device. - Page 8 Safety notes Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 9: Description
Description Product characteristics Power supply units Type Power Input voltage Output voltage Article number PS598-1 300 W 100 to 240 VAC 24 VDC 6GK5 598-1AA00-3AA0 Note Two connectors for the 24 VDC output voltage The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can only use one connector on the front or the connector on the rear of the PS598-1. -
Page 10: Unpacking And Checking
2. Check all the parts for transport damage. If the consignment is incomplete or if there is damage to the exterior, contact your supplier or your local Siemens office. Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05... -
Page 11: Mounting
Mounting Safety notices for installation NOTICE Damage to the device due to inadequate cooling If the ventilation slits are fully or partly covered, the temperature inside the housing can rise and exceed the maximum permitted temperature causing damage to the device. The ventilation slits are located on the side panels of the housing. -
Page 12: Mounting The Ps598-1 On The Rear Panel Of An Xr500
Mounting 4.3 Mounting the PS598-1 on the rear panel of an XR500 Procedure Figure 4-1 19" rack mounting of the power supply unit To mount the PS598-1 power supply unit in a 19" rack, follow the steps below: 1. Secure the two mounting brackets with four screws each (M3 x 6 supplied with the product) ①... - Page 13 Mounting 4.3 Mounting the PS598-1 on the rear panel of an XR500 Procedure Figure 4-2 Rear panel mounting of the SCALANCE XR552-12M. SCALANCE XR528-6M is used analogously. On the rear panel of an IE switch, there are sockets for the direct connection of a maximum of two PS598-1 power supply units.
- Page 14 Mounting 4.3 Mounting the PS598-1 on the rear panel of an XR500 Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 15: Connection
Connection Connecting devices with 100 to 240 VAC power supply Switches for the input voltage ① ③ The socket X1 (position ) and the switch S1 Power (position ) for the input voltage are located on the right-hand side of the front panel of the housing: ①... - Page 16 Connection 5.1 Connecting devices with 100 to 240 VAC power supply NOTICE Reliable grounding Reliable grounding of the devices mounted in the rack must be guaranteed. This applies, in particular, to power supply cables that are not connected directly to the power supply circuit. With the PS598-1 power supply unit, the IEC power connector (IEC 60320-1) provides the connection to protective earth.
- Page 17 Connection 5.1 Connecting devices with 100 to 240 VAC power supply Contact Assignment +24 VDC Ground One PS598-1 per device, no redundancy Figure 5-4 Connecting a power supply unit to a SCALANCE XR552-12M. SCALANCE XR528-6M is used analogously. Connect the IE switch and the PS598-1 with one cable for 24 VDC and a cable for ground. As an alternative, you can also mount the PS598-1 on the rear of the IE switch and secure it with screws.
- Page 18 Connection 5.1 Connecting devices with 100 to 240 VAC power supply Three PS598-1 units for two devices - 2-out-of-3 redundancy Figure 5-6 Connecting three power supply units to a SCALANCE XR552-12M. SCALANCE XR528-6M is used analogously. Connect each IE switch to its own PS598-1. In addition to this, connect both IE switches to the third PS598-1.
-
Page 19: Led Display
Connection 5.2 LED display LED display LED display A PS598-1 has two LEDs each, one green and one red. If the green LEDs is lit (24V OK), the output voltage is correctly applied. If the red LED is lit (SHUT DOWN) an error has occurred. Possible errors/faults: •... - Page 20 Connection 5.2 LED display Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 21: Upkeep And Maintenance
Upkeep and maintenance The PS598-1 has a service panel, behind which there is a removable air filter. The air filter can be replaced during operation. Procedure 1. Open the service panel. 2. Take the air filter out of the device. 3. - Page 22 Upkeep and maintenance Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 23: Technical Data
Technical data Device variants The following technical specifications apply to the following device: • PS598‑1 Connectors Interface Execution Power • 4-pin terminal block for 2 x 24 VDC on the front of the device. • Plug on the rear of the housing for direct connection to a SCALANCE XR500. - Page 24 Technical data Environmental conditions Property Value Transportation/storage temperature -40 °C to +85 °C Operating temperature 0 °C to +60 °C Maximum relative humidity < 95 % no condensation in operation at 25 °C Operating altitude above sea level de‐ • 2000 m at max.
-
Page 25: Dimension Drawings
Dimension drawings View from front and above Dimensions are specified in mm. Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05... - Page 26 Dimension drawings Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 27: Approvals
Approvals The SIMATIC NET products described in these Operating Instructions have the approvals listed below. Note Issued approvals on the type plate of the device The specified approvals apply only when the corresponding mark is printed on the product. You can check which of the following approvals have been granted for your product by the markings on the type plate. -
Page 28: Mechanical Stability (In Operation)
EC L174, 01/07/2011, pages 88-110 You will find the EC declaration of conformity for these products on the Internet pages of Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/15273/ cert). - Page 29 • "Industrial Ethernet / PROFINET Industrial Ethernet" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/27069465) • "Industrial Ethernet / PROFINET - Passive Network Components" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/84922825) • "EMC Installation Guidelines" configuration manual (https:// support.industry.siemens.com/cs/ww/en/view/60612658)
- Page 30 Approvals 9.2 Mechanical stability (in operation) Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
-
Page 31: Index
Index Modular device, 12 Overvoltage protection, 15 Power supply, 15 Power supply unit, 11, 12, 15 Power supply units, 9 Safety notices, 7 System manual, 29 Ventilation slit, 11 Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05... - Page 32 Index Power supply unit PS598-1 for SCALANCE XR-500 Compact Operating Instructions, 02/2023, A5E03275848-05...
