1.4 I/O Panel
9
No. Description
1
2.5G LAN RJ-45 Port*
2
Line In (Light Blue)**
3
Front Speaker (Lime)**
4
Microphone (Pink)**
5
USB 3.2 Gen1 Type-A Ports (USB32_45)
* There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
SPEED LED
LAN Port
Activity / Link LED
Status
Off
Blinking
On
** Function of the Audio Ports in 7.1-channel Configuration:
Port
Light Blue (Rear panel)
Lime (Rear panel)
Pink (Rear panel)
Lime (Front panel)
8
8
Description
No Link
Data Activity
Link
1
6
5
7
No. Description
6
USB 3.2 Gen1 Type-A Port (USB32_1)
7
USB 3.2 Gen1 Type-C Port (USB32_TC1)
8
HDMI Port
9
USB 2.0 Ports (USB_12)
Speed LED
Status
Description
Off
10Mbps connection
Orange
100Mbps/1Gbps connection
Green
2.5Gbps connection
Function
Rear Speaker Out
Front Speaker Out
Central /Subwoofer Speaker Out
Side Speaker Out
2
3
4
