Video Door Station with Standalone Prox Reader
The JF-DVF-XP is a color audio-video door station for Aiphone's JF-series, containing a standalone proximity card
reader with embedded host controller. Capable of storing up to 5,000 sets of credentials (cards) and operating
completely independent of an external host controller or PC, the JF-DVF-XP is ideal for all installations where reliable,
inexpensive and easy-to-manage access control is desired.
Note: Programming of the JF-DVF-XP requires Aiphone's XP-KIT Programming Starter Kit for -XP series standalone
proximity card readers.
1
NAMES & FEATURES
JF-DVF-XP
PACKAGE CONTENTS:
JF-DVF-XP
Vandal-resistant Door Station
Blank name
placard
JF-DVF-XP
- INSTRUCTIONS -
1
2
3
4
5
6
Security Driver
Semi-flush backbox &
tamper-resistant bolts
NAMES & FUNCTIONS:
1. Camera
2. Microphone
3. Name placard
FEATURES:
· Up to 5,000 credential storage (cards)
· Standalone configuration without central 'Host'
or personal computer
· Night Lock function with contact output for
controlling after hours access and alarm
system mode
· Forced Entry alarm output for triggering
external sounder or alarm system
· Optional handheld Remote Programmer for
advanced functionality
OPTIONAL ACCESSORIES:
· SBX-DVF-P – Surface-mount stainless steel
backbox
· XC5T/9 –
Blank User Card (Qty. 1)
· XRP3 –
Handheld Remote Programmer
· XP-KIT –
Programming Starter Kit,
contains:
XRP3 – Qty (1)
XC5T/9 – Qty (10)
XMMC3/9 – Qty (1)
(Note: XP-KIT is required for programming of
the JF-DVF-XP!)
4. Speaker
5. Call button
6. Standalone Prox
Reader / Controller
Pg. 1
