- Page 1 MODEL: HD56kWe external (REU-AM3237WC-ZK) INFINITY HD56kWe continuous flow water heater Installation guide...
- Page 2 Warning Improper installation, adjustment, alteration, service and maintenance can cause property damage, personal injury or loss of life. For more information about buying, using, and servicing of Rinnai appliances call: 0800 RINNAI (0800 746 624). Rinnai New Zealand Limited 105 Pavilion Drive, Mangere, Auckland...
-
Page 3: Table Of Contents
Contents ............4 Dimensions ............5 Appliance location ..........6 General installation information ......7 Water delivery temperature ........8 Water controller installation ........9 HD56kWe controller communication cables ..10 Commissioning .............11 PCB interface and dip switch settings ....12 Appliance programming parameters ....13 Before installation Unpack the appliance and check for damage. DO NOT install any damaged items. - Page 4 gas hot, water heater with inbuilt frost protection and status monitor. It has electronic ignition and requires electricity to operate. The INFINITY HD56kWe is factory preset to 55 °C, but can be set to deliver higher temperatures, up to 85 °C, making them ideal for commercial applications. Ingress protection rating •...
-
Page 5: Dimensions
Dimensions 2-5.5 x 16 2-5.5 x 24 long hole long hole 4xØ13 hole A dimension 37.4 mm Cable access (remote controller) Cold 49.2 mm Air intake Cold water inlet Cable access 40.2 mm Gas connection Cable access 28.2 mm (remote controller) Hot water outlet Service connection points inlet. -
Page 6: Appliance Location
This will avoid the appliance from failing to operate under windy IMPORTANT conditions. Rinnai recommend a maximum pipe run of 10 m. Power point can be within the pipe cover if a pipe cover is installed—must comply with AS/NZS Wiring rules. Rinnai DOES NOT serviced. -
Page 7: General Installation Information
The water heaters will operate at lower appliance can be positioned by hanging it on one screw. Once in position the appliance can Contact Rinnai for gravity fed or low pressure installations. Water chemistry and impurity limits are detailed in the operation guide within the warranty section. -
Page 8: Water Delivery Temperature
Diagram 1 - 55 °C Appliance Diagram 2 - Not a 55 °C Appliance (TLD = Temperature Limiting Device) When the Rinnai INFINITY is set to deliver water at a temperature higher than 55 °C, it will be personal hygiene. -
Page 9: Water Controller Installation
Other manufacturers water controllers are NOT compatible with Rinnai water heaters. Water controllers MUST NOT be used with any solar boost water heater. Rinnai water controllers bought in from other countries are not compatible with Rinnai appliances sold in New Zealand. -
Page 10: Hd56Kwe Controller Communication Cables
Wired water controllers operate at an extra low voltage (12 V DC) which is supplied from the water heater, a 10 m long communication cable is supplied for connection to the water heater. Only Rinnai supplied communication cables may be used. spade connectors in total) may be terminated. When attaching three or four cables it is necessary to join the cable terminators as shown below. -
Page 11: Commissioning
Inlet supply pressure MUST BE checked and set within the operating parameters of the appliance in all instances. If the appliance cannot be adjusted to perform correctly call 0800 RINNAI (0800 746 624) for assistance. Commissioning steps Flush water pipes and gas line supply lines. -
Page 12: Pcb Interface And Dip Switch Settings
PCB changeover is required. The PCB replacement and data transfer MUST BE performed by a licensed Consult the relevant Rinnai INFINITY service manual or contact Rinnai Dipswitch detail viewed from front regarding PCB changeover and data transfer. -
Page 13: Appliance Programming Parameters
70 °C 75 or 85 °C The Rinnai HD56kWe will come factory preset to 55 °C (01A + 02A), the default setting. If this needs changing, refer Table 2 above. Relates to the status of the unit should a power disruption occur. For both settings 07A and 07b, if reset to come back on when the power is restored. - Page 14 the temperature of the outgoing hot water rises more than 3 °C (default, or 6 °C if 11b) above the selected temperature shown on the digital monitor or the preset limit, when water controllers are Please note: To change menu 11, menu 21 needs to be OFF (21b). 14 EZ connect N/A to NZ, this cable is not stocked.
- Page 16 U359-0811(00) co.nz REU-AM3237(NZ) Tel: 0800 746 624 07000012393681 http://www.youtube.com/rinnainz http://facebook.com.rinnainz Rinnai INFINITY HD56kWe installation guide 01-22 Installation guide...
