Tripp Lite SRCABLERINGSM Installation Manual

Cable Management Rings for Rack Enclosures
Contents
SRCABLERINGSM
(Small)
Installation
Insert the rings into the toolless button mounts of a Tripp Lite Rack Enclosure. To ensure the cable management ring is properly
seated into the keyholes, gently tap the edge mounted closest to the cable management rail (indicated by the arrow in the
figures below) with a rubber mallet. Repeat as needed.
SRCABLERINGSM
1
2
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
Photos and illustrations may differ slightly from actual products.
Installation Guide
Models: SRCABLERINGSM, SRCABLERINGLG
