QuickStart Guide

D-575ZOOM / C-360ZOOM / X-350
START HERE
It is strongly recommended that you follow these step-by-step
numbered instructions to set up and quickly begin using your
new Digital camera.
For more detailed instructions on advanced features, please refer to
the printed Basic Manual included in your package, or the Reference
Manual on the CD-ROM.

PREPARING THE CAMERA FOR USE

Before you begin using your Olympus Digital camera...
a.
Loading the battery
Note: The batteries and xD-Picture card
compartments are accessed by opening the
respective compartment covers.
• Close the lens barrier.
• Slide the battery compartment cover to the direction of the
arrow, and lift open the cover as shown in the illustration.
• Insert the batteries into the compartment.
• Close the battery compartment cover so that it pushes the
battery in and slide the cover while pressing the
Note: If the battery compartment cover is hard to
close, do not force it. Press
to close the cover, and then slide it into position.
• To remove the batteries, make sure that the monitor and the
lamps at the side of the viewfinder are off.

TURNING ON THE CAMERA

All you need to do is slide the lens barrier open or closed to turn the camera ON or OFF.
a.
Turning the camera ON
(SHOOTING MODE)
• Slide the lens barrier open fully until it clicks. The lens extends and the subject is displayed on the monitor.
• To turn the camera off, slide the lens barrier until you feel the first click. Wait until the lens is fully retracted, then
close the lens barrier all the way.
Power on
TIP
To maximize battery life, the built-in power-saver operates, and the camera enters sleep mode after approximately three (3)
minutes of non-use.
b.
Setting the Date and Time
Set the date and time before using the camera for the first time. This affects the way image file names are
created, and will conveniently include this information with each picture.
• With the front lens barrier closed, press
monitor. The date and time can also be set when the camera is in the shooting mode.
• Press to display the top menu.
• Press to select MODE MENU.
• Press to select SETUP, and then press
• Press to select , and then press
• Use to select the date format.
• Adjust the date and time in the appropriate fields by using
Repeat this step until all date/time fields have been set.
Note: Time is entered using the 24-hour format.
• Press twice to set the date and time and exit the menu.
c.
Camera Diagram and Controls
Now take a moment to familiarize yourself with the key areas of camera controls by reviewing the illustrations.
Strap eyelet
DC-IN jack
DC-IN jack
cover
Card cover Battery compartment
cover
VT747201
OLYMPUS AMERICA INC.
Two Corporate Center Drive, Melville,
NY 11747-3157, U.S.A.
http://www.olympusamerica.com/support
The following items are also included in the Digital camera package: Basic Manual, AV cable, warranty card, registration card (not provided
in some areas), and safety precautions booklet.
mark.
on the cover firmly
Power off
(OPTIONAL)
once. The monitor will turn on with "NO PICTURE" displayed in the
.
.
to select the field, and
Self-timer control lamp Flash
Lens barrier
Lens A/V OUT (MONO) jack
Olympus Europa GmbH
Wendenstrasse 14-18,
20097 Hamburg, Germany
http://www.olympus-europa.com

UNPACKING THE BOX CONTENTS

Gather your Digital camera and the parts as shown in the illustration. You'll need these to complete the steps for the camera
set-up procedures that follow. The items, such as batteries, supplied with the camera may differ depending on the area you
purchase the product.
Digital camera Strap AA (R6) alkaline batteries (2)
b.
Inserting the xD-Picture Card
The xD-Picture Card is where the camera stores your pictures
and is available in a variety of memory capacities. The pictures
you take with the camera remain on the xD-Picture Card even
when the camera is turned off and/or the batteries are removed.
• Open the card cover.
• Face the card the correct way and insert it into the card slot.
• Insert the xD-Picture Card into the spring-loaded card slot as
shown in the illustration. Push the card fully into the slot. The card
will lock into place when fully inserted.
• To remove, push the card all the way in to unlock it, then let it return
slowly.
• Close the card cover securely.
Confirm you have installed the battery and xD-Picture Card
properly by pressing
the camera off by pressing
c.
Attaching the strap
Attach the strap as illustrated to make the camera easier to
handle.
Viewfinder
to set the proper value.
Sequential shooting
Microphone
Connector cover
USB connector
Note: Depending on the camera settings, not all indicators will be displayed.
CAMEDIA Master USB cable (gray color)
CD-ROM
Contact area
. The "NO PICTURE" message should be displayed in the monitor. Turn
again.
(OPTIONAL)
Shutter button Zoom lever
Green lamp
Orange lamp
Monitor
Playback button
(QUICK VIEW )
Arrow pad ( )
Macro button
Shooting mode button Flash mode button
Self-timer button
Camera Settings in Shooting Mode as shown in Monitor
Shooting mode
Battery check
Green lamp
Flash stand-by
Macro mode
Flash mode
Self-timer
Sound record
Record mode
Resolution
Camera Settings in Playback Mode as shown in Monitor
Battery check
http://www.olympus.com/
xD-Picture Card
Monitor Lens
OK/Menu button
Tripod socket
Exposure compensation
Metering
White balance
AF target mark
Memory gauge
Number of storable
still pictures
Print reservation
Number of prints
Sound record
Protect
Record mode
Resolution
Exposure compensation
White balance
Date and time
File number
(still picture)
