Add-On Devices

Connecting External Devices

Connecting External Devices

Connecting PC Cards

The notebook PC Card slot is available for storing data and expanding the
communication capabilities of the notebook. The notebook supports standard Type II
and III PC Cards (PCMCIA and CardBus).

To insert or remove a PC Card

Note
The location and number of the PC Card slots vary by model series.
Inserting a PC Card
1. Hold the PC Card with the label side up and its connectors facing the card slot.
2. Slide the PC Card all the way into the bottom of the slot. Most cards are properly
48
seated when the outer edge is flush with the casing of the notebook, but some
cards are designed to protrude from the case.
Location of PC Card slots varies by series.
