Assembly and installation

Equipment handling and unpacking

Cabinet installation

RPE group installation

Equivalent packs

The 2-Mb/s Remote Peripheral Equipment (RPE) may be shipped fully
assembled in cabinets; or shelves and circuit packs may be shipped
individually for installation in existing cabinets.
Before starting the installation refer to 553-YYY1-210 for instructions
regarding the procedures for unpacking and handling of equipment.
If new cabinets are to be installed refer to 553-YYY1-210 for cabinet
installation procedures. Refer to 553-2741-200 Appendix 1 for RPE
cabinets at a remote site for ST or SN machines.
RPE shelves in local or remote sites are located in any cabinet location
that would normally house a Peripheral Equipment (PE) shelf. The
local site RPE shelf must be located within 50 cable feet (15 m) of any
connected network circuit packs. At the remote site the RPE shelf must
be within 50 cable feet (15 m) of any connected PE shelves. Refer to
553-2741-200 Appendix 1 for RPE shelves for ST or SN machines.
One RPE shelf pair (local and remote shelf) can have a maximum of
four network loops assigned to it. Each RPE shelf pair is defined as an
RPE group. The installation procedures are detailed in Procedures 2-1
and 2-2.
The equivalent NT and TELI (Sweden) packs are as shown in Table 2-1.
Installation and acceptance procedures
2-1 of 22 pages
553-2931-200
