2-2 Installation and connections
Appendix 1 to 553-2601-200
Chart 2-2 describes the procedures which should be followed when
2.05
installing an additional QSD66 PE or QSD69 RPE shelf assembly in an
existing QCA144 RPE cabinet.
Chart 2-3 describes the procedures which should be followed when
2.06
installing a QBL24 Battery Unit.
Chart 2-4 describes the procedures which should be followed when
2.07
installing an expansion QBL24 Battery Unit.
Chart 2-5 describes the procedures which should be followed when
2.08
installing a QUA6 Power Fail Transfer Unit (PFTU).
Chart 2-6 describes the procedures which should be followed when
2.09
installing alarm and transfer wiring (P10).
Chart 2-7 describes the procedures which should be followed when
2.10
installing a QPC705 power converter.
Chart 2-8 describes the procedures which should be followed when
2.11
installing QUD24 cooling units.
2.12 Chart 2-9 describes the procedures which should be followed when
installing a QCAD321 junction box assembly.
Chart 2-10 describes the procedures which should be followed when
2.13
installing QBL15 battery distribution box.
