QuickScan™ I QD2131
General Purpose Corded
Handheld Linear Imager
Bar Code Reader
Regulatory Addendum
850030014 (Rev.C) September 2017
This document is an addendum to the
Quick Reference Guide (QRG) for this
product. See the QRG for additional
product information.
©2015-2017 Datalogic S.p.A. and/or its affiliates. All
rights reserved. Datalogic and the Datalogic logo are
registered trademarks of Datalogic S.p.A. in many
countries, including the U.S.A. and the E.U.
www.datalogic.com
Regulatory Information
All models are designed to be compliant with rules and regulations in
locations they are sold and will be labeled as required.
Any changes or modifications to equipment, not expressly approved by
Datalogic could void the user's authority to operate the equipment.
Statement of Agency Compliance
This device complies with part 15 of the FCC Rules. Operation is sub-
ject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Class B Compliance Statement
The user is cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void the user's
authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the fol-
lowing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio or television technician
for help.
Canadian Notice
This equipment does not exceed the Class B limits for radio noise
emissions as described in the Radio Interference Regulations of the
Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits radioelectriques
depassant les limites applicables aux appareils numeriques de la
classe B prescrites dans le Reglement sur le brouillage radioelectrique
edicte par le ministere des Communications du Canada.
Do not attempt to open or otherwise service any
components in the optics cavity. Opening or ser-
vicing any part of the optics cavity by unautho-
CAUTION rized personnel may violate safety regulations.
Customs Union
The CU conformity certification has been achieved; this allows the
Product to bear the Eurasian mark of conformity.
Power Supply
This device is intended to be connected to a UL Listed/CSA Certified
computer which supplies power directly to the reader or else be sup-
plied by UL Listed/CSA Certified Power Unit marked "Class 2" or LPS
power source rated 5-14V minimum 900mA.
QD2430 can be powered by either a 5V or 12V power supply.
Argentina Power Supply Statement
Características de la fuente
de alimentación eléctrica.
5 V
100 - 240 Vca
Entrada:
Atencíon
350 mA, 50-60 HZ
5VDC, 2.5A
Salida:
(-)Negativo al centro
12 V
100 - 240 Vca
Entrada:
600 mA, 50-60 HZ
12VDC, 1500mA
Salida:
(-)Negativo al centro
Utilice en su red solo fuentes certificadas en Argentina.
El uso de fuentes de alimentación no compatibles puede resultar en riesgo
de incendio o de choque eléctrico para el usuario.
Imager Labeling
Sample labels are shown here to illustrate their location only. Please
view the labels on your product for actual details, as they may vary
from those depicted.
Scanner Regulatory Label
The QuickScan™ Handheld Reader is not user-
serviceable. Opening the case of the unit can
cause internal damage and will void the war-
ranty.
CAUTION
