User Guide
4
Select Away Mode
▪ Press "M" to enter away mode and
▪ Press "<" or ">". "SET" appears; set the away mode setpoint.
▪ Press "M" again to exit away mode.
5
Set Timer
For WT-P and WT-PR variants only
▪ Press
; "hh" flashes. Press"<" or ">" to adjust hour. Press
again; "mm" flashes. Press "<" or ">" to adjust minute. Press
again; "week" flashes. Press "<" or ">" to adjust week.
▪ Complete all adjustments. Press any other button to exit (au-
tomatic exit after 6 seconds with no operation).
6
Advanced Programmable Timer
For WT-P and WT-PR variants only
The Advanced Programmable Timer mode enables the setting of a
timer-controlled program for automatic comfort temperature, and
an energy-saving lower setback temperature if standard room
comfort temperature is not required.
▪ The function consists of 2 programs:
▪ Program 1: 4 events in 5 days (Mon. Tue. Wed. Thu. Fri.)
▪ Program 2: 4 events in 2 days (Sat. Sun.)
▪ Program 1: Press
to display Mo. Tu. We. Th. Fr.
▪ Program 1, Event 1:
▪ Use "<" or">" to select the required start time.
▪ Press
to accept setting.
▪ Use "<" or ">" to select the required temperature.
▪ Press
to accept setting.
▪ Program 1, Event 2-4:
▪ Repeat the Event 1 procedure for programming Event
2-4.
▪ Program 2: Sa. Su. are now shown in the display.
▪ Program 2, Event 1:
▪ Use "<" or ">" to select the required start time.
▪ Press
to accept setting.
▪ Use "<" or ">" to select the required temperature.
▪ Press
to accept setting.
7
Check Floor Temperature
Press "M" and hold. Press "<" within 6 seconds.
flashes and the current floor temperature is displayed. Operate
again, then exit (automatic exit after 6 seconds with no operation).
4
2
Basic Plus
Room Thermostats Floor Heating
will be displayed.
▪ Program 2, Event 2-4:
▪ The thermostat will continue the 4-event program based on
▪ To set and change the desired room temperature temporari-
▪ A default program provides timer control if the customer
Weekday/
Weekend
Weekday,
Mon-Fri.
Weekend,
Sat. -Sun.
* Floor temperature control mode.
VUCUA102
▪ Repeat the Event 1 procedure for programming Event
2-4.
the present time and day.
ly:
▪ Press "<" or ">" at any time to change the desired tem-
perature value. "SET" is shown in the display.
▪ When releasing the "<" or ">", the display returns to
showing the actual temperature. This temperature
change is only temporary and will be maintained only
until the next programmed setting!
does not set own programs. The default program is as fol-
lows.
Event 1
Event 2
Start time/temp.
6:30/20 °C
8:30/15 °C
(27 °C)*
(25 °C)*
7:30/20 °C
9:30/20 °C
(27 °C)*
(27 °C)*
Event 3
Event 4
16:30/20 °C
22:30/15 °C
(27 °C)*
(25 °C)*
16:30/21 °C
22:30/15 °C
(28 °C)*
(25 °C)*
Danfoss Heating Solutions
