- Page 1 X50Z series Operating Instructions Plasma Television Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only. English...
- Page 2 “AVCHD” and the “AVCHD” SDXC Logo is a trademark logo are trademarks of of SD-3C, LLC. Panasonic Corporation and Sony Corporation. DLNA , the DLNA Logo and ® Manufactured under license DLNA CERTIFIED™ are from Dolby Laboratories. trademarks, service marks,...
-
Page 3: Table Of Contents
Contents Panasonic does not guarantee operation and performance of peripheral devices made by other manufacturers; and we disclaim any liability or damage arising from operation and/ or performance from usage of such other maker’s peripheral Be Sure to Read devices. -
Page 4: Safety Precautions
Using an unapproved pedestal or other fixtures may make the TV unstable, risking injury. Be sure to ask away from this product your local Panasonic dealer to perform setup. ● Use approved pedestals (p. 7) / wall-hanging brackets at all times (p. - Page 5 Important Installation Notices Install the TV on a stable surface Allow sufficient space around the TV for If a television is not positioned in a sufficiently stable radiated heat location, it can be potentially hazardous due to falling. ● Minimum distance When using the Many injuries, particularly to children, can be avoided by pedestal, keep the...
-
Page 6: Accessories / Options
Keep these parts out of reach of young children. Optional accessories Please contact your local Panasonic dealer to purchase the recommended optional accessories. For additional details, please read the manual of the optional accessories. Wireless Adaptor for VIERA ●... - Page 7 Do not use the pedestal if it becomes warped or physically damaged. ● If you use the pedestal while it is physically damaged, personal injury may result. Contact your local Panasonic dealer immediately. During set-up, make sure that all screws are securely tightened.
- Page 8 Assembly screw (4) Assembly screw (4) Pole Base (silver) (black) ● ● R: TBL5ZA3311 TBL5ZX0441 ● L: TBL5ZA3310 (42” class) ● TBL5ZX0430 (50” class) M5 × 18 M5 × 30 ■ ■ Assembling the pedestal Securing the TV Use the assembly screws to fasten the pole Insert the pole into the TV, and then fasten securely the base...
-
Page 9: Identifying Controls
Identifying Controls Remote Control [VIERA Link Menu] (p. 60) POWER ● Accesses VIERA Link Menu INPUT SD CARD MENU SURROUND ASPECT ● Confirms selections and choices. ● Press after selecting channel positions to quickly INFO EXIT change channel. ● Displays the Channel List. [Option Menu] (p. - Page 10 Indicator / Control panel Mains power On / Off switch ● Use to switch the mains power. If you turned the TV off during Standby mode by the remote control last time, the TV will be in Standby mode when you turn the TV on with Mains power On / Off switch.
-
Page 11: Basic Connection
Basic Connection External equipment and cables shown are not supplied with this TV. Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. When disconnecting the mains lead, be absolutely sure to disconnect the mains plug at the socket outlet first. Terminals SD Card slot (p. - Page 12 Note ● Keep RF (antenna) cable away from the mains lead to avoid and minimise mains interference pickup. ● Do not place the RF cable under the TV. To obtain optimum quality picture and sound, an aerial, the correct cable (75 Ω coaxial), and the correct terminating ●...
- Page 13 Network ■ Wired connection LAN cable (Unshielded) ● Use the Unshielded Twist Pair (UTP) LAN cable. ∗ Less than 10 cm DLNA Certified media server “Using Network Services (DLNA)” (p. 49) Ferrite core - Large size (supplied) Installing the Ferrite core Pull back the tabs Wind the cable twice Close...
-
Page 14: Auto Tuning
Auto Tuning Search and store TV channels automatically. ● These steps are not necessary if the setup has been completed by your local dealer. ● Please complete connections (p. 11 - 13) and settings (if necessary) of the connected equipment before starting Auto Tuning. - Page 15 Select the connection type Connection Type select ● If your access point supports WPS (Push Please select network connection type. button), then select this option. If not, access WPS(Push button) select [Search for access point]. Search for access point [WPS(Push button)] 1.
-
Page 16: Using The Freeview Guide (Digital
4. Select [Yes] Access Point Settings select Encryption key is set to:- XXXXXXXX Select ‘Yes’ to confirm. Select ‘No’ to change. ● To re-enter the encryption key, select [No]. 5. After the access point setting is finished, perform the connection test Connection Test : succeeded Check access point connection. - Page 17 Watching TV Turn power on ● Mains power On / Off switch should be on. (p. 10) POWER Select Digital TV or Analogue TV mode The selected mode is displayed. Digital TV ● You can also select the mode pressing the TV button repeatedly on the TV (p.
- Page 18 Other useful functions Display Information banner Display Information banner ● Also appears when changing a channel. INFO Example: Digital TV 1 ABC ONE WALES All Digital Channels 20:35 Select favourites Coronation Street Software Update 20:00 - 20:55 Rating: PGR Channel position and name Current time Programme Category...
- Page 19 Display the selectable settings for the current status Confirm or change the current status instantly select OPTION change [Video Selection] (Digital TV) [Subtitle Language] (Digital TV) Selects the image (if available) Selects the language in which subtitles should appear (if available) [Audio Selection / AD] (Digital TV) Selects between alternative languages for sound tracks [MPX] (Analogue TV)
- Page 20 [16:9] [4:3 Full] Directly displays the image at 16:9 Displays a 4:3 image enlarged without distortion (anamorphic). horizontally to fit the screen. ● HD signal only [14:9] [Zoom1] Displays the image at the standard Displays a 16:9 letterbox or 4:3 image 14:9 without distortion.
