Page 1 I N S T R U C T I O N M A N U A L...
Page 2 Lou Lentine Echelon Fitness Multimedia, LLC...
Page 3 Hello, I am Lou Lentine, CEO of Echelon, and I would like to welcome you to the Echelon community. You’ve made a great decision for yourself and your family. The Echelon Experience is an innovative combination of fitness products integrated with our state-of-the-art Echelon Fit app.
Page 4 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT 15.21 FCC RF RADIATION EXPOSURE STATEMENT: You are cautioned that changes or modifications not expressly approved This Transmitter must not be co-located or operating in conjunction by the party responsible for compliance could void the user’s authority to with any other antenna or transmitter.
Page 5 INNOVATION, SCIENCE AND ECONOMIC DEVELOPMENT CANADA (ISED) INNOVATION, SCIENCE ET DÉVELOPPEMENT ÉCONOMIQUE CANADA (ISED) THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CAUTION: EXPOSURE TO RADIO CANADIAN ICES-003. FREQUENCY RADIATION To comply with the Canadian RF exposure compliance requirements, this CET APPAREIL NUMÉRIQUE DE CLASSE B EST device and its antenna must not be co-located or operating in conjunction CONFORME À...
Page 6: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS �� 8 DESCRIPTION/PARTS LIST �� 11 WARNING LABELS �� 12 ECHELON MEMBERSHIP ACTIVATION �� 14 SET UP INSTRUCTIONS �� 16 Folding Instructions/Storage �� 20 Belt Adjustment�� 23 CONSOLE OPERATION �� 24...
Page 7 Console Display�� 24 Display Definition�� 25 Control Button Definition �� 25 Features �� 27 Measurement for BMI Program �� 30 App �� 31 Connect to Echelon Fit ® ERROR CODES & TROUBLESHOOTING �� 31 CUSTOMER SERVICE �� 33...
Page 8: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS The manufacturer recommends placing the Echelon STRIDE treadmill in a ® WHILE CLEANING YOUR ECHELON STRIDE TREADMILL, ® space where you have the following minimum clearance dimensions for safe PLEASE USE A SOFT RAG WITH MILD DETERGENT OR mounting and dismounting of the treadmill: WATER TO WIPE DOWN THE MACHINE.
Page 9 • NEVER exceed the weight limit for this treadmill. The weight limit for this 13. Do not use a GFCI (ground fault circuit interrupt) outlet or GFCI circuit treadmill is 300 lbs / 135 kg. Do not use the Echelon STRIDE if your body breaker.
Page 10 THIS SAFETY INFORMATION AND USER MANUAL are safely placed on handlebars during use. DO NOT REPLACE THE NEED TO BE ALERT AND • ALWAYS be cautious when getting on and off the Echelon STRIDE. ® • ALWAYS wait until the incline is lowered all the way running belt comes TO USE COMMON SENSE WHEN USING THE to a complete stop before dismounting.
Page 11: Description/Parts List
DESCRIPTION / PARTS LIST STRIDE DESCRIPTION Device Holder 2. Console 3. Smartphone Holder 4. Folding Joint Cover 5. Button Platform 6. Handlebar Upright 8. Motor Upper Cover 9. Side Cover 10. Folding Lever 11. Side Rail 12. Solid Side Rail 13. Running Belt 14.
Page 12: Warning Labels
WARNING LABELS Icon + Voltage Label Rating Label Pinch WARNING - AVERTISSEMENT - ADVERTENCIA CAUTION: Risk of Injury to Persons. ATTENTION : Risque de blessure. PRECAUCIÓN: Riesgo de lesiones. To avoid injury, use extreme Pour éviter toute blessure, soyez Para evitar lesiones, tenga mucho Warning caution when stepping onto or off extrêmement prudent(e) au...
Page 13 Remove the cord from the treadmill receptacle before transporting or servicing the treadmill in any way, to avoid damage to the treadmill or plug. Review the above labels to ensure none are missing from the Echelon STRIDE. If any of the above ®...
Page 14: Echelon Membership Activation
ECHELON MEMBERSHIP ACTIVATION Download the Echelon Fit ® Ensure the latest version of the Echelon Fit app is installed from the Google Play Store or the Apple Store. Operational Instructions Connect to the Echelon Fit app to access tutorials and operation instructions.
Page 15 Alternatively, you can go to member.echelonfit.com and follow the on-screen instructions to choose a plan and set up your account. This info Select purchase location and follow the on-screen instructions. will be needed to login to your account on the Echelon Fit app. ®...
Page 16: Set Up Instructions
SET UP INSTRUCTIONS Open the box and remove the treadmill. Remove the plastic wrap from the treadmill. STEP STEP Set up the treadmill. Gently lower the treadmill to the floor. Grip the lift handle, located underneath the running deck. Grip the handlebars and push down until a “click” sound is heard, locking the handlebars into place.
Page 17 Set the console up. Rotate the console upward. STEP STEP Remove excess packaging. Remove the protective cardboard pieces from the treadmill. Slowly peel off the protective plastic cover from the screen. SET up InSTruCTIOnS |...
Page 18 SET UP INSTRUCTIONS (cont’d.) Plug in treadmill. Plug in the power cord at the front of the treadmill. Plug the other end of the cord into a power outlet. Always remove the plug when moving or storing the treadmill. Press the power button into the ON position. When the treadmill is on, the ON / OFF button will be lit.
Page 19 Start treadmill. Press START on the console to start running belt. A countdown form 3 to 1 will be displayed on the console before the running belt begins to move. Adjust the speed level under 2 MPH and check to see if belt runs smoothly before treadmill use. Clip the safety key to clothes or belt prior to workout STEP SET up InSTruCTIOnS |...
Page 20: Folding Instructions/Storage
FOLDING / STORAGE Auto Folding. Fold the device hook down and push the device holder into the console. Rotate console down. Lightly push down on the handlebars and press both Folding Buttons at the same time. Once the handlebars are unlocked, rotate them back against the Uprights.
Page 21 Storage Options. Upright position Store against wall Store under bed STEP 10-a 10-b Recommended Storage: upright position using straps. Place treadmill in standing position against a wall for storage, or place it under a bed to save space. The height of the folded treadmill is 10.25 in (26 cm). If the space under your bed is less than 10.25 in (26 cm), please store the treadmill elsewhere.
Page 22 FOLDING / STORAGE (cont’d.) 32 IN (81 CM) WIDTH APART Safety Straps. Safety straps, anchors, & screws 47.2 IN (120 CM) ABOVE FLOOR Safety strap position STEP 11-a 11-b When storing the treadmill in an upright position, please install safety straps to the wall to secure and prevent treadmill from tipping over.
Page 23: Belt Adjustment
BELT ADJUSTMENT Belt Adjustment: If the belt has drifted right, unplug the safety lock and power switch and turn the right adjusting bolt 1/4 turn clockwise. Insert the power switch and safety lock, run the treadmill, and observe the running belt’s position. Repeat until the running belt is centered on the running deck.
Page 24: Console Operation
CONSOLE OPERATION CONSOLE DISPLAY | COnSOLE OpEraTIOn...
Page 25: Display Definition
DISPLAY DEFINITION Pulse and Distance Incline and Altitude Time Show “Distance” when no heart rate detected. Display switches between “Incline” and “Altitude” Shows duration of the exercise. every 5 seconds. Once heart rate signal is detected, display switches between “Distance” and “Pulse.” Incline unit = 0 –...
Page 26 CONSOLE OPERATION (cont’d.) START Switch Distance Unit Press “Start” button. Belt will begin moving after a 3-second countdown. Press “PROG” and “MODE” together for over 5 seconds. After entering the factory settings, switch from the flashing F01 display by tapping PAUSE / STOP “MODE”...
Page 27: Features
FEATURES When power is on, display lights up for 2 seconds on all windows and 4. To start pre-set programs, press “Program” buttons to choose any of the enter standby mode. 8 programs, and the corresponding program number will be displayed on “Speed &...
Page 28 CONSOLE OPERATION (cont’d.) PROGRAMS / SECTIONS SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE | COnSOLE OpEraTIOn...
Page 29 PULSE SLEEP MODE SAFETY KEY To show a pulse, place both hands firmly on Console goes into "Sleep Mode" when there is All data clears after removing the safety key no function for more than 10 minutes. Pressing pulse sensor pads for 5 seconds. Pulse window and all windows display "---".
Page 30: Measurement For Bmi Program
CONSOLE OPERATION MEASUREMENTS FOR BMI PROGRAM Category Default Value Input Range Note Under “Standby Mode,” press “Program” button and choose “FAT ” program. F-1 (Gender) 1 – 2 1 = Male Press “MODE” button to enter basic data, including Gender / Age / Height / 2 = Female Weight.
Page 31: Connect To Echelon Fit
CONNECT TO ECHELON FIT ® To connect the Echelon Fit app and begin a live session, search and download “Echelon Fit” from the Apple App Store or Google Play. ® Follow the prompts in the app for Bluetooth connection and registration.
Page 32 ERROR CODES & TROUBLESHOOTING ERROR CODE PROBLEMS SOLUTIONS 1. Check if any part on motor is stuck. Unplug power cable and adjust motor. Plug back in the power cable and re-start to run the treadmill. Over-current 2. Check if motor has burned smell. If so, the motor will need changed. Protection 3.
Page 33: Customer Service
Submit a Request: Warranty Information Your Echelon STRIDE comes with a 1-year parts and labor warranty. Should the need arise, all you need is a proof of purchase and our customer service team will be happy to assist. Additional 1- or 3-year extended warranties are available through customer service.
Page 34 NOTES...
Page 36 MODEL: ECH-STRIDE ECHELON FITNESS MULTIMEDIA, LLC 605 CHESTNUT STREET, SUITE 700 CHATTANOOGA, TN 37450 ECHELONFIT�COM READ INSTRUCTIONS MADE IN PATENT REV: 02142022 BEFORE OPERATING CHINA PENDING...
