- Page 1 DOUBLE DISHDRAWER™ DISHWASHER CONTEMPORARY DD24DDFTX9, DD24DV2T9, DD24DDFTB9, DD24DAX9, DD24DCTW9 DD24DCTB9, DD24DCTX9, DD24DCHTX9, DD24DV2T9 INSTALLATION GUIDE US CA...
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! Tip Hazard Electric Shock Hazard Failure to follow this advice may result in Failure to follow this advice may result in injury or product damage. electrical shock or death. • Take care when removing product •... -
Page 4: Tools And Components
TOOLS AND COMPONENTS PARTS SUPPLIED TOOLS REQUIRED Keep all packing materials until the unit has been inspected. Not supplied Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. Fisher &... - Page 5 PRODUCT DIMENSIONS — DD24DC MODELS DD24DC PRODUCT DIMENSIONS INCHES 32 1/4 – A Overall height* 820 – 880 34 5/8 B Overall width 23 9/16 C Overall depth 22 9/16 D Height of chassis 31 15/16 E Depth of chassis 21 3/4 F Height of upper door panel 15 1/2 G Height of lower door panel 12 1/4...
- Page 6 PRODUCT DIMENSIONS — DD24DA MODELS DD24DA PRODUCT DIMENSIONS INCHES 32 1/4 – 820 – A Overall height* 34 5/8 B Overall width 23 9/16 C Overall depth 22 9/16 D Height of chassis 31 15/16 E Depth of chassis 21 3/4 F Height of upper door panel 15 1/2 G Height of lower door panel 12 1/4...
- Page 7 PRODUCT DIMENSIONS — DD24DD MODELS DD24DD PRODUCT DIMENSIONS INCHES 32 1/4 – A Overall height* 820 – 880 34 5/8 B Overall width 23 9/16 C Overall depth*** 22 9/16 D Height of chassis 31 15/16 E Depth of chassis 21 3/4 F Height of upper door panel 15 1/2 G Height of lower door panel 12 1/4...
- Page 8 PRODUCT DIMENSIONS — DD24DV2T MODELS DD24DV2T PRODUCT DIMENSIONS INCHES 34 – A Overall height* 864 – 924 36 3/8 B Overall width 23 9/16 C Overall depth*** 22 9/16 D Height of chassis 33 11/16 E Depth of chassis 21 3/4 F Height of upper door panel 17 3/8 G Height of lower door panel 12 1/4...
- Page 9 CABINETRY DIMENSIONS CLEARANCES Connections can be located in an adjacent cabinet on either side of the DishDrawer*** PLAN ISOMETRIC STD MODELS TALL MODELS CABINETRY CLEARANCES INCHES CABINETRY DIMENSIONS INCHES INCHES A Minimum clearance to adjacent cupboard door 1/16 A Minimum inside height* 32 1/4 B Minimum clearance to corner cupboard 23 5/8 – ...
- Page 10 PLUMBING & ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to ‘Cabinetry preparation’ for service access requirements. If the drain hoses supplied are not long enough to reach your services, you may purchase a Fisher &...
- Page 11 HARD-WIRING (OPTIONAL) You have the option to hard-wire your DishDrawer™ Dishwasher. To do this, we recommend to remove the supplied power cord and do the hardwiring installation as close to the cavity as possible. Ensure only copper conductors are used. Slide the terminal block cover sideways to unlock and hinge open to access the terminal block.
- Page 12 HARD WIRING (OPTIONAL) Screw down the Live, Neutral and Earth wires correctly. Refit module cover before sliding the access cover back into place, ensuring the 2 clips shown are fully locked. Before refitting the drawers, ensure the hoses are not twisted and all latches are facing forward.
- Page 13 CABINETRY PREPARATION SERVICE ACCESS MOISTURE PROTECTION We recommend locating the service holes on either side of the DishDrawer™ Dishwasher as shown below. If the holes are created through wood, ensure the edges are smooth and rounded If the holes are created through metal, ensure the supplied edge protector is fitted. Align the supplied moisture protection tape to Ensure power cord is routed through a separate service hole to the hoses.
- Page 14 SECURE TO CABINETRY VIA BRACKETS (METHOD A) Secure all four side brackets to the DishDrawer™ Dishwasher, aligning Partially open one of the drawers and bracket A with slot A and bracket B remove the first screw cover from the with slot B. trim moulding.
- Page 15 SECURE TO CABINETRY VIA DRAWER REMOVAL (METHOD B) Using your hand or the supplied hex socket and a screwdriver, level the DishDrawer™ Dishwasher as required. Optionally, fit the two top brackets. Rotate clockwise to increase the height Ensure the ends of the brackets are not of each leg and anticlockwise to lower.
- Page 16 INSTALL TOE KICK – DD24DC, DD24DP & DD24DD MODELS Measure toe kick height. Where Snap excess + smooth edges. the toe kick meets the bottom of the tub is the recommended Snap both end tabs. cut-off point. Slide toe kick onto the mounting rails Carefully score toe kick at and secure desired height.
- Page 17 INSTALL TOE KICK – DD24DA MODELS Measure the distance from the floor to the base of the lower door panel. Refer to the table below for the recommended Punch or drill out the two mounting cut location. holes with a 5mm drill bit on each side of the toe kick as shown.
- Page 18 PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION SINK TRAP/WASTE TEE INSTALLATION Install the drain hose support to the Install the drain hose support to the back wall, as close to the underside of back wall, as close to the underside of the countertop as possible.
- Page 19 PLUMBING & ELECTRICAL CONNECTION AIR GAP INSTALLATION Install your Air Gap Kit to the benchtop. We recommend using a Dual Air Gap Kit. Refer to ‘Plumbing & electrical connection’ for minimum install heights. Dual Air Gap Single Air Gap Thread wire clips onto the hoses before fitting them to the hose joiner.
-
Page 20: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Installation Electrical … … Check all parts are installed correctly and are secure. Ensure all electrical tests have been conducted in accordance with local regulations. … Ensure all clearance gaps have been maintained. Test operation …... -
Page 21: Troubleshooting
TROUBLESHOOTING DD24DD, DD24DV2T models No program indicator lights up when the drawer is opened Ensure power is connected and is switched on. DISPLAY POSSIBLE CAUSE WHAT TO DO may need to be activated. Refer to your user guide for details. AUTO POWER-ON Water 1 Ensure the water supply is turned on. - Page 22 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2021. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
