TECHNICAL INFORMATION MANUAL
MBR/MBE
Blowers
•
Refer to Service Manual RS6100004 for installation, op-
eration, and troubleshooting information.
•
All safety information must be followed as provided in the
Service Manual.
•
Refer to the appropriate Parts Catalog for part number
information.
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does not assume
any responsibility for property damage or personal injury due to improper service procedures or services
performed by an unqualified person.
Copyright © 2004-2008 Goodman Manufacturing Company,
Models listed
on page 3
RT6223002 Rev. 4
L.P.
July 2008
Advertisement
Related Manuals for Goodman MBR Series
Summary of Contents for Goodman MBR Series
- Page 1 Refer to the appropriate Parts Catalog for part number information. This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does not assume RT6223002 Rev. 4 any responsibility for property damage or personal injury due to improper service procedures or services July 2008 performed by an unqualified person.
-
Page 2: Product Identification
Goodman will not be responsibile for any injury or property damage arising from improper service or service procedures. If you install or perform... - Page 3 Do not connect or use any device that is not design certified by Goodman for use with this unit. Serious property damage, personal injury, reduced...
-
Page 4: Product Design
PRODUCT DESIGN MBR/MBE blower cabinets are designed to be used as a The MBR/MBE blower cabinets with proper coil matches can two-piece blower and coil combination. MBR/MBE blower be positioned for upflow, counterflow, horizontal right or hori- sections can be attached to cased evaporator coil. This two zontal left operation. - Page 5 MBR/MBE BLOWER SPECIFICATIONS 3 1/4 5 1/8 (3) KNOCKOUTS 1.125 1.375 1.750 .875 KNOCKOUT (2 PLACES) 6 1/2 MBR800/1200/1600/2000 & MBE1200/1600/2000 Physical Information Dimensions, inches (mm) Shipping Blower Wheel Blower Motor Weight MODEL (D x W) (HP) lbs.(kg) MBR800 17½ MBR1200 (445) (660)
- Page 6 MBR/MBE BLOWER SPECIFICATIONS...
- Page 7 MBR/MBE BLOWER SPECIFICATIONS HKR HEATER DATA ELECTRIC HEATER KIT BLOWER NO HEAT KIT HKR-03* HKR05-(C)' HKR-06* HKR-08(C)* HKR-10(C)* 0800AA-1AA 1200AA-1AA 1600AA-1AA 2000AA-1AA 1200AA-1AA 1600AA-1AA 2000AA-1AA 1200AA-1BA 1600AA-1BA 2000AA-1BA ^ = Circuit 1: Single Phase for Air Handler Motor * = Revision level that my or may not be designated Circuit 2: 3-Phase for HKR3 Heater Kits C = Circuit Breaker option X = Allowable combinations...
- Page 8 BLOWER PERFORMANCE DATA MBR BLOWER PERFORMANCE SPECIFICATIONS MBR0800**-* MBR1200**-* MBR1600**-* MBR2000**-* SPEED STATIC SCFM SCFM SCFM SCFM 1240 1500 1800 2160 1170 1460 1740 2080 1120 1360 1680 1990 HIGH 1060 1280 1610 1890 1200 1520 1790 1110 1430 1690 1380 1540 1730...
-
Page 9: Wiring Diagrams
WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. ROOM THERMOSTAT #18 GA. 4 WIRES WITH COOLING 3 WIRES WITHOUT MBR UNIT GREEN WHITE... - Page 10 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. SYSTEM COMPOSITE DIAGRAM MBR0800 10kW & BELOW HEAT PUMP ROOM THERMOSTAT MBR UNIT GREEN...
- Page 11 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Single Stage Cooling with Single or Two-Stage Heating ROOM THERMOSTAT HUMIDISTAT CONDENSING...
- Page 12 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. ROOM OUTDOOR THERMOSTAT THERMOSTAT CONDENSING HUMIDISTAT (OPTIONAL) UNIT NOTES: SEE NOTE 4 1.) Y/Y2 ENABLES HI SPD FAN COOLING THERMOSTATS...
- Page 13 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. ROOM HEATPUMP THERMOSTAT HUMIDISTAT HEATPUMP CONDENSER (OPTIONAL) YCON SEE NOTE 4 THERMOSTATS HUMIDISTAT E\W1 W/W2...
- Page 14 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. ROOM HEATPUMP THERMOSTAT HUMIDISTAT HEATPUMP CONDENSER (OPTIONAL) YCON OUTDOOR SEE NOTE 4 THERMOSTATS HUMIDISTAT...
- Page 15 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Two-Stage Cooling with Conventional Two-Stage Thermostat ROOM THERMOSTAT RSG - 2 SPD CONDENSING HUMIDISTAT (OPTIONAL)
- Page 16 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Two-Stage Cooling with Conventional Two-Stage Thermostat ROOM OUTDOOR THERMOSTAT THERMOSTAT RSG - 2 SPD CONDENSING...
- Page 17 PLEASE REFER IN THE "ON" POSITION TO MANUAL FOR PROPER DIP SWITCH GOODMAN MFG. CO. L.P. CONFIGURATION. 2nd STAGE HEATER 1st STAGE HEATER HEATPUMP - 2 STG EMHT 1 STG AUX HEAT Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 18 5.) DIP SWITCH #4 MUST BE TO MANUAL FOR PROPER IN THE "ON" POSITION DIP SWITCH GOODMAN MFG. CO. L.P. CONFIGURATION. 2nd STAGE HEATER 1ST STAGE HEATER 1ST STAGE AUX HEAT ENABLED BY ROOM T'STAT 2ND STAGE AUX ENABLED BY ROOM T'STAT AND OUTDOOR T'STAT...
- Page 19 PLEASE REFER 5.) DIP SWITCH #4 MUST BE IN THE "ON" POSITION TO MANUAL FOR PROPER DIP SWITCH GOODMAN MFG. CO. L.P. CONFIGURATION. 2nd STAGE HEATER 1ST STAGE HEATER NO AUX HEAT IN HEATPUMP MODE UNTIL OUTDOOR T'STAT CLOSES HEATPUMP - 2 STG EMHT 1 STG AUX - 1 OUTDOOR T'STAT...
- Page 20 STAT OPENS ON HUMIDITY RISE 5.) DIP SWITCH #4 MUST BE IN THE "OFF" POSITION PLEASE REFER TO MANUAL FOR PROPER DIP SWITCH GOODMAN MFG. CO. L.P. CONFIGURATION. 1ST STAGE HEATER HEATPUMP - WITH 1 STG EMHT 1 STG AUX HEAT ROOM HEATPUMP...
- Page 21 STAT OPENS ON HUMIDITY RISE TO MANUAL FOR PROPER DIP SWITCH 5.) DIP SWITCH #4 MUST BE IN THE "OFF" POSITION GOODMAN MFG. CO. L.P. CONFIGURATION. 2ND STAGE HEATER 1ST STAGE HEATER 1ST STAGE AUX HEAT ENABLED BY ROOM T'STAT...
- Page 22 PLEASE REFER TO MANUAL 5.) DIP SWITCH #4 MUST BE IN THE "OFF" POSITION FOR PROPER DIP SWITCH GOODMAN MFG. CO. L.P. CONFIGURATION. 2ND STAGE HEATER 1ST STAGE HEATER NO AUX HEAT IN HEATPUMP MODE UNTIL T'STAT CLOSES HEATPUMP - 2 STG EMHT 1 STG AUX - 1 OUTDOOR T'STAT...
- Page 23 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. IF NEEDED Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 24 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. IF NEEDED Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 25 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 26 WIRING DIAGRAMS HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 27 Table 5. - Troubleshooting Encoded Two Stage Cooling Thermostats Options TEST FUNCTION SIGNAL OUT SIGNAL FAN INDICATION S1 + LOW SPEED COOL YCON + * S1 - * * LO SPEED COOL * * YCON - * * Y / Y2 HI * * ERROR CONDITION ( DIODE ON THERMOSTAT BACKWARDS ) S1 + - HI SPEED COOL...
