Low Temperature Dry Block Calibrator (CALsys -30/110) User's Guide TEMPSENS INSTRUMENTS (l) PVT. LTD. UNIT ll A-190, Road No.5, M.I.A., Udaipur-313003 INDIA Ph. : +91-294-3500600, Fax : +91-294-3500631 Email : tech@tempsens.com Web : www.tempsens.com...
Page 2
Legal Disclaimer The information contained in this document is the property of TEMPSENS. TEMSPENS reserves the right to make changes to this document and to the product described herein without notice. Before installing and using the product, review the latest version of the applicable documentation, which are available from the Tempsens website at: http://www.tempsens.com/...
Cautions and Preventions....................... 8 Document Conventions......................8 Chapter 1 Introduction..........................9 1.1 About CALsys30/110....................... 9 1.2 Basic Working Model of CALsys -30/110................. 10 1.3 Physical Measurements......................11 1.4 Wiring Diagram........................12 1.5 Technical Specifications......................13 Chapter 2 Setting Up CALsys -30/110......................14 2.1 Installation..........................
Page 4
7.3 Replace Solid State Relay......................26 Chapter 8 Troubleshooting CALsys -30/110....................27 8.1 CALsys -30/110 unit does not turn on..................27 8.2 CALsys -30/110 unit is not stable................... 27 8.3 The temperature of the calibrator does not rise..............27 Page | 3...
Page 5
Temperature Calibrator (CALsys -30/110) User's Guide Appendix A : Calibration Services ....................28 In House Calibration Facility....................28 On-site Calibration Facility...................... 29 Fixed-Point Calibration Facility....................29 Appendix B : Warranty ......................... 30 Limit of Liability........................30 Caution in Using the Product....................30...
Preface Welcome to the Low temperature Dry Block Calibrator (CALsys -30/110) user guide. This guide provides detailed information about all the product options and features, and explains how to use the product and configure basic settings to suit your requirements.
Temperature Calibrator (CALsys -30/110) User's Guide Electrical Safety WARNING: ·This equipment must be correctly grounded before use. Make sure the ground conductor wire (colored green/yellow) in the main power cable is connected to a protective earth/ground. If the equipment is not properly grounded, the high voltage may flow through the equipment body (chassis).
After use, do not return the apparatus to its carrying case until the unit has cooled down. There are no user serviceable parts inside. When required, contact Tempsens agent for repair. Ensure all materials, especially flammable materials are kept away from the hot parts of the apparatus, to prevent fire risk.
Temperature Calibrator (CALsys -30/110) User's Guide Cautions and Preventions To avoid possible damage to the instrument, follow these guidelines: Before working inside the equipment, turn the power off and disconnect the power cord. DO NOT turn the unit upside down with the inserts in place; the inserts will fall out of the unit.
Introduction 1.1 About CALsys -30/110 CALsys -30/110 has been designed to provide stable and accurate temperature to enable professionals to calibrate temperature sensing devices by comparison method. It is designed to be rugged and easily maintained. This model provides an isothermal enclosure (aluminum block) in which the thermocouple/RTD can be calibrated against the temperature of the calibrator.
Peltier Cell via solid-state relay. There is one electricity driven fan which is situated under the heating chamber for cooling the heater. The CALsys -30/110 dry block calibrator was designed for portability, moderate cost and ease of operation. With proper use the instrument should provide continued accurate calibration of temperature sensors and devices.
Introduction 1.5 Technical Specification CALsys -30/110 has the following technical specifications: PARAMETER SPECIFICATION Temperature Range -30°C to 110°C Resolution 0.1°C ± 0.04°C at -30 °C Stability ± 0.06°C at 0 °C ± 0.07°C at 110 °C ± 0.05°C at -30°C Radial Uniformity ±...
Chapter 2 Setting up CALsys -30/110 2.1 Installation Place the Dry Block on a flat surface with at least 10 inches of free space around the instrument. Overhead clearance is required. DO NOT Place this unit under a cabinet or structure. Plug the power cord into a grounded mains outlet located on the controlling unit rear panel.
Ÿ carefully. Inspect the unit after unpacking for any signs of damage, and confirm that your delivery is in accordance with the packing note. If you find any damage to the unit or an item is missing, notify Tempsens immediately The following accessories are included in the package: ·...
This unit is fully tested before dispatching. However, verify its operation as follows: 1. After connecting the CALsys -30/110 to the electricity supply, the temperature controller display should show the temperature of the chamber, and the last set-point value. The fan on the bottom should be heard running.
Chapter 3 Operating CALsys -30/110 3.1 Turning On the unit 1. Before plugging the unit to main power outlet, ensure that the voltage, frequency and current from the main power outlet are within the recommended rages (typically: 230 VAC±10, 50/60 Hz).
9. Reset the controller and/or repeat the calibration for another calibration point or for another sensor. 10.When the calibration is completed, reset the controller to 0°C. Before moving CALsys -30/110 to new location the unit must be cooled to below 100°C.
Take the reading of sensors (master and test) at stable temperature with the help of digital multi- meter, or by using Tempsens' TEMPMET 08 or TEMPMET 09 for reading RTD or TC sensor. 3.4 Cooling Down the Source Before transporting the metal block, ensure that the temperature of bath has cooled sufficiently.
Chapter 4 Operating Unit Controller 4.1 Front Panel Layout The following image shows the front panel of CALsys -30/110 Measured Temperature Required Temperature * PAGE SCROLL DOWN 4.2 The Temperature Controller The controller has a dual display, the upper display indicates the measured temperature, and the lower display indicates the desired temperature or set point.
Operating Unit Controller 4.4 Monitoring the Controller Status A row of beacons indicates the controllers status as follows: OP1: Heat Output Ÿ OP2: Cool Output (only for models which operate below 0°C) Ÿ REM: This beacon indicates activity on computer interface Ÿ...
Chapter 5 Digital Communication Digital Communication allows the controller to communicate with a PC or a networked computer system through RS-232 (or EIA232) protocol. RS-232 (or EIA232) is a standard communication protocol for linking computer and its peripheral devices to allow serial data exchange. RS-232 communication is not available if Remote Set point is fitted.
Digital Communication 6.2 Digital Communications Parameters The following table shows the available parameters. IGITAL OMMUNICATION COMMS CCESS CROLLING ISPLAY ARAMETER ESCRIPTION ALUE EFAULT EVEL O MODULE FITTED R232 R 232 M ODBUS INTERFACE R485 EIA485 M ODBUS INTERFACE S ORDER MODULE IDENTITY C OMMUNICATION DENTITY...
Chapter 6 Software Installation The provided Tempsens software offers possibilities to connect furnace temperature bath and change set point, maximum time span, view real time graph and evaluate measuring data. 6.1 Installation Install the calibration software using the installation guide file on CD ROM. After installing the software, start the application.
Page 26
Software Installation PVI Value displays the current present value of furnace temperature. The Scale Trend section enables you to configure Y-Axis Min (minimum value: 0), Y-Axis Max (maximum value: 1500), Maximum Time Span of data logging up to 120 minutes, and then click the Start Graph button. After completing the task, click Save To File to save settings to file.
Turn the electricity supply off before attempting any cleaning operation. The only moving part in this unit is fan, which is sealed for life. Depending on the environment in which CALsys -30/110 is used, periodic cleaning is recommended. Cleaning may be accomplished by the use of a small dry paint brush. The instrument should be periodically checked to ensure it is in good order both mechanically and electrically.
8.1 CALsys -30/110 unit does not turn on If the CALsys -30/110 unit does not turn on or operate as usual, check if the fuse is broken, and replace the fuse if necessary. If the fuse breaks repeatedly, contact Tempsens for technical support.
Appendix A: Calibration Services Tempsens Calibration Center is an independent unit of Tempsens instruments (I) Pvt. Ltd, having laboratories at Udaipur, Vadodara & Bangalore. It is accredited for wide range of temperature calibration services. It is the only private sector Laboratory in the country with accredited Fixed Point Temperature Calibration Facilities.
INTERFERENCE WITH OR FAILURE TO PROPERLY MAINTAIN THIS INSTRUMENT MAY INVALIDATE THIS GUARANTEE Limit of Liability TEMPSENS is not liable for any damages that arise from the use of any examples or processes mentioned in these Specifications are subject to change without notice. Caution in Using the Product TEMPSENS PRODUCTS ARE INTENDED FOR USE BY TECHNICALLY TRAINED AND COMPETENT PERSONNEL FAMILIAR WITH GOOD MEASUREMENT PRACTICES.
