Muratec MFX-1300 Quick Reference
Muratec mfx-1300: quick start
Hide thumbs
Also See for MFX-1300:
- Field engineering manual (232 pages) ,
- Specifications (2 pages) ,
- Features (2 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Muratec MFX-1300
Summary of Contents for Muratec MFX-1300
- Page 2 Press to change COPY/FAX to Fax mode. Enter the fax number using the numeric keypad Press the one-touch key* Press SPEED DIAL/TEL INDEX enter the three-digit identifier for the speed-dial number using the numeric keypad : When you press a one-touch key, you do not need to press START You can set up to 50 sheets of letter-, legal- or...
- Page 3 Press COPY/FAX to change to Fax mode. Open the platen cover. If there's a document in the ADF, remove it. Place the document on the FBS glass face down and align it to the right front corner. Close the platen cover. Press DOCUMENT SIZE select the document size.
- Page 4 Press to change COPY/FAX to Fax mode. Set the document in the ADF face up, or on the FBS glass face down. Adjust the document type and the contrast, if necessary. " Enter the fax number using the numeric keypad Press the one-touch key* Press SPEED DIAL/TEL INDEX...
- Page 5 Press COMM.CANCEL/CONFIRM. Press to scroll through currently stored commands. Press to see the individual numbers within the broadcast. Press until you find the number you want to cancel. If you want to cancel the command shown, press CANCEL, CANCEL If you want to cancel another command, go back to step 2. Press STOP...
- Page 6 Press to change COPY/FAX to Copy mode. Set the document in the ADF face up, or on the FBS glass face down. Press to clear COPY RESET the previously entered copy settings. Adjust the following, if necessary. • Select the document size by pressing the DOCUMENT SIZE •...
-
Page 7: Press Start
Press to change COPY/FAX to Copy mode. Press to turn the sort SORT setting to on or off. When the sort setting is On, the LED on glows. SORT Helpful Tip The sort setting is set to On for the default setting. To change the default setting: 1. - Page 8 If you want enlarged copies, use the FBS glass. Set the document in the ADF or on the FBS glass. Adjust the document type and the contrast, if necessary. Enter the document size by pressing the DOCUMENT SIZE & Fixed ratio Choose the desired ratio by using or of the cursor key.
- Page 9 Adjust by 1 percent increments Press to turn the ZOOM ZOOM Adjust the ratio by 1 percent increments using or of the cursor key. You can set the ratio between 50% and 200%. Direct Press #. Enter your desired ratio (50 to 200) using the numeric keypad.
- Page 10 Press to change COPY/FAX to Copy mode. Open the bypass tray on the right side of your machine. Flapper release lever Pull out the hopper of the bypass tray and pull the flapper release lever. Set the document in the ADF face up, or on the FBS glass face down.
- Page 11 The LCD will show the default paper size for the bypass tray. If you want to change it, proceed to step 6. Otherwise, skip to step 8. Press to change the paper BYPASS size. The LCD will show: Press until your desired recording paper size appears.
- Page 12 If you see this message on the LCD and wish to continue scanning from the jammed page, press ENTER To abort the operation, press CANCEL. In this step, if more than 60 seconds passes without pressing any keys, the machine will erase from memory all pages stored during this operation and the machine will return to the standby mode.
- Page 13 To remove the document . . . Open the scanner cover. Remove the original document. If you cannot remove it, go to step 2. Otherwise, skip to step 3. Open the inner cover. Remove the original document. Gently close the scanner cover. Make sure both sides are If the document has become wrinkled snapped down securely.
- Page 14 Important ! Be careful not to put your hand between the top cover and the machine. Pull up the top cover release and open the top cover. Important ! Shield the drum cartridge from light, especially strong light. Remove the toner and drum cartridge.
- Page 15 Important ! The fuser unit becomes very hot. Do not touch the fuser unit when you are removing jammed paper. Remove the jammed paper. Gently close the top cover. Press firmly on the both sides of the cover until you hear it click. Open the side cover.
-
Page 16: Function Table
To go to the right or left in this table, press key. For example, if you want to enter a Speed-Dial, press Program key, , , , Note: “Page” in the rightest column in this table means the pages in the MFX-1300/1700 Operating Instructions. - Page 17 07.Quick Memory Tx 08.TTI Tx 09.ECM Mode 10.Block Junk Fax 11.Security Rx 12.PIN Mode 13.Passcode 14.Rotate Rx (for MFX-1700 only) 14.DRD (for MFX-1300) 15.DRD (for MFX-1700) 3.Copy Settings 01.Scan Parameters 02. Print parameter 03.Auto Reset Time 04.Copy Auto 05.Copy Protect 06.Sort Copy 07.Nega/Posi...
- Page 18 Level one function Level two function B. User Settings 4.Printer Settings 5.Scanner Settings* C. Other Settings 1.Journal & Reports 2.Cover Page 3.Department Code 4.F-Code Box 5.Batch Tx D. Doc. Management 1.Store Document 2.Erase Document 3.Document Print *3: This option appears only if the optional NIC (network interface card) has been installed. *4: This option appears only if the optional printer controller has been installed.
- Page 19 Level one function Level two function Level three function E. Print 1.List Print 01.Machine Settings 02.Fax Settings 03.Copy Settings 04.Journal 05.Commands List 06.One-Touch List 07.Speed-Dial List 08.P One-Touch List 09.Group List 10.Block Junk Dial List 11.Cover Page 12.Depart. Time List 13.F-Code Box List 14.F-Code Doc.
- Page 20 Muratec America, Inc. 6400 International Parkway Suite 1500 Plano, Texas 75093 http://www.muratec.com © Muratec America, Inc. 2002 Printed in China. MAI order number: OMF1300QRG MML item number: D88-90250-60...
