NETGEAR Sprint Spark Get Started

All manuals and user guides at all-guides.com
Get Started
What's in the Box
Your Device
Battery
USB Cable
Battery
Cover
Your Mobile Hotspot lets you set up and share an on-the-go Wi-Fi hotspot
for up to 10 devices.
Your Device
Sprint
LCD screen
100%
SprintWiFiXXX
10
39028176
1.25 of 5 GB left
External
antenna port
micro-USB charging port
Main LCD Screens
You can view basic settings and alerts on the LCD screen. Press the Navigation button
to scroll through the following screens:
Home Screen Wi-Fi Name and Wi-Fi Protected
Password Setup (WPS)
Sprint
100%
SprintWiFiXXX
10
39028176
1.25 of 5 GB left
Manage Your Account
Online: sprint.com/mysprint From a Phone
• Make a payment, see your bills, enroll in • Sprint Customer Service:
Dial 1-888-211-4727
online billing.
• Check usage and account balance. • Business Customer Service:
Dial 1-888-788-4727
• See or modify the details of your
Sprint service plan.
• Get detailed instructions and
download content.
Resources
• User Guide – View the comprehensive User • Device Help – From the Mobile Hotspot
home page on your computer, click Support.
Guide online at sprint.com/support.
• Web – Go to sprint.com/support to
• Updates – The first time you connect your
access troubleshooting and other
Mobile Hotspot, from your Web browser go
to the device's home page by entering
resources. For software updates, go
http://192.168.1.1. Click Settings, click the
to sprint.com/downloads.
Software and Reset tab, and then, under
Software Update, click Check for Update.
Welcome!
Thanks for choosing Sprint. This booklet helps you get started with your
Sprint Spark™ capable*
ReadyNow – For more help in getting up and running with your new device,
take advantage of exclusive Ready Now resources at sprint.com/readynow.
You can even schedule a one-on-one appointment at a Sprint Store near you.
For ongoing support and resources, visit sprint.com/support. There, you'll
find guides, tutorials, and more to help you get the most out of your device.
Note: Available applications and services are subject to change at any time.
* The Sprint Spark enhanced LTE network is available in select markets.
Visit sprint.com/coverage for more information.
201-18774-01
Before You Start
Insert the Battery
1. Remove the back cover using the thumb catch
on the corner of the hotspot.
2. Align the battery's contacts with those inside
the battery compartment and gently press
down until the battery is seated.
Get Started Guide
3. Replace the back cover.
(This guide)
Note: Your device comes with a micro-SIM card
preinstalled. Do not remove the micro-SIM card.
Charge the Battery
1. Insert the USB cable into the charging
Charging Adapter
adapter.
2. Insert the small end of the USB cable into
the micro-USB charging port at the bottom
of the hotspot.
3. Plug the charging adapter into a standard
AC power outlet.
Get Connected
Power Up the Device
If the device is not powered on, press and
hold the Power button on the front of the
device for at least two seconds.
Power/Wake device/
Navigation button
External
• The device will automatically activate.
antenna port
Note: It can take several minutes for your
device to connect with the Sprint network.
Web Interface
Manage, monitor, and customize your device settings by using the Mobile Hotspot
Web-based interface.
About Your Device
1. On a computer connected to the Internet
via the Mobile Hotspot, open a browser and
type http://MyHotSpot or http://192.168.1.1
into the address bar and press Enter. The
Mobile Hotspot home page opens.
Sustainability
At Sprint, environmental responsibility is
more than talk. We're continuously working
to reduce our carbon footprint and decrease
our use of natural resources.
That's why you'll find your user guide, along
with expanded support resources, online at
sprint.com/support.
To find out more about our commitment,
visit sprint.com/green.
This guide is printed with vegetable based
inks and contains a minimum of 30%
recycled content or post consumer waste.
NETGEAR Fuse Mobile Hotspot .
Get Ready
1. Make sure you are in an area covered by
the Sprint network (not roaming).
2. Make sure the device you are trying to
connect to your Mobile Hotspot has its
Wi-Fi (wireless network connection) mode
turned on.
3. Make sure your Mobile Hotspot is set up on
your Sprint account. (Sign on to your
account at sprint.com/mysprint to verify.)
Connect to Your Device
1. Turn on your Mobile Hotspot and your
Wi-Fi-enabled device.
2. Open the Wi-Fi application or controls on
the computer or Wi-Fi-enabled device that
you want to connect to your Mobile Hotspot
and find the Wi-Fi name.
3. When prompted, enter your Wi-Fi password
to connect to the Internet.
Note: Your Wi-Fi name (SSID) and password
appear on the Mobile Hotspot LCD display.
2. In the Sign In field, enter the password
(1-31 letters, numbers, and symbols).
3. Click Sign In to display the home page.
Survey
Please tell us what you think about your
new device.
We are interested in your initial impressions
of this new Sprint device. Within two weeks of
your device purchase, please go to the website
http://labs.sprint.com/sprintphonesurvey to
complete a brief survey. Your feedback will
help us provide the wireless features and
services you want most.
Thank you for choosing Sprint.
©2015 Sprint. Sprint and the logo are trademarks of
Sprint. Other marks are property of their respective
owners. Screen images simulated. Appearance of
device may vary.
