Braun Under-Vehicle Lift NUVL855C Service Manual

Hide thumbs Also See for Under-Vehicle Lift NUVL855C:
Table of Contents

Advertisement

Quick Links

Download this manual
Under-Vehicle Lift
31937
Private Use Wheelchair Lifts
DOT — Private Use Lift
DOT — Private Use Lift
"DOT — Private Use Lift" verifies that this platform lift meets only
the "private use lift" requirements of FMVSS No. 403. This lift may
be installed on all vehicles appropriate for the size and weight of
the lift, except for buses, school buses, and multi-purpose
passenger vehicles other than motor homes with a gross vehicle
weight rating (GVWR) that exceeds 4,536 kg (10,000 lb).
"Providing Access to the World"
International Corporate Hdqrs: P .O. Box 310
1-800-THE LIFT
www.braunlift.com
35932 Rev. A
March 2010
Service Manual for:
Winamac, IN 46996 USA
®
(574) 946-6153
FAX: (574) 946-4670
W ARNING
®
Read manual
before operating
lift. Failure to do
so may result in
®
serious bodily
®
injury and/or
property damage.
Keep manual in
lift storage pouch.
