Braun Under-Vehicle Lift NUVL855C Service Manual

Hide thumbs Also See for Under-Vehicle Lift NUVL855C:
Table of Contents

Advertisement

Quick Links

Download this manual
www.braunlift.com
®
"Providing Access to the World"
International Corporate Hdqrs: P.O. Box 310
1-800-THE LIFT
®
(574) 946-6153
35185 Rev. A
June 2010
Service Manual for:
Under-Vehicle Lift
Private Use Wheelchair Lifts
Series
DOT — Private Use Lift
DOT — Private Use Lift
"DOT — Private Use Lift" verifies that this platform lift meets only
the "private use lift" requirements of FMVSS No. 403. This lift may
be installed on all vehicles appropriate for the size and weight of
the lift, except for buses, school buses, and multi-purpose
passenger vehicles other than motor homes with a gross vehicle
weight rating (GVWR) that exceeds 4,536 kg (10,000 lb).
®
®
Winamac, IN 46996 USA
FAX: (574) 946-4670
®
03
03
Read manual
before installing
or servicing lift.
Failure to do so
may result in
serious bodily
injury and/or
property damage.
W ARNING
