Toro 30629 Installation Instructions

Premium Seat Kit
Groundsmaster
Model No. 30629
Use of this product may cause exposure to chemicals known to the State of California
to cause cancer, birth defects, or other reproductive harm.
Installation
1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Engage the parking brake.
3. Shut off the engine and remove the key.
2
Removing the Existing Seat
No Parts Required
Procedure
1. Remove the 4 bolts and washers that secure the
seat-support straps to the fuel tank
Note:
Retain the bolts and washers for installing
the new seat.
2. Disconnect the electrical harness from the seat
switch on the bottom of the seat.
3. Remove and discard the bolts and washers that
secure the seat belt to the existing seat
1).
© 2019—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
® 3500-D/3505-D and Reelmaster
WARNING
CALIFORNIA
Proposition 65 Warning
(Figure 1).
(Figure
Register at www.Toro.com.
Note:
Retain the seat belt for installing the new
seat.
4. Remove and discard the 4 locknuts that secure
the seat to the seat-support straps
Note:
You may discard the seat straps.
Figure 1
1. Seat
2. Seat belt
Original Instructions (EN) All Rights Reserved *3428-921* A
Printed in the USA
Form No. 3428-921 Rev A
® 3100-D
Installation Instructions
(Figure
3. Support strap
1).
g220545
