EU Light Kit
2015 and After Groundsmaster
Cab
Model No. 30639
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
5
6
Media and Additional Parts
Description
Parts catalog
Installation instructions
© 2014—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Description
No parts required
Flasher bracket
Flange head screw, 1/4 x 1/2 inch
Flange nut, 1/4 inch
Flasher module
wiring harness
Switch, hazard
Cable tie
Headlamp bracket, left hand (for model
without cab)
Headlamp bracket, right hand (for model
without cab)
Headlamp bracket, right hand (for model
with cab)
Headlamp bracket, left hand (for model
with cab)
Headlamp right hand
Headlamp left hand
Flange head bolt, 1/2 1–1/4 inch
Flange nut, 1/2 inch
Headlight wiring cover (for model
without cab)
Plastic plug
Cable ties
Fuse, 10 amp
Fuse block
Decal, turn signal fuse
Rear lamp assembly
Cable tie mount
Cable tie
Register at www.Toro.com.
®
5910 Series Rotary Mower with
Qty.
–
1
2
2
1
1
1
2
1
1
1
1
1
1
2
2
2
8
6
1
1
1
2
2
4
Qty.
1
1
Form No. 3392-727 Rev A
Installation Instructions
Use
Disconnect the battery.
Install the flasher module.
Install the signal controller and hazard
switch.
Install the headlights.
Install the fuse block.
Install the rear lamps.
Use
Original Instructions (EN)
All Rights Reserved *3392-727* A
Printed in the USA.
Advertisement
Related Manuals for Toro 30639
Summary of Contents for Toro 30639
- Page 1 Form No. 3392-727 Rev A EU Light Kit 2015 and After Groundsmaster ® 5910 Series Rotary Mower with Model No. 30639 Installation Instructions Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty.
-
