Yaskawa V1000 / A1000 /
GA500 / GA800 TCP Modbus
Communication Setup
Change IP and Communication Parameters On V1000
For GA series drives make sure the Yaskawa Drive Wizard is updated to the most
recent version.
Quick access for the correct parameters:
Set these parameters from the front panel of the VFD and cycle power.
The default IP from the factor is 192.168.1.20. Each of those numbers is an octet, and we will be
changing the third and fourth octet. The resulting IP address will be 192.168.208.90
(Some of this information is from
cards with Short
Video)
Parameter Number
F7-01
F7-02
F7-03
Quick Start Settings for EtherNet IP and Modbus TCP/IP option
Parameter Description
IP Address 1
IP Address 2
IP Address 3
Settings for Ethernet, PROFINET and
Modbus TCP/IP
192: Sets the most significant octet
(192 is the default value)
Example: 192.168.001.020
168: Sets the second significant octet
(168 is the default value)
Example: 192.168.001.020
208: Sets the third significant octet
(001 is the default value)
Example: 192.168.208.020
Advertisement
Related Manuals for YASKAWA V1000
Summary of Contents for YASKAWA V1000
- Page 1 GA500 / GA800 TCP Modbus Communication Setup Change IP and Communication Parameters On V1000 For GA series drives make sure the Yaskawa Drive Wizard is updated to the most recent version. Quick access for the correct parameters: Set these parameters from the front panel of the VFD and cycle power.
- Page 2 90: Sets the fourth significant octet F7-04 IP Address 4 (020 is the default value) Example: 192.168.001.090 0: Static F7-13 Address Mode at Startup 1: BOOTP 2: DHCP O1-03 Frequency Display Unit Selection 1 : 0.01% units F7-03 : 208 F7-04 : 090 (If multiple drives are present, see note at bottom.) F7-13 : 00 O1-03 : 1 on release later than 16161 The six parameters below are usually set by Mach (sometimes).
- Page 3 -Change F6-14 to "1" 9. Power cycle control and enclosure to reset VFD. NOTE: For multiple V1000's, each drive will need it's own IP address. So, set the F7-04 parameter for each drive in ascending order (90, 91, 92.) NOTE: For the B1-01 and B1-02 parameters, we ship many of our drives with an option card that requires them both be set to "3."...
- Page 4 correct parameters.
