Water Filtration System model GX1S01C (Filters not included)
Check with your local public works department for
plumbing codes. You must follow these guidelines
as you install the Water Filtration system.
Use the Water Filtration system on a potable,
safe-to-drink, home COLD water supply only.
The filter cartridge will not purify the water,
or make it safe to drink.
Do not use on a hot water supply (100°F. max.).
Install or store where it will not be exposed to temperatures
below freezing or exposed to any type of weather. Water
freezing in the system will damage it.
Your Water Filtration system will withstand up to 125 pounds
per square inch (psi) water pressure. If your house water
supply pressure is higher than 100 psi, install a pressure
reducing valve before installing the Water Filtration system.
REQUIRED TOOLS FOR INSTALLATION
Slotted and Phillips screwdrivers
Pliers and adjustable jaw wrench
GX1S01C is Tested and Certified
by NSF International against
ANSI/NSF Standard 42 for
material and structural integrity
requirements only.
Filter (not included)
FXUTC – Taste and Odor
Inlet-outlet–3/8" NPT
GENERAL ELECTRIC COMPANY, Appliance Park, Louisville, KY 40225
GE SmartWater
INSTALLATION INSTRUCTIONS
SAFETY PRECAUTIONS
Component
SPECIFICATION GUIDELINES
Service
flow rate
1.0 gpm
3000 gal. or 6 months
Part No. 215C1044P011
For Use and Care questions call: GE Answer Center® 800.626.2000
™
WARNING:
Do not use with water that is
microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
Discard all unused and packaging material after
installation. Small parts remaining after installation could
be a choke hazard.
OPTIONAL KITS AND TOOLS FOR INSTALLATION
NOTE: Installation kit (SSKIT), sump wrench (UCWRNCH)
and faucet (UNFCTBL or UNFCTWW) are sold separately
for model GX1S01C.
Hand- or battery-powered drill and
valve installation)
Electric drill and drill bit to drill
required) if mounting hole is needed for faucet
Pipe cutter
File
CAUTION:
qualified plumber or installer for drilling procedures.
Special drill bits may be needed for porcelain or
stainless steel.
Capacity
Pressure
40-125 psi
Pub. No. 49-50044
(10-99 JR)
1
" bit (saddle
⁄
1
4
" hole (type as
⁄
3
4
To avoid damaging the sink, consult a
Temperature
40-100°F
