IPLEX FX/LX STEREO
MEASUREMENT
REFERENCE GUIDE
PREPARATIONS FOR STEREO
MEASUREMENT
• Attach a stereo optical adapter to the distal end of a
scope while the live screen is displayed.
<For FX/LX 8.5-mm type>
Select the stereo optical adapter to be used in the
adapter selection screen, and press the [MEAS/ENTER]
joystick.
<For LX 4-mm and 6-mm types>
Confirm the name of the stereo optical adapter and the
set number, and then select "OK". Press the
[MEAS/ENTER] joystick.
• When using a stereo optical adapter for the first time,
installation will be required. Select the [NEW STEREO
ADAPTER] option from the menu and follow the
on-screen directions. For full details please refer to the
instruction manual.
MEASUREMENT METHOD (MEASUREMENT MODE)
• Immediately after executing stereo measurement or
selecting "METHOD" in the stereo measurement
screen, the measurement method (measurement mode)
selection screen is displayed.
• Refer to the following page for the usable measurement
method (measurement mode). (Some functions are not
available for LX.)
SPOT RANGING —
OBJECT DISTANCE MEASUREMENT
• Tilt the [ZOOM] lever toward [W] to activate the
measuring distance to object function.
• Highest accuracy is achieved when green zone is
displayed in object distance. To achieve highest
measurement accuracy, bring the insertion tube to an
object as close as possible.
• Push the
[MEAS/ENTER]
joystick to proceed
to the stereo
measurement
screen.
• Object distance is
ceaselessly
displayed in the
stereo
measurement
screen.
Measurement Object distance
point cursor
