Icom IC-F24/S Service Manual Addendum page 20

Feb. 2009
SECTION 6.
[ANT UNIT]
REF PARTS
NO. NO.
L601 6200013010 S.COI 0.30-0.9-5TL 10.3N <COMO>
C601 4030017600 S.CER ECJ0EC1H080C
[CONNECT UNIT]
REF PARTS
NO. NO.
C501 4030017460 S.CER ECJ0EB1E102K
C502 4030016930 S.CER ECJ0EB1A104K
J501 6910016390 CON IMSA-9230B-1-02Z145-PT1
PARTS LIST
DESCRIPTION M.
LOCATION
B
B
DESCRIPTION M.
LOCATION
T
T
[MAIN UNIT]
H/V REF PARTS
NO. NO.
7.2/12.5 IC1 1110003201 S.IC
IC2 1130008561 S.IC
IC4 1140005991 S.IC
5.8/15.3 IC5 1110005340 S.IC
IC6 1110005320 S.IC
IC7 1110005330 S.IC
IC8 1190000350 S.IC
IC9 1110005350 S.IC
IC10 1130011770 S.IC
H/V
IC12 1110001811 S.IC
IC13 1140012721 S.IC
IC14 1110006260 S.IC
8.3/5.3
IC15 1130011540 S.IC
9.3/5.3
Q1 1560000841 S.FET
Q2 1580000731 S.FET
Q3 1580000800 S.FET
Q4 1530002601 S.TRA
Q5 1530000371 S.TRA
Q6 1590003230 S.TRA
Q7 1560001232 S.FET
Q8 1560001241 S.FET
Q9 1530003311 S.TRA
Q10 1530003311 S.TRA
Q11 1530003311 S.TRA
Q12 1530003311 S.TRA
Q13 1530002920 S.TRA
Q14 1530002920 S.TRA
Q15 1590001400 S.TRA
Q16 1590003290 S.TRA
Q17 1530002851 S.TRA
Q18 1560000541 S.FET
Q19 1530002851 S.TRA
Q21 1510000920 S.TRA
Q22 1510000920 S.TRA
Q23 1520000460 S.TRA
Q24 1590001190 S.TRA
Q25 1590003230 S.TRA
Q26 1590003290 S.TRA
Q27 1590003290 S.TRA
Q28 1590003430 S.TRA
Q29 1590003270 S.TRA
Q30 1510001080 S.TRA
Q31 1590001190 S.TRA
Q32 1590003020 S.TRA
Q33 1590003230 S.TRA
Q34 1560001360 S.FET
Q35 1560001360 S.FET
D1 1750001080 S.DIO
D2 1750000581 S.DIO
D3 1750000711 S.VAR
D4 1750000711 S.VAR
D5 1790001260 S.DIO
D6 1790001240 S.DIO
D7 1750000711 S.VAR
D8 1750000711 S.VAR
D9 1750000711 S.VAR
D10 1750000711 S.VAR
D14 1790001260 S.DIO
D15 1790001260 S.DIO
D16 1750000711 S.VAR
D17 1750000711 S.VAR
D18 1720000570 S.VAR
D21 1750000711 S.VAR
D22 1750000711 S.VAR
D24 1790001250 S.DIO
D25 1790001250 S.DIO
D26 1790001790 S.DIO
D27 1750000520 S.DIO
D28 1790001260 S.DIO
D29 1750000940 S.DIO
D30 1750001080 S.DIO
D31 1790001010 S.ZEN
1790001010 S.ZEN
1790001010 S.ZEN
FI1 2030000150 S.MON DSF753SB 46.350 MHz(FL-335)
FI2 2020002410 CER
FI3 2040001440 S.LC
X1 6070000191 S.DIS
X2 6050011940 S.XTA
X3 6050011720 S.XTA
L1 6200012490 S.COI
L2 6200013010 S.COI
L3 6200012610 S.COI
L4 6200012610 S.COI
L5 6200010850 S.COI
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION M.
TA31136FNG(EL) B
TC75S51F(TE85L,F) T
MB15A02PFV1-G-BND-ERE1 T
NJM12902V-TE1-#ZZZB T
NJM13403V-TE1-#ZZZB T
NJM12904V-TE1-#ZZZB T
M62363FP-650C T
NJM2870F05-TE1-#FZZB B
CD4066BPWR T
TA7368FG(5,ER) T
HD6433687C73FPV(FX-2775A-1) T
BD5242G-TR T
BR24L16FV-WE2 B
2SK1829(TE85R,F) T
3SK293(TE85L,F) B
3SK324UG-TL-E B
2SC4215-O(TE85R,F) B
2SC3356-T1B S (R25) T
UNR9113J-(TX) T
RD07MVS2-T112 T
RD01MUS1-T113 T
2SC5107-O(TE85R,F) T
2SC5107-O(TE85R,F) T
2SC5107-O(TE85R,F) B
2SC5107-O(TE85R,F) T
2SC4226-T1 R25 T
2SC4226-T1 R25 T
XP1214(TX) B
UNR9213J-(TX) B
2SC4116-BL(TE85R,F) T
2SK880-Y(T5RICOM,F) B
2SC4116-BL(TE85R,F) T
2SA1577 T106 Q T
2SA1577 T106 Q T
2SB1132 T100 R T
XP6501-(TX).AB T
UNR9113J-(TX) T
UNR9213J-(TX) T
UNR9213J-(TX) T
UNR911HJ-(TX) B
UNR9210J-(TX) B
2SA2048 TLR T
XP6501-(TX).AB T
XP4216-(TX) T
UNR9113J-(TX) T
2SK3019 TL T
2SK3019 TL T
RB886G T2R B
1SV307(TPH3,F) B
HVC350BTRF-E B
HVC350BTRF-E B
MA2S077-(TX) B
MA2S728-(TX) B
HVC350BTRF-E B
HVC350BTRF-E B
HVC350BTRF-E B
HVC350BTRF-E B
MA2S077-(TX) T
MA2S077-(TX) T
HVC350BTRF-E T
HVC350BTRF-E T
MA368(TX) B
HVC350BTRF-E T
HVC350BTRF-E T
MA2S111-(TX) T
MA2S111-(TX) T
RB876W TL B
DAN222TL B
MA2S077-(TX) B
ISS400 TE61 B
RB886G T2R T
MA8043-L(TX) [USA-03] B
MA8043-L(TX) [GEN-03]
MA8043-L(TX) [USA-05]
B
LTM450FW
NFE31PT152Z1E9L
(NFM60R20T152) B
CDBKB450KCAY24-R0 T
CR-783 TTS14VSB-A6 15.3 MHz T
CR-764 SMD-49TB 19.6608 MHz B
0.30-0.9-6TR 13.6N <COMO> B
0.30-0.9-5TL 10.3N <COMO> B
0.40-0.9-2TL 2.8N <COMO> B
0.40-0.9-2TL 2.8N <COMO> B
LQW18AN22NG00D
(LQW1608A22NG00) [USA-02] B
S.=Surface mount
H/V
LOCATION
51.8/19
68.9/21
38.3/35.7
29.7/11.6
15.9/34.6
29.2/34.6
40.3/15.2
84.2/14.2
22.9/34.6
89.3/13.2
12.5/14.3
6.6/5.9
16/11.6
75/39.6
76.8/37.9
66.2/37.9
51.4/23.1
74.3/33.5
72.5/19.1
82.6/27
76.1/27.5
67/30.3
59.4/36.3
56.3/37
59/31.5
54.9/30.7
54.2/37.1
56.5/32.6
59.1/32.6
55.5/44.1
51.5/40.4
43.3/29.9
71.9/16.4
24.9/25.9
81/15.2
76.3/15.1
75.7/11.7
49.7/18.4
24.8/16.7
63.1/10.6
35.7/9.2
91.9/8.6
91.4/5.2
16.5/23.1
19.9/22.5
10.7/30.1
9.1/26.6
90.2/38.7
91.5/31.1
87.5/33.5
87.5/34.8
87.4/36.7
85/39.9
81.8/33.5
81.8/34.8
73.6/35.9
72.2/35.9
65.8/35.3
65.8/36.7
52.6/38.9
49.4/28.3
49.6/26.9
50.5/33.7
50.5/35.2
41.5/39.2
70.5/40.4
35.7/7.1
21.3/6
8.5/11.2
23.1/4
88.5/36.2
74.5/19.9
62.8/27.1
81.2/17.8
54.4/20
36.9/28.9
12/5.9
94.7/36.4
94.8/31.9
92.9/26.3
89.9/20.6
89.1/36.5
