  • Page 1 NP70PNP / NP71PNP...
  • Page 3 Preface Notebook Computer NP70PNP / NP71PNP Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the NP70PNP / NP71PNP series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD ....................A-6 Schematic Diagrams......... B-1 Overview ..................1-1 Specifications ..................1-2 System Block Diagram ..............B-2 External Locator - Top View with LCD Panel Open ......1-4 Processor 1/11 .................B-3 External Locator - Front & Right Side Views .........1-5 Processor 2/11 .................B-4 External Locator - Left Side &...
  • Page 12 Preface Misc - GPIO, I2C, ROM .............. B-30 NVVDD1 ..................B-62 IFP I/O Interface ................B-31 NVVDD2 ..................B-63 Straps and XTAL ................. B-32 PEX_VDD ..................B-64 NVIDIA Power Sequence ............B-33 FBVDDQ ..................B-65 OVR-M ..................B-34 1V8_AON, NV3V3, 3.3VA ............B-66 mDP ....................B-35 Audio Board + Redriver ...............B-67 Panel, Inverter ................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the NP70PNP / NP71PNP series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Options i7-12700H (2.30GHz), TDP 45W NVIDIA Advanced Optimus Capable Technology i5-12500H (2.50GHz), TDP 45W Supports up to 4 Active Displays  LCD Options Intel Integrated GPU Latest Specification Information LCD, 17.3" (43.94cm), 16:9, QHD (2560x1440)/FHD Intel®...
  • Page 15 Introduction Communication Environmental Spec Built-In 10/100/1000Mb Base-TX Ethernet LAN Temperature ° ° 1.0M HD Webcam Operating: 5 C - 35 Non-Operating: -20°C - 60°C WLAN/ Bluetooth M.2 Modules: Relative Humidity (Factory Option) Intel® Dual Band Wi-Fi 6E AX211, 2x2 AX Operating: 20% - 80% Wireless LAN + Bluetooth Non-Operating: 10% - 90%...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Webcam 2. *Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. Display 5. Power Button 6.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. Speaker 2. MicroSD Card Reader 3. Thunderbolt 4 RIGHT SIDE VIEW Port 4. RJ-45 LAN Jack 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. Vent 3. USB 3.2 Gen 1 LEFT SIDE VIEW Type-A Port 4. USB 2.0 Port 5. Microphone-In Jack 6. 2-In-1 Audio Jack (Headphone and Microphone) 7.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. RJ-45 LAN Jack 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (M.2 SSD Module) 2. Mini-Card Connector (WLAN Module) 3. Memory Slots DDR4 SO-DIMM 4. CPU 5. GPU Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. DC-In Jack 2. Mini Display Port 3. HDMI Port 4. Keyboard Cable Connector 5. LED KB Connector 6. MicroSD Card Reader 7. Thunderbolt 4 Port 8. RJ-45 LAN Jack 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. RJ-45 LAN Jack 2. CCD Connector 3. Fan Connector 4. LED Connector 5. Clickpad Cable Connector 6. Battery Connector 7. Audio Connector 8. LCD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the NP50D5 series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, optical device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the Keyboard: 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom case (Figure 1a). a. Remove the screws. 3. Carefully lift the bottom case up in the direction of the arrow at point and remove it (Figure 1b b.
  • Page 30 Disassembly 4. The battery will be visible at point on the computer (Figure 2c Figure 2 5. Carefully disconnect the cable , then remove screws (Figure 2d Battery Removal 6. Lift the battery off the computer (Figure 2e (cont’d.) 7. Reverse the process to install a new battery (do not forget to replace all the screws and the bottom cover). c.

  • Page 31: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 3 Keyboard Removal Keyboard Removal Procedure a. Remove the adhesive 1. Turn off the computer, remove the battery (page 2 - mylar from the keyboard. 2. The keyboard adhesive mylar will be visible at point on the computer.
  • Page 32 Disassembly 4. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable . Disconnect the key- Figure 4 board ribbon cable from the locking collar socket by using a flat-head screwdriver to pry the locking collar pins Keyboard Removal away from the base (Figure...
  • Page 33 Disassembly Keyboard Installation Procedure Figure 5 1. Make sure to insert a part of the adhesive mylar and then install it properly in the location as shown (Figure Keyboard 5a). Installation 2. Pull the mylar cover to reveal the adhesive side of the mylar (Figure 5b).

  • Page 34: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 6 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 35 Disassembly 4. Carefully lift and slightly slide the hard disk up Figure 7 5. Disconnect the hard disk assembly from the connector (Figure 7c HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 7d Removal (cont’d.) 7. Reverse the process to install a new hard disk (do not forget to replace the screws). c.

  • Page 36: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 8 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 8a).
  • Page 37 Disassembly M.2 SSD-2 Removal Procedure Figure 9 1. Turn off the computer, turn it over, remove the battery (page 2 - M.2 SSD-2 Module 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a). Removal 3.
  • Page 38 Disassembly M.2 SSD-2 Installation Procedure Figure 10 M.2 SSD-2 Module 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and hard disk (page 2 - 10). Installation 2. Disconnect the HDD connector cable (remove the screw and HDD bracket , if available) (Figure...

  • Page 39: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 11 RAM Module The computer has four memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) support- Removal ing DDR4 Up to 3200 MHz. The main memory can be expanded up to 32GB. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 40: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 12 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 12a).

  • Page 41: Wireless Lan, Combo Module Cables

    Disassembly Wireless LAN, Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identifi- cation as outlined in the table below.
  • Page 42 Disassembly 2 - 18...

  • Page 43: Part Lists

    Appendix A: Part Lists This appendix breaks down the NP70PNP / NP71PNP series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 page A - 4 Bottom page A - 5 Main Board page A - 6 A - 2...

  • Page 45: Top

    Figure A - 1 Top A - 3...

  • Page 46: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 47: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 48: Lcd

    Figure A - 4 A - 6 LCD...

  • Page 49: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the NP70PNP / NP71PNP notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 50 Schematic Diagrams System Block Diagram 5V,3.3V,5VS,3.3VS NPXXPNP System Block Diagram SHEET 53 nVIDIA NV eDP (4x) VCCST,VCC1P8_CPU,1.8VA 40x40mm GN20-E3 2714 Balls SHEET 54 PCIE Gen4 X8 DDS Bus Switch eDP PANEL (Include VRAM,OVRM,Green PAK) Connector VDD3,VDD5 INTEL eDP (4x) PS8461E-A3 SHEET 15 ~ 24, 26 ~ 34 SHEET 72 SHEET 36...
  • Page 51 Schematic Diagrams Processor 1/11 U57B INS70566183 BMAP_REV = 0.52 M_A_DQ[63:0] DDR4(IL) / DDR4(NIL) / DDR5(NIL) / LP4x-LP5(NIL) M_A_DQ41 DH58 CD49 DDR0_DQ_0_7/DDR0_DQ_0_7/DDR0_DQ_0_7/DDR0_DQ_0_7 DDR0_CLK_P_1/DDR3_CLK_P/DDR3_CLK_P/DDR3_CLK_P/DDR1_CLK_P_1 M_A_CLK_DDR1 M_A_DQ45 DG57 CD48 DDR0_DQ_0_6/DDR0_DQ_0_6/DDR0_DQ_0_6/DDR0_DQ_0_6 DDR0_CLK_N_1/DDR3_CLK_N/DDR3_CLK_N/DDR3_CLK_N/DDR1_CLK_N_1 M_A_CLK_DDR#1 M_A_DQ40 DH56 CH61 DDR0_DQ_0_5/DDR0_DQ_0_5/DDR0_DQ_0_5/DDR0_DQ_0_5 NC/DDR2_CLK_P/DDR2_CLK_P/DDR2_CLK_P/DDR1_CLK_P_0 M_A_DQ44 DG60 CF61 DDR0_DQ_0_4/DDR0_DQ_0_4/DDR0_DQ_0_4/DDR0_DQ_0_4 NC/DDR2_CLK_N/DDR2_CLK_N/DDR2_CLK_N/DDR1_CLK_N_0 M_A_DQ46 DL60 CN49 DDR4 NC...
  • Page 52 Schematic Diagrams Processor 2/11 U57C INS70681331 BMAP_REV = 0.52 M_B_DQ[63:0] DDR4 / LP4x / LP5_ascend / LP5_descend / DDR5 M_B_DQ41 BB58 DDR0_DQ_4_7/DDR1_DQ_0_7/DDR2_DQ_0_7/DDR4_DQ_0_7 DDR1_CLK_P_1/DDR7_CLK_P/DDR7_CLK_P/DDR7_CLK_P/DDR3_CLK_P_1 M_B_CLK_DDR1 M_B_DQ40 BA57 DDR0_DQ_4_6/DDR1_DQ_0_6/DDR2_DQ_0_6/DDR4_DQ_0_6 DDR1_CLK_N_1/DDR7_CLK_N/DDR7_CLK_N/DDR7_CLK_N/DDR3_CLK_N_1 M_B_CLK_DDR#1 M_B_DQ44 BB56 AB61 DDR0_DQ_4_5/DDR1_DQ_0_5/DDR2_DQ_0_5/DDR4_DQ_0_5 NC/DDR6_CLK_P/DDR6_CLK_P/DDR6_CLK_P/DDR3_CLK_P_0 M_B_DQ45 BA60 DDR0_DQ_4_4/DDR1_DQ_0_4/DDR2_DQ_0_4/DDR4_DQ_0_4 NC/DDR6_CLK_N/DDR6_CLK_N/DDR6_CLK_N/DDR3_CLK_N_0 M_B_DQ46 BE60 AG49 DDR4 NC DDR0_DQ_4_3/DDR1_DQ_0_3/DDR2_DQ_0_3/DDR4_DQ_0_3...

  • Page 53: Processor 11/11

    Schematic Diagrams Processor 3/11 U57A INS70534234 eDP PANEL BMAP_REV = 0.52 DIFF=85ohm TCP_0 DDIA_TXP_3 TCP0_TXRX_P1 EDP_TXP_3 TCP0_TXRX1_DP DDIA_TXN_3 TCP0_TXRX_N1 TCP0_TXRX1_DN EDP_TXN_3 DDIA_TXP_2 TCP0_TXRX_P0 TCP0_TXRX0_DP EDP_TXP_2 EDP_TXN_2 DDIA_TXN_2 TCP0_TXRX_N0 TCP0_TXRX0_DN EDP_TXP_1 DDIA_TXP_1 TCP0_TX_P1 TCP0_TX1_DP DIFF=85ohm DDIA_TXN_1 TCP0_TX_N1 EDP_TXN_1 TCP0_TX1_DN DDIA_TXP_0 TCP0_TX_P0 TCP0_TX0_DP EDP_TXP_0 DDIA_TXN_0...
  • Page 54 Schematic Diagrams Processor 4/11 INS70537596 BMAP_REV = 0.52 U57H PEX4_TX3 PCIEX4_A_TX_P_3 PCIEX8_TX_P_7 PEG_TX7 15 PEX4_TX#3 PCIEX4_A_TX_N_3 PCIEX8_TX_N_7 PEG_TX#7 15 PCIEX4_A_RX_P_3 PCIEX8_TX_P_6 PEX4_RX3 PEG_TX6 15 PEX4_RX#3 PCIEX4_A_RX_N_3 PCIEX8_TX_N_6 PEG_TX#6 15 PCIEX8_TX_P_5 PEG_TX5 15 PEX4_TX2 PCIEX4_A_TX_P_2 PCIEX8_TX_N_5 PEG_TX#5 15 PEX4_TX#2 PCIEX4_A_TX_N_2 PCIEX8_TX_P_4 PEG_TX4 15 PCIEX4_A_RX_P_2 PCIEX8_TX_N_4...
  • Page 55 Schematic Diagrams Processor 5/11 BOARD ID1 LCD15 GPP_E11 U57J LCD_15 R742 100K_04 3.3VS BOARD_ID1 INS70745827 BMAP_REV = 0.52 LCD_17 R739 100K_04 LCD17 AD41 FC46 CSI_D_DP_1/CSI_C_DP_2 CNV_WT_D1P CNVI_W T_D1P AB41 FA46 CSI_D_DN_1/CSI_C_DN_2 CNV_WT_D1N CNVI_W T_D1N AG41 EV43 CSI_D_DP_0/CSI_C_DP_3 CNV_WT_D0P CNVI_W T_D0P AF41 EY43 CSI_D_DN_0/CSI_C_DN_3...
  • Page 56 Schematic Diagrams Processor 6/11 INS70811509 BMAP_REV = 0.52 U57F UART0_TXD EN48 EY28 0_04 R134 GPP_H11/UART0_TXD/M2_SKT2_CFG1 GPP_D14/ISH_UART0_TXD/I2C4B_SCL SATA_M2_PW R_EN2 UART0_RXD EN46 EV28 GPP_H10/UART0_RXD/M2_SKT2_CFG0 GPP_D13/ISH_UART0_RXD/I2C4B_SDA W LAN_W AKEUP# 0_04 R164 EL41 EY36 GPP_D16 GPP_H13/I2C7_SCL/UART0_CTS#/M2_SKT2_CFG3/ISH_GP7B/DEVSLP1B GPP_D16/ISH_UART0_CTS#/I2C7B_SCL DEVSLP1 GPP_H12 GPP_D15 EK41 EW36 GPP_H12/I2C7_SDA/UART0_RTS#/M2_SKT2_CFG2/ISH_GP6B/DEVSLP0B GPP_D15/ISH_UART0_RTS#/I2C7B_SDA follow CRB GPP_D18 EW30...
  • Page 57 Schematic Diagrams Processor 7/11 INS70945612 BMAP_REV = 0.52 U57G EY34 ER56 33_04 R789 GPP_D19/I2S_MCLK1_OUT GPP_R0/HDA_BCLK/I2S0_SCLK/DMIC_CLK_B0/HDAPROC_BCLK HDA_BITCLK EP60 33_04 R787 GPP_R1/HDA_SYNC/I2S0_SFRM/DMIC_CLK_B1 HDA_SYNC GPP_R2 EV53 ER57 33_04 R443 GPP_S0/SNDW0_CLK/I2S1_SCLK GPP_R2/HDA_SDO/I2S0_TXD/HDAPROC_SDO HDA_SDOUT EY53 ER59 GPP_S1/SNDW0_DATA/I2S1_SFRM GPP_R3/HDA_SDI0/I2S0_RXD/HDAPROC_SDI HDA_SDIN0 FA50 ER53 33_04 R786 GPP_S2/SNDW1_CLK/DMIC_CKL_A0/I2S1_TXD GPP_R4/HDA_RST#/I2S2_SCLK/DMIC_CLK_A0 AZ_RST#_R GPP_R5 FC50...
  • Page 58 Schematic Diagrams Processor 8/11 3.3VS STRAP 2 of 24 GPP_B18 INS70813196 SYS_RESET# R120 1K_04 BMAP_REV = 0.52 GPP_B18 U57U R124 *100K_04 R804 *4.7K_04 1.8VS CPU_CFG15 AF37 R803 *20K_04 R178 CFG_15 RSVD_TP_1 3.3VA CPU_CFG14 AH35 CFG_14 RSVD_TP_19 2021/10/05 CPU_CFG13 AF35 CFG_13 RSVD_TP_37 Rubband CPU_CFG12...
  • Page 59 Schematic Diagrams Processor 9/11 VDDQ INS71037525 VCCGT VCORE INS71027867 VCORE BMAP_REV = 0.52 BMAP_REV = 0.52 U57O U57M AD61 CP44 BA44 VDD2_1 VCCGT_1 VCCCORE_1 VCCCORE_51 AG61 CR45 BB43 VDD2_2 VCCGT_2 VCCCORE_2 VCCCORE_52 AN61 CT44 BB45 CG14 VDD2_3 VCCGT_3 VCCCORE_3 VCCCORE_53 AP41 CU43 BC44...
  • Page 60 Schematic Diagrams Processor 10/11 U57N INS71052522 VCCIN_AUX VCCIN_AUX 1.8VA PRIMARY SIDE SECONDARY SIDE BMAP_REV = 0.52 VCCIN_AUX VCCIN_AUX 7.7A 1.9A AL20 DW20 VCCIN_AUX_1 VCCPRIM_1P8_1 AL32 DW22 VCCIN_AUX_2 VCCPRIM_1P8_2 AN20 DW27 VCCIN_AUX_3 VCCPRIM_1P8_3 AN22 DW30 VCCIN_AUX_4 VCCPRIM_1P8_4 C136 AN30 DY21 C103 C123 C138 VCCIN_AUX_5...
  • Page 61 Schematic Diagrams Processor 11/11 BMAP_REV = 0.52 BMAP_REV = 0.52 BMAP_REV = 0.52 BMAP_REV = 0.52 NA_71925 NA_71925 NA_71925 NA_71925 INS70641895 INS70647479 INS70654879 INS70668362 U57P U57Q U57R U57S BMAP_REV = 0.52 NA_71925 NCTF AL15 BF58 CD58 DC47 ED58 INS70679026 U57D NCTF AL17 CE51...

  • Page 62: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] VTT_MEM VDDQ J_DIMMA_1B 2.5V J_DIMMA_1A M_A_DQ[63:0] VDD19 VDD18 M_A_DQ4 PLACE THE CAP CLOSE TO SODIMM M_A_CLK_DDR0 CK0_T VDD17 M_A_DQ5 M_A_CLK_DDR#0 CK0_C VDD16 VPP2 DDR_VREFCA_CHA_DIMM M_A_DQ2 M_A_CLK_DDR1 CK1_T VDD15 VPP1 M_A_DQ3 M_A_CLK_DDR#1 CK1_C VDD14 M_A_DQ1...

  • Page 63: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 VTT_MEM J_DIMMB_1B Channel B SO-DIMM 0[RAM2] VDDQ 2.5V VDD19 VDD18 VDD17 J_DIMMB_1A VDD16 VPP2 M_B_DQ[63:0] VDD15 VPP1 M_B_DQ1 M_B_CLK_DDR0 CK0_T VDD14 M_B_DQ4 M_B_CLK_DDR#0 CK0_C VDD13 3.3VS M_B_DQ6 M_B_CLK_DDR1 CK1_T VDD12 M_B_DQ3 M_B_CLK_DDR#1 CK1_C VDD11 M_B_DQ0 VDD10 VDDSPD M_B_DQ5...

  • Page 64: Vga Pci-E Interface

    Schematic Diagrams VGA PCI-E Interface 1V8_AON 33,63 NVVDD_PWRGD R177 NV PCI EXPRESS 10K_04 SM3018KWH PEG_CLKREQ# 1V8_AON R821 *10K_04 1V8_AON R180 R822 *10K_04 *10K_04 Place between 1/24 PCI_EXPRESS Place near balls GPU and PS PEX_VDD *SM3018KWH BR31 PEG_WAKE# PEX_WAKE BF32 PEX_DVDD BT30 BF34 30,33...

  • Page 65: Frame Buffer Partition A/B

    Schematic Diagrams Frame Buffer Partition A/B PAGE3: GPU FRAME BUFFER PARTITION A/B 3/24 FBB 2/24 FBA FBB_DBI[7..0] FBB_D0 FBB_CMD0 FBA_D0 AC51 FBA_CMD0 FBA_DBI[7..0] FBB_DBI[7..0] 19,20 FBB_D0 FBB_CMD0 FBA_D0 FBA_CMD0 FBA_DBI[7..0] 17,18 FBB_D1 FBB_CMD1 FBA_D1 AB48 AA56 FBA_CMD1 FBB_D1 FBB_CMD1 FBA_D1 FBA_CMD1 FBB_EDC[7..0] FBB_D2...

  • Page 66: Frame Buffer A

    Schematic Diagrams Frame Buffer A FRAME BUFFER PARTITION A 31..0 FBA_W CK01 FBA_DBI[3..0] FBVDDQ FBA_W CK01 M10D FBA_W CK01# FBA_DBI[3..0] FBA_W CK01# FBA_W CK23 FBA_EDC[3..0] FBA_W CK23 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBA_W CK23# FBA_EDC[3..0] FBA_W CK23# FBA_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBA_W CKB01 FBA_CMD[24..0] FBA_W CKB01 FBA_W CKB01#...
  • Page 67 Schematic Diagrams Frame Buffer A FRAME BUFFER PARTITION A 63..32 FBA_W CK45 FBA_DBI[7..4] FBVDDQ FBA_W CK45 FBA_W CK45# FBA_DBI[7..4] FBA_W CK45# FBA_W CK67 FBA_EDC[7..4] VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBA_W CK67 FBA_W CK67# FBA_EDC[7..4] FBA_W CK67# FBA_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBA_W CKB45 FBA_CMD[52..28] FBA_W CKB45 FBA_W CKB45#...

  • Page 68: Frame Buffer B

    Schematic Diagrams Frame Buffer B FBB_W CK01 FRAME BUFFER PARTITION B 31..0 FBB_DBI[3..0] FBVDDQ FBB_W CK01 M12D FBB_W CK01# FBB_DBI[3..0] FBB_W CK01# FBB_W CK23 FBB_EDC[3..0] FBB_W CK23 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBB_W CK23# FBB_EDC[3..0] FBB_W CK23# FBB_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBB_W CKB01 FBB_CMD[24..0] FBB_W CKB01 M12A...
  • Page 69 Schematic Diagrams Frame Buffer B FRAME BUFFER PARTITION B 63..32 FBB_W CK45 FBB_DBI[7..4] FBVDDQ FBB_W CK45 M11D FBB_W CK45# FBB_DBI[7..4] FBB_W CK45# FBB_W CK67 FBB_EDC[7..4] FBB_W CK67 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBB_W CK67# FBB_EDC[7..4] FBB_W CK67# FBB_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBB_W CKB45 FBB_CMD[52..28] FBB_W CKB45 M11A...

  • Page 70: Frame Buffer Partition C/D

    Schematic Diagrams Frame Buffer Partition C/D GPU FRAME BUFFER PARTITION C/D 5/24 FBD 4/24 FBC FBD_D0 FBD_CMD0 FBC_D0 FBC_CMD0 FBC_D0 FBC_CMD0 FBC_D1 FBC_CMD1 FBC_DBI[7..0] FBD_D1 FBD_CMD1 FBC_D1 FBC_CMD1 FBC_DBI[7..0] 22,23 FBC_D2 FBC_CMD2 FBD_D2 FBD_CMD2 FBC_D2 FBC_CMD2 FBC_D3 FBC_CMD3 FBC_EDC[7..0] FBD_D3 FBD_CMD3 FBC_D3 FBC_CMD3...

  • Page 71: Frame Buffer C

    Schematic Diagrams Frame Buffer C FRAME BUFFER PARTITION C 31..0 FBC_W CK01 FBVDDQ FBC_W CK01 FBC_DBI[3..0] M14D FBC_W CK01# FBC_DBI[3..0] FBC_W CK01# FBC_W CK23 FBC_EDC[3..0] FBC_W CK23 VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBC_W CK23# FBC_EDC[3..0] FBC_W CK23# FBC_CMD[24..0] 8Gb GDDR6 SGRAM C-die FBC_W CKB01 FBC_CMD[24..0] FBC_W CKB01 M14A...
  • Page 72 Schematic Diagrams Frame Buffer C FRAME BUFFER PARTITION C 63..32 FBC_W CK45 FBVDDQ FBC_W CK45 FBC_DBI[7..4] M13D FBC_W CK45# FBC_DBI[7..4] FBC_W CK45# FBC_W CK67 FBC_EDC[7..4] FBC_W CK67 FBC_W CK67# VRAM=K4Z80325BC-HC14 (16*256M*2CH) FBC_EDC[7..4] FBC_W CK67# FBC_CMD[52..28] FBC_W CKB45 FBC_CMD[52..28] 8Gb GDDR6 SGRAM C-die FBC_W CKB45 M13A M13B...

  • Page 73: Edp-C

    Schematic Diagrams EDP-C Sheet 24 of 69 EDP-c Title Title Title [24] EDP-c SPEC [24] EDP-c SPEC [24] EDP-c SPEC Size Size Size Document Number Document Number Document Number ADL-H+GN20-E3 ADL-H+GN20-E3 ADL-H+GN20-E3 6-71-NP5P0-D02 6-71-NP5P0-D02 6-71-NP5P0-D02 Date: Date: Date: Wednesday, December 29, 2021 Wednesday, December 29, 2021 Wednesday, December 29, 2021 Sheet...

  • Page 74: Gpu Gnd

    Schematic Diagrams GPU GND GPU GND 11/24 XVDD 16/24 GND_2/5 21/24 GND_3/5 CONFIGURABLE 15/24 GND_1/5 24/24 GND_5/5 23/24 GND_4/5 POWER CHANNELS AR42 AE35 (NC on substrate) AL13 AR43 NVVDD NVVDD AE36 AL14 AR44 BF52 AE37 AL15 BF54 AE38 AL16 AR50 BG12 AA10 AE39...

  • Page 75: Gpu Nvvdd, Fbvddq

    Schematic Diagrams GPU NVVDD, FBVDDQ GPU NVVDD, FBVDDQ NVVDD NVVDD 17/24 VDD_1/2 NVVDD NVVDD NVVDD NVVDD 18/24 VDD_2/2 AB14 AF29 22/24 VDDMS FBVDDQ AB15 AF30 FBVDDQ AK38 AP39 AY27 AB13 AB16 AF31 VDDMS VDDMS AK39 AP40 AY28 AB44 AB17 AF32 VDDMS VDDMS 19/24 FBVDDQ...

  • Page 76: Gpu Decoupling - Nvvdd

    Schematic Diagrams GPU Decoupling - NVVDD Under GPU GPU NVVDD DECOUPLING GPU MSVDD DECOUPLING Under GPU NVVDD NVVDD NVVDD C289 C120 C212 C211 C304 C236 C303 C105 C235 C290 NV_0805 NV_0805 NV_0805 NVVDD Co-lay NVVDD C352 C153 C134 C206 C263 C314 C315 C256...

  • Page 77: [29] Gpu Decoupling-Fbvddq

    Schematic Diagrams GPU Decoupling - FBVDDQ FBVDDQ_GPU Under GPU Close to GPU FBVDDQ FBVDDQ Partition A 6x 1uF and 2x 10uF C451 C306 C298 C427 C372 C150 C183 C424 C220 C293 C310 C450 C281 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 1u_6.3V_X6S_04 10u_4V_X6S_06 10u_4V_X6S_06 NV_0402...

  • Page 78: Misc - Gpio, I2C, Rom

    Schematic Diagrams Misc - GPIO, I2C, ROM 1V8_AON MISC: GPIO, I2C, and ROM 1V8_AON NV3V3 R727 VBIOS ROM 14/24 MISC 2 *10K_04 1V8_AON R723 GPIO26_ROM_WP# 2M-Byte(16M-bit) R852 VGA_ROM_CS# STRAP0 ROM_CS 0_04 STRAP0 0_04 R847 R855 STRAP1 (OPTIMUS) STRAP1 R733 VGA_ROM_SI *10K_04 *10K_04 STRAP2...

  • Page 79: Ifp I/O Interface

    Schematic Diagrams IFP I/O Interface IFP I/O INTERFACE 7/24 IFPAB DL-DVI DVI/HDMI BT10 8/24 IFPC IFPA_AUX BT11 HDMI IFPA_AUX R785 1K_1%_04 BH20 IFPCD_RSET DVI/HDMI BR20 IFPA_L3 40 mil Under GPU R140 *1K_1%_04 BH23 BP20 IFPAB_RSET IFPA_L3 IF_PLLVDD BH19 BM10 IFPCD_PLLVDD IFPC_AUX GPU_PLLVDD HDMI_CTRLDATA...

  • Page 80: Straps And Xtal

    Schematic Diagrams Straps and XTAL Near GPU XTAL GPU_PLLVDD Under GPU 13/24 XTAL/PLL 40mil GPU_PLLVDD BG22 HCB1608KF-300T60 1V8_AON SP_PLLVDD 20mil 30ohm ESR 10mohm bead BG25 VID_PLLVDD C148 C116 C291 1u_6.3V_X6S_04 22u_6.3V_X6S_08 4.7u_6.3V_X6S_06 C139 NV_0402 M-C0805 NV_0603 1u_6.3V_X6S_04 NV_0402 40mil GPCADC_AVDD C284 1u_6.3V_X6S_04 BF25...

  • Page 81: Nvidia Power Sequence

    Schematic Diagrams NVIDIA Power Sequence DEFAULT HW POWER SEQUENCE 3.3VA FBVDDQ_EN NV_FBVDDQ_EN NV_EN_DOW N NV_PEXVDD_EN 27,65 VIN_DOWN PEX_VDD_EN From EC C691 *0.1u_10V_X7R_04 OVERT# OVERT# NVVDDS_EN OVERT#_EC R444 *200K_04 51,57,63,66 EC_GPIO 1V8_AON_PW RGD SUSB# NVVDD_EN NV_NVVDD_EN 63,64 R951 *0_04 15,63 NVVDD_PW RGD NVVDDS_PWRGD 3V3_SYS_EN NV_NV3V3_EN...

  • Page 82: Ovr-M

    Schematic Diagrams OVR-M Output power MEASUREMENT VDD3 3.3VS R310 R317 *0_04 0_04 U812_VCC C513 1u_6.3V_X6S_04 PW R_SRC_NV_VINP_R PFM_CH1_BS_IN1 U812_VCC R220 0_04 NVVDD BS_IN1 OVRM => change back OVRM => change back PW R_SRC_NV C465 *0.1u_50V_X5R_04 R219 *750_04 2021/10/19 2021/10/19 NV_0402 Rubband Rubband FBVDDQ...

  • Page 83: Mdp

    Schematic Diagrams For Safety LPS. NV_MDP_PW R 3.3V 1.5A 1.5A VOUT SY6288DAAC C770 *10u_6.3V_X5R_06 10u_6.3V_X5R_06 Layout Swap SY6288C20AAC NV_MDP_PW R ESD73034D 9,39,49,53,56,67,72 SUSB# I_MDP_D#2 I_MDP_D#2J GND1 COMMON GND2 I_MDP_D2 I_MDP_D2J High Close to Display PORT I_MDP_D#3 I_MDP_D#3J I_MDP_D3 I_MDP_D3J I_MDP_AUX#_J AUX_CHN I_MDP_D#2J LANE_2N...

  • Page 84: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL POWER DEFAULT PANEL CONNECTOR EMI Requirment SHORT VLED EMC11 EMC1 EMC8 EMC9 OPEN_2A LED PANEL (EDP Channel). 0.1u_50V_X5R_04 0.1u_50V_X5R_04 2021/1109 Angus PLVDD J_LCD1 1u_6.3V_X5R_02 EMC2 EMC24 EMC25 EMC51 1000p_50V_X7R_04 0.1u_50V_X5R_04 0.1u_50V_X5R_04 0.1u_50V_X5R_04 C822 0.1u_6.3V_X5R_02 DP_TXN0 C818 0.1u_6.3V_X5R_02 DP_TXP0...

  • Page 85: Hdmi

    Schematic Diagrams HDMI TMDS_CLOCK#_R EMR5 6.04_1%_04 TMDS_CLOCK#J TMDS_CLOCK_R TMDS_CLOCKJ EMR6 6.04_1%_04 HDMI TMDS_DATA0#_R TMDS_DATA0#J EMR7 HDMI 6.04_1%_04 TMDS_DATA0_R EMR8 6.04_1%_04 TMDS_DATA0J HDMI CONNECTOR HDMI HDMI ESD73034D HDMI HDMI_5VS TMDS_DATA1#_R EMR3 6.04_1%_04 TMDS_DATA1#J J_HDMI1 TMDS_DATA1_R TMDS_DATA1J EMR4 6.04_1%_04 VOUT HDMI C777 C776 C766 TMDS_DATA2#_R...

  • Page 86: Holes

    Schematic Diagrams Holes *C98D98N *C98D98N *C111D111N *C111D111N *C111D111N *C111D111N *MTH10_0D6_0 *MTH10_0D6_0 *MTH10_0D6_0 *MTH7_0D2_8 *C98D98N *C98D98N *C98D98N *M-MARK *M-MARK *M-MARK *MTH7_0D2_8 *M-MARK *M-MARK *M-MARK *H7_0D2_8 *H7_0D2_8 H7_0D2_8 H7_0D2_8 *M-MARK *M-MARK Sheet 37 of 69 *MTH7_0D2_8 P/N = 6-34-D90C0-021-1 P/N = 6-34-D90C0-021-1 Holes M/B PCH K/B HOLD...

  • Page 87: Pm Control, Clock Gen

    Schematic Diagrams PM Control, Clock Gen 3.3VS 3.3VA 3.3VA VDD3 R506 *0_04 C729 *0.1u_10V_X7R_04 VDD3 U28B R829 R828 U28A 74LVC08APW TO VR_ON & EC VCCST_OVERRIDE 100K_1%_04 100K_1%_04 74LVC08APW 9,39 RSMRST# ALL_SYS_PW RGD_R ALL_SYS_PW RGD SUSB# R510 0_04 R471 0_04 9,35,39,49,53,56,67,72 SUSB# ALL_SYS_PW RGD 9,36,51,57...

  • Page 88: Retimer 1/2

    Schematic Diagrams Retimer 1/2 +VCC3P3_LC_TCP0 +VCC0V9_SVR_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SX_TCP0 +VCC3V3_SVR_TCP0 U53D +VCC3V3_SVR_TCP0 INS66041717 U53C +VCC3P3A_SVR_TCP0 C646 SVR_VSS_2 VCC3P3_SX INS66041384 C650 C640 C658 C665 C664 SVR_VSS_1 +VCC3P3_ANA_TCP0 2.2u_6.3V_X5R_04 VCC3P3_ANA VCC3P3_SVR 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 VCC3P3_LC VCC3P3_SVR VSS_ANA VSS_ANA +VCC0P9_SVR_TCP0_PHASE SVR_IND_2 VCC3P3A VSS_ANA VSS_ANA C632 C635 SVR_IND_1 VSS_ANA...

  • Page 89: Retimer 2/2

    Schematic Diagrams Retimer 2/2 U53B U53A INS66042699 INS66043311 TBT_EE_CLK EE_CLK I2C_SDA RETIMER_I2C_SDA TBT_EE_CS_N ALL THESE CAPS ARE STUFFED EE_CS_N I2C_SCL RETIMER_I2C_SCL TCP0_TX0_C_DP TBTA_TXRX1_P_R TBT_EE_DI C972 0.22u_10V_X5R_02 TCP0_TX0_DP ASSRXP1 BSSRXP1 EE_DI I2C_INT RETIMER_I2C_INT C971 0.22u_10V_X5R_02 TCP0_TX0_C_DN TBTA_TXRX1_N_R TBT_EE_DO TC_RETIMER_FORCE_PW R TCP0_TX0_DN ASSRXN1 BSSRXN1 EE_DO...

  • Page 90: Pd65993, Type-C

    Schematic Diagrams PD65993, Type-C VCC3V3_PD R888 *0_04 TBTA_VBUS VBUS Source 5V,3A TBT_PA_VBUS HCB2012KF-800T80 80Ohm, 0.01Ohm DCR, 8A Idc MTDK5S6R main:6-21-B4K20-024 Q52A second: 6-21-B4K60-024 R325 ACE_I2C_SDA2 C999 SMD_VGA_THERM 30,51 10K_04 J_TYPEC2 TBT_TPS65993 1u_25V_X5R_06 TBTA_TX_1_P TBTA_TXRX_1_P TBT_RESET_N LDO_3V3 TX0_P RX0_P GPIO0_TBT_RESET_N TBTA_TX_1_N TBTA_TXRX_1_N TX0_N RX0_N...

  • Page 91: Audio Codec

    Schematic Diagrams Audio Codec AUDIO CODEC ALC256 HEADPHONE_R HEADPHONE_L LINE1-VREFO-L LINE1-VREFO-R MIC2_VREFO AUDG C676 10u_6.3V_X5R_06 AUDG 3802K-Q02N-09L SPKOUTR+ SPKOUTR+_R R916 CODEC 100K_04 ANALOG DIGITAL CODEC 5VS_AUD Place next to pin 26 HCB1005KF-121T20 HCB1608KF-800T30 C739 J_SPKR1 C735 CODEC 180p_50V_NPO_04 CODEC CODEC *1u_6.3V_X5R_02 C1003 C1018...

  • Page 92: M.2 Wlan+Bt, Pcie 4X Ssd

    Schematic Diagrams M.2 WLAN+BT, PCIE 4X SSD WLAN+BT WLAN HOLD WLAN_3.3V WLAN CNVI_WAKE#_R 6-34-P750S-010 R349 10K_04 J_WLAN1 60 mil GND13 3.3V3 WLAN_3.3V CNVI_WT_CLKP WT_CLKP 3.3V2 WLAN WLAN C625 C647 C670 CNVI_WT_CLKN WT_CLKN PEWAKE1_N WLAN GND12 CLKREQ1_N WLAN 0.01u_16V_X7R_04 22u_6.3V_X5R_06 0.1u_6.3V_X5R_02 CNVI_WT_D0P WT_D0P PERST1_N...

  • Page 93: M.2 Pcie 4X Ssd

    Schematic Diagrams M.2 PCIE 4X SSD NGFF_M (M2) SSD (GEN4 PCIE 4X) EMI requirment 3.3VS 2021/9/2 >120 mil M2_SSD2_3.3VS ONLY GEN4 PCIe J_SSD2 R925 C700 C699 C698 H: PCIe GND13 *100K_04 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 22u_6.3V_X5R_06 GND12 3.3V8 M.2 SSD M.2 SSD M.2 SSD GND11 3.3V7...

  • Page 94: Usb Type-C

    Schematic Diagrams USB Type-C 2021/10/28 J_TYPEC1 USB3.2 TYPE-C UCF3T-21S01-0P21 Angus USBVCC3.1_1 A_UTXP_SW2_J USB3_RXP4_J 100 MIL TX0_P RX0_P A_UTXN_SW2_J USB3_RXN4_J C769 TX0_N RX0_N 10u_6.3V_X5R_06 C764 USBVCC3.1_1 USBVCC3.1_1 VBUS VBUS 3.3V TYPE-C 0.1u_10V_X5R_04 TYPEC_CC1 SBU2 TYPE-C TYPE-C TYPEC_UDP_J TYPEC_UDN_J SY6288E1AAC USB2_P_T USB2_N_B R578 4.7K_04 6-02-62881-9C0...

  • Page 95: Lan I219V

    Schematic Diagrams LAN i219V INTEL LAN i219V LAN_MDIP0 LAN_CLKREQ# CLK_REQ_N MDI_PLUS0 LAN_RTD3_RST#_R LAN_MDIN0 PE_RST_N MDI_MINUS0 LAN_MDIP1 CLK_PCIE_GLAN PE_CLKP MDI_PLUS1 LAN_MDIN1 CLK_PCIE_GLAN# PE_CLKN MDI_MINUS1 SMBUS PULL-UP OPTIONS PCIE_RXP7_I219 LAN_MDIP2 PETp MDI_PLUS2 PCIE_RXN7_I219 LAN_MDIN2 SMBUS SPEED PETn MDI_MINUS2 1MHz(Defaul setting) 499ohm 100KHz/400KHz 2.2Kohm PCIE_TXP7_GLAN LAN_MDIP3...

  • Page 96: Card Reader

    Schematic Diagrams Card Reader RTS5227S/ OZ711LV2 NOTE2: SP7 : Internal pull-down 200K 1.IF RTD3-COLD IS NEEDED TO BE SUPPORTED, WAKE# MUST BE If use microSD socket, SD_WP#(#29) can't floating, PULLED-UP TO +3.3V_AUX ON THE MB. DURING D3 COLD, WAKE# must connect to CND WILL BE ASSERTED AT THE EVENT OF SD CARD INSERTION OR REMOVAL.

  • Page 97: Hdd, Click Tp, Audio

    Schematic Diagrams HDD, Click TP, Audio 6-02-75495-9C0 USB CHARGER PORT VDD5 USBVCC_CH 80 mil 80 mil (on Audio Board) VOUT C677 10u_6.3V_X5R_06 C668 TYPE-A1 W/ CHG TYPE-A1 R309 *100K_04 R324 *0_04 0.1u_6.3V_X5R_02 High Enable 9,35,39,53,56,67,72 SUSB# <FUNCTION> SY6288C20AAC DD_ON R323 0_04 USB_DD_ON TYPE-A1...

  • Page 98: Led, Ccd, Tpm, Power Sw Con

    Schematic Diagrams LED, CCD, TPM, Power SW Con. VDD_TPM for common design R842 *0_04 3.3VA 2021/10/04 R834 0_04 Rubband VDD3 R840 R841 *4.7K_04 *4.7K_04 TPM_GPIO GPIO0 R836 *4.7K_04 TPM_PP VDD_TPM C945 C931 DEL R713 C963 C932 39,41,44,45,47,48 BUF_PLT_RST# RST# VSS_3 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 1u_6.3V_X5R_02...

  • Page 99: Kbc-Ite It5570

    Schematic Diagrams KBC-ITE IT5570 EC ROM Debug Port ALSPI_* = 1.5"~5.8" C750 VDD3 IT5570 *0.1u_6.3V_X5R_02 1Mbit OPTION ( VDD3 PCB Footprint = 85204-04L ALSPI_MSI_L R991 33_04 DEBUG PORT KBC_AVDD *3801K-Q04N-06L ALSPI_MSO_L HCB1005KF-121T20 R988 33_04 R990 3IN1 3.3K_1%_04 VDD3 44,51 3IN1 IT5570 80CLK ALSPI_CE#_L...

  • Page 100: Rgb Kb

    Schematic Diagrams RGB KB RGB KB Only LCD 17" VDD3 RGBKB_PWR J_KBLED1 R412 *100K_04 KB-LED-RGB KB-LED-RGB 1K_04 R447 0_06 LED_KB_PIN4 R410 100_04 RGBKBSW_R KBZONE_R RGBKB-DET#_R RGBKB-DET# KBZONE_B R411 KB-LED-RGB KB-LED-RGB KBZONE_R KBZONE_G SM3422KTDSH EC_PWM_LEDKB_R FP225H-008S11M KB-LED-RGB fp225h-008gxxxm_r R448 0_06 P/N = 6-20-94K30-108 RGBKBSW_G KBZONE_G LCD_17...

  • Page 101: 5V, 5Vs, 3.3V, 3.3Vs

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS VREG3 DD_ON# VDD3 VDD3 SUSB VREG3 R869 PR85 PR84 10K_04 VREG3 47K_04 DD_ON 100K_04 EMC22 EMC48 EMC49 EMC23 POWER_SWITCH R882 SUSB# DD_ON# SUSB PW R_SW # R870 200K_04 POWER_SWITCH PC74 47K_04 POWER_SWITCH Q50A SM3018KW H PC70 SM3018KW H 49,51,55,72...

  • Page 102: Vccst

    Schematic Diagrams VCCST VCCST (1.05v) 40 mil VCC1P05_OUT_FET VCC1P8_CPU VCCST FA7601 C837 10u_6.3V_X5R_06 40 mil 1.8VA VCC1P8_CPU VCCST OUT1 OUT2 VCCST OUT1 OUT2 C842 *1mm VCCST_CT1 VCCST_CT1 VDD3 PWR_VCC1P8_PROC 40 mil 40 mil 0.1u_6.3V_X5R_02 R626 VDD3 VOUT *220p_50V_NPO_04 3.3VA *100_04 VCCST C690 R428...

  • Page 103: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 PR92 PR83 20K_1%_04 18K_1%_04 EN_3V EN_5V PJ19 *CV-40mil PC72 1000p_50V_X7R_04 2.5A 2.5A VREG3 PC279 PC284 PC285 PC298 PC281 PC300 PC299 PC294 VDD3 PC76 1u_6.3V_X5R_04 VREG3 PGOOD PC71 PC79 VDD5 PR94 0_06 PR80 0_06 VBST2 VBST1 0.1u_10V_X7R_04 0.1u_10V_X7R_04 PR93 0_06...

  • Page 104: Ddr 1.2V / 0.6Vs, 2.5V

    Schematic Diagrams DDR 1.2V / 0.6VS, 2.5V DDR4 PD12 1.2V 1.2V/0.6VS PU27 POW ER VDDQ PC290 PC291 SS14W S G5616BRZ1U POW ER VDDQ VDDQ_R PC292 POW ER VDDQ VTT_MEM(0.6V) POW ER VDDQ PC289 PC297 VLDOIN VBST EMR11 VDDQ 10u_6.3V_X5R_06 0.1u_25V_X7R_06 POW ER VDDQ VDDQ_R VTT_MEM...

  • Page 105: Mp2964 Controller

    Schematic Diagrams MP2964 Controller PR23 0_04 PR21 0_04 VRACPU_VOSEN VGT_VOSEN VCCIN_SENSE VCCGT_SENSE PR22 0_04 PR20 0_04 VRACPU_VORTN VSSIN_SENSE VGT_VORTN VSSGT_SENSE PR174 0_04 PR166 0_04 VCORE_EN PR95 10K_04 PJ20 *CV-40mil VDD3 PC86 *0.1u_16V_X7R_04 Power DEFAULT SHORT PR188 1K_1%_04 PJ21 PR183 9,36,39,51 ALL_SYS_PWRGD PR187 1K_1%_04...

  • Page 106: Vcore

    Schematic Diagrams VCore VCORE OUTPUT STAGE Vcc: PWM1/2/3/4 TDC:93A IccMax:160A phase 1 3.3V PC133 PC96 PC104 close to ic MP86941GQVT-Z E-CAP EMC31 VIN1 0.01u_50V_X7R_04 PC120 100u_25V_POSCAP VIN2 1u_6.3V_X6S_04 VCORE_BST_PWM1 VCC, VID -->VID Range~0~1.5V+0.1V Offset For Noise AGND VCORE PC16 PC14 PR160 0_04 PC137...

  • Page 107: Vccgt

    Schematic Diagrams VCCGT VccGT: PWM9/8 TDC:30A IccMax:50A VCCGT VID -->VID Range~0~1.5V 1.3A phase 1 3.3V close to ic PC155 PC116 PC126 EMC42 PU15 MP86941GQVT-Z 0.01u_50V_X7R_04 VIN1 PC148 VIN2 1u_6.3V_X6S_04 GT_BST_PW M1 AGND VCCGT PR171 0_04 PC166 VCCGT_PW M5 1u_25V_X7R_06 PR181 0_04 GT_SW _PW M1 57,58,59...

  • Page 108: Vccin Aux

    Schematic Diagrams VCCIN AUX Power_MF change IMON setting PR205 *100_04 VCCIN_AUX 2021/12/28 PR211 0_04 Rubband VCCIN_AUX_SENSE PC173 *1000p_50V_X7R_04 VSSIN_AUX_SENSE PR210 0_04 PR204 *100_04 PR26 *20mil short-p PC183 *0.1u_16V_X7R_04 PC17 PR221 10K_04 PJ23 *CV-40mil 0.22u_16V_X7R_06 VDD3 PR220 0_04 1.8VA_PGD PR219 PC182 PR217 2_06 2.2_06...

  • Page 109: Ac_In Charger

    Schematic Diagrams AC_In Charger J_DC_JACK1 2DC3003-016211F PCB Footprint = 2dc3003-016211f PN = 6-21-D34W0-105 JDC_AC EML1 HCB2012KF-800T80 DC_19V PC12 PC13 PC11 PR19 PR18 EML2 HCB2012KF-800T80 4.7_06 4.7_06 PC15 2.2u_25V_X5R_08 Sheet 60 PQ10 AC_In Ch MDU1721 MDU1517 PRS1 WMCSL0612R005FETA PC83 PC210 PC214 PC239 PC215 PC216...

  • Page 110: [63] Nvvdd1

    Schematic Diagrams NVVDD1 EC_GPIO 33,51,57,66 EN Type VDD3 1V8_AON NV3V3 1N914BWS Open Drain R11(PTC) close to hot area you concern Push Pull PR155 PR137 PR153 *10K_1%_04 10K_1%_04 *10K_1%_04 1V8_AON PR134 0_04 30,33,66 I2CC_SDA_PP PNTC1 Mode EW TF02-104F4F-N PR135 0_04 High High Phase Count 30,33,66 I2CC_SCL_PP...

  • Page 111: [64] Nvvdd2

    Schematic Diagrams NVVDD2 PWR_SRC_NV NVVDD VBoot=0.75V EMC38 EMC41 PC10 PC88 PC111 PC122 0.01u_50V_X7R_04 0.01u_50V_X7R_04 PC157 1u_25V_X7R_06 M-C0603 Power BCN PWR_SRC_NV Del PC5, Add PC14 3.3V PU10 2021/12/28 PC156 1u_25V_X7R_06 Rubband NVVDD_DRMOS_VCC PR168 0_06 NVVDD PC115 PC125 noise solution PC165 1u_25V_X7R_06 PC141 PL10 M-C0603...

  • Page 112: Pex_Vdd

    Schematic Diagrams PEX_VDD PU22 PEX_VDD PR273 AOZ2261NQI-11 0_06 PEXVDD 3.3V PC253 PC248 PC249 PC245 4.7u_6.3V_X5R_04 PR279 PEXVDD PR276 100K_1%_04 *10K_1%_04 PEXVDD PEXVDD PR270 0_06 PC237 0.1u_16V_X7R_04 PEXVDD PEXVDD PEX_VDD_PWRGD PGOOD PEXVDD PR281 *10K_1%_04 PEXVDD PEXVDD PFM* PEX_VDD PR280 Sheet 63 of 69 PL18 10K_1%_04 PEXVDD...

  • Page 113: Fbvddq

    Schematic Diagrams FBVDDQ FBVDDQ EC_GPIO 33,51,57,63 1N914BWS 1V8_AON NV3V3 VDD3 VDD3 EN Type R11(PTC) close to hot area you concern Open Drain PR294 PR45 PR44 Push Pull PR284 1V8_AON *10K_04 *10K_04 *10K_1%_04 *10K_1%_04 PR290 PR299 Mode 10K_1%_04 *10K_04 High High Phase Count PR47 0_04 30,33,63...

  • Page 114: 1V8_Aon, Nv3V3, 3.3Va

    Schematic Diagrams 1V8_AON, NV3V3, 3.3VA 1.8VA 1.8VA C707 C704 VDD3 1V8_AON 1V8_AON 1V8_AON 1V8_AON FA7601 10u_6.3V_X5R_06 0.1u_6.3V_X5R_02 1V8_AON 1V8_AON 1V8_AON 1.8VS R425 R416 EMC21 EMC20 100K_04 10_06 1V8_AON OUT1 OUT2 1.8VS 1V8_AON 1V8_AON 0.1u_6.3V_X5R_02 0.1u_6.3V_X5R_02 OUT1 OUT2 C694 C692 C687 0.1u_6.3V_X5R_02 10u_6.3V_X5R_06 1V8_AON...

  • Page 115: Audio Board + Redriver

    Schematic Diagrams Audio Board + Redriver USB2.0 CON AC25 22u_6.3V_X5R_06 AGND USB3.0 CON 6-71-NP5P8-D01 60 mil AUDIO BOARD AC24 0.1u_6.3V_X5R_02 A_USBVCC1 AGND AUDIO BOARD AC20 22u_6.3V_X5R_06 AUDIO BOARD AGND 1AR1 *0_02 4AR1 *0_02 AC26 22u_6.3V_X5R_06 60 mil AUDIO BOARD AGND AC22 22u_6.3V_X5R_06 A_USBVCC_CH...

  • Page 116: Led Board

    Schematic Diagrams LED Board 1LR1 *0_02 4LR1 *0_02 6-71-NP5H4-D01 2LR1 *0_02 5LR1 *0_02 3LR1 *0_02 6LR1 *0_02 7LR1 *0_02 8LR1 *0_02 LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD LED BOARD 6-52-55001-021 GREEN YELLOW HDD LED 750_1%_04 L_LED_HDD#...

  • Page 117: Power Sw Board

    Schematic Diagrams Power SW Board 1BR1 *0_02 4BR1 *0_02 6-71-NP5PS-D01 2BR1 *0_02 5BR1 *0_02 POWER SW BOARD 3BR1 *0_02 6BR1 *0_02 7BR1 *0_02 8BR1 *0_02 POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD POWER BOARD Sheet 68 Power SW POWER...

  • Page 118: Power Sequence

    998.36us (to SUSC#) SUSC# VDDQ 5.58ms (to SUSC#) VTT_MEM 8.07ms (to SUSC#) SUSB# 3.3VS 413.49us (to SUSB#) SUSB# 1.04ms (to SUSB#) CLEVO CO. CLEVO CO. CLEVO CO. Title Title Title [71] Power Sequencing [71] Power Sequencing [71] Power Sequencing Size Size...
