Specifications - JVC AV32L2EUGR Service Manual

AV32L2EUGR
AV32L2EUBL
AV32L2EUGY

SPECIFICATIONS

Item
Dimensions ( W× × × × H× × × × D )
Mass
TV RF System
Colour System
Stereo System
Teletext System
Receiving Frequency
VHF
UHF
Intermediate Frequency
VIF Carrier
SIF Carrier
Colour Sub Carrier Freq.
PAL
SECAM
NTSC
Power Input
Power Consumption
Aerial Input Term
Picture Tube
High Voltage
Speaker
Audio Output
EXT-1/EXT-2/EXT-3 (IN/OUT)
EXT-4 (Input) Video
Audio(L/R)
S / Video
AUDIO OUT (Variable)
Headphone jack
Remote Control Unit
Design & specifications are subject to change without notice
2
901mm × 556mm × 557mm
53.8kg
CCIR ( B/G, D/K, L, L', I )
PAL / SECAM / NTSC (Only in EXT mode)
A2 (B/G, D/K) / NICAM (B/G, I, D/K, L)
Fastext (UK system) / TOP (German system)
WST(World Standard system)
47MHz ～ 470MHz
470MHz ～ 862MHz
! French cable TV channel of broadcast frequencies 116 ～ 172MHz & 220 ～ 469MHz
38.9MHz (B/G, D/K, I, L) / 33.95MHz (L')
33.4MHz (5.5MHz : B/G)
32.9MHz (6.0MHz : I ) / 32.4MHz (6.5MHz : L, D/K) / 40.45MHz (6.5MHz : L')
4.43MHz
4.40625MHz / 4.25MHz
3.58MHz / 4.43MHz
AC 220V ～ 240V , 50Hz
189W(Max) / 140W(Avg),
75 Ω unbalanced, Coaxial
Visible size : 76cm, Measured diagonally
+
1.0kV
31.0kV (at zero beam current)
-1.5kV
20cm × 4cm, Oval type × 2 with BOX
7.5W + 7.5W
21-pin Euro connector (SCART socket) × 3
1Vp-p 75 Ω (RCA pin jack)
500mVrms(-4dBs), High Impedance (RCA pin jack)
Y : 1Vp-p POSITIVE (Negative sync Provided, when terminated with 75 Ω )
C : 0.3Vp-p (Burst signal, when terminated with 75 Ω )
0 ～ 1Vrms, Low Impedance (RCA pin jack × 2)
Stereo mini jack ( φ 3.5mm )
RM-C54 (AAA/R03 dry cell battery × 2)
No.51817
